Lucky Star 5MVP3 User manual

5MVP3
Ver.4.0+
AT Form Factor
Main Board
User's Manual

Copyright
Copyright © 1998 by this company. No part of this document may
be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or
by any means without prior written permission. This manual and the
information contained herein are protected by copyright. All rights
reserved.
Manual version: 1.1
Published in 1998

Warning and disclaimer
This manual is designed to provide information about the
Pentium® system board. Every effort has been made to make this
manual as accurate as possible, but no warranty or fitness is implied.
All the information is provided on an 'as is' basis. The author and his
corresponding publishing company shall have neither liability nor
responsibility to any person or entity with respect to any loss or
damages arising from the information contained in this manual or
from the use of the system board that accompanies it.
Information contained in this manual is subject to change without
notice. The manufacturer of the main board will not be held
responsible for technical or editorial omissions made herein, nor
for the incidental or consequential damages resulting from its
furnishing, performance, functionality or use. Subsequent changes
to this manual will be incorporated into the next edition. We
welcome any suggestion regarding this manual or our computer
products.
Trademarks
●Intel and Pentium are registered trademarks of Intel Corporation.
●IBM is a registered trademark of International Business Machines
Corporation.
●Microsoft is a registered trademark of Microsoft Corporation.
●PCI is a registered trademark of PCI Special Interest Groups.
●AWARD is a registered trademark of Award Software Inc.
All other trademarks are the property of their respective owners.

MVP3 Main Board I
Table of contents
Chapter 1 Introduction_______________________ 1
1-1 Main Board Overview____________________________________1
1-2 Specifications__________________________________________3
1-3 Notice of Hardware Installation_____________________________5
Chapter 2 Installation_________________________ 7
2-1 Layout Reference________________________________________7
2-2 Quick reference to CPU Speed Setup_________________________8
2-3 Jumper Settings________________________________________ 10
2-3-1 S1_____________________________________________10
2-3-2 S2_____________________________________________12
2-3-3 JP4 DIMM Voltage Selector________________________13
2-3-4 JP5 Flash ROM Voltage Selector____________________14
2-3-5 JP7 CMOS Status________________________________15
2-4 Connectors___________________________________________ 16
2-4-1 CN10 Front Panel Connectors_______________________16
2-4-2 Back Panel Connectors____________________________18
COM 1/COM2________________________________________ 18
LPT Parallel Port _____________________________________ 19
CN8 USB____________________________________________ 20
Keyboard ____________________________________________20
CN4 Mouse__________________________________________ 21
2-4-3 CN5 ATX Power Supply Connector__________________ 22
2-4-4 CN7 AT Power Supply Connector____________________23
2-4-5 CN8 IR Connector________________________________24
2-4-6 FAN1/FAN2 Connectors___________________________25
2-4-7 FDC Floppy Interface_____________________________ 26
2-4-8 IDE1 and IDE2 Ports______________________________27
2-4-9 LAN___________________________________________ 28
2-5 Expansion Slot_________________________________________29
2-6 DIMM Memory Installation_______________________________ 31

MVP3 Main Board I
Chapter 3 BIOS Setup________________________ 33
3-1 Award BIOS CMOS Setup________________________________33
3-2 Standard CMOS Setup___________________________________ 34
3-3 BIOS Features Setup____________________________________ 36
3-4 Chipset Features Setup___________________________________40
3-5 Power Management Setup________________________________ 42
3-6 PNP/PCI Configuration Setup_____________________________ 45
3-7 Integrated Peripherals____________________________________47
3-8 Supervisor/ser Password_________________________________ 50
3-9 IDE HDD Auto Detection________________________________ 53
3-10 Load Setup Defaults_____________________________________56
3-11 Save and Exit Setup_____________________________________.57
3-12 Quit Without Saving____________________________________ 58
Chapter 4 Appendix__________________________59
4-1 Memory Map__________________________________________59
4-2 I/O Map______________________________________________60
4-3 Time & DMA Channels Map______________________________ 61
4-4 Interrupt Map__________________________________________62
4-5 RTC & CMOS RAM Map________________________________ 63
4-6 Award BIOS Hard Disk Type______________________________ 64
4-7 ISA I/O Address Map____________________________________ 66
Chapter 5 Q & A______________________________68
5-1 Error Messages During Power On Self Test ___________________68
5-2 Frequently Asked Questions_______________________________70

