LS tractor LS3150-B Product manual

OM 0421QH-A
10/13
O
OP
PE
ER
RA
AT
TO
OR
R'
'S
S
A
AN
ND
D
P
PA
AR
RT
TS
S
M
MA
AN
NU
UA
AL
L
L
LS
S3
31
15
50
0-
-B
B
Q
Qu
ui
ic
ck
k
H
Hi
it
tc
ch
h
a
an
nd
d
S
Su
ub
bf
fr
ra
am
me
e
L
LS
S3
31
15
50
0-
-C
C
D
Dr
ri
iv
ve
e
k
ki
it
t
F
Fo
or
r
J
J
S
Se
er
ri
ie
es
s
T
Tr
ra
ac
ct
to
or
rs
s
SERIAL NO. 21200001 AND UP


TABLE OF CONTENT
OM 0421QH-A 1
INTRODUCTION – TO THE PURCHASER............................................................................................2
SAFETY PRECAUTIONS....................................................................................................................3-9
Before Operation............................................................................................................................3
Notice.............................................................................................................................................4
Subframe & Implements..............................................................................................................4-5
Before Operation.............................................................................................................4
Implements & Subframe Operation.................................................................................5
The Tractor..................................................................................................................................6-7
General Information.........................................................................................................6
Operating the Tractor......................................................................................................6
During Operation.............................................................................................................7
Roll-Over Protective Structure "ROPS "..........................................................................7
Maintenance...................................................................................................................................8
Transporting...................................................................................................................................9
Storage ........................................................................................................................................9
DECALS................................................................................................................................................10
ASSEMBLY......................................................................................................................................11-20
Quick Hitch and Subframe Assembly..........................................................................................11
Subframe Assembly......................................................................................................11
Lift System Assembly....................................................................................................12
Installation of Rear Supports & the Hose Support Bracket............................................13
Installation of Front Support..........................................................................................14
Drive Kit Installation - LS3150-C...................................................................................15
Attaching the Subframe to the Tractor .....................................................................16-17
Transport Position.........................................................................................................17
Removing the Subframe from the Tractor................................................................18-19
MAINTENANCE....................................................................................................................................20
Subframe & Drive Kit Maintenance..............................................................................................20
PARTS.............................................................................................................................................21-27
Introduction..................................................................................................................................21
Male Quick Hitch & Subframe ................................................................................................22-23
Male Quick Hitch .........................................................................................................................24
Mid PTO Drive Kit - LS3150-C.....................................................................................................25
Fixed Driveline ............................................................................................................................26
Driveline – Male Half ...................................................................................................................27
TORQUE SPECIFICATION TABLE......................................................................................................28

INTRODUCTION
OM 0421QH-A 2
TO THE PURCHASER
All products are designed to give safe,
dependable service if they are operated and
maintained according to instructions. Read
and understand this manual before
operation.
This manual has been prepared to assist the
owner and operators in the safe operation and
suitable maintenance of the equipment. The
information was applicable to products at the
time of manufacture and does not include
modifications made afterwards.
Read and understand this operator's manual
before attempting to put equipment into
service. Familiarize yourself with the operating
instructions and all the safety
recommendations contained in this manual and
those labeled on the equipment and on the
tractor. Follow the safety recommendations
and make sure that those with whom you work
follow them.
Illustrations
The illustrations may not necessarily reproduce
the full detail and the exact shape of the parts
or depict the actual models, but are intended
for reference only.
Direction Reference
All references to right and left, forward or
rearward, are from the operator's seat, facing
the steering wheel.
To assist your dealer in handling your needs, please record hereafter the model number and serial
number of your equipment and tractor. It is also advisable to supply them to your insurance company.
It will be helpful in the event that an equipment or tractor is lost or stolen.
TRACTOR IMPLEMENT
MODEL:
SERIAL NUMBER:
DATE OF PURCHASE:
DEALER NAME:

