Lumax Roboluber LX-1182 Quick start guide

1
OPERATIONAL MANUAL
20 VOLT CORDLESS GREASE GUN
For use with 14 oz. (400 cc / 397 g) Cartridge
or 16 oz. (500 cc / 454 g) Bulk Capacity
LX-1182
Form :
LX-1162-IS
Store thiS Manual in the Pocket of carrying caSe for future reference
Thank you for purchasing RoboLuber Cordless Grease Gun. By selecting RoboLuber you have chosen a
High-quality, Precision Engineered product that has been designed and manufactured to Lumax’s High
Standard for Dependability, Ease of Operation, and Operator Safety.
RoboLuber is a Heavy-duty, Cordless Automatic Grease Gun designed and developed for use by
professionals for manual lubrication of the grease points. Made of specially designed, Tough and
Breakage Resistant Hardened Steel Gearing with Precision Bearings allows smooth and efficient power
transport with exceptionally long working life. The high capacity motor is designed to run so cool under
load that no reset switches are necessary.
Latest technologies and unique, innovative features give you maximum performance from your
RoboLuber. Finest Raw Materials, Innovative Design, Precise Manufacturing and Strict Quality Control
ensure exceptional service life. RoboLuber gets your job done faster, better and with the highest
productivity - Getting the job done at a lower cost.
If you use your RoboLuber properly and only for what it is intended, you will enjoy safe, reliable service,
for a long time to come.
Thank you for buying a quality Lumax product.
Form: LX-1182-IS
High Performance Lithium-ion

2
Table of Contents
RoboLuber Contents..........................................................................................................3
Safety Tips ..........................................................................................................................4
Specifications................................................................................................................. 5-6
RoboLuber Accessories................................................................................................. 6-7
Work Area, Electrical, Personal, General and Specific Safety Rules ........................... 8-9
Operation......................................................................................................................... 10
RoboLuber Use, Care and Service.............................................................................. 10-11
Safety Instructions for Charger & Battery ................................................................... 11-12
Battery Charging ........................................................................................................ 13-14
Tips for Maintaining Maximum Battery Life.................................................................... 14
Installing or Removing Battery Pack ............................................................................... 15
Grease Filling Operating Instructions..........................................................................16-17
Troubleshooting.......................................................................................................... 18-19
Warranty Information ......................................................................................................20
Spanish Version..........................................................................................................21-40
French Version ............................................................................................................41-60

3
CONTENTS
1. Heavy-duty Case (LX-104)
2. Trigger-Lock Lever
3. LED Light
4. Pressure Adjustable Switch
5. Air Bleeder Valve (LX-1422)
6. Pressure Relief Valve
7. One-hour Fast Charger, 110~240V, 50/60 Hz. (LX-2183)
8. Battery Charge Indicator Switch
9. High Capacity, Li-ion 20V Rechargeable Battery (LX-2182)
10. Extra, High Capacity, Li-ion 20V Rechargeable Battery (LX-2182)
11. 30” Ultra-flex Hose with Spring Guards (LX-1214) with 7/16-28” UNEF
Fitting, 1/8” NPT (M) Outlet, (10,000 PSI / 690 bar Max. Working Pressure)
12. 4-Jaw Coupler (LX-1400)
13. Anti-fatigue Carrying Strap (LX-100)
14. Operation Manual Pocket
OPERATIONAL MANUAL
20 VOLT CORDLESS GREASE GUN
For use with 14 oz. (400 cc / 397 g) Cartridge
or 16 oz. (500 cc / 454 g) Bulk Capacity
LX-1182
9 & 10
2
3
4
5
6
11
13
1
7
8
12
14

4
SAFETY FIRST
Your Safety is very important to us. Properly cared for, RoboLuber will give you extended time of rugged,
trouble-free performance. Please read this Operational Manual carefully. The Instructions contained in
this Manual must be read and understood by the operator prior to operating RoboLuber. It is extremely
important that you read the entire Manual to become familiar with the RoboLuber before you begin to
operate the unit. Please store this Operational Manual in the pocket of Carrying Case, for later reference.
Lumax Lubrication Products are Precision Engineered Tools, which are capable of creating Pressures well
above 10,000 PSI (690 BAR). Always use Safety Equipment. Always wear adequate Eye Protection.
Only Professional use assures Danger-free operation of these products. Warning: Extreme Pressure may
cause Nozzle Extension or Grease Hose to burst. Keep hands clear of the Extension and Hose during
operation of the Grease Gun. Always follow Grease Hose Instructions and Warnings.
Do not abuse the Hose. Never use the Hose to carry the Tool. Keep the Hose away from Heat,
Sharp Edges, or Moving parts. Never touch a Hose that is under Pressure. Hold the Hose only in
the area of the Spring Guard. Hoses are subject to rapid aging. Never use a Hose that is older than 2
years. Hoses must never be Bent or Twisted with force. The smallest bending radius for hose is 4” (100 mm).
Immediately replace the Hose at first sign of Wear, Kink, or Damage to the outside Jacket.
Maintain your equipment periodically and check before each use that all connections are securely
fastened. High Working Pressures may result in grease being injected into flesh upon malfunction of
one of the Components. Only use Components that show no indications of damage. Be extra careful
while working with Needle Point Grease Adapters and Dispensers.
Keep your hands away from the Needle Point at all times when injecting Grease. Grease injection
injuries are a very serious injury. While working on the Grease Gun Barrel, make certain that the open,
threaded barrel-end always points away from yourself or others. Never point the Outlet at yourself or
others. Seek immediate medical care after an injury.
Important Operating Tip
RoboLuber has a built-in pressure relief valve that is factory pre-set to relieve pressure above 7,000
PSI (483 Bar) in case you encounter a Clogged or Tight Bearing, Clogged or damaged Grease Fitting,
or a Blocked Lubrication Line. Caution: If such a situation exists, then the piston in your RoboLuber
will work Feverishly (like a Jack Hammer rather than of a normal, smooth piston action). It will also
make unusual sound because it exerts undue pressure on the motor. You should immediately
stop the operation and remedy the blockage before continuing lubrication with the RoboLuber.
Do not continue to hold down trigger if the Grease Gun is stalled. This could Damage the Mechanism
and Motor or even cause a Fire. If you continue pressing the trigger, the excess grease will flow
back into the Barrel. However, this action is absolutely and strongly not recommended as it
would Damage the Tool, beyond repair.

