Luminex Ethernet - DMX8 / WiFi User manual

Ethernet - DMX8 / WiFi
User Guide V3.x.x

Ethernet - DMX8 / WiFi User Guide V3.x.x
Document eth-dmx8-w_man_ 3_lumwifi
Copyright © 2003-2009 .
All rights reser ed.
No part of this documentation may be reproduced or transmitted in any form or by any means, electronic
or mechanical, including photocopying and recording, without the prior written permission of Luminex.
The information in this documentation is supplied without warranty of any kind, either directly or
indirectly, and is subject to change without prior written notice. Luminex, its employees or appointed
representati es will not be held responsible for any damages to software, hardware, or data, howsoe er
arising as a direct or indirect result of the product(s) mentioned herein.
Issued by:
Publications Department,
Luminex LCE,
Herent 42,
Neerpelt,
B-3910,
Belgium.
Documentation re iewed by Bart Swinnen.
Printed in the EU.

Table of Contents
Warranty information........................................................................5
Limited warranty..........................................................................5
Returning under warranty..............................................................5
Freight........................................................................................ 5
General.......................................................................................... 6
Packaging....................................................................................6
Description.................................................................................. 6
Specification................................................................................ 6
Dimensions...............................................................................6
Weight..................................................................................... 6
Electrical.................................................................................. 6
Connectors............................................................................... 6
En ironmental...........................................................................7
Connecti ity.................................................................................... 8
Rear panel................................................................................... 8
Mains.......................................................................................8
DMX input / output.................................................................... 8
Interface........................................................................................ 9
Front panel.................................................................................. 9
Unlock the node......................................................................10
Reset the node (Out of jail)....................................................... 10
Network configuration..............................................................11
IP setting ...........................................................................11
UDP ports setting.................................................................12
DMX configuration....................................................................13
Outlet route......................................................................... 14
DMX output...................................................................... 14
DMX input........................................................................ 16
Merged DMX input............................................................. 18
Frame rate setting................................................................ 19
Break time setting................................................................ 19
Mark After Break (MAB) time setting.......................................19
DMX output time setting........................................................ 20
Global settings........................................................................21
Recall profile........................................................................ 22
Store profile.........................................................................23
Firmware ersion .................................................................23
Status indication......................................................................24
Web interface................................................................................ 25
Home........................................................................................ 25
Setup........................................................................................ 26
Node 1 & 2............................................................................. 26
DMX Routing........................................................................... 27
Merging Policies :.....................................................................28
Inputs (Local mode)..............................................................28
Inputs (IP Merging)...............................................................31

Outputs (IP Merging)............................................................31
Reco er channel................................................................... 33
Patch files :.........................................................................35
Network settings..................................................................36
IP Settings..........................................................................36
Global.................................................................................... 37
DMX details......................................................................... 37
Miscellaneous.......................................................................38
Toolbox......................................................................................39
Profile manager....................................................................... 39
Firmware upgrade....................................................................40
Wireless........................................................................................41
Wireless basics........................................................................... 41
Installation considerations.........................................................41
Set the Ethernet DMX8/W Wireless de ice.....................................43
Web Browser:.........................................................................43
Network................................................................................. 45
Wireless settings.....................................................................46
Site Sur ey.............................................................................48
Ad anced :............................................................................. 49
Firmware upgrade:...................................................................49
Status page............................................................................ 50
Reseting the Ethernet DMX8/W wireless de ice............................51
Application examples................................................................... 51
Point to point..........................................................................51
Point to multi-point.................................................................. 52
Repeater................................................................................53
Tools :.......................................................................................55
Checking your computer IP address:..............................................55
Checking the connection .......................................................... 55
Specifications (Wireless De ice):................................................56
Additional Documentation................................................................57
Page 4 of 54 Ethernet - DMX8 / WiFi

Warranty information
Limited warranty
Unless otherwise stated, your product is co ered by a one (1) year parts
and labor limited warranty. It is the owner’s responsibility to furnish
receipts or in oices for erification of purchase, date, and dealer or
distributor. If purchase date cannot be pro ided, date of manufacture will
be used to determine warranty period.
Returning under warranty
Any Product unit or parts returned to Luminex LCE must be packaged in a
suitable manner to ensure the protection of such Product unit or parts,
and such package shall be clearly and prominently marked to indicate that
the package contains returned Product units or parts. Accompany all
returned Product units or parts with a written explanation of the alleged
problem or malfunction.
Freight
All shipping will be paid by the purchaser. Items under warranty shall ha e
return shipping paid by the manufacturer only in the European Union.
Under no circumstances will freight collect shipments be accepted. Prepaid
shipping does not include rush expediting such as air freight. Air freight
can be sent customer collect in the European Union.
Warranty is oid if the product is misused, damaged, modified in any way,
or for unauthorized repairs or parts.
Ethernet - DMX8 / WiFi Page 5 of 54

