LTV LTV-SDNO30-DC User manual

00P677280ZSEB3
Integrated High Speed Dome Camera
Outdoor Dome
Installation Guide
Version 1.3

Installation Guide
1
Preface
Information given in this manual was current when published. The company reserves the
right to revise and improve its products. All specifications are subject to change without
notice.
Notice
This manual provides installation information for the outdoor integrated high
speed dome. To work with the dome cameras, any installer or technician
must have the following minimum qualifications:
•A basic knowledge of CCTV systems and components
•A basic knowledge of electrical wiring and low-voltage electrical
hookups
•Have read this manual completely
Copyright
Under copyright laws, the contents of this installation guide may not be copied,
photocopied, translated, reproduced or reduced to any electronic medium or
machine-readable format, in whole or in part, without prior written permission
of the company.
Important Information
Before proceeding, please read and observe all instructions and warnings in
this manual. Retain this manual with the original bill of sale for future
reference and, if necessary, warranty service. When unpacking your unit,
check for missing or damaged items. If any item is missing, or if damage is
evident, DO NOT INSTALL OR OPERATE THIS PRODUCT. Contact your
dealer for assistance.
Regulation
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.

Installation Guide
2
This symbol on the product or on its packaging indicates
that this product shall not be treated as household waste in
accordance with Directive 2002/96/EC. Instead it shall be
handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By proper
waste handling of this product you ensure that it has no
negative consequences for the environment and human
health, which could otherwise be caused if this product is
thrown into the garbage bin. The recycling of materials will
help to conserve natural resources.
For more details information about recycling of this product,
please contact your local city office, your household waste
disposal service or the shop where you purchased the
product.
Compliance is evidenced by written declaration from our
suppliers, assuring that any potential trace contamination
levels of restricted substances are below the maximum
level set by EU Directive 2002/95/EC, or are exempted due
to their application.

Installation Guide
3
Warnings and Cautions
•Handle the camera carefully
Do not abuse the camera. Avoid striking, shaking, etc. The camera could
be damaged by improper handing or storage.
•Installing electricity wiring carefully
Ask qualified personnel of electrical wiring for the installation. Please note
that input electricity to the unit is at tolerance of DC12V/AC24V ± 10%.
The camera is capable of surge protection; ensure AC power model unit
grounded appropriately against damage of heavy current or electric
shock.
Refer to the camera’s installation guide for more information.
AC model data cable AC power input: 3-pin terminal block
•Do not disassemble the camera
To prevent electric shock, do not remove screws or covers. There are no
user serviceable parts inside. Ask a qualified service person for servicing.
•Do not block cooling holes on the bracket
This camera has a cooling fan inside. Blocking the cooling holes leads to
build up of heat the camera and may cause malfunction.
•Do not operate the camera beyond the specified temperature,
humidity or power source ratings
Use the camera under conditions where temperature is between -35°C ~
50°C (-31°F ~ 122°F), and relative humidity is below 90%.
•Do not use strong or abrasive detergents when cleaning the camera
body
Use a dry cloth to clean the camera when it is dirty. In case the dirt is hard
to remove, use a mild detergent and wipe the camera gently.
•Never face the camera towards the sun
Do not aim the camera at bright objects. Whether the camera is in use or
not, never aim it at the sun or other extremely bright objects. Otherwise,
the camera may be smeared or damaged.