5
WEAR YOUR
FORESIGHT IS BETTER
THAN NO SIGHT
SAFETY GOGGLES
The operation of any Power Tool can result in foreign
objects being thrown into your Eyes, which can result
in Severe Eye Damage. Before beginning Power Tool
operation, always Wear Safety Glasses or Safety Goggles
and a Full Face Shield when needed. Always Wear Eye
Protection which is marked to comply with ANSI Z87+
RoboLuber is a Heavy-duty, fully Battery Operational,
Automatic Grease Gun. RoboLuber is designed and
developed for use by professionals for manual lubrication
of the grease points. RoboLuber is designed to pump and
dispense Grease using 20 Volt Battery Power. Under any
circumstances, the Maximum Specification Ratings should
never be exceeded. Any other use not in accordance with
these Instructions will result in loss of claim for Warranty.
Lumax reserves the right to change specifications without
notice. Specifications may differ from country to country.
SPECIFICATIONS
20 Volt Cordless Grease Gun: LX-1182
Operating Power 20 Volt
Maximum Operating Pressure 4,000~10,000 PSI (310~690 bar)
Pressure Relief Valve 7,000 PSI / 483 bar (Factory Preset)
Grease Reservoir Capacity 14 oz. (400 cc / 397g) Cartridge or
16 oz. (500 cc / 454g) Bulk
Operating Temperature Range 0° to 120°F (-18 to +50°C)
Average Operating Current 3.6~5.4 Amp.
RPM of Motor 20,000
Motor Torque 120 mNm
Current Consumption of Motor 3.0A
Lubricant (Grease) Up to NLGI #2
Grease Output 4.2 oz./min. (120g/min) at normal pressure
1.2 oz./min. (35g/min) at high pressure
Time it takes to dispense one 14 oz. (397g) 4 minutes
Grease Cartridge*
No. of Grease Cartridges that can be
dispensed with a Single (full charged) Battery*: > 6
Net Weight of Grease Gun (Including Battery): 6.6 lb. (3kg)
Dimensions of Grease Gun (Including Battery): 10-1/4” x 9-7/8” x 3-1/2” (26 x 25 x 9cm)
Dimensions of Total Unit (Including Case): 20-7/8” x 17” x 5” (530 x 430 x 125mm)
Weight of Total Unit (Including Case): 12 lb. (5.5 kg)
* Based upon NLGI #2, Multi-purpose Grease.
Note: Output will vary upon type of Grease, its
Viscosity, Temperature and on type of application.
Battery Pack: LX-2182
Battery Type: Li-Ion
Voltage: 20 Volt DC
Capacity: 1500 mAh
Net Weight: 13 oz. (380g)
Dimensions: 5” x 2-3/4” x 3-7/8”
(127 x 73 x 46 mm)
Important
New Battery Packs are shipped
in an uncharged state. Charge your
Battery Pack for 6 hours before
first use and follow the charging
instructions in your Charger manual.

6
SPECIFICATIONS
Power Battery Charger: LX-2183
Output: 21 Volt, DC 1.4A
Input Voltage and Frequency: 100~240V AC, 50/60 Hz.
Charge Time: 1 Hour
Battery Charger Current (Fast Charge): 1500 mAh
Net Weight of Battery Charger: 4.6 oz. (130g)
Dimensions of Battery Charger: 3-1/2” x 2-1/8” x 2-3/8” (90 x 55 x 60 mm)
Outlet Hose, LX-1214: 30” with 2 Springs, 1/8” NPT x 7/16-28 UNEF
Max. Pressure Rating: 10,000 PSI (518 bar)
ACCESSORIES
These accessories or attachments are recommended for use with your RoboLuber specified in this
manual. The use of any other accessories or attachments may present a risk of injury to you or people
around you. The accessories or attachments should be used only in the proper and intended manner.
WARNING! Always remove Battery Pack before Changing or Removing Accessories. Be aware that
your RoboLuber is always in an operating condition, because it does not have to be plugged into an
Electrical Outlet. Avoid accidental starting. Prior to inserting Battery Pack or operating the unit, always
check to see that the Trigger-Lock Lever is not in a “flipped-up” position. Carrying tools with your finger
on the switch or inserting the Battery Pack into a Tool with the switch Trigger-Lock Lever in a “flipped-up”
position invites accidents. Only use Accessories specifically recommended for RoboLuber. Others may
be hazardous and may void Warranty.
LX-1402
LX-1400 LX-1401
LX-1407
LX-1404
LX-1406
LX-1408

7
LX-1409
LX-1410
LX-1412
LX-1414
LX-1415
LX-1416
LX-1418
LX-1420
LX-1422
LX-1424
LX-1434
LX-1168
LX-1212
LX-1411
LX-1186