General
Packaging
•1 x Ethernet – DMX8 / WiFi
•1 x 2dBi antenna
•1 x User guide + CD Rom
Description
The Ethernet - DMX8 / WiFi is an Ethernet node that ser es 8 DMX512
outlets, compatible with the ArtNet protocol.
All 8 outlets are conform to the DMX-512A and can be used as input or
output. The Ethernet link is a 10/100BaseT (auto detect) connection on a
Neutrik RJ45 Ethercon connector. All configuration can be done o er
Ethernet through a built in website, or by using the controls on the front
end. A bright blue LCD with white text and 5 na igation keys are pro ided
to control the unit. This all comes in a 19" 1 unit high metal housing.
Specification
Model: Ethernet - DMX8 / WiFi
Manufacturer: LUMINEX Lighting Control Equipment
•Dimensions
482 x 183 x 44 (mm)
19” x 7,2” x 1,75”
Package: 520 x 235 x 50 (mm)
•Weight
2,5 kg
•Electrical
Voltages: 90 – 260 VAC
Frequency: 47 – 63 Hz
Rated power: 20 W
Fuses: 125V, 500mA, Slow blow only (5mm x 20mm)
250V, 315mA, Slow blow only (5mm x 20mm)
•Connectors
1 x Neutrik RJ45 Ethercon connector
8 x Neutrik gold plated 5 pin XLR (female)
1 X RP-SMA antenna connector
•Environmental
Operating temperature: 0 ~ 60°C (32 ~ 140°F)
Page 6 of 54 Ethernet - DMX8 / WiFi

Connectivity
Rear panel
•Mains
The de ice operates with an AC oltage between 90V and 260V within a
frequency range of 47Hz and 63Hz.
A fixed power lead with lose cable end is directly connected to the de ice
(no plug/connector). Please use an authorized plug and connect the cores
in the mains lead in accordance with the following scheme:
Green / Yellow: Earth
Blue: Neutral
Brown: Li e
!!! This equipment must be earthed !!!
•DMX input / output
8 Neutrik 5 pin gold plated female connectors are pro ided as outlet (input
or output).
Connector Function
Pin 1 Signal common (0 olt)
Pin 2 Data complement (-)
Pin 3 Data true (+)
Pin 4 Not used
Pin 5 Not used
All outlets are compliant with the DMX512-A timing specification and are
terminated and rebiased.
Ethernet - DMX8 / WiFi Page 7 of 54

Interface
Front panel
The front panel interface is pro ided with 5 na igation buttons and a
bright blue 2 lines, 16 character LCD.
All settings and setup explained in this chapter can also be made by using
the built in web pages. See Web interface chapter at page 24.
Four indication screens will rotate continuously on the display with an
inter al of a few seconds. The unit also returns to these root screens when
no button is pressed for 2 minutes.
You can isualize the screen of your choice by simply pressing the right
arrow button (>>).
Another indication screens sequence is also a ailable by pressing up arrow
button or “+”. This sequence displays all outlets legend and mode. This
can be ery useful for a technician who just need to know what is
connected to a dedicated outlet. This sequence is a ailable e en if the
node is password protected through Web interface.
Page 8 of 54 Ethernet - DMX8 / WiFi
>> > > > > >>
<< << <<
+ + + +
-
.: Eth-DMX8 :.
ID: 001 >
1:Node 1
2.0.0.2 >
2:Node 2
2.0.0.3 >
Eth 12345678
L ........ >
<<: to na igate left in the menu hierarchy
>>: to na igate right in the menu hierarchy
<<>>: to na igate between character fields
Enter: to mo e down in the menu hierarchy
or to confirm an edit field
Up/Down: to get out of root screen and enter main menu
-: To change alues of edit fields
Up: to na igate up in the menu hierarchy
+: To change alues of edit fields
+: To isualize outlet legend and mode sequence
LED indication of network
link for rear ports A – Wireless
de ice WLAN LED.
Built in Switch
Power LED