SAFETY PRECAUTIONS
OM 0421QH-A 3
SAFETY FIRST
This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on
labels on the machine itself to warn of the possibility of personal injury. Read these
instructions carefully. It is essential that you read the instructions and safety regulations
before you attempt to assemble or use this unit.
DANGER : Indicates an immediate hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING : Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION : Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
IMPORTANT : Indicates that equipment or property damage could result if instructions
are not followed.
NOTE : Gives helpful information.
All products are designed to give safe, dependable service if they are operated and maintained
according to instructions. Read and understand this manual before operation. It is the owner's
responsibility to be certain anyone operating this product reads this manual, and all other applicable
manuals, to become familiar with this equipment and all safety precautions. Failure to do so could
result in serious personal injury or equipment damage. If you have any questions, consult your dealer.
BEFORE OPERATION
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are
generally attracted to machines and the work
being done. Never assume children will remain
where you last saw them.
1. Keep children out of the operating area and
under the watchful eye of another responsible
adult.
2. Be alert and turn machine off if children enter
the work area.
3. Before and when backing, look behind for
small children.
4. Never carry children while operating the
machine. They may fall off and be seriously
injured or interfere with the safe operation of
the machine.
5. Never allow children to play on the machine or
attachment even when they are turned off.
6. Never allow children to operate the machine
even under adult supervision.
7. Use extra care when approaching blind
corners, shrubs, trees, or other obstructions
that might hide children from sight.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 4
NOTICE
A safe operator is the best assurance against accidents. All operators, no matter how experienced
they may be, should read this operator's manual and all other related manuals before attempting to
operate the equipment. Please read the following section and pay particular attention to all safety
recommendations contained in this manual and those labeled on the equipment and on the tractor.
SUBFRAME &IMPLEMENTS
Before Operation
1. Read and understand this operator's
manual and tractor operator's manual.
Know how to operate all controls and how
to stop the unit and disengage the controls
quickly.
2. Never wear loose, torn, or bulky clothing
around the tractor, the subframe and the
implements. It may catch on moving parts
or controls, causing injury.
3. Before and during seasons, thoroughly
inspect the area where the equipment is to
be used and remove all objects that may
be thrown or cause damage to the
equipment.
4. Set transmission to neutral and disengage
clutch, if equipped, before starting the
engine.
5. Do not operate equipment in wintertime
without wearing adequate winter garments.
Always wear protective clothing.
6. Never attempt to make any adjustments
while engine is running. Read this manual
carefully to acquaint yourself with the
equipment as well as the tractor operator's
manual. Working with unfamiliar equipment
can lead to accidents. Be thoroughly
familiar with the controls and proper use of
the equipment.
7. Keep all safety guards in place and verify
hardware for proper tightening.
8. Check for moving parts excessive wear
regularly. Replace worn parts with genuine
parts.
9. Replace all missing, illegible, or damaged
safety and warning decals. See list of
decals in operator's manual.
10. Keep safety decals clean of dirt and grime.
11. Do not modify or alter this equipment or
any of its components, or any equipment
function without first consulting your dealer.
12. Use of rear counterweights is
recommended. Weights provide the
necessary balance to improve stability,
traction and steering. Use only those
recommended by your dealer.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 5
Implements & Subframe Operation
1. Before leaving the tractor unattended, take
all possible precautions. Park the
tractor/subframe on level ground, place the
transmission in neutral, set the parking
brake, disengage the PTO, lower the
equipment to the ground, place all levers
including auxiliary control levers in neutral,
shut off the engine and remove the ignition
key.
2. Before starting the tractor/ implement,
inspect and clean every rotating part.
3. Prior to operation, clear work area of all
objects that can be picked up and thrown.
Mark all curbs, pipes, etc. that cannot be
moved.
4. Be sure the PTO switch/lever is in OFF
position before starting engine.
5. Exercise extreme caution when operating
on or crossing a gravel drive, walks, or
roads. Stay alert for hidden hazards or
traffic.
6. Do not carry passengers.