8
GENERAL SAFETY RULES - FOR ALL BATTERY OPERATED TOOLS
WARNING! FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW
MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS PERSONAL INJURY
WORK AREA:
• Keep your work area clean, dry and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate Power Tools in Explosive Atmospheres, such as, in the presence of Flammable
Liquids, Gases, or Dust. Power tools create sparks which may ignite the Dust or Fumes,
particularly, in confined spaces.
• Keep Bystanders, Children, and Visitors away while operating a Power Tool. Distractions can
cause you to lose control. Protect others in the work area from Debris such as Chips and Sparks.
Provide Barriers or Shields, as needed.
ELECTRICAL SAFETY:
• A Battery Operated Tool with Integral Batteries or a separate Battery Pack must be recharged
only with the specified Charger for the Battery. A Charger that may be suitable for one type
of Battery may create a risk of Fire when used with another Battery.
• Use Battery Operated Tool only with specically designated Battery Pack. Use of any other
Batteries may create a Fire or Explosion.
PERSONAL SAFETY:
• Stay alert! Watch what you are doing. Use common sense when operating a Power Tool.
Do not use Power Tool when tired or under the influence of Drugs, Alcohol, or Medication.
A moment of inattention while operating Power Tools may result in serious personal injury.
• Be aware that your RoboLuber is always in an operating condition, because it does not have to
be plugged into an Electrical Outlet.
• Avoid accidental starting. Prior to inserting Battery Pack or operating the unit, always check to
see that the Trigger-Lock Lever is not in a “flipped-up” position. Carrying tools with your finger on
the switch or inserting the Battery Pack into a Tool with the switch Trigger-Lock Lever in a “flipped-
up” position invites accidents.
• Remove Wrenches before turning the Tool on. A wrench that is left attached to the Tool may
result in personal injury.
• Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
• Be sure no one is below when using the tool in high locations.
• Do not over-reach. Keep proper footing and balance at all times. Proper footing and balance
enable better control of the tool in unexpected situations.
• Hold Tool by Insulated Gripping Surfaces when performing an operation.
• Do not leave the tool running. Operate the tool only when hand-held.
• Maintain Labels and Nameplates. These carry important information.
TOOL USE AND CARE:
• Use Clamps or other practical way to secure and support the work piece to a stable platform.
Holding the work by hand or against your body is unstable and may lead to loss of control.
• Do not force Tool. It will do the job better and safer at the rate for which it is designed.
• Do not use Tool if Switch does not turn it “On” or ”Off”. A Tool that cannot be controlled with
the switch is dangerous and must be repaired. Do not continue to hold down trigger if the
Grease Gun is stalled. This could damage the motor or cause Fire.


9
• Disconnect Battery Pack from Tool or before making any Adjustments, Changing
Accessories, or Storing the Tool. Such preventive Safety Measures reduce the risk of starting
the Tool accidentally.
• Store idle Tools out of reach of Children and other untrained persons. Tools are Dangerous
in the hands of untrained users.
• When Battery Pack is not in use, keep it away from other metal objects, like: Paper Clips,
Coins, Keys, Nails, Screws, or other small Metal Objects that can make a connection from one
terminal to another. Shorting the battery terminals together may cause Sparks, Burns, or a Fire.
• Maintain Tools with Care. Properly maintained tools are less likely to bind and are easier to control.
• Check for Misalignment or Binding of Moving Parts, Breakage of Parts, and any other
condition that may affect the Tool’s Operation. If Damaged, have the Tool Serviced
before using. Many accidents are caused by poorly maintained tools. Do not use a damaged
tool. Tag damaged tools “Do not use” until repaired.
• Use only accessories that are only recommended by Lumax for your model. Only accessories
that are capable of handling a minimum of 4,500 PSI (310 bar) should be used. Accessories that
may be suitable for one tool may create a risk of injury when used on another tool.
SPECIFIC SAFETY RULES
• Lumax Lubrication products are Precision Engineered Tools, which are capable of creating pressures
well above 10,000 PSI (690 BAR). Always use Safety Equipment. Always Wear Adequate Eye
Protection. Only Professional use assures Danger-free operation of these products. Warning:
Extreme Pressure may cause Nozzle Extension or Grease Hose to burst. Keep hands clear of
the Extension and Hose during operation of the Grease Gun. Be extra careful while working with
Needle point Grease Adapters and Dispensers. Keep your hands away from the Needle Point
at all times and when injecting Grease. Grease injection injuries are a very serious injury.
While working on the Grease Gun Barrel, make certain that the open, threaded barrel-end always
points away from yourself or others! Never point the Outlet at yourself or others.
• Only use Lumax Whip Hose Extensions or Adapters. Always follow Grease Hose Instructions
and Warnings. Do not abuse the Hose. Never use the Hose to carry the Tool. Keep the
Hose away from Heat, Sharp Edges, or Moving parts. Never touch a Hose that is under
Pressure. Hold the Hose only in the area of the Spring Guard. Hoses are subject to rapid aging.
Never use a Hose that is older than 2 years. Hoses must never be Bent or Twisted with force.
The smallest bending radius for hose is 4” (100 mm). Immediately replace the Hose at the first
sign of Wear, Kink, or damage to the outside Jacket.
• Never operate the Grease Gun in Explosive Atmosphere. Power Tools can create Sparks which
may Ignite Flammable Liquids, Dust, or Fumes. Do not touch the Coupler or the work piece
immediately after operation: they may be extremely hot and could burn your skin.
• Do not use Battery Charger in Damp or Wet Locations.
• Check your RoboLuber before each use to ensure that all Connections are Securely fastened.
High Working Pressures may result in grease being injected into flesh upon malfunction of
one of the Components. Only use Components that show no indications of Damage.
• Seek immediate medical care if an injury occurs.

