Lumin Lights Power Par Q610 DMX User manual

1
Power Par Q610 DMX
User Manual
www.LuminLights.com
[email protected]
877-842-8338

2
Congratulations on the purchase of your Lumin Lights product. With proper
care and a good working knowledge of the unit and all its controls, it will serve
you well for years to come.
Your Lumin Lights product carries a 2 year Warranty on all parts and labor
(except batteries which carries a 1 year warranty). Every unit we ship is tested
and leaves our warehouse in perfect working order. If a unit ever malfunctions
or is damaged during shipping, contact us immediately and one of our helpful
staff will assist you in repairing or replacing the unit.
Please save all original boxes and packaging in case you ever need to ship a unit
back to us for repair or replacement. Any units shipped back without the
original packaging, parts or accessories are subject to a 20% restocking fee.
If you ever need help with your product and this manual is not clear or does not
answer a specific question, you can always go to our website for demo and
instructional videos on each product. If the manual and the videos still don’t
resolve your questions, then please email or call our staff and we will personally
assist you.
1-888-266-6898
[e-mail]
www.LuminLights.com
Lumin Lights Inc. Limited Warranty
Lumin Lights Inc. warranties its products against manufacturer’s defects
and component failure for a period of 2 years on all products and com-
ponants (except batteries which carry a 1 year warranty) to the original
purchaser. Warranty is not transferrable to a second owner.
If a warranty claim is filed, customer must present proof of purchase and all
original packaging.
Lumin Lights will inspect all warrantee claims and inspect each unit that is
returned. If there is evidence of tampering, modifications or obvious abuse,
the product will not be covered by this warranty.
Lumin Lights will repair or replace at its discretion all warrantied units.

3
CAUTION!
This device has left our premises in perfect condition. In order to maintain this condition
and to ensure safe and reliable operation, it is necessary for the user to follow the safety
instructions and warning notes written in this manual.
Never use this device in a wet area or expose to water. Doing so may result in damage
to the unit or physical injury to the operator.
If power linking, do not connect more than 4 fixtures together as this will result in
blowing the fuse in the first light. More than 5 units can be powered off the same voltage
line with the use of an outlet strip by running the power cord from several units to the
power strip and then connecting no more than 4 additional units in series using the
power in, power outs of the lights. If a fuse should blow, replace it with the same exact
type. The Fuse is located in the power plug socket. Use a flat edge standard
screwdriver to gently lift the plastic tab with the picture of a fuse on it.
Do not open the lights or in any way alter the light or wires as this will void your
warrantee. If there is ever a problem with your unit, contact Lumin Lights and one of our
friendly staff will assist you with repairs or replacements.
.
IMPORTANT!
Do not throw out, destroy, rip, mark up, write on, cut or modify the box and
packing materials. If you ever need to ship your unit back for repairs or
replacement, the unit must be shipped back in the original box with all packing
material and accessories. Failure to do so can result in damage to the unit during
shipping and will void your warrantee. Any units being returned without all
original packaging and accessories or whose packaging and accessories have been
damaged, lost, modified or in any other way not in original sellable condition will
be subject to a 20% restocking fee. SAVE YOUR BOXES OR AT LEAST A FEW OF THEM FOR
REPAIRS AND RETURNS.

4
Package Contents:
1 Power Par Q610
1 plastic bag for Power Par Q610
1 Double Yoke Hanging bracket
2 Bracket Knobs
2 black rubber bracket knob washers
1 small zip lock bag for Knobs and rubber washers
1 dmx antenna
1 small zip lock bag for DMX antenna
1 Edison to IEC power cable
2 square pieces of Styrofoam inside box
1 product manual
Features:
Voltage: AC110-240V 50/60Hz
Power: 100W
Light source: 6*10W LEDS(6*10W RGBA/W)(4 in 1)
4 operation modes: Stand Alone, DMX, Sound Active, Master/Slave
Sound controlled via built-in microphone
4 / 7 DMX channels selectable
Advantages of LED-technology: extremely long life, low power consumption minimal heat emission
Packing Size: 35x18x23cm
Unit Dimensions: 8.25 X 8.25 X 4.75
Weight: 6.5 lbs (3.8 kgs)
Expected battery life with all colors on at full intensity: 4 hours
Expected battery life range for 1 to 4 colors at varying intensities: 4 to 22 hours
Back Panel:

5
Top Panel:
Charging The Battery:
With the power switch turned off, use the supplied Edison to IEC power cable and plug your
fixture into an electrical wall outlet. The recharge indicator LED will light up blue if the bsttery
is not charged to 100%. The batteries take about 4 hours to get to a full charge and at that
point the recharge indicator LED will turn green to let you know the light is fully charged. The
Power In
Power Out
DMX IN
DMX OUT
4 Button
LCD Display
Recharge
Indicator
LED
Wireless
DMX
Antenna
Power
ON/OFF
Switch
Frequency/DMX
Universe Switch
DMX Wireless
Indicator LED
Wireless DMX ON/OFF Switch
Battery
Compartment
Door