7. Keep clear of rotating parts. Do not put
hands or feet under, or into implement with
engine running.
8. Park the tractor/implement on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, lower
the equipment to the ground, place all
control levers in neutral, shut off the engine,
remove the ignition key and allow the
rotating parts to stop BEFORE making any
repairs, adjustments or inspections.
9. If the implement starts to vibrate
abnormally, disengage the PTO, stop the
engine immediately and check for cause.
Excessive vibration is generally a sign of
trouble.
10. Do not run the engine indoors except when
starting engine and transporting attachment
in or out of building. Carbon monoxide gas
is colorless, odorless and deadly.
11. Do not attempt to operate on steep slopes.
If operating on slopes is necessary,
exercise extreme caution when changing
direction.
12. Never operate implement without guards,
and other safety protective devices in
place.
13. Keep clear of chute discharge. This chute
has the capability of throwing objects at far
distances.
14. Never operate implement near glass
enclosures, automobiles, window wells,
embankments, etc., without proper
adjustment of snow discharge angle.
15. Never operate machine at high transport
speeds on a slippery surface.
16. Use extra caution when backing up.
17. Disengage power to implement when
transporting or when not in use.
18. Never operate the implement without good
visibility and lighting.
19. Prolonged exposure to loud noise can
cause impairment or loss of hearing. Wear
a suitable hearing protective device such as
earmuffs or earplugs to protect against
objectionable or uncomfortable noises.
20. Never allow anyone near the work area.
21. Keep all shields and covers in place. All
tractor and equipment shields and covers
must be correctly installed at all times.
When necessary to remove these, they
must be reinstalled before resuming
operation.
22. Keep clear of all rotating driveline
component. Be especially observant of
implement areas of discharge, intake or
other mechanical motion.
23. Securely lock equipment drive shaft. Check
that all tractor and equipment drivelines are
in good working order. Equipment drive
shaft coupler must securely lock to and be
retained by annular groove on tractor drive
shaft.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 6
THE TRACTOR
General Information
1. Read the operator's manual carefully before
using tractor. Lack of operating knowledge
can lead to accidents.
2. Do not permit anyone but the operator to
ride on the tractor. There is no safe place for
passengers.
Operating the Tractor
1. Never run the tractor engine in a closed
building without adequate ventilation, as
the exhaust fumes are very dangerous.
2. Adopt safe driving practice: Keep the brake
pedals latched together at all times unless
independent braking is required. Never use
independent braking during transport.
3. Always drive at a safe speed relative to
local conditions and ensure that your
speed is low enough for an emergency
stop to be safe and secure.
4. Reduce speed prior to turns to avoid the
risk of overturning. Keep speed to a
minimum.
5. Always keep the tractor in gear to provide
engine braking when going downhill. Do
not coast.
6. Never allow an open flame near the fuel
tank or battery.
7. Make sure the PTO shield is installed when
using the equipment and always replace
the PTO shield if damaged.
8. Park the tractor/implement on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, lower
the equipment to the ground, place all
levers including auxiliary control levers in
neutral, shut off the engine and remove the
ignition key BEFORE leaving the tractor.
9. Never park the tractor on a steep slope.
10. Do not attempt to operate on steep slopes.
Avoid sudden uphill turns on steep slopes.
11. Use of rear counterweights for better
traction and stability is recommended.
12. Handle fuel with care, as it is highly
flammable.
13. Use approved fuel container.
14. Never add fuel to a running engine or a hot
engine.
15. Fill fuel tank outdoors with extreme care.
Never fill fuel tank indoors. Replace fuel
cap securely and wipe up spilled fuel.
16. Never allow anyone to operate the
implement until they have read the manual
completely and are thoroughly familiar with
basic tractor and implement operation.
17. Make sure the tractor is counterweighted
as recommended by your dealer. Weights
provide the necessary balance to improve
stability, traction and steering.
18. Always make sure all implement
components are properly installed and
securely fastened BEFORE operation.
19. Never attempt to start the engine and/or
engage implement drive while standing
beside the tractor.
20. Always start the engine from the operator's
seat with all the transmission lever(s) and
implement drive lever in neutral.
21. DO NOT bypass the safety system by
shorting across the terminals of the starter
motor to start the engine. This may cause
the tractor to move suddenly.
22. If the safety start system does not work,