10
OPERATION
Before using your RoboLuber for the first time, the Battery Pack should be charged for a minimum
of 6 hours. If the Battery Pack is installed in the RoboLuber, remove it by following instructions under
Installing or Removing Battery Pack. Important: New Battery Packs are shipped in semi-charged
state. Charge your Battery Pack for 6 hours before first use.
The Battery Pack accepts only about 80% of its Maximum Capacity with its first few charge cycles. Full
loading Capacity of the Battery Pack is only reached after 4 - 5 Charges. RoboLuber has a built-in
Trigger-Lock Lever which ensures the grease gun won’t operate accidently. The Trigger-Lock Lever has
to be “flipped-up” to operate the Gun. To start the RoboLuber, simply flip-up the Trigger-Lock Lever and
pull the trigger. Release the trigger to stop. If RoboLuber is operated continuously until the Battery Pack
has almost discharged, allow it to rest for 15 minutes before proceeding with a fresh Battery Pack. As a
Battery Pack approaches the discharged state, you will notice a sharp drop in tool performance. When
the tool is unable to perform the task at hand, it is time to recharge the Battery Pack.
Your RoboLuber has been properly lubricated and is ready for use.
• Always Prime RoboLuber before using it to Lubricate Grease Points.
• Always Prime the RoboLuber after each Refill or Grease Cartridge change.
Air pockets in the Cartridge will cause the Grease Gun to lose its prime.
• To prime, operate RoboLuber until grease flows from the hose. Use Air Release Valve to expel
any Air pockets.
• RoboLuber has a built-in pressure relief valve that is factory pre-set to relieve pressure above
7,000 PSI (483 Bar). Caution: If there is a Clogged or Tight Bearing, Clogged or damaged Grease
Fitting, or a Blocked Lubrication Line, the piston in your RoboLuber will work Feverishly (like a Jack
Hammer rather than of a normal, smooth piston action). It will also make unusual sound because
it exerts undue pressure on the motor. You should immediately stop the operation and remedy
the blockage before continuing lubrication with the RoboLuber.
• Do not continue to hold down trigger if the Grease Gun is stalled. This could Damage the
Mechanism and Motor or even cause a Fire. If you continue pressing the trigger, the excess
grease will flow back into the Barrel. However, this action is absolutely and strongly not
recommended as it would Damage the Tool.
CLEANING: To avoid accidents, always disconnect the tool and/or charger from the power supply
before cleaning. Clean dust and debris from charger and tool vents. Keep tool handles clean, dry and
free of oil or grease. RoboLuber may be cleaned most effectively with compressed dry air. Always wear
safety goggles when cleaning tools with compressed air. Ventilation openings and switch must
be kept clean and free of foreign matter. Do not attempt to clean by inserting pointed objects through
opening. Do Not use any Cleaning Agents or Solvents (gasoline, turpentine, lacquer thinner, paint
thinner, carbon tetrachloride, chlorinated cleaning solvents, ammonia and household detergents that
contain ammonia). These Cleaning Agents and Solvents are harmful to plastics and other insulated
parts and will damage RoboLuber. Never use flammable or combustible solvents around tools.
SERVICE / MAINTENANCE: NO USER SERVICEABLE PARTS INSIDE. Visually inspect for any
Damaged, Loose, or Missing Parts. If the Equipment is Worn or Damaged, remove from Service. Never
disassemble the Tool, Battery Pack or Charger. Contact Lumax for damage assessment or Repair.
To maintain product Safety and Reliability, Repairs, Maintenance or Adjustment should be performed by
Lumax only. Preventive Maintenance performed by Unauthorized Personnel may result in Misplacing
of internal Wires and Components which could cause Serious Hazard. Use of unauthorized parts
may create risk of Injury and will void the Warranty.
SERVICEMEN: Caution: Disconnect Tool and/or Charger from Power Source before Servicing.

11
SAFETY INSTRUCTIONS FOR CHARGER AND BATTERY PACKS
Charge only Lumax 20 Volt Battery Packs in Lumax Chargers.
Other types of Batteries may Explode causing Personal Injury and Damage
This manual contains important Safety and Operating Instructions for Lumax Model LX-2183 Battery
Charger.
• Before using a Battery Charger, read all instructions and cautionary markings on Battery Charger,
Battery Pack, and product using Battery. Caution: Never attempt to connect two Chargers together.
• CAUTION: To reduce the risk of injury, Lumax Model LX-2183 Charger should only be used to
charge Lumax Battery Pack Model LX-2182. Do not charge Lumax Model LX-2182 Battery Pack with
any other Charger.
• WARNING: If the Battery Pack is cracked or damaged, do not insert into Charger. Risk and
Danger of Electrical Shock or Electrocution.
• To reduce the risk of Personal Injury and Damage, never immerse your RoboLuber, Battery Pack
or Charger in Liquid or allow Liquid to flow inside them.
• Do not Expose Charger to Water, Rain, Snow, or Frost.
• Use of an attachment not recommended or sold by Lumax may result in a risk of Fire, Electric
Shock, or Injury to persons.
• Do not abuse Cord. Never carry Charger by Cord or yank it to disconnect from receptacle. Pull by
plug rather than cord when disconnecting Charger. Have “damaged” or “worn” Power Cord and
strain reliever replaced immediately. Do not attempt to repair Power Cord.
• Make sure Cord is located so that it will not be stepped on, tripped over, or otherwise subjected
to damage or stress.
Correct

Caution: To avoid any damage to the Air Release Valve and the
Battery Pack - when placing on a workbench or on the floor do
not let your RoboLuber sit it on its side.
Incorrect
High Performance Lithium-ion

WARNING!

