Luceo Technologies PARALLEX Series User manual

1
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Luceo Technologies GmbH
Am Borsigturm 13
Berlin 13507
Germany
Tel: [phone]
Fax: [phone]
E-Mail: [email protected]
Web: www.luceotec.com
USER MANUAL
ELECTRICAL PATTERN GENERATOR
P/N L-6001-EPG10-6
SERIES: PARALLEX®/PARALLEX SYSTEM
DOC.REV.1.5

2
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
GENERAL 3
GENERAL DESCRIPTION 3
KEY FEATURES OF THE EPG10 MODULE 5
SAFETY INFORMATION 6
CLASSIFICATION 6
SAFETY INSTRUCTIONS 6
BEFORE INITIALIZING AND OPERATING THE UNIT 6
OPERATING THE UNIT 7
SAFETY SYMBOLS 8
INSTALLATION 9
BEFORE INITIALIZING AND OPERATING THE UNIT 9
INITIAL INSPECTION 9
OPERATING ENVIRONMENT 9
TEMPERATURE 9
HUMIDITY 9
VENTILATION 9
HANDLING CONNECTORS 10
STORING AND SHIPPING 10
CLAIMS AND REPACKAGING 10
RETURNING SHIPMENTS TO LUCEO TECHNOLOGIES GMBH 10
OPERATING INSTRUCTIONS 12
OPERATING ELEMENTS OF THE PATTERN GENERATOR 12
STATUS LED’S OF EPG10 MODULE 13
GETTING STARTED 13
GUI AND PROGRAMMING REFERENCE 13
ABOUT LUCEO 14
APPENDIX 15
FIGURES 15
TABLES 15

3
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
GENERAL
GENERAL DESCRIPTION
The Electrical Pattern Generator (EPG) module is built for use in the PARALLEX® mainframe, which
has a modular setup depending on the user’s configuration (i.e. E-BERT-, Clock Source-, Clock
divider-, CDR-module). The mainframe is controlled via GPIB, USB or LAN.
The EPG is the ideal module to provide pseudo random pattern or user pattern with good jitter and
noise performance up to 14,4Gbps (option 144). It must be driven by an external clock between 2GHz
and 14.4GHz.
The output signal is differential but can also be used single ended. Also available is a pattern trigger
output, which is helpful to investigate the shape of the output signal.
Furthermore the EPG settings are controllable by the PARALLEX® graphical user interfaces
(PARALLEX® GUI) via one of the 3 interfaces GPIB, USB or LAN. The GPIB commands for
controlling the EPG module are documented in the GPIB programmer’s guide.
Please take a look at our website www.luceotec.com for newly released modules; we are constantly
expanding our product spectrum.
Figure 1: Typical appearance of the PARALLEX ®

4
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Figure 2: Collection of PARALLEX ® modules

5
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
KEY FEATURES OF THE EPG10 MODULE
Wide data rate range from 2Gbps to 14.4Gbps (with option 144)
Variable output voltage 0.5Vpp to 1Vpp
Additional CLK output signal to cascade up to 3 EPG10 modules
Pattern trigger output
LabView® drivers for embedding into manufacturing equipment
Controllable via GPIB, USB or LAN
Differential DATA output
Small size: 1” width (25.4mm)
Standard Accessories
Dust plugs for ports
User’s manual
Programmer’s guide for GPIB, USB and LAN

6
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
SAFETY INFORMATION
CLASSIFICATION
The clock source module has of a metal chassis that is directly connected to earth when plugged into
the PARALLEX ® chassis.
SAFETY INSTRUCTIONS
The following safety instructions must be observed whenever the unit is operated, serviced, or
repaired. Failure to comply with any of these instructions or with any precaution or warning contained
in the user’s manual is in direct violation of the standards of design, manufacture, and intended use of
the unit. Luceo Technologies GmbH assumes no liability for the customer’s failure to comply with any
of these safety requirements.
BEFORE INITIALIZING AND OPERATING THE UNIT
Inspect the unit for any signs of damage, and read the user’s manual thoroughly.
Install the unit as specified in the Getting Started section.

