Lumens VC-A61P User manual

To download the latest version of Quick Start
Guide, multilingual user manual, software, or
driver, etc., please visit Lumens
https://www.MyLumens.com/support
VC-A61P / VC-A61PN
HD camera
(PTZ Video Camera)
User Manual - English
Version VCAW207f
NDI®is a registered trademark of Vizrt Group

English - 1
Table of Contents
Copyright Information..................................................................................... 2
Chapter 1 Safety Instructions ........................................................................ 3
Chapter 2 Package Contents ......................................................................... 4
Chapter 3 Function Introduction.................................................................... 5
3.1 I/O functions Introduction ....................................................................................5
3.2 Description of LED indicator................................................................................7
3.3 Tally Indicator Light Function Description..........................................................7
Chapter 4 Instruction for installation............................................................. 8
4.1 Preparation before installation.............................................................................8
4.2 Instruction for installation....................................................................................8
4.3 Connecting devices............................................................................................15
Chapter 5 Remote Control and Setting Menu............................................. 20
5.1 Functions of remote control ..............................................................................20
5.2 Setting Menu .......................................................................................................21
Chapter 6 Network Function Settings Description..................................... 29
6.1 Connecting Camera to Network.........................................................................29
6.2 Web Page Function Description.........................................................................32
Chapter 7 DIP Switch Setting....................................................................... 49
7.1 DIP SWITCH.........................................................................................................49
Chapter 8 Troubleshooting .......................................................................... 50
Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information........ 51

English - 2
Copyright Information
Copyrights © Lumens Digital Optics Inc. All rights reserved.
Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc.
Copying, reproducing or transmitting this file is not allowed if a license is not provided by
Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after
purchasing this product.
In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to
make changes to product specifications without prior notice. The information in this file is
subject to change without prior notice.
To fully explain or describe how this product should be used, this manual may refer to names
of other products or companies without any intention of infringement.
Disclaimer of warranties: Lumens Digital Optics Inc. is neither responsible for any possible
technological, editorial errors or omissions, nor responsible for any incidental or related
damages arising from providing this file, using, or operating this product.

English - 3
Chapter 1Safety Instructions
Always follow these safety instructions when using the product:
1 Operation
1.1 Please use the product in the recommended operating environment, away from water or source of heat.
1.2 Do not place the product in tilted position or unstable trolley, stand or table.
1.3 Please clean the dust on the power plug prior to usage. Do not insert the product’s power plug into a multiplug to
prevent sparks or a fire.
1.4 Do not block the slots and openings in the case of the product. They provide ventilation and prevent the product
from overheating.
1.5 Do not open or remove covers, otherwise it may expose you to dangerous voltages and other hazards. Refer all
servicing to licensed service personnel.
1.6 Unplug the product from the wall outlet and refer servicing to licensed service personnel when the following
situations happen:
If the power cords are damaged or frayed.
If liquid is spilled into the product or the product has been exposed to rain or water.
2 Installation
2.1 For security considerations, please make sure the standard hanging rack you bought is in line with UL or CE safety
approbations and installed by technician personnel approved by agents.
3 Storage
3.1 Do not place the product where the cord can be stepped on as this may result in fraying or damage to the lead or
the plug.
3.2 Unplug the product during thunderstorms or if it is not going to be used for an extended period.
3.3 Do not place the product or accessories on top of vibrating equipment or heated objects.
4 Cleaning
4.1 Disconnect all the cables prior to cleaning and wipe the surface with a dry cloth. Do not use alcohol or volatile
solvents for cleaning.
5 Batteries (for products or accessories with batteries)
5.1 When replacing batteries, please only use similar or the same type of batteries.
5.2 When disposing of batteries or products, please adhere to the relevant instructions in your country or region for
disposing of batteries or products.
Precautions
This symbol indicates that this
equipment may contain
dangerous voltage which could
cause electric shock. Do not
remove the cover (or back). No
user-serviceable parts inside.
Refer servicing to licensed service
personnel.
This symbol indicates that there
are important operating and
maintenance instructions in this
User Manual with this unit.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class Adigital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
Notice :
The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
IC Warning
This digital apparatus does not exceed the Class Alimits for radio noise emissions from digital apparatus as set out in the
interference-causing equipment standard entitled "DigitalApparatus," ICES-003 of Industry Canada.
Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe A
prescrites dans la norme sur le material brouilleur: "Appareils Numeriques," NMB-003 edictee par l'Industrie.
EN55032 CE Warning
Operation of this equipment in a residential environment could cause radio interference.
KC Warning
This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it,
and this equipment is to be used in the places except for home.