Installation Guide
4
Table of Contents
1. Introduction................................................................................................................5
2. Standard Package Content .......................................................................................6
3. Dome Setups and Cable Connection .......................................................................7
3.1 Preparations for Dome Setups ..........................................................................7
3.2 Dome Setups ....................................................................................................9
3.2.1 Switch Definition ..................................................................................9
3.2.2 Communication Switch Setting ..........................................................10
3.2.3 Dome ID Setting ................................................................................10
3.2.4 Dome Control Protocol Setting .......................................................... 11
3.3 Dome Cable Definition and Requirements ......................................................12
3.3.1 Cable Requirements ..........................................................................12
3.3.2 22-Pin Data Cable .............................................................................13
3.3.3 22-Pin Connector Definition...............................................................13
3.3.4 RS-485 Connector Definition .............................................................14
3.3.5 Cable Wiring and Connection ............................................................15
4. Dome Installation.....................................................................................................17
4.1 Dome Dimension.............................................................................................17
4.2 Optional Accessories.......................................................................................17
4.3 Ceiling Mounting with Straight Tube................................................................23
4.4 Wall Mount ......................................................................................................25
4.4.1 Wall Mounting with Gooseneck Tube.................................................25
4.4.2 Mini Pendant Mount...........................................................................26
4.4.3 Wall Box Mounting.............................................................................27
4.5 Corner Mount ..................................................................................................28
4.5.1 Corner Standard Mounting Plate .......................................................28
4.5.2 Corner Thin/Wide Box Mounting........................................................30
4.6 Pole Mount......................................................................................................31
4.6.1 Pole Thin/Wide Direct Mounting ........................................................31
4.6.2 Pole Thin/Wide Box Mounting............................................................32
5. System Expansion...................................................................................................34
5.1 Connecting with Power Box ............................................................................34
5.2 Data Formats Transforming.............................................................................35
5.3 Signal Distribution ...........................................................................................36
5.4 Coaxial Telemetry............................................................................................37
6. System Integration ..................................................................................................38
6.1 Using Pelco Keyboard.....................................................................................38
6.2 Using Philips Allegiant Keyboard.....................................................................39
Appendix A: Technical Specification .............................................................................40

Installation Guide
5
1. Introduction
With weather resistant feature, the Integrated High Speed Dome Camera is
applicable to outdoor installation. The dome camera supports one cabling for
easy installation, and can be integrated with CCTV products, such as DVRs,
Control Keyboards, and CCTV accessories for a total surveillance solution. In
addition, large set of built-in protocols provide connectivity to other
surveillance systems. The built-in protocols include DynaColor, Pelco, VCL,
Philips, AD-422 (Manchester), etc., which allow the Integrated High Speed
Dome Camera to be integrated with other suppliers' surveillance systems.
General Operation Requirements:
A minimum of one control device is required for operation, such as a control
keyboard, a DVR or a PC. The integrated high speed dome camera contains
a built-in receiver that decodes commands from a control device.
Connect dome cameras to other devices, as shown in the diagram below, to
complete a video surveillance system.
NOTE: To extend the network distance up to 1.2 km (4000 feet) and to
protect the connected devices, it is highly recommended to place a
repeater at the mid-point. However, a repeater may be needed in the network
distance less than 1.2 km if the used cables are not the CAT 5, 24-gauge
cables (see 3.3.4 RS-485 Connector Definition). Refer to the repeater’s
manual for detailed information.

Installation Guide
6
2. Standard Package Content
Before proceeding, please check the box contains the items listed here. If any
item is missing or has defects, DO NOT install or operate the product and
contact your dealer for assistance.
Dome Body
50-cm Data Cable for power
supply, video and telemetry
Screws
Optical Cover 50-cm, 13-pin Alarm Cable Waterproof rubber
Quick Guide
CD: Operation Manuals
Lubricant

Installation Guide
7
3. Dome Setups and Cable Connection
Before installing or connecting the dome camera, please refer to this section
and complete preparations for dome setups and various switch settings.
3.1 Preparations for Dome Setups
The following installation procedure is for the outdoor dome equipped with the
sunshield housing. Please follow the steps below to complete dome housing
installation.
STEP 1
Unpack the dome package and
take out the dome body.
STEP 2
Rotate the top holder and take
it off from the dome body.
STEP 3
Remove the protective cover
and PE sheet.

Installation Guide
8
STEP 4
Attach the dome cover to the
dome body. Before doing that,
apply some lubricant on the
cover’s water-proof rubber to
make the installation process
smoother.
Note that the tiny protrusion on
the dome cover must align with
one of the four holes on the
dome body.
STEP 5
Gently pressure the dome
cover downward with two
hands on the side of it.
DO NOT press the cover, as
shown in the figure; this might
cause damage to the dome
body.
STEP 6
Screw the dome cover and
body together.