consult your dealer immediately.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 7
During Operation
1. Do not allow passengers on the
tractor/implement at any time. There is no
safe place for passengers on this
equipment. The operator MUST sit in the
tractor seat.
2. Eye and hearing protection is
recommended when operating the
implement.
3. Operate only during daylight hours, or when
the area is well lit with bright artificial light.
4. Park the tractor/implement on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, lower
the equipment to the ground, place all
control levers in neutral, shut off the engine
and remove the ignition key BEFORE
leaving the operator’s seat.
5. Inspect the implement after striking any
foreign object to assure that all implement
parts are safe and secure and not
damaged.
6. Be especially observant of the operating
area and terrain. Watch for holes, rocks, or
other hidden hazards. ALWAYS inspect the
area prior to operating implement.
7. DO NOT operate implement near the edge
of drop-offs or banks.
8. DO NOT operate implement on steep
slopes as overturn may result.
9. Operate up and down (not across)
intermediate slopes. Avoid sudden starts
and stops.
10.Drive tractor backwards up steeper slopes
with implement off. Then operate as you
travel down the slope.
11.Slow down before you change directions on
any slope.
12.Use wheel weights on your tractor to
increase stability on slopes.
13.Never stand alongside of the unit while the
engine is running.
Roll-Over Protective Structure (ROPS)
1. DO NOT weld, drill or alter the ROPS.
Damaged ROPS must not be straightened
or used. If damage does occur, consult
your dealer.
2. If the ROPS is lowered or removed from
the tractor for any reason, it must be
erected and/or refitted immediately.
Original bolts or equivalent replacements
must be used and tightened to the correct
torque.
3. Massey Ferguson does not recommend
usage of tractor with ROPS removed.
4. If a fold-down ROPS is used, the ROPS
can be folded down for storage, but it must
be pinned in the upright position prior to
operation.
5. Seat belt usage: With ROPS installed on
the tractor it is imperative that the seat belt
be installed, used and correctly adjusted,
at all times. DO NOT use a seat belt if
operating without ROPS.
6. Additional safety equipment: A fire
extinguisher and first aid kit should be kept
readily accessible. These are available
through your dealer.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 8
MAINTENANCE
ALWAYS USE GENUINE PARTS WHEN
REPLACEMENT PARTS ARE REQUIRED
1. Keep the tractor and implement properly
maintained.
2. Park the tractor/implement on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, lower
the equipment to the ground, place all
control levers in neutral, shut off the engine
and remove the ignition key and allow the
rotating parts to stop BEFORE making any
implement adjustments.
3. To avoid injury, do not adjust, or service the
implement with the tractor engine running.
Make sure rotating components have
completely stopped before leaving the
operator’s seat.
4. Keep the tractor/implement clean. Snow ,
dirt or ice build-up can lead to malfunction
or personal injury from thawing and
refreezing in garage.
5. Always wear eye protection when cleaning
or servicing the implement or subframe.
6. Service the unit in safety: DO NOT service
the tractor while the engine is running or
hot, or if the unit is in motion. Always lower
implement to the ground. If necessary to
service unit with blower raised, securely
support with stands or suitable blocking
before working underneath. Do not rely on
hydraulically supported devices for your
safety. They can settle suddenly, leak
down, or be accidentally lowered.
7. Do not attempt to service machine, clear
obstructions or unplug blockages with the
engine running. Always shut off engine and
allow all motion to cease.
8. The manufacturer will not claim
responsibility for fitment of unapproved
parts and/or accessories and any damages
as a result of their use.
9. Make sure all shields and guards are
securely in place following all service,
cleaning, or repair work.
10.Do not modify or alter this equipment or any
of its components or operating functions. If
you have questions concerning
modifications, consult with your dealer.
11.Do not operate a unit which is defective or
has missing parts. Make sure that all
recommended maintenance procedures are
completed before operating the unit.
12.Check all controls regularly and adjust
where necessary. Make sure that the
brakes are evenly adjusted.
13.Periodically check all nuts and bolts for
tightness, especially wheel hub and rim
nuts.
14.To avoid serious personal injury: Escaping
hydraulic/diesel fluid under pressure can
penetrate the skin causing serious injury.
Do not use your hands to check for leaks.
Use a piece of cardboard or paper to
search for leaks.
15.Stop engine and relieve pressure before
connecting or disconnecting lines. Tighten
all connections before starting engine or
pressurizing lines.