7
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
OPERATING THE UNIT
Warning
To avoid the risk of injury or death, always observe the following precautions before initializing the
unit:
Use the Module ONLY in the PARALLEX ® mainframe.
Willfully interrupting the protective earth connection is prohibited.
Never look into the end of an optical cable connected to an optical output device that is
operating. Laser radiation is invisible, and direct exposure can severely injure the human eye.
Turning off the power to the device does not always block the externally supplied radiation to
the connector at the input of the unit.
Do not use the unit outdoors.
To prevent potential fire or shock hazard, do not expose the unit to any source of excessive
moisture.
Do not operate the unit when its covers or panels have been removed.
Do not interrupt the protective earth grounding. Any such action can lead to a potential shock
hazard that can result in serious personal injury.
Do not operate the unit if an interruption to the protective grounding is suspected. In this case,
ensure that the unit remains inoperative.
Do not attempt to adjust or perform any maintenance or repair procedure when the unit is
opened and connected to a power source.
Repairs are to be carried out only by a qualified professional.
Do not attempt any adjustment, maintenance, or repair procedure to the unit’s internal
mechanism if immediate first aid is not accessible.
Disconnect the power cord from the unit before adding or removing any components.
Operating the unit in the presence of flammable gases or fumes is extremely hazardous.
Do not perform any operating or maintenance procedure that is not described in the user’s
manual.
Some of the unit’s capacitors can be charged even when the unit is not connected to the
power source.

8
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
SAFETY SYMBOLS
The following symbols and messages can be marked on the unit (Table 1). Observe all safety
instructions that are associated with a symbol.
Table 1: Safety Symbols
Symbol
Description
Laser safety. See the user’s manual for instructions on handling and operating the unit
safely.
See the user’s manual for instructions on handling and operating the unit safely.
Electrostatic discharge (ESD). See the user’s manual for instructions on handling and
operating the unit safely.
Frame or chassis terminal for electrical grounding within the unit.
Protective conductor terminal for electrical grounding to the earth.
WARNING
The procedure can result in serious injury or loss of life if not carried out in proper
compliance with all safety instructions. Ensure that all conditions necessary for safe
handling and operation are met before proceeding.
CAUTION
The procedure can result in serious damage to or destruction of the unit if not carried
out in compliance with all instructions for proper use. Ensure that all conditions
necessary for safe handling and operation are met before proceeding.

9
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
INSTALLATION
BEFORE INITIALIZING AND OPERATING THE UNIT
Inspect the unit for any signs of damage.
Read the user’s manual thoroughly, and become familiar with all safety symbols and
instructions to ensure that the unit is operated and maintained safely.
INITIAL INSPECTION
Check that the unit and contents are complete:
Wear an anti-static wrist strap, and work in an electrostatic discharge (ESD) controlled area.
Inspect the shipping container for any indication of excessive shock to the contents, and
inspect the contents to ensure that the shipment is complete.
Inspect the unit for structural damage that can have occurred during shipping.
Keep the packaging.
Immediately inform Luceo Technologies GmbH and, if necessary, the carrier if the contents
of the shipment is incomplete, if the unit or any of its components are damaged or defective,
or if the unit does not pass the initial inspection.
OPERATING ENVIRONMENT
In order for the unit to meet the specifications, the operating environment must meet the following
conditions for temperature, humidity and ventilation.
TEMPERATURE
The unit can be operated in the temperature range of 0 to 50 °C.
HUMIDITY
The unit can be operated in environments with up to 85% humidity (10 to 50 °C). Do not expose it to
any environmental conditions or changes to environmental conditions that can cause condensation to
form inside the unit.
VENTILATION
The unit contains holes to achieve airflow to transport the heat out of the module. Do not place any
stickers or labels on the module cover which will reduce the airflow. Blocking the air circulation of the
unit can cause the unit to overheat, compromising its reliability and possibly leading to permanent
damage.
Warning To avoid electrical shock, do not initialize or operate the unit if it shows
any sign of damage to any portion of its exterior surface, such as the outer cover
or panels.

10
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Warning
Do not use the unit outdoors.
To prevent potential fire or shock hazard, do not expose the unit to any
source of excessive moisture.
HANDLING CONNECTORS
Caution
Connecting damaged or dirty cables, optical fibers or connectors to the unit
can damage the connectors of the unit.
Use a torque wrench with a maximum torque of 1Nm
(0.74 lbs-ft) to connect cables to the SMA connectors.
A torque of more than 1Nm can damage the SMA connectors permanently.
Use of inappropriate tools when connecting cables and fibers to connectors
(wrenches, spanners etc) can result in mechanical damage to adjacent
connectors and to the connector itself. Similar damage can occur if using a
torque wrench set to a torque above the maximum recommended value.
It is recommended to use dust caps or 50Ω terminations for unused ports /
connectors to avoid connectors becoming damaged by dirt or electrostatic
discharge.
Ensure that long cables or other connected equipment cannot apply forces
or torques that may damage the connectors.
Do not stand the unit on the connectors, as it may damage them.
Optical connectors must be kept clean to avoid damage or performance
degradation. All optical connectors have removable adapters to allow access
to the cleanable surface.
Please ensure adequate cleaning procedures. Ask Luceo Technologies for
advice if required.
STORING AND SHIPPING
To maintain optimum operating reliability, do not store the unit in locations where the temperature falls
below -40 °C or rises above 70 °C. Avoid any environmental condition that can result in internal
condensation. Ensure that these temperature and humidity requirements can also be met whenever
the unit is shipped.
CLAIMS AND REPACKAGING
Immediately inform Luceo Technologies GmbH and, if necessary, the carrier, if
The content of the shipment is incomplete
The unit or any of its components are damaged or defective
The unit does not pass the initial inspection
In the event of carrier responsibility, Luceo Technologies GmbH will allow for the repair or replacement
of the unit while a claim against the carrier is being processed.
RETURNING SHIPMENTS TO LUCEO TECHNOLOGIES GMBH
Luceo Technologies GmbH only accepts returns for which an approved Return Material Authorization
(RMA) has been issued by Luceo Technologies GmbH sales personnel. This number must be
obtained prior to shipping any material to Luceo Technologies GmbH. The owner’s name and address,
the model number and full serial number of the unit, the RMA number, and an itemized statement of
claimed defects must be included with the return material.