Installation Guide
9
STEP 7
Set the switches located on the
bottom of the dome body.
Refer to section 3.2 Dome
Setups for detailed information
about various switch setting.
3.2 Dome Setups
Before connecting the dome camera to other devices of CCTV system,
please complete the dome ID and communication switch settings. These
switches are located on the bottom of the dome camera.
3.2.1 Switch Definition
Please refer to the following figure and table for switch location and
definitions.
A Reserved
B Communication Switch
C Dome ID Switch
D Dome Control Protocol Switch
E RJ-45 Connector (for IP Dome only)
F 22-Pin Connector
G ISP Connector (for FW upgrade)

Installation Guide
10
3.2.2 Communication Switch Setting
The table below shows the function of each switch within the Communication
Switch.
Communication Switch SW 1
SW 2 RS-485 Setting
SW 3 Termination
SW 4 Line Lock
SW 5 System Initialization
SW 6 Reserved
RS-485 is the interface that communicates the dome camera and its control
device; for this reason, the RS-485 setup of the dome and the control device
must be the same. The RS-485 default setting is half-duplex (see the diagram
follows). Please do not change the default setting without qualified specialist
or supplier’s notice. As for the SW 3 and SW 4, they are used for termination
and Line Lock adjustment respectively. The SW 5 is mainly used when users
want to restore the camera to the factory default status; moreover, once
firmware upgrade is carried out, users also need to reset the SW 5 afterward.
RS-485 Setting
Half-duplex
Full-duplex
3.2.3 Dome ID Setting
Use the switch to change your speed dome ID by turning the arrow to the
desired number respectively. For instance, if the dome ID is 123, the ID switch
should be set as below.
NOTE: No two domes should be given the same ID, or communication
conflict may occur.

Installation Guide
11
Centesimal Digit Decimal Digit Single Digit
NOTE: The number “0” should locate upwards as shown in above
diagram for correct switch definition.
3.2.4 Dome Control Protocol Setting
Define the protocol you are going to use basing on the devices of your
surveillance system. Generally, use one protocol even the devices are
provided from different manufacturers. Use the switch to set your dome
control protocol and the baud rate. Refer to the table below and turn the
arrow to choose a protocol for your speed dome.
Switch No. Protocol Baud Rate
00 VCL 9600
01 Pelco D 2400
02 Pelco P 4800
04 Chiper 9600
05 Philips 9600
07 DSCP 9600
08 AD422 4800
09 DM P 9600
11 Pelco D 4800
12 Pelco D 9600
13 Pelco P 2400
14 Pelco P 9600
15 JVC 9600
21 Kalatel-485 9600
22 Kalatel-422 4800
Select protocol: Pelco D, with switch no. 01 and baud rate 2400, for instance,
the protocol switch should be set as below.

Installation Guide
12
Decimal Digit Single Digit
NOTE: The number “0” should locate upwards as shown in above
diagram for correct switch definition.
3.3 Dome Cable Definition and Requirements
For operation, the integrated dome camera requires the video cable to carry
the video signals to the remote viewing site, power cable to power the dome
and RS-485 data cable to carry commands from the control device.
3.3.1 Cable Requirements
For operation, the integrated high speed dome cameras require video and
data cables as described below:
•The video cable sends video signals to a remote viewing site. Using a
coaxial cable to send video signals is recommended.
•RS-485 cable carries commands from a control device to the dome
cameras. A CAT 5, 24 gauge cable is recommended.
•The power cable provides AC 24V power supply to the dome.
NOTE: Ensure power supply corresponds with the dome’s power
requirement, or product impairment will occur. If any mistake happens,
please contact with a qualified maintenance engineer.

Installation Guide
13
3.3.2 22-Pin Data Cable
Power
Input
3-Pin Terminal Block
Video
Output BNC connector
RS485
Connector 4-wire
2-Wire
NOTE: Be careful not to pull the cables improperly during installation.
Additionally, it is suggested to fasten the cables after cable connection
is completed. Furthermore, when wiring the power cable, make sure
the G/Y wire (Ground) inserted into the mid-pin of the terminal block.
3.3.3 22-Pin Connector Definition
With the 22-pin connector, installers can simply connect the power, video and
RS-485 cables to the dome at once. Particularly, the alarm pins are
serviceable for connecting alarm input and output devices, such as alarm
sensors, sirens or flashing lights with the surveillance system. For the
definition of each pin, please refer to the list below.