To get in the configuration menus and to setup the de ice, press the arrow
down or “-” button.
An arrow left or right (<>) in the screen indicates the possibility to
na igate with the left right buttons of the front end.
●Unloc the node
When the node is set in auto-lock mode or is password protected through
the Web interface, it will automatically lock the front end after 2 min of
inacti ity of front end controls. If you try to change something with front
end, the following message “DEVICE LOCKED” will blink.
To unlock the node with no password :
–Hold down up and down arrow button for 2 seconds
–A “HOLD TO UNLOCK” message appears
–“DEVICE UNLOCKED” : the node is unlocked
To unlock the node set with a password :
–Hold down up and down arrow button for 2 seconds
–Password has to be set with left and right buttons, change alue with
up and down buttons.
–Press enter to confirm the password=> the node is unlocked
•Reset the node (Out of jail)
This useful function makes it possible to bring the node in a factory
default.
1. Power down the unit.
2. Hold down up, down, left and right buttons all together
3. Power on the node.
4. Wait until “Reboot default” message is displayed
5. Release buttons, then press enter to confirm
6. “FACTORY RESTART !! WAIT !!” is displayed
7. The node is now in a factory default: IP: 2.0.0.2 / 2.0.0.3
Ethernet - DMX8 / WiFi Page 9 of 54
>> >> > > > >
<< < < < <
+
-
< 1: IN MRG >
Out et 1
< 2: IN M CST >
Out et 2
< 8: OUT >
Out et 8

●Networ configuration
IP setting
The de ice uses ArtNet as protocol to distribute multiple DMX lines o er
Ethernet. Because of the ArtNet specification, the number of outlets is
limited to 4 (4 inputs and / or 4 outputs) per node. The Ethernet – DMX8 /
WiFi howe er has 8 outlets. That is why the de ice uses 2 IP addresses.
There are irtually 2 ArtNet nodes running on this one de ice. This allows
us to ser e 8 outlets, 4 for e ery node. Because an ArtNet node is known
by it's IP address on a network, we ha e to pro ide 2 unique IP addresses
(IP 1 and IP 2). Howe er, this pro ides you to the opportunity to run 2
separate networks on the same de ice.
From Configuration network press Enter to get into Network Config,
Set IP 1. Here you can use the left, right keys to choose to configure IP
1, IP 2 or UDP port. Choose Set IP 1 and press Enter. The IP edit screen
appears with the first digit blinking. The following procedure is similar for
IP 2.
Page 10 of 54 Ethernet - DMX8 / WiFi
With the up down keys you can alter the
alue of the blinking edit field.
You can change from edit field by using the
left and right key.
In the remaining fields the alue can be
between 0 and 255. You can hold down the
up or down keys to easily set large numbers.
The count will accelerate after a while.
Once the IP is set, press ENTER to go to the
confirmation screen.
In this confirmation screen you can choose
with the left right keys whether you want to
confirm your changes or cancel them.
Press ENTER in the con enient screen to
Confirm or to Cancel the IP setting.
Enter
<<
Enter
Enter
>>
<<
Enter Enter
Network Config
Set IP 1 >
IP 1 Config
2. 0. 0. 2
2. 0. 0. 2
CONFIRM >
2. 0. 0. 2
< CANCEL
>> >> >> >>
<< << < <
++++
-
>> >>
<< <<
+
Enter
>> >>
<< <<
Enter Enter Enter
Enter Enter Enter
>> >>
<< < < < <
Enter Enter Enter Enter Enter
.: Eth-DMX8 :.
ID: 001 >
1:Node 1
2.0.0.2 >
2:Node 2
2.0.0.3 >
Eth 12345678
< L ........ >
Configuration
Network >
Configuration
< DMX >
Configuration
< G oba Set.
Network Config
Set IP 1 >
Network Config
< Set IP 2 >
Network Config
< Netmask 1 >
IP 1 Config
2. 0. 0. 2
IP 2 Config
2. 0. 0. 3
Netmask 1 Config
255. 0. 0. 0
2. 0. 0. 2
CONFIRM >
2. 0. 0. 2
< CANCEL
2. 0. 0. 3
CONFIRM >
2. 0. 0. 3
< CANCEL
255. 0. 0. 0
CONFIRM >