MVP3 Main Board 1
Chapter 1 Introduction
1-1 Main Board Overview
The main board is a new-generation AGP Pentium® main board with high
performance in rendering and texture for 3D Graphics. Based on Apollo MVP3
chipset, the main board has intergrated the latest advances in processor, memory,
I/O technologies into an AT form factor. It is also designed for the upcoming 100
MHz F.S.B CPUs, like AMD K6-2/K6-3 series or Cyrix MII CPUs.
The main board utilizes VIA Apollo MVP3 and supports new architects such as
high-speed AGP graphic port, SDRAM, Ultra DMA/33, bus master IDE and USB
port. It has three Dual In-line Memory Modules (DIMM) which can be installed
with SDRAM memory. The memory subsystem supports up to 512Mbyte SDRAM
of non-buffered 3.3V using standard 168-pin DIMM sockets.
The main board implements high performance I/O Controller utilizes with fully
Plug and Play device which supports 2.88 MB Floppy, Dual 16550 Compatible
(with 16 bytes FIFO, up to 460K baud rate) Serial Port, ECP (Enhanced
Capabilities Port), EPP (Enhanced Parallel Port) parallel port, Infrared IrDA
(HPSIR), and Amplitude Shift Keyed IR. (ASKIR) port.
The main board supports 3*PCI & 3*ISA for highest performance I/O add-on
adapter cards. The system board supports three Matrix Independent for complete
multiple PCI adapters operation up to 133MB/s data transfer rate on PCI bus
compared to 33MB/s on EISA bus, synchronized operation CPU to PCI Interface
for best graphical performance, 120MB/s PCI to system DRAM together with
utilizing Snoop Ahead Features, and support back to back sequential CPU to PCI
Memory writes to PCI Burst Write for full PCI through put.
MVP3 chipset doesn’t support Ultra DMA/66 mode HDD…

MVP3 Main Board 2
The main board is also strengthened with Power Management Wake up Event such
as “WOL (Wake up on LAN),” and “Modem ring on,” which are the new
inventions to enable PCs to be turned on over the network or modem. These are
also key benefits in PC operation, asset management, new system setup and power
conservation.
In addition to the above features, this main board is a DIP switch design, which
offers an easier procedure to set CPU speed compared with present Pentium main
boards.
In conclusion, the main board is a combination of the highest in performance,
flexibility, efficiency, and ease of use that meets a variety of price/performance
levels. The main board is an ideal platform for the increasing requirements of
today’s and future’s desktop application.

MVP3 Main Board 3
1-2 Specifications
●PCB board size: 25 cm x 22 cm
●PCB layer: 4 layers
●ZIF Socket 7
Support Intel® Pentium, Cyrix 6x86 series/ MII series, IDT WinChip series
and AMD K5/K6/K6-2/K6-III CPUs
CPU is not enclosed in the package
●Memory DIMM: 3 of 168-pin 3.3V DIMM
!
!!
!Professional PC
*100 MHz freq. : PC-100 DIMM
66MHz DIMM can be used with 100 MHz CPUs, but the user must adjust jumper S1
pin 7 for asynchronous operation.
* 66 MHz freq.: SDRAM up to 384MB
EDO RAM up to 768MB (3.3V only)
!
!!
!Basic PC: 66 MHz freq.
* SDRAM up to 384MB
* EDO RAM up to 768MB(3.3V only)
●Expansion Slot : 3x ISA slots, 3x PCI slots and 1x A.G.P. slot
●Chipset : VIA Apollo MVP3
!
!!
!VIA VT82C586B
!
!!
!VIA VT82C598MVP
●BIOS
licenced Award® full PnP (Plug & Play) BIOS, flash ROM BIOS
●Cache: 512K; 1024K

MVP3 Main Board 4
●I/O function
!
!!
!2 x PCI IDE devices
!
!!
!1 x FDC, 2 x serial ports(16550 fast com)
!
!!
!1x parallel port device /EPP/ECP
!
!!
!2x USB connector
!
!!
!IrDA (infrared) connector
●Green function: Complied with APM (Advanced Power Management)
●AT form factor
●Electrical--- Typical power supply
Below is reference for ATX power supply.
Voltage Tolerance Current
+5V ±5% 22 Amperes
+3.3V ±5% 3 Amperes
+12V ±10% 800 mA
-5V ±5% 150 mA
-12V ±5% 100 mA
WOL (Wake up on LAN) function :
Power supply should offer at least 750mA to the signal “5V trickle voltage” to
support.
●Power supply regulation
Onboard switching voltage that support appropriate power to the CPU and
future upgraded CPUs.
●Special features
!
!!
!Wake up on LAN
!
!!
!Modem ring on
!
!!
!Windows 95 power off
!Auto detection of CPU voltage, temperature, and fan speed

MVP3 Main Board 5
1-3 Notice of Hardware Installation
Before hardware installation, make sure you have checked the following
things.
A. Check the package
If any of these items is missing or damaged, contact the dealer from whom
you purchase. Leave this main board in its original package until you are
ready to install it. In the package, there are:
!
!!
!the main board
!
!!
!manual
!
!!
!cables
!
!!
!driver & utility / CD
B. Make sure power is off.
C. Avoid ESD (Electrical Static Discharge).
While working with this main board, wear a grounded wristband or ankle
strap to avoid ESD (Electrical Static Discharge).