12
• Do not use an extension cord unless absolutely necessary. Use of improper extension cord could
result in a risk of Fire and Electric Shock. If an extension cord must be used, make sure :
a. That Pins on Plug of extension cord are the same Number, Size, and Shape
b. That the extension cord is properly wired and in good Electrical Condition
c. Wire Size of Cord is at least as specified in following chart :
Length of Cord in ft. / (m) 25 (7.5) 50 (15) 100 (30) 150 (45)
AWG size of Cord / (mm)218 (1) 18 (1) 18 (1) 16 (1.5)
d. If an extension is to be used outdoors it must be marked with the suffix W-A following the
cord type designations. For example: SJTW-A to indicate it is acceptable for outdoor use.
• The Charger (LX-2183) is designed to operate on Standard Household electrical power. Do not
attempt to use it on any other Voltage. Do not attempt to use a step-up Transformer, an Engine
Generator or DC Power Receptacle (for LX-2183)
• Do not operate Charger with damaged Cord or Plug. Have them replaced immediately to avoid
a hazard. Pull the Plug out of the Socket immediately should Smoke or Fire emit from the
Charger. Do not attempt to repair Power Cord or the Charger.
• Do not operate Charger if it has received a Sharp Blow, been dropped, or otherwise Damaged in
any way. Take it to a Qualified serviceman.
• Do not disassemble Charger or Battery Pack. Take it to a Qualified serviceman when service or
repair is required. Incorrect re-assembly may result in risk of electrical shock or fire.
• Unplug Charger from Outlet before attempting any maintenance or cleaning to reduce risk of
Electric Shock. Electric Power of 120 Volts is present at charging Terminals and risk exists of Electric
Shock or Electrocution.
• Charge the Battery Pack in a well ventilated place. Do Not cover the Charger and Battery with
a Cloth, etc., while charging. Do not allow anything to cover or clog the Charger vents.
• Do not charge Battery Pack in Damp or Wet locations.
• Do not incinerate the Battery Pack even if it is severely damaged or is completely worn out.
The Battery Pack can explode in a Fire.
• Do not store the Charger or Battery Packs in locations (such as a Metal Tool Shed, or a Car in
the summer) where the temperature may reach or exceed 122°F (50°C). This could lead to
deterioration of the storage Battery.
• Do not charge Battery Pack when the temperature is below 32°F (0°C) or above 104°F (40°C).
This is very important for efficient operation.
• Do not charge any other Cordless Tool or Battery with Lumax Model LX-2183 Charger.
• Do not short across the terminals of the Battery Pack. Extremely high temperatures could
cause Personal Injury or Fire.
• Always cover the Battery Terminals with the Battery Cover when the Battery Pack is not used.
Do not touch the Terminals with any Conductive Material. Avoid storing Battery Pack in a container
with other metal objects such as nails, coins, etc. A Battery short can cause a large current flow,
overheating, possible burns and even a breakdown.
• Do not attempt to disassemble the Battery Pack or remove any component projecting from
the Battery Terminals. Fire or Injury may result. Never attempt to open Battery Pack for any reason.
If the housing of the Battery Pack cracks or breaks, return to appropriate centers for Recycling.
• The Lumax Battery Pack Model LX-2182 contains Rechargeable Li-ion Batteries. The only way
to dispose of expended Lumax Battery Pack is to recycle it. These batteries must be
collected, recycled or disposed of in an environmentally sound manner. Under various State
and Local Laws, it may be illegal to dispose of this Battery into the municipal waste stream.
Dispose of your Battery Pack according to Federal, State and Local Regulations.

13
BATTERY CHARGING
CHARGING BATTERY PACK (LX-2182) WITH 1 HOUR CHARGER (LX-2183)
CHARGING: Make sure the Input Power Circuit Voltage is the same as that shown on the Charger
Specification Plate. Connect Charger to Power Source Outlet.
CAUTION: Vent slots in bottom of Battery Pack must not be obstructed. Do not charge Battery Pack
when temperature is below 32°F (0°C) or above 104°F (40°C). Recharging the Battery Pack before this
condition is reached will reduce the total work life of the Battery Pack. Discharging the Battery Pack
beyond this point could damage the Battery Pack. Never completely discharge the Battery Pack.
NOTE: Charger is a fast recharge type charger. Insert the small plug on the end of the charger lead
into the plug hole on back of the battery. A red light on the Charger indicates the battery is charging.
When the battery is fully charged the red light turns green. The battery can be charged attached to or
removed from the grease gun. To remove battery from the grease gun, press the red button on back
of battery and slide battery out of the rear of the gun. DO NOT force battery if fitting or removing from
gun. Replace battery into grease gun, by carefully aligning the battery to the cavity on the gun, slide
battery in, until the battery locks into place. The first few charges should be for a minimum of 6
hours before use.
Battery Packs are affected by temperature. Your Battery Pack will perform best and have longest life if it is
charged when the temperature is between 60° - 80°F (15° - 27°C). Note: Battery Pack temperature will
increase during and shortly after use. Battery Pack may not accept a full charge if it is charged immediately
after use. For best results allow the Battery Pack to cool to room temperature before charging. Do not
charge in temperatures below 32°F (0°C) or above 104°F (40°C). Under these conditions, capacity will
be reduced. A substantial drop in operating time per charge may mean that the Battery Pack is nearing
the end of its life and should be replaced.
The temperature of the Battery Pack should be less than 120°F (48°C), before the Charger would start
charging. Red light would glow indicating the Battery Pack is receiving a fast charge. However, should
the temperature of the Battery Pack be higher than 131°F (55°C), Green light would glow initially indicating
the temperature of Battery Pack is greater than 131°F (55°C) and the Charger will not begin the charge
until the Battery Pack cools down. Once the Battery Pack cools down, the Charger would automatically
commence fast charging. This would be indicated by the Red light. Under normal conditions the Battery
Pack will be fully charged by over 90% within an hour. Green light would glow indicating that the Battery
Pack is fully charged and you may remove the Battery Pack from the Charger.
IMPORTANT NOTE:When the Battery Pack is fully charged, disconnect the Charger from Power
Source (unless you’re charging another Battery Pack) and slip the Battery Pack back into the tool.
• Drop off expended Battery Packs at your local
replacement Battery retailer, or your Recycling Center.
For further information, call 1-800-8-BATTERY.