SAFETY PRECAUTIONS - continued
OM 0421QH-A 9
TRANSPORTING
1. Transporting on public roadway: When
driving the tractor and equipment on the
road or highway under 25 mph, at night or
during the day, use flashing amber warning
lights and the Slow Moving Vehicle
("SMV") identification emblem.
2. Check local traffic codes that may apply to
unit usage on public roads and highways in
your area. The use of flashing amber lights
is acceptable in most localities. However,
some localities may prohibit their use.
3. Always disengage equipment drive prior to
transporting unit.
STORAGE
Before storing the subframe or implement,
certain precautions should be taken to
protect it from deterioration.
1. Clean the subframe and implement
thoroughly.
2. Make all the necessary repairs.
3. Replace all safety signs that are damaged,
lost, or otherwise become illegible. If a part
to be replaced has a sign on it, obtain a
new safety sign from your dealer and install
it in the same place as on the removed
part.
4. Repaint all parts from which paint has worn
or peeled.
5. Lubricate the subframe and implement as
instructed under "Lubrication" section.
6. When the subframe and implement are dry,
oil all moving parts. Apply oil liberally to all
surfaces to protect against rust.
7. Store in a dry place.

DECALS
OM 0421QH-A 10
Replace Immediately if Damaged
662675
657364

ASSEMBLY
OM 0421QH-A 11
QUICK HITCH AND SUBFRAME ASSEMBLY
The Quick Hitch and the Subframe are partially assembled at the factory, however parts contained in
the bag must be installed. Use the present manual and lay out all parts for assembly. Separate bolts
and nuts into various sizes. After assembly, torque all the bolts according to the Torque Specification
Table enclosed at the end of the manual.
Subframe Assembly (Figures 1a-1b)
1. Figure 1a: Grease the outside of the
pivot bushings (1 3/4") (item 5), place
bushings in each hole on the male quick
hitch (item 1) and align and align the
pivot holes with the subframe holes
(item 2).
2. Figure 1a: Attach the male hitch to the
subframe with two 7/8" x 3 3/4" bolts,
four 7/8" flat washers, two 7/8"
lockwashers and two 7/8"NC nylon
insert lock nuts (items 3-4-6-7). In the
order shown Tighten bolts.
3. Figure 1b: Assemble, without
tightening, the mid support (item 1) to
the subframe (item 2) using four 5/8"NC x
2 1/2" lg hex bolts, eight 5/8" flat washers,
four 5/8" lockwashers and four 5/8"NC
nylon insert locknuts (items 3-4-5-6) in the
order shown.
Figure 1a
Figure 1b

ASSEMBLY
OM 0421QH-A 12
Lift System Assembly
(Figures 2a-2b-2c)
NOTE: Put thread sealant on all the
elbows, quick couplers and hoses.
1. Figure 2a: Install the two 90° 3/8" NPT
elbows on the cylinder ports as shown
on figure.
2. Figure 2b: Remove the lower cylinder
pin (item 2) which won't be necessary
to install the cylinder (item 1).
3. Figure 2b: Attach the 3/8"NPT male
end of the two hoses (item 3) to the
cylinder ports (item 1).
3. Figure 2b: Install a 3/8"NPT male x
3/8"NPT swivel female elbow (item 4)
on the other end of the hoses.
4. Figure 2b: Install a 3/8"NPT female
quick coupler (item 5) and a dust plug
(item 6) on the hoses elbows (item 4).
5. Figure 2b: Install a yellow identification
ring (item 7) on one hose and a green
one (item 8) on the other hose.
6. Figure 2c: Remove the cotter pin and
the pin (items 2-1) from the cylinder
(item 3) and attach the cylinder to the
subframe these two pins.
7. Figure 2c: Lift the male quick hitch and
attach the cylinder (item 3) with the
cylinder pin (item 4) and the 4mm x
80mm hair pin (item 5) in the upper
hole that is the quick hitch working
position.
Figure 2a
Figure 2c
Figure 2b