MVP3 Main Board 6

MVP3 Main Board 7
Chapter 2 Installation
2-1 Layout Reference
FAN2
FAN1
S2
SOCKET
SRAM
SRAM
JP4
VT82C598MVP
VT82C586B
AGP
IDE1
IDE2
LPTMOUSE
USB
I/O
JP5
BIOS
SL3 SL2 SL1 PCI3 PCI2 PCI1
COM2
COM1
K/B
CN5
CN6
FD
C
DIMM3 DIMM2 DIMM1
JP7
LAN
CN10
IR

MVP3 Main Board 8
2-2 Quick Reference to CPU Speed Setup
The setup of CPU speed is simplied to a “DIP switch form,” which is only related
to jumpers S1 and S2. This design is also convenient to recognize those jumpers
as below.
ON DIP
1 2 3 4 5 6 7
1 2 3 4
DIP
ON
S2: CPU voltage selector

MVP3 Main Board 9
S1 S2Intel Pentium PU
Clock SYS. Clock CPU Voltage Ratio 1234561234
P54C 100 MHZ 66 MHZ 3.3V 1.5X off off off off on on on off on on
P54C 120 MHZ 60 MHZ 3.3V 2X on off off on on on on off on on
P54C 133 MHZ 66 MHZ 3.3V 2X on off off off on on on off on on
P54C 150 MHZ 60 MHZ 3.3V 2.5X on on off on on on on off on on
P54C 166 MHZ 66 MHZ 3.3V 2.5X on on off off on on on off on on
P55C 166 MHZ 66 MHZ 2.8/3.3V 2.5X on on off off on on off off off on
P54C 180 MHZ 60 MHZ 3.3V 3X off on off on on on on off on on
P54C 200 MHZ 66 MHZ 3.3V 3X off on off off on on on off on on
P55C 200 MHZ 66 MHZ 2.8/3.3V 3X off on off off on on off off off on
P55C 233 MHZ 66 MHZ 2.8/3.3V 3.5X off off off off on on off off off on
S2 S2Cyrix CPU Clock SYS.
Clock CPU Voltage Ratio 1234561234
150+ M1 60 MHZ 3.52V 2X o
n
of
f
of
f
o
n
o
n
o
n
o
n
o
n
o
n
o
n
166+ M1 66 MHZ 3.52V 2X on off off off on on on on on on
6X86L 150 60 MHZ 2.8/3.3V 2X on off off on on on off off off on
6X86L 166 66 MHZ 2.8/3.3V 2X on off off off on on off off off on
6X86L 200 75 MHZ 2.8/3.3V 2X on off off on on off off off off on
6X86MX 166 66 MHZ 2.9/3.3V 2X on off off off on on on off off on
6X86MX 166 60 MHZ 2.9/3.3V 2.5X on on off on on on on off off on
6X86MX 200 75 MHZ 2.9/3.3V 2X on off off on on off on off off on
6X86MX 233 75 MHZ 2.9/3.3V 2.5X on on off on on off on off off on
6X86MX 266 83 MHZ 2.7/3.3V 2.5X on on off off on off on on on off
6X86MII 300 66 MHZ 2.9/3.3V 3.5X off off off off on on on off off on
6X86MII 333 83 MHZ 2.9/3.3V 3X off on off off on off on off off on
S1 S2AMD CPU Clock SYS.
Clock CPU Voltage Ratio 1234561234
K5-PR100/PR133 66 MHZ 3.52V 1.5X off off off off on on on on on on
K5-PR166 66 MHZ 3.52V 2.5X on on off off on on on on on on
K6-PR166 66 MHZ 2.9/3.3V 2.5X on on off off on on on off off on
K6-PR200 66 MHZ 2.9/3.3V 3X off on off off on on on off off on
K6-PR233 66 MHZ 3.2/3.3V 3.5X off off off off on on off off on on
K6-PR233 66 MHZ 3.3/3.3V 3.5X off off off off on on on off on on
K6-PR266 66 MHZ 2.2/3.3V 4X on off on off on on off on off off
K6-PR300 66 MHZ 2.2/3.3V 4.5X on on on off on on off on off off
K6-2 250 100MHZ 2.2/3.3V 2.5X on on off off off off off on off off
K6-2 266 66 MHZ 2.2/3.3V 4X on off on off on on off on off off
K6-2 300 100MHZ 2.2/3.3V 3X off on off off off off off on off off
K6-2 333 95 MHZ 2.2/3.3V 3.5X off off off on off off off on off off
K6-2 350 100MHZ 2.2/3.3V 3.5X off off off off off off off on off off
K6-2 380 95 MHZ 2.2/3.3V 4X on off on on off off off on off off
K6-2 400 100MHZ 2.2/3.3V 4X on off on off off off off on off off
K6-2 450 100MHZ 2.4/3.3V 4.5X o
n
o
n
o
n
of
f
of
f
of
f
of
f
of
f
o
n
of
f
K6-2 475 95 MHZ 2.4/3.3V 5X of
f
o
n
o
n
o
n
of
f
of
f
of
f
of
f
o
n
of
f
K6-3 400 100MHZ 2.4/3.3V 4X o
n
of
f
o
n
of
f
of
f
of
f
of
f
of
f
o
n
of
f
K6-3 450 100MHZ 2.4/3.3V 4.5X o
n
o
n
o
n
of
f
of
f
of
f
of
f
of
f
o
n
of
f