14
TIPS FOR MAINTAINING MAXIMUM BATTERY LIFE
Lumax Battery Packs will operate for hundreds of cycles when they are maintained and used according
to these instructions:
1. Charge the Battery Pack before being completely discharged (<10% of the charge is left).
2. Always stop tool operation and charge the Battery Pack when you notice less tool power.
Be alert for Battery Packs that are nearing their end of life. If you notice decreased tool
performance or significantly shorter running time between charges then it is time to replace the
Battery Pack. Failure to do so can cause the tool to operate improperly or damage the Charger.
3. Charge the Battery Pack with room temperature at 50°-104°F (10°-40°C).
4. Let a hot Battery Pack cool down before charging it.
5. A Battery Pack that is stored for three months without being used will discharge itself. Batteries
discharge at a rate of about 1% per day. Charge the Battery Pack every six months even if it is
unused, to maximize Battery life.
6. Long term Battery storage should be in the discharged state. Battery Pack last longer and
re-charge better when they are stored discharged. Remember to fully recharge Battery Pack
before using after prolonged storage.
7. Store your Battery Pack in a Cool, Dry place. Do not store it where the temperature may exceed
120°F (50°C) such as in a vehicle or metal building during the summer. High temperatures will
overheat the Battery Pack, reducing Battery life.
8. If it is stored for several months, the Battery Pack will gradually lose its charge. One to three
cycles of charging and discharging through normal use will restore the capacity of the Battery
Pack. During the life of the Battery Pack, the operating time between charges becomes shorter.
If the operating time becomes extremely short after a proper charge, the usable life of the Battery
Pack has been reached and it should be replaced.
WARNING! To reduce the risk of Personal Injury and Damage, never immerse your RoboLuber, Battery
Pack or Charger in Liquid or allow Liquid to flow inside them. To reduce the risk of Explosion, never Burn
a Battery Pack even if it is Damaged, Dead or completely Discharged.
CAUTION: The Battery Charger is for charging Lumax 20V Li-Ion Battery Pack. Never use it for other
purposes or for other manufacturer’s Batteries. When you charge a new Battery Pack or a Battery Pack
which has not been used for a long period of time, it may not accept a full charge. This is a normal condition
and does not indicate a problem. You can recharge the Battery Pack fully after discharging it completely
and recharging a couple of times. When you charge a Battery Pack from a just-operated tool or a Battery
Pack which has been left in a location exposed to direct sunlight or heat for a long time, let it cool off
to room temperature before charging for best results. Then re-insert it and try to charge it once more.
When you charge a new Battery Pack or a Battery Pack which has not been used for a long period,
sometimes the charging light will go out quickly. If this occurs, remove the Battery Pack and re-insert it.
If the charging light goes out within one minute even after repeating this procedure a couple of times,
the Battery Pack is “dead”. Replace it with a new one. If Battery Pack does not charge properly:
a. Check for Voltage at Outlet by plugging in some other electrical device.
b. Check to see if Outlet is connected to a light switch which turns power “off” when lights are
turned “off”.
c. Check Battery Pack terminals for dirt. Clean with cotton swab and alcohol, if necessary.
Double check to ensure that alcohol is completely evaporated before you insert the Battery
Pack into the Charger or RoboLuber.
d. If you still do not get proper charging, please call Lumax, for further assistance.
Note: Use of Chargers or Battery Packs not sold by Lumax will void the Warranty.

15
INSTALLING & REMOVING BATTERY PACK
TO INSTALL BATTERY PACK (LX-2182): Prior to inserting Battery Pack or operating the unit, always
check to see that the Trigger-Lock Lever is not in a “flipped-up” position.For optimum weight distribution
and balance; align Battery Pack with opening in the Grease Gun Motor Assembly Housing and insert
the Battery Pack from the back. Slide the Battery Pack into Grease Gun’s Motor Assembly Housing until
it locks in place.
TO REMOVE
BATTERY PACK
Always switch off the tool before removal of the Battery Pack (LX-2182).
Depress the Red Release Button on the Battery and Slide-out Battery Pack out of the Grease Gun.
CAUTION: To insert the Battery Pack, align the tongue on
the Motor Assembly Housing with the groove in the Battery
Pack and slide it into place. Always insert the Battery Pack
all the way until it locks in place with a little click. If not, it
may accidentally fall out of the tool, causing injury to you or
someone around you. Do not use force when inserting the
Battery Pack. If the Battery Pack does not slide in easily, it is
not being inserted correctly.