English - 4
Chapter 2Package Contents
VC-A61P / VC-A61PN
M3 Screws
Remote Control
Silver x8 / Black x2
Power Cord
Power Adapter
RS-422 Connector
Appearance may vary
depending on
country/region
Metal Plate A
Metal Plate B

English - 5
Chapter 3Function Introduction
3.1 I/O functions Introduction
3.1.1 Front View
NO.
Item
Function Descriptions
1.
Tally indicator light
Display the tally light status of the camera
2.
Camera lens
30x HD camera lens
3.
Power LED
indicator
Display the status of the camera
4.
Standby LED
indicator
Display the status of the camera

English - 6
3.1.2 Back View
NO.
Item
Function Descriptions
5.
RS-232 input
RS-232 input port, at most 7 cameras can be connected in a serial
connection
6.
RS-232 output
RS-232 output port, at most 7 cameras can be connected in a
serial connection
7.
Kensington lock
hole
Lock hole of safety lock
8.
IR SELECT
The remote control ID setting is only controlled after corresponding
to the Camera Select on the remote control
9.
DC 12 V power
Port
DC power supply connecting port
10.
Ethernet port
Network cable port supports routers or hubs of PoE+ (IEEE
802.3at) with power supply
11.
Audio input
Support Line In/Mic In
12.
OUTPUT Switch
Adjust the resolution setting. The default is 1080p/59.94
13.
RS-422 Port
RS-422 connecting port, at most 7 cameras can be connected in a
serial connection
14.
HDMI output
HDMI output (Audio output supported)
15.
3G-SDI output
3G-SDI output(Audio output supported)
*Support the audio output of 48 KHz only/resolutions up to 1080p
59.94/50
LOCK

English - 7
3.1.3 Bottom
NO.
Item
Function Descriptions
16.
Tripod lock hole
The camera is mounted on a (specification) 1/4” - 20 UNC
tripod
3.2 Description of LED indicator
Status
Power
Standby
Startup in progress
(initialization)
Green light
Orange light
In use
Green light
No indicator
In standby mode
No indicator
Orange light
3.3 Tally Indicator Light Function Description
The tally indicator light function can be enabled through RS-232 command. Please refer to
RS-232 command set document.

English - 8
Chapter 4Instruction for installation
4.1 Preparation before installation
Installation and connection of the HD camera requires special skills. To install by yourself,
please follow necessary steps, ensure steady and tight installation of the device, and pay
attention to your safety to avoid any accident.
4.1.1 Ensure the safety of the installation environment. Please do not install the device on
unstable ceiling or in a place where the device is in danger of falling to avoid any accident.
4.1.2 Please check whether accessories in the box are complete or not. Please contact the
supplier for any shortage, and make sure to keep the accessories in the box intact.
4.1.3 Please choose a proper place for installation of camera in advance. Please determine
an installation place according to the following requirements
4.1.1.1 Confirm the position for the object to be captured.
4.1.1.2 Confirm whether the camera is set at a proper distance from other light sources.
4.2 Instruction for installation
4.2.1 I would like to install camera on the desk
4.2.1.1 Precautions for installation
Please install the machine on a flat desk
Do not grab the camera head by hand when handling the device
Do not rotate the camera head by hand, improper rotation may result in breakdown
of the camera
4.2.1.2 Installation steps
1. Please adjust DIP switch at first prior to installation
<Remark> Please refer to Chapter 7 DIP Switch Setting for the relevant
descriptions on DIP switch.
2. Place the camera on a flat desk directly to ensure the normal vertical and
horizontal operation of the machine
4.2.2 I would like to install the camera on the ceiling
4.2.2.1 Prepare for the parts and equipment required during the installation

