Relay Modules
RL58-1/RL58-2
Description
Specifi cations
The fi re detection control panels Series BC216 and
BC016, respectively, provide 16 freely programmable
open-collector control outputs. Eight of these outputs
are connected to a fl at cable connector. The Relay Mo-
dules RL58-1 and RL58-2 allow for the easy conversion
of these control outputs to dry changeover contacts.
The componentry is connected to the fi re detection con-
trol panel via a fl at cable.
The RL58-1 provides eight relay outputs with a maxi-
mum contact rating of 30W. The current is limited to 1A
and the voltage is limited to 60VDC. The RL58-2 offers
four relay outputs with a maximum of 5A/230VAC. The
terminal of the RL58-2 are designed for mains voltage.
Two relay modules RL58-2 are each cascadable via pin
connectors. The relay module is delivered with fl at ca-
ble and mounting accessories for easy installation.
• 8 or 4 relay outputs, respectively,
with one dry changeover contact
each
• Actuation display by LED for each
output
• Switch contacts on terminals
• Easy mounting on componentry
carrier
• Connection with control panel via fl at
cable
Operating voltage 20 – 31VDC
Current consumption at 24V typ. 22mA per activated circuit
Control current typ. 1.2mA per input
Ambient temperature -5°C to +50°C
RL58-1
Switching power per contact 1A/60V/30W
Contact life approx. 5 mill. switching cycles (unloaded)
approx. 300,000 switching cycles (at 24VDC/1A)
Dimensions L × W × H 85 × 65 × 37 (mm)
Weight 330g
Part No. 222004
Order name Relay Module 8-Fold/60VDC RL58-1

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
RL58_DBL_LST_EN_0804.PDF • PAGE 2
ABuilding Safety. Building Security.
RL58-2
Maximum switching power per contact 3A/30VDC or 5A/230VAC
Contact life approx. 20 mill. switching cycles (unloaded)
approx. 400,000 switching cycles (at 230VAC/3A)
Dimensions L × W × H 98 × 74 × 28 (mm)
Weight 120g
Part No. 222010
Order name Relay Module 4-Fold/230VAC RL58-2