ASSEMBLY
OM 0421QH-A 13
Installation of Rear Supports & the Hose Support Bracket
(Figure 3)
1. Lift the tractor hood (item 1) and remove
the four 8mm hex bolts that maintain the
front hood and the side panels (item 2).
Remove also the two threaded knobs on
each side of the drive console. Keep
hardware for future reinstallation. Put aside
the panels to not damage them.
NOTE:If your tractor is equipped with
a front loader, remove the three bolts
that hold the front loader support and
replace them with three 12mm x 70mm
hex bolts (item 3). If your tractor is not
equipped with a front loader, use the
12mm x 55mm hex bolts.
The bolts must exceed about 3/4" from
the welded nuts of the tractor frame.
2. Install the hose support bracket (item 4), then
slide the spacer (item 5) and the right rear
bracket (item 6) inside the tractor frame and
attach with three 12mm x 70mm hex bolts
(item 3). Tighten completely.
3. Attach the rear bracket with three 12mm
lockwashers (item 7) and three 12mm hex nuts
(item 8). Using a short key is recommended for
the tight space. Do not tighten the nuts.
4. Do the same procedure to install the left rear
bracket. To slide the spacer and the bracket,
you have to move the two hoses.
NOTE:The side panels (item 2) will be
reinstalled on future step.
Figure 3

ASSEMBLY
OM 0421QH-A 14
Installation of Front Support
(Figure 4)
1. Attach the front support (item 1) and, the
spacer (item 6) or the tractor grill guard,
using two 12mm x 50mm hex bolts -
item 3A first, two 12mm lockwashers
(item 4) and two 12mm flat washers
(item 5). Use the oblong hole to align the
bolt with the welded nut of the tractor
frame (item 2). Do not tighten.
2. Support the front support (item 1) and then
attach to the tractor bumper with two
12mm x 50mm hex bolts - item 3B, two
12mm lockwashers (item 4) and two
12mm flat washers (item 5). Do not
tighten.
Figure 4

ASSEMBLY
OM 0421QH-A 15
Figure 5b
Figure 5a
Drive Kit Installation – LS3150-C
(Figures 5a-5b)
1. Install the 1/4" NF grease fitting (item 2) on
each 1" ball bearing (item 1A-1B) and
position the grease fittings so that 1A point
up and 1B point down as shown on figure.
2. Secure the ball bearings in position using
5/8" x 1 3/4" lg bolts (item 3), lockwashers
(item 4) and nylon insert locknuts (item 5).
NOTE: The bearings are swivel, to allow
alignment. Make sure the setscrews do not
get out the inside of the bearings; that would
block the output shaft to get through the
bearing.
3. From the front of the subframe, slide the
output shaft (item 6) through the ball
bearings (item 1A-1B). Position the output
shaft respecting the distance shown on
figure 1b. Apply thread sealant adhesive on
each bearing's Allen setscrews, and then
tighten securely. Lubricate the bearings.
4. After the subframe is mounted on the tractor
(see the following pages for the procedure),
attach the longest yoke of the fixed driveline
(item 7) to the output shaft (item 3)and the
quick connect yoke on the tractor's PTO.
5. The male half driveline (item 8) is installed
when mounting the snowblower.
WARNING: To avoid serious personal
injury: Make sure that the quick coupler is
securely locked in place. A "click" must be
heard.
WARNING: The driveline can be
damaged and could cause serious personal
injury if the quick hitch is not attached
properly.

ASSEMBLY
OM 0421QH-A 16
Attaching the Subframe to the Tractor (Figures 6-7-8)
WARNING: To avoid serious personal
injury: Park the tractor on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, place all
control levers in neutral, shut off the engine,
remove the ignition key and allow the
rotating parts to stop BEFORE attaching the
subframe underneath the tractor.
1. Start the tractor engine, release the parking
brake and move the tractor over the subframe
making sure they are well lined up. Put the
controls in neutral, set the parking brake and
turn off the engine.
2. Figure 6: Hang the front of the subframe
(item 1) on the front support tube (item 2).
Lock in place with the 13 11/16" lg "L" pin
(item 3) and a round wire lock pin (item 4).
3. Figure 7a-7b: Lift the rear of the subframe
(item 1) and attach the mid support (item 2)
with the 10 3/8" lg "L" pin (item 3) and a round
wire lock pin (item 4). Tighten the bolts
(items 5-6) as well as the front support bolts
(fig.7b, item 1) according to the Torque
Specification Table at the end of the manual.
4. Figure 7a: Place the hose support bracket to
a 45angle toward the front.
NOTE:Make sure the 10 3/8" lg rear pin (item 3)
can be removed easily once the bolts are
tightened.
Figure 6
Figure 7a
Figure 7b