English - 9
1. Accessories in the box (metal plates A, B, M3 screw silver x 8, black x 2)
2. Screw for locking on ceiling mounted hanger x 4
3. Drilling machine, screw driver, ladder
4.2.2.2 Camera Size
L x W x H : 174 x 187 x 190 mm
Weight: 2.0 Kg
4.2.2.3 Max. rotation dimension of camera

English - 10
4.2.2.4 Size Diagram
1. Bottom of machine
The camera can be mounted on a 1/4”, -20 UNC PTZ tripod deck by using the lock
holes on the bottom for the tripod
2. Metal Plate size diagram
Metal plate A - machine side
Metal plate A locking screw

English - 11
Metal plate A - machine side

English - 12
Metal plate B - ceiling side
Metal plate B - ceiling side
M3 threaded hole
M3 threaded hole
M3 threaded hole
Metal plate B locking screw
Metal plate B locking bolt

English - 13
4.2.2.5 Precautions for installation
1. Before installation, please confirm the orientation of the machine relative to the
object to be captured
2. It is recommended that the machine should be set at a distance of more than 1.5
meter away from the object to be captured. Please adjust for a best distance
according to the magnification of the lens
3. The machine (including metal plates) is weighed at about 2.5 kg. If it is to be
installed on the ceiling, please use the hanger that has obtained UL security
approval to prevent the machine from falling down.
4. Please check whether the camera is installed securely on a regular basis
4.2.2.6 Installation steps
1. Please adjust resolution on DIP switch at first
<Remark> Please refer to Chapter 7 DIP Switch Setting for the relevant
descriptions on DIP switch
2. Fix the metal plate A on the machine base with 4 M3 silver screws
3. Lock the metal plate B on ceiling mounted hanger
<Remark>Caution: (1) Please use the hanger that has obtained UL security
approval
(2) Please reserve the hole for the connecting wires of the
camera
1.5 meter ↑
Projector
Computer

English - 14
4. Combine the metal plate A and the metal plate B
(1) Push the metal plate A up to the ceiling and then to the right to latch the metal
plate B
(2) And then secure with 2 M3 silver screws and 1 M3 black screw
4.2.2.7 How to remove
1. Remove the connecting wires from the camera
2. Uninstall the camera together with the ceiling, loosen the three screws that fix the
metal plates A and B and push to the left to remove the machine
3. Then remove the screws on the hanger and the machine
black
screw

English - 15
4.3 Connecting devices
4.3.1 Connecting to PC (video conference)
<Remark> SDI supports the audio output of 48 KHz / resolutions up to 1080p 59.94/50
4.3.2 Connecting to an HDTV/computer monitor (HDMI)
HDMI Cable
Or
SDI Cable
MTU
HDMI cable
LOCK
LOCK

English - 16
4.3.3 Connecting to Internet
For details of web page connection setting and description, please refer to Chapter 6
Network Function Settings Description
4.3.4 Connecting AUDIO IN
Set the [Audio In] in the OSD to reflect the input device
Network cable
Router
or Hub
Audio Cable
MIC or audio mixer
LOCK
LOCK

English - 17
4.3.5 Connecting RS-232
With RS-232 in/out, at most 7 Lumens cameras can be connected.
RS-232 pins definition instructions

English - 18
4.3.6 Connecting RS-422
With RS-422, at most 7 Lumens cameras can be connected.
<Caution> When RS-422 connection is being used, do not use RS-232
connection.
RS-422 pins definition instructions

English - 19
RS-422 connection instructions
1.Hold the two sides of RS-422 connector and pull out in the direction shown by the arrow
in the figure below
2.Peel off a section of copper wire (AWG Nos. 28 to 18) and insert it into the connector
hole; then use flat screw driver to fix it
3.Insert the wired RS-422 connector back to the Camera. Now the connection is
completed