6
supplied battery should be good for about 500 charges but as time goes on, the batteries will
hold less and less of a charge until they will need to be replaced, just like a car battery or cell
phone battery.
To replace the battery:
1. Remove the 4 screws from the battery compartment door and remove the door which
will have the battery attached to it.
2. Remove the 2 screws that are in the middle of the battery compartment door on each
side to remove the hold down bracket.
3. Next unclip the battery wire connector and connect the new battery.
4. Replace the battery hold down bracket by using 2 screws and then place the battery
back into the fixture.
5. Finally, replace the 4 screws on the battery compartment door.
Note: These units use a Lithium Ion battery and to avoid having the batteries explode
from over charging, the unit employs trickle technology. The unit will charge the battery
up to 100% and then drain it down to 90% and then charge it back up to 100%. It will keep
repeating this cycle as long as the unit is plugged in and charging.
LCD display:
Display
Function
ADDR (DMX Address)
A001-A512
CHND (DMX Channel Mode)
4/7 CH
SLND(Master and Slave)
NAST(Master)
SLAU（Slave）
SHND (Built-In Stand Alone
Preograms)
SOUN: sound Active Mode
COLO: color(COL1…COL7、AUTO)
FADE: color fade(speed: SP01-SP08)
MANU (manual color adjusted)
RED(0-255)
GREE(0-255)
BLUE(0-255)
UHIT(0-255)
TEST
R、G、B、W/A、RGBW/A color Auto-
check
FHRS
Work times
Operation:
To turn the unit on, flip the ON/OFF switch located on the back of the unit to the ON position.
Use the 4 button LCD display to navigate through the various menus listed above. With each
press of the MENU button, the display will advance to the next menu item. Once you get to

7
the menu item you want, press the ENTER button to enter the value screen for that menu
item. Then use the UP/DOWN buttons to change the value until you get to the setting you
want. Then press the ENTER button once and the display will revert back to the previous
screen. Immediately hit the ENTER button again and the display will go back to the value you
just set. Wait 15 seconds for the light to store and save the setting. Once the light has saved
the setting, it will revert to the mode it was previously in. (Alternately, you can simply power
off and power on the light after the second press of the ENTER button to save the setting and
return the light to its previous mode).
Stand Alone mode will utilize the SHND menu. There you can set the light into Sound Active
Mode, Color Mode or Fade Mode.
1. Sound Mode:
A. Press the MENI Button repeatedly until the display shows SHND.
B. Press ENTER and the display will show SOUN (Sound Active Mode).
C. Press ENTER once and the display will go back to SHND, immediately press
ENTER again and the display will go back to sound. You unit is now in Sound
Active mode and the color of the LEDS will change as the built in Mic picks up
any outside sound.
2. Color Mode:
A. Press the MENI Button repeatedly until the display shows SHND.
B. Press ENTER and the display will show SOUN (Sound Active Mode).
C. Press the UP/DOWN buttons until the display reads COLO, then press ENTER.
D. The display will change to COL1 (color 1) which will be Red. With each press of
the UP button, the display will advance to the next preprogrammed color (COL
2, COL3, COL4, etc.)
E. Once you find the color you want, press ENTER once and immediately press
ENTER a second time to set and store the color (Alternately, you can simply
power off and power on the light after the second press of the ENTER button to
save the setting and return the light to the saved color).
F. While using the UP button to scroll through the preprogrammed colors, you
will see that after the last preprogrammed color that the display will change to
AUTO. AUTO is a preprogrammed show where the LEDS will “jump” from one
color to the next continuously. To save this setting and run the light in AUTO
MODE, repeat the procedure in section E above.
3. Fade Mode:
A. Press the MENI Button repeatedly until the display shows SHND.
B. Press ENTER and the display will show SOUN (Sound Active Mode).
C. Press the UP/DOWN buttons until the display reads FADE, then press ENTER.
D. The display will change to SP1 (Speed 1). Use the UP/DOWN buttons to change
the speed or rate of the Fades. The higher the #, the faster the color fades.
E. Once the Fade speed is to your liking, repeat the procedure in Section E above.
Manual Color Adjustment (MANU):
If you are using the light in stand-alone mode and none of the preset colors are the
exact shade you need, you can manually adjust the brightness of each individual color in
order to achieve the particular shade you want. For example, if the built in Pink color is too
light and you want it to be a little darker and more towards a lavender or purple , then you can
go into the MANU menu and turn the brightness of the Red LEDs down so that the blue
shows up more which would help to get a lavender or purple color.