UDP ports setting
The UDP ports are used to indicate the Ethernet ports number on which
the network socket has to listen for ArtNet data. 2 UDP ports are a ailable
on the node, 1 for four uni erses. These numbers are indicated in Hex
alue and the default is 0x1936. These alues may only be changed by an
experienced network administrator.
Ethernet - DMX8 / WiFi Page 11 of 54
Use the up down keys to change the alue of
e ery digit separately.
E ery digit can be a alue between 0 and F
(hexadecimal).
Use the left right keys to change from edit
field.
Once the UDP port is set, press ENTER to go
to the confirmation screen.
In this confirmation screen you can choose
with the left right keys whether you want to
confirm your changes or cancel them.
Press ENTER in the con enient screen to
Confirm or to Cancel the UDP port setting.
> >
Enter
Enter
>>
<<
Enter Enter
Network Config
< UDP port 1
UDP port 1
0x1936
Port 1: 0x1936
CONFIRM >
Port 1: 0x1936
< CANCEL

•DMX configuration
E ery DMX outlet can be configured separately as input or output. These
inputs and outputs get a DMX line address on ArtNet. It is possible to
distribute 256 different DMX lines o er ArtNet.
The Ethernet – DMX8 / WiFi runs 2 ArtNet Nodes with outlet 1 to 4 on
Node 1 and outlet 5 to 8 on Node 2. Some settings of the DMX outlets are
dependent on the Node setting.
The DMX line address (Uni erse) on ArtNet is a combination of the outlet's
Subnet and Subswitch. The Subnet di ides the possible range of 256
addresses in groups of 16 addresses. E ery outlet has one Subnet setting
(from 0x0 – 0xF, 0- 15). And e ery outlet has a separate Subswitch (from
0x0 – 0xF, 0 – 15). Combined this gi es the following result.
The Subnet is the high nibble of the complete address and the Subswitch
is the low nibble of the address.
Outlet 1:
Subnet: 0x2 Outlet 1-> Subswitch: 0xC
Result address: 0x2C
In decimal this would be:
Result = (Subnet x 16) + Subswitch
Result address = (2 x 16 ) + 12 = 44
Happily, if you're not used to work on hexadecimal alues, the node allows
you to set you outlet DMX line in decimal alue. The corresponding
hexadecimal alue will be displayed in brackets.
Example:
Page 12 of 54 Ethernet - DMX8 / WiFi
>> > > > > >>
< < < < < <
++++
-
>> > > > >
< < < < < <
+
Enter
>> > > > > >>
< < << < < <<
+
.: Eth-DMX8 :.
ID: 001 >
1:Node 1
2.0.0.2 >
2:Node 2
2.0.0.3 >
Eth 12345678
< ........ >
Configuration
Network >
Configuration
< DMX >
Configuration
< G oba Set.
Firmware Ver.
< 3.0.0
DMX Config
Out et route >
DMX Config
< FrameRate >
DMX Config
< Break time >
DMX Config
< MAB time >
DMX Config
< Output time
Out et : 1
Univ: 0 (00)

Outlet route
➢DMX output
To setup an outlet as output, follow the following procedure.
Choose DMX Config, Outlet route press Enter and select the outlet with
the left right keys.
Enable
Yes Enables the outlet
No Disables the outlet
Dir (Direction)
Output Sets the outlet as DMX output
Input Sets the outlet as DMX input
Mode (output)
Single The DMX outlet outputs normal DMX data coming in o er ArtNet.
Zero DMX outlet outputs DMX data with all zero alues for all 512 channels.
Univ (Universe)
Sets the outlet's DMX line address. ArtNet Hexadecimal alue is a ailable in brackets
Ethernet - DMX8 / WiFi Page 13 of 54
Select with up and down keys to enable or to disable the
outlet. When disabled no further configuration is needed.
Select INPUT or OUTPUT direction of DMX outlet
Set the DMX output mode: SINGLE or ZERO
Select the DMX line address. The combined ArtNet
uni erse address is shown in brackets. This is the
combination of the outlet's subnet and subswitch.
Set merging of ArtNet DMX packages of different IP
sources on or off.
When IP merging enabled you can choose between
HTP, LTP or CST (Custom mode).
>> >> >>
<< << < <
+
Enter
>> >>
<< <<
Enter
NO
YES Enter
+
-
OUTPUT Enter INPUT Enter
Enter
Enter
Enter
>>
<<
Enter Enter
DMX Config
Out et route >
DMX Config
< FrameRate
DMX Config
< Break Time
DMX Config
< MAB Time
DMX Config
Out et : 1 >
DMX Config
< Out et : 2 >
DMX Config
< Out et : 8
Out et : 1
Enab e : YES
Out et : 1
Dir: OUTPUT
Out et : 1
Dir: INPUT
Out et : 1
Mode : SINGLE
Out et : 1
Univ: 0 (00)
Out et : 1
IP Merging: OFF
Save setup ?
CONFIRM >
Save setup ?
< CANCEL