16
GREASE FILLING - OPERATING INSTRUCTIONS
The Grease Gun can use a Lubricant Cartridge or be filled with Grease from Bulk Container. Refer to
Grease Filling Instructions, below. Wipe Grease Fittings clean before Lubricating. Remove any old Grease
and/or Dirt that might get into the equipment to be Lubricated. Push Coupler onto Grease Fitting at a
slight angle (the Coupler attaches easier at a slight angle than when centered). Center Coupler on the
Grease Fitting. Operate the Trigger Switch to lubricate. After lubricating, turn the Coupler at a slight
angle to release the grip of Coupler jaws from the Grease Fitting.
A. HOW TO SUCTION LOAD YOUR GREASE GUN:
1. Unscrew the Head Assembly from the barrel of the Grease Gun.
2. Insert the open end of the barrel below the surface of the Grease
(See Figure 1).
3. Slowly pull the Plunger Rod (Follower-rod) while pushing the barrel
deeper into the Grease to prevent air pockets from being pulled into
the barrel.
4. When the rod is fully extended, lock the Plunger Rod into place with
posi-stop Plunger Lock.
5. Screw the Head Assembly onto the barrel. Tighten the Head
Assembly securely.
6. Unlock the Plunger Rod from the end cap, by releasing the
Plunger Lock. This would push the Plunger Rod into the barrel.
7. Purging the Air in Grease Chamber and Priming the Grease Gun:
Priming is the act of removing air and introducing Grease into the Grease Gun’s pumping mechanism.
When filling the Grease Gun, it is very important to prevent air pockets and to purge any air that may
be trapped in the barrel.
Caution: Air pockets in the lubricant will cause the Grease Gun to lose its prime. In most cases
the Grease Gun will prime while pressing the Air Bleeder Valve and simply pulling the Trigger Switch
several times in short bursts until trapped air is expelled. Should Grease fail to appear, the Head
Assembly must be bled. This could be done by unscrewing the Grease Gun Barrel by couple of
threads and, applying slight pressure to the “T” handle, pushing it towards the head assembly.
Pull the Trigger Switch several times in short bursts and the Grease should now start flowing. If the
Gun is now primed then tighten the Barrel. Some Heavier Greases may require this step of “Purging
Air” twice. Pull the Trigger Switch until Grease flows from the Coupler.
B. HOW TO LOAD YOUR GREASE GUN WITH A LUBRICANT CARTRIDGE:
1. Unscrew the Head Assembly from the barrel of the Grease Gun.
2. Pull back the Plunger Rod. When the rod is fully extended, lock the Plunger Rod into place
with posi-stop Plunger Lock.
3. Remove the plastic cap from the end of Grease Cartridge and, insert open end first, into the
barrel of Grease Gun (See Fig. 2)
4. Push the Grease Cartridge into the barrel until the rim of the pull-tab end contacts the rim of the
barrel (See Fig. 3). Then remove the pull-tab seal from the end of the Grease Cartridge (See Fig. 4).
5. Screw the head back onto the barrel. Tighten the Head Assembly securely.
6. Unlock the Plunger Rod from the end cap, by releasing the Plunger Lock. This would push the Plunger
Rod into the barrel.
Figure 1

17
7. Purging the Air in Grease Chamber and Priming the Grease Gun: Priming is the act of removing air
and introducing Grease into the Grease Gun’s pumping mechanism. When filling the Grease Gun,
it is very important to prevent air pockets and to purge any air that may be trapped in the barrel.
Caution: Air pockets in the lubricant will cause the Grease Gun to lose its prime. In most cases
the Grease Gun will prime while pressing the Air Bleeder Valve and simply pulling the Trigger Switch
several times in short bursts until trapped air is expelled. Should Grease fail to appear, the Head
Assembly must be bled.
This could be done by unscrewing the Grease Gun Barrel by couple of threads and, applying slight
pressure to the “T” handle, pushing it towards the head assembly. Pull the Trigger Switch several times
in short bursts and the Grease should now start flowing. If the Gun is now primed then tighten the
Barrel. Some Heavier Greases may require this step of “Purging Air” twice. Pull the Trigger Switch
until Grease flows from the Coupler.
Grease Cartridge
Plastic Cap
Barrel
Twist
Figure 2 Figure 3 Figure 4
Barrel
Pull-Tab Seal

18
Possible Cause
Grease Cartridge or Barrel
is empty
Loss of Prime or Air is trapped
in the Grease Gun head
Rubber Seal is not placed in its
correct position, is damaged
or is missing
Initial tightening of Barrel into
Head Assembly not sufficient
or the Rubber Seal inside the
Head Assembly is damaged
or missing
Initial tightening of Hose
Extension into Head Assembly
and/or Coupler not sufficient
Filler Nipple may be loose
Worn Bleeder Valve “O” Ring
Worn out or damaged Gears,
Piston and/or bore in Head
Assembly
Problem
Grease Gun will not
dispense Grease
Grease Cartridge will
not empty completely
Also, if you are not sure
whether the Cartridge
is completely empty
or not
Grease leakage visible
between Barrel and
Head Assembly
Grease leakage visible
at Hose Extension or
at Head Assembly
Solution
Replace the Grease Cartridge or refill the
Barrel
Expel the trapped air, while pressing the
Air Bleeder Valve, and pushing the Plunger
(Follower) Rod handle or simply by depressing
the Trigger Switch several times in short bursts
until trapped air is expelled. Should Grease
fail to appear, the Head Assembly must be
bled. This could be done by unscrewing
the Grease Gun Barrel by couple of threads
and, applying slight pressure to the Plunger
(Follower) Rod, pushing it towards the head
assembly. Pull the Trigger Switch several times
in short bursts and the Grease should now
start flowing. If the Gun is now primed then
tighten the Barrel. Some Heavier Greases
may require this step of “Purging Air” twice.
Pull the Trigger Switch until Grease flows from
the Coupler.
Ensure that the Rubber Seal is in its correct
position and Tighten Barrel into Head
Assembly securely. Replace Seal, if damaged
or is missing
Push the Follower Rod into the Barrel as far as
it will go to move the Grease forward
Measure the Rod Handle from the end cap
on the Barrel to the tip of the Rod Handle. If
the measurement is more than 1-3/4”, the
Cartridge is not empty.
Tighten Barrel into Head Assembly securely
or replace the Rubber Seal
Tighten Hose Extension into Head Assembly
and Coupler into the Extension
Tighten Filler Nipple into Head Assembly
securely
Replace “O” Ring or Air Bleeder Valve
Time to replace Gun
TROUBLESHOOTING CHART