11
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Ship returned material in the original shipping container and packing material. If these are not
available, packaging guidelines are as follows:
Wear an anti-static wrist strap and work in an ESD controlled area.
Cover the front panel, if applicable, with a strip of cardboard.
Wrap the unit in anti-static packaging. Use anti-static connector covers, if applicable.
Pack the unit in a reliable shipping container.
Use enough shock-absorbing material (10 to 15 cm or 4 to 6 in on all sides) to cushion the unit
and prevent it from moving inside the container.
Seal the shipping container securely.
Clearly mark FRAGILE on its surface.
Always provide the model and serial number of the unit and, if necessary, the RMA number on
any accompanying documentation.
Ship the unit only to the address given at the beginning of this document.

12
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
OPERATING INSTRUCTIONS
OPERATING ELEMENTS OF THE PATTERN GENERATOR
Front Panel view of the pattern generator module.
Figure 3: EPG10 front panel view
The operating elements of the EPG10 module are described in Table 2: Operating elements.
Reset
SMA Data signal
output P
Handhold
Mounting Hole
Mounting Hole
Mounting Hole
Mounting Hole
LED Module State
SMA High Speed
Clock Output
LED for CLK Input
SMA Data signal
output N
SMA High Speed
Clock Input
SYNC Input
Pattern
Trigger Output

13
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Table 2: Operating elements
Key
Description
Reset
Sets the respective EPG10 module to the hard reset state:
Output state: ON
Data output invert: OFF
Output voltage: 500mVpp
Data pattern : PRBS 7
Error injection: OFF
Trigger output: ON
Internal controller hard reset ON
STATUS LED’S OF EPG10 MODULE
The status LED’s are described in Table 3.
Table 3: Status LED’s
LED
Description
CLK IN
If the LED is ON, an valid CLK-signal is detected at SMA CLK IN
CLK IN
If the LED is OFF, no valid CLK-signal is detected at SMA CLK IN
System Fault
If the LED is ON, the module might be in an undefined state. For example a
communication error occurred.
GETTING STARTED
Depending on the configuration of the PARALLEX ® there will be different possibilities to set up the
EPG10 module.
It is recommended to terminate unused input and output ports of the EPG10 module with 50OHM to
avoid reflections.
GUI AND PROGRAMMING REFERENCE
When using the provided PARALLEX ® GUI, please refer to the “Manual-GUI PARALLEX®
PARALLEX-Rev (xx)”to use all functions of this module.
If you want to write your own software all necessary information can be found in the provided
“PARALLEX_programmers_guide_Rev (xx)”.

14
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
Luceo Technologies GmbH
Am Borsigturm 13
Berlin 13507
Germany
Tel: [phone]
Fax: [phone]
E-Mail:[e-mail]
Web: www.luceotec.com
ABOUT LUCEO
LUCEO Technologies GmbH was created by engineers involved in optical transceiver design, who
recognized critical gaps in test and measurement equipment for optical component and transceiver
characterization. Luceo’s test system is the first to combine a complete BERT test solution with
affordable cost and German build quality. Targeted for high volume production test applications,
Luceo’s equipment optimizes speed and ease-of-use, allowing users to achieve minimum cost-per-
test. Founded in 2005, Luceo is headquartered in Berlin, Germany, with a worldwide sales network.
Product specifications and descriptions are subject to change without notice.
All rights reserved.

15
ELECTRICAL PATTERN GENERATOR User Manual --- Rev 1.5 --- 2012/11
www.luceotec.com
APPENDIX
FIGURES
Figure 1: Typical appearance of the PARALLEX ® 3
Figure 2: Collection of PARALLEX ® modules 4
Figure 3: EPG10 front panel view 12
TABLES
Table 1: Safety Symbols 8
Table 2: Operating Keys 13
Table 3: Status LED’s 13