MVP3 Main Board 10
2-3 Jumper Settings
With a careful design for the CPU speed jumper, this main board has been
simplied to a “DIP Switch” form. It is very convenient to set CPU speed under
DIP switch.
2-3-1 S1
S1 Pin 1 to Pin 3: CPU Ratio Selector
S1
Pin1Pin2Pin3CPU Ratio
off off off 1.5/3.5x
on off off 2.0x
on on off 2.5x
off on off 3.0x
on off on 4.0x
on on on 4.5x
offonon5.0x
off off on 5.5x
S1
ON DIP
1 2 3 4 5 6 7

MVP3 Main Board 11
S1 Pin 4 to Pin 6: CPU Frequency Selector
S1
Pin4Pin5Pin6CPU Frequency
on on on 60 MHz
off on on 66.6 MHz
on on off 75 MHz
off on off 83.3 MHz
on off off 95 MHz
off off off 100 MHz
S1 Pin 7: SDRAM Clock Frequency
S1 Pin 7 SDRAM Clock Freq.
on SDRAM clock is fixed on 66 MHz
off SDRAM Clock is the same with CPU clock

MVP3 Main Board 12
2-3-2 S2 CPU Voltage Selector
S2
Pin1Pin2Pin3Pin4CPU Vcore
on off off off 2.1V
off on off off 2.2V
off off on off 2.4V
on on on off 2.7V
off off off on 2.8V
on off off on 2.9V
off off on on 3.2V
on off on on 3.3V
on on on on 3.5V
1 2 3 4
DIPON
S2: CPU voltage selector

MVP3 Main Board 13
2-3-3 JP4 DIMM Voltage Selector
JP4 is a 4-pin connector to select either 3.3V or 5V DIMM voltage. Select “1-2,
3-4” for 5V DIMM, or “5-6, 7-8” for 3.3V DIMM..
JP4 DIMM Voltage
1-2, 3-4 5V
5-6, 7-8 3.3V
JP4: DIMM voltage selector
1 2
7 8

MVP3 Main Board 14
2-3-4 JP5 Flash ROM Voltage Selector
JP5 is a 3-pin connector to select 5V or 12V flash ROM. Select “1-2” for 5V or
“2-3” for 12V.
JP5 Flash ROM Voltage
1-2 5V
2-3 12V
JP5: Flash ROM
voltage selector
Pin1

MVP3 Main Board 15
2-3-5 JP7 CMOS Status----clearing content of CMOS
JP7 is a 3-pin connector. Clear CMOS if system password is forgotten. Below is
details to show how to clear CMOS.
JP4 CMOS Status
1-2 Normal
2-3 Clear CMOS
Procedure to clear CMOS:
Step 1: Shut down the system and disconnect the power supply from AC power.
Step 2: Pull out the AT cable from AT connector.
Step 3: Short the CMOS jumper by putting jumper cap on Pin 2-3 for a few seconds.
Step 4: Return to pin 1-2 for normal setup.
Step 5: Link power cable to the connector & connect AC power to power supply.
Step 6: Turn on system power.
if you’d like to set password, press “Del” Key during system bootup to enter
CMOS setup and establish a new password.
Pin1
JP7: CMOS status