19
Thank you for buying RoboLuber. We would appreciate your comments about the product. Your feedback
would help us to better the product and enhance its’ performance.
Please write to: Lumax, 3705 Centre Circle, Fort Mill, SC 29715, USA
or Fax to: 803-547-0800 www.Lumax.com
Possible Cause
Battery not inserted properly
Battery needs Charging
Blocked Lubrication Line or
Clogged Fitting
Ball or Check Valve Seat Area
may need Cleaning
Charger may not have Power
Battery may be dead
Problem
Motor does not run
Piston works Feverishly
rather than of a
Normal, Smooth Piston
Action or Motor makes
Unusual Sound
Battery Fails to take
Charge
Solution
Remove the Battery and re-insert
Charge Battery
Check Lines and Fitting. Clean or remove any
Obstructions
Remove Bolt from the front of the head and
inspect Ball or Check Valve Seat Area
Check Power Source
Replace Battery
TROUBLESHOOTING CHART

20
LIMITED WARRANTY POLICY ON NEW EQUIPMENT
PLEASE READ THE FOLLOWING CAREFULLY
Lumax warrants all lubrication equipment manufactured by Lumax to be free from defects in material and
workmanship on the date of sale by an authorized Lumax distributor to the original purchaser for use. Lumax
will during one (1) year, following the date of purchase, repair, or replace any part of the equipment determined
by Lumax to be defective. This warranty applies only when the equipment is installed, operated, and maintained
in accordance with Lumax written recommendations.
Lumax does not make any representation or warranty of any kind to the buyer that he or she is qualified
to make any repairs to the product or that he or she is qualified to replace any parts of the product. In fact,
Lumax expressly states that all repairs and parts replacements should be undertaken by certified and licensed
technicians and not by the buyer. The buyer assumes all risk and liability arising out of his or her repairs
to the original product or replacement parts thereto, or arising out of his or her installation of replacement
parts thereto. If equipment proves to be defective during this warranty period, it will be repaired or replaced
without charge, provided that factory examination indicates the equipment to be defective. This warranty does
not cover, and Lumax shall not be liable for general wear and tear, accident, overload, or any malfunction,
damage, or wear caused by faulty installation, misapplication, misuse, abuse, abrasion, corrosion, inadequate
or improper maintenance, negligence, accident, tampering, or substitution of non-Lumax component parts.
Nor shall Lumax be liable for the equipment repaired or altered by anyone not authorized by Lumax to repair
or alter the equipment.
Lumax will also not be liable for malfunction, damage, or wear caused by the incompatibility of Lumax
equipment with accessories, equipment or materials not supplied by Lumax. This warranty is extended to
the original retail purchaser only and is conditioned upon the prepaid return of the equipment claimed to
be defective to an authorized Lumax distributor for verification of the claimed defect. If the claimed defect is
verified, Lumax will repair or replace free of charge any defective parts. The equipment will be returned to the
original buyer, transportation prepaid. If inspection of the equipment does not disclose any defect in material
or workmanship, repairs will be made at a reasonable charge, which charges may include the cost of parts,
labor, and transportation.
This warranty is exclusive, and is in lieu of any other warranties, express or implied, including but not limited to
warranty of merchantability or warranty of fitness for a particular purpose. Lumax sole obligation and buyer’s
sole remedy for any breach of warranty shall be as set forth above. The buyer agrees that no other remedy
(including but not limited to, incidental or consequential damage for lost profits, lost sales, injury to person or
property, or any other incidental or consequential loss) shall be available. In no event shall Lumax be liable for
incidental or consequential damages.
The liability of Lumax on any claim for loss or damage arising out of the sale, resale, or use of lubrication
equipment, materials dispensing equipment, and other related equipment should in no event exceed the
purchase price. Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights, which vary from state to state. Any action for breach of warranty must be
brought within two (2) years from the date of sale.
Lumax makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular
purpose in connection with accessories, equipment, materials, or components sold but not manufactured by
Lumax (such as Electric Motors, Switches, Hoses, etc.) are subject reasonable assistance in making any claim
for breach of these warranties. In no event will Lumax be liable for indirect, incidental, special, or consequential
damages resulting from Lumax supplying equipment hereunder, or the furnishing, performance, or use of any
products or other goods sold hereto, whether due to a breach of contract, breach of warranty, the negligence
of Lumax or otherwise. Any implied warranties applicable to lubrication equipment, materials dispensing
equipment, and other related equipment manufactured by Lumax , including the warranties of merchantability
and fitness for a particular purpose, will last only for one (1) year from the date of purchase. Some states
do not allow limitations on how long an implied warranty last, so the above limitation may not apply to you.
© 2016 Lumax. All Rights Reserved.
Lumax and the Products described in it are Copyrighted by Lumax, with All Rights Reserved.
This Form may not be Copied in Whole or Part, without the Express Written Consent of Lumax .