Installation Guide
14
The 22-pin connector definition is listed as below.
Pin Definition Cable
1 AC 24-1/DC (＋) 20AWG
2 ALM NC
3 AC 24-2/DC (－) 20AWG
4 ALM NO
5 FG 20AWG
6 ALM COM
7 T+
8 R-
9 T-
10 R+
24AWG
11 ISOG
12 ALM-1
13 ALM-3
14 ALM-2
15 ALM-4
16 ALM-5
17 ALM-6
18 ALM-7
19 ALM-8
20 ALM GND
21 VGND
22 Video 24AWG
NOTE: For alarm connection, please refer to section 3.3.5 Cable
Wiring and Connection.
3.3.4 RS-485 Connector Definition
RS-485 is the interface that communicates the dome camera and its control
device. Please connect the control keyboard to the speed dome through the
terminal block. The recommended cables for RS-485 communication are CAT
5cables; maximum cable length for over 24-gauge wire is 4000 feet (1219
meters). If the total cable length exceeds 4000 feet, using a repeater to
maintain the signals is recommended. Please refer to the figure and table
below for pin defination and wiring.

Installation Guide
15
3.3.5 Cable Wiring and Connection
Users may need to do cable wiring when: (1) Connecting self-provided cords
to the connector housing instead of using the equipped data cable or (2)
Connecting alarm input and output devices. The table follows will illustrate the
way to wire cords into the connector housing.
Insert the terminal into the pin
holes on the connector housing,
with the hook outward, as
indicated in the figure.
To unlock the terminal, press the
hook, as indicated in the figure,
with a proper tool and pull it out
gently.
Pin Corresponding Pins
(22-Pin Connector) Definition
1 7,10 T+, R+ (D+)
2~4 Reserved
5 8,9 T-, R- (D-)

Installation Guide
16
Connect the 22-pin connector to
the dome camera.

Installation Guide
17
4. Dome Installation
Basing on user’s installation environments, the dome can be installed on
ceiling, on wall or on pole. In the following section, various dome installation
accessories, installation methods and installation procedures will be
described in detail.
4.1 Dome Dimension
The dome dimension is Ø172 x 302.5mm (6.7x11.9 Inches) and Ø190 x
302.5mm (7.5x11.9 Inches), with sunshield. The diagrams below show
detailed dimension for the dome’s different parts.
4.2 Optional Accessories
Dome Camera Accessories
Sunshield
White Color, Height: 129.5 mm (5.05 inches); Diameter: 190 mm (7.48 inches); 0.15 kg
(0.33 lbs)
Vandal Proof(Transparent)/PMMA (Transparent)/Smoke Cover
Diameter: 137 mm (5.4 inches)

Installation Guide
18
Security Screw Set (equipped with Vandal Proof Cover)
Power Adapter
77H07-A1030 (Input: 100~115VAC/Output: 24VAC 72VA)
77H07-A2030 (Input: 220~230VAC/Output: 24VAC 72VA)
NOTE: When wiring, make sure the G/Y wire (Ground) inserted into the mid-pin of
the terminal block.
Mounting Accessories
Gooseneck Tube
White, Iron, 298×385 mm (11.73×15.56 inches) ; 2.1 kg (4.6 lbs)
Supplied with rubber washer-8×1, pendant tube washer×1, spring washer-8×1 and
waterproof rubber×1, M8*12 screw×1.
Mini Pendent Mount
White; 184×104×115.2 mm (7.24×4.09×4.54 inches)
Supplied with rubber washer-8×1, pendant tube washer×1, spring washer-8×1 and M8*12
screw×1.

Installation Guide
19
Straight Tube
White, Iron, Height: 250/500 mm (9.8/19.7 inches) ,Diameter: 50 mm (2 inches)
1 kg (2.2 lbs) / 1.8 kg (4 lbs), Supplied with rubber washer-8×1, pendant tube washer×1,
spring washer-8×1 and waterproof rubber×1, M8*12 screw×1.
Corner Standard Mounting Plate
White, 222(L)×204(W)×117(D) mm (8.7×8×4.6 inches); 2 kg (4.4 lbs); Supplied with
washer-8×4, spring washer×4, M8*20 screw×4, M8 nut×4.
Pole Thin Direct Mounting
White/Ivory; 232(L)×136(W)×60(D) mm (9.1×5.4×2.4 inches); Diameter: 112~140 mm
(4.4~5.5 inches); 0.7 kg (1.6 lbs). Supplied with stainless steel straps×4, M8*16 screw×4,
washer×4.