ASSEMBLY
OM 0421QH-A 17
1. Hydraulic hose
2. Cardboard
3. Ma
g
nif
y
in
g
g
lass
5. Figure 8: Attach the hose support (item 1) to
the hose support bracket with a 1/2" x 1 1/2"
hex bolt, a 1/2" lockwasher and a 1/2" nylon
insert lock nut (items 2-3-4). Do not tighten.
6. Figure 7a: Run the hoses (item 7) through the
hose support (item 8) and connect them on the
tractor's hydraulic auxiliary ports.
7. Install an identification ring on each tractor
hydraulic ports according to the one of the
hoses.
8. Reinstall the tractor front and side panels
previously removed.
9. Attach the two hoses together with the nylon tie
wraps.
Transport Position (Figure 9)
This subframe transport position allows the
equipment to be positioned at an angle of
more than 15° to make it easier to load on a
trailer.
Remove the cylinder hairpin and cylinder pin
(items 2-1). Lift the quick hitch (item 3) and
attach the cylinder (item 4) in the lower hole of
the quick hitch (item 5) with the two pins
(items 1-2).
WARNING: To avoid serious
personal injury. Escaping hydraulic/
diesel fluid under pressure can
penetrate the skin causing serious
injury.
Do not use your hands
to check for leaks. Use
a piece of cardboard
or paper to search for
leaks.
Stop engine and relieve pressure
before connecting or disconnecting
lines.
Tighten all connections before
starting engine or pressurizing lines.
If any fluid is injected into the skin,
obtain medical attention immediately or
gangrene may result.
Figure 8
Figure 9

ASSEMBLY
OM 0421QH-A 18
1. Hydraulic hose
2. Cardboard
3. Ma
g
nif
y
in
g
g
lass
Removing the Subframe from the Tractor
(Figures 10a-10b-10c)
WARNING: To avoid serious personal
injury: Do not place anything under the
subframe (feet, hands, tools, etc.).
WARNING: To avoid serious personal
injury: Park the tractor on level ground,
place the transmission in neutral, set the
parking brake, disengage the PTO, place
all control levers in neutral, shut off the
engine, remove the ignition key and allow
the rotating parts to stop BEFORE
removing the subframe from underneath
the tractor.
1. Figure 10a: Remove the snowblower
from the subframe and remove the
driveline from under the tractor then
disconnect the equipment's hydraulic
hoses if applicable.
2. Figure 10b: Raise the quick hitch
(item 5) fully. Relieve the hydraulic
pressure in the hoses.
3. Figure 10b: Disconnect the two hoses
(item 1) and install the dust plugs on
the hoses and tractor valve. Remove
the hoses from the hose support
(item 2) roll them up and place on the
quick hitch (item 5).
4. Figure 10b: Remove the round wire
lock pin (item 3) and the rear "L" pin
(items 3-4). Lower the rear part of the
subframe on the ground and reinstall
the pins in the subframe hole to keep
them at hand.
WARNING: To avoid serious
personal injury. Escaping hydraulic/ diesel
fluid under pressure can penetrate the skin
causing serious injury.
Do not use your hands to
check for leaks. Use a piece
of cardboard or paper to
search for leaks.
Stop engine and relieve pressure before
connecting or disconnecting lines.
Tighten all connections before starting
engine or pressurizing lines.
If any fluid is injected into the skin, obtain
medical attention immediately or gangrene
may result.
Figure 10a
Figure 10b
Table of contents
Other LS tractor Tractor Accessories manuals

LS tractor
LS tractor LS BLADE MBD1160A User manual

LS tractor
LS tractor LL4100 User manual

LS tractor
LS tractor LW3150 Product manual

LS tractor
LS tractor LL8100 User manual

LS tractor
LS tractor LL2100 User manual

LS tractor
LS tractor LB2100 Series User manual

LS tractor
LS tractor MT122 User manual

LS tractor
LS tractor LM1160 User manual

LS tractor
LS tractor LL3100 User manual

LS tractor
LS tractor LL1101 User manual