8
To adjust the color manually:
A. Press the MENI Button repeatedly until the display shows SHND.
B. Press ENTER and the display will show SOUN (Sound Active Mode).
C. Press the UP/DOWN buttons until the displays reads MANU and then press
ENTER.
D. The display will read R255. R stands for Red and 255 is the brightness setting.
The brightness scale goes from 0 (LEDs of that color are off) to 255 (LEDs of
that color are at full brightness or Intensity).
E. To select a different color, press the UP/DOWN buttons until you get to the
color you want. Then press ENTER and the display will start flashing (Example:
B255). Use the UP/DOWN buttons to change the value and then press enter
once (Display changes to B255 and is solid (not blinking), Immediately press
ENTER again and the display will read B255 and be flashing (some software
version will not flash), then wait 15 seconds for the light to store the setting, or
simply power off and on the light and the setting will be stored.
4. Test Mode:
Test Mode (TEST) will test to see if all the LED colors are working by cycling
through them). To get to TEST mode:
A. Press the MENU Button repeatedly until the display shows TEST.
B. Press ENTER and the test will begin. The light will cycle: Red, Green, Blue,
White/Amber, mixed colors etc., continuously until the MENU button is pressed
again or the light is powered off and on again.
5. FHRS:
FHRS is the number of hours that the light has on it. At the factory the lights
are tested anywhere from 3 hours to 24 hours, so seeing multiple hours on a new light is
normal and does not mean the light is used. It simply means the light has been tested for
several hours to test it as part of our quality control measures.
6. Master/Slave Mode:
MASTER/SLAVE mode allows the light to either set as a Master to control other
lights, or a Slave which will follow directions from a Master light. To set the light into Master
or Slave mode:
A. Press the MENU button repeatedly until SLND shows on the display, then press
ENTER.
B. Use the UP/DOWN buttons to change the display to either MAST or SLAV and
then press ENTER once and immediately a second time to save the setting.
Wait 15 seconds for the setting to save or simply power off and on the un it.
7. DMX Mode (ADDR):
DMX Mode will allow you to control the light remotely with either a DMX Hardware
control board or Software Controller. To set the DMX starting address of the
fixture:
A. Press the MENU button repeatedly until ADDR shows on the display and then
press ENTER.
B. The display will change and show 001. Use the UP/DOWN buttons to change
the DMX starting address to the DMX address that your controller needs in
order to control the light.
C. Once the address is set, press ENTER once and immediately press it again to

9
store the DMX starting address and wait 15 seconds for the setting to save or
simply power off and on the unit.
8. DMX Channel Mode:
The DMX channel mode means how many channels will the light operate in and
what particular functions of the light will be controlled on each channel. This unit
has either a 4 channel mode or a 7 channel mode. (Refer to the DMX chart for
channel assignments in each mode). To set the DMX Channel Mode:
A. Press the MENU button repeatedly until CHND shows on the display, then
press ENTER.
B. Uses the UP/DOWN buttons to change the display to either 4CH or 7CH and
press ENTER once and then immediately press ENTER again to save the
setting. Wait 15 seconds for the setting to save or simply power off and on the
unit.
USING THE BUILT-IN WIRELESS DMX FEATURE:
This unit comes equipped with a built in wireless DMX transmitter/Receiver operating on the
2.4 GHz frequency band. To activate the wires DMX, simply turn on the switch at the top of
the unit and the LED which is right next to the switch will light up and either flash Red (if the
light is set in MASTER mode), flash Green (if the unit is in Slave mode and receiving a DMX
signal) or stay lit a steady color (if it is in Slave mode but is not receiving a DMX signal).
There is a small black button on top near the DMX on/off switch and DMX LED indicator.
Pressing that button will change the frequency and thus the DMX universe that the unit can
send or receive on. There are 7 different Frequencies/Universes that the unit can operate on
and each on is defined by a different color on the LED indicator.
NOTE: If you are controlling 2 units wirelessly in Master/Slave mode, both units must be on
the same color/Frequency/Universe in order to be able to communicate with each other. The
same holds true if you are using one of our wireless DMX stick or box transmitters from your
lighting board or computer to send DMX signals to these units.
DMX Channel Assignment Charts:
4 Channel:
Channel
Channel values
Color
1
0-255
Red
2
0-255
Green
3
0-255
Blue
4
0-255
White/Amber
7 Channel:
Channel
Channel
values
Function
1
0-------15
Closed
16-------255
Brightness is from dark to bright

10
2
1-------255
Red color dimmer
3
0-------255
Green color dimmer
4
1-------255
Blue color dimmer
5
1-------255
White/Amber color dimmer
6
0------15
Closed
16------255
Strobe is from slow to fast
7
0------15
Closed
16------255
Mixed color auto(speed is from slow to fast)