IP Mer in
OFF Disable the IP merging feature
HTP Merge 2 ArtNet streams set with same uni erse address; All channels
outputted from that outlet will result of a Highest Take Precedence policy
between the two first registered ArtNet sources.
LTP Merge 2 ArtNet streams set with same uni erse address; All channels
outputted from that outlet will result of a Last Take Precedence policy
between the two first registered ArtNet sources.
CUSTOM Need the use of a Web browser. Create here a complete softpatch, select
the 2 ArtNet sources IP addresses and uni erse addresses to merge. You
can affect each kind of merging policy (HTP, LTP, Backup, S1 only, S2
only..) on each channel of the selected outlet. You can also set here the
Trigger channel to remotely change theses policies through DMX.
Page 14 of 54 Ethernet - DMX8 / WiFi

➢DMX input
To setup an outlet as input, follow the following procedure.
Choose DMX Config, Outlet route press Enter and select the outlet with
the left right keys.
Enable
Yes Enables the outlet
No Disables the outlet
Dir (Direction)
Output Sets the outlet as DMX output
Input Sets the outlet as DMX input
Ethernet - DMX8 / WiFi Page 15 of 54
Enter
>> > > > >
< < < < < <
+
Enter
>> > >
< < < <
Enter
NO
YES Enter
+
-
INPUT Enter
+
-
Enter
Enter
+
-
Enter
Enter
Enter
>>
< <
DMX Config
Out et route >
DMX Config
< FrameRate >
DMX Config
< Break Time >
DMX Config
< MAB Time >
DMX Config
Out et : 1 >
DMX Config
< Out et : 2 >
DMX Config
< Out et : 8
Out et : 1
Enab e : YES
Out et : 1
Dir: OUTPUT
Out et : 1
Dir: INPUT
Out et : 1
Mode : NORMAL
Out et : 1
Mode : MERGE
Out et : 1
Univ: 0 (00)
Out et : 1
IP Merging: OFF
Out et : 1
IP Merging: BCK
Out et : 1
Backup ms: 400ms
Out et : 1
Recover: AUTO
Save setup ?
CONFIRM >
Save setup ?
< CANCEL
Set the DMX input mode: NORMAL or MERGE
Select the DMX line address. The combined
ArtNe t uni erse address is shown in
brackets. This is the combination of the
outlet's subnet and subswitch.

Mode (input)
Normal The DMX outlet works as a normal DMX input putting data on ArtNet.
Merge The outlet will be merged with the next outlet. This option is only
a ailable for outlet 1, 3, 5 and 7. When this mode is chosen, the next
outlet is automatically set as input. Merge policies can be set by
configuring the next outlet. (see Merged DMX input)
Univ (Universe)
Sets the outlet's Subswitch to complete the complete uni erse, or DMX line address
of the normal input or the merge result.
IP Mer in
Off The DMX outlet works as a normal DMX input putting data on ArtNet.
Bck The outlet act as networked backup input. It will function as a input
backup of the main ArtNet source set with the same uni erse address.
When in alid or no DMX is recei ed from the primary ArtNet source, this
outlet will automatically take o er. The primary source takes o er again
as soon as alid data is a ailable again
Backup ms
Set here the time within the node as to wait before switching to the backup outlet
(from 400 to 9999ms) in case of primary ArtNet source stream failure.
Recover
Auto If the failed ArtNet stream is back again on the network, the node will
switch back automatically to this pre ious ArtNet source, and thus
disable the backup outlet.
Manual The node will not switch back automatically to the pre ious ArtNet
stream. You'll ha e to switch yourself to the pre ious ArtNet stream by
using the reco er channel patched in the enabled trigger uni erse. See
page 28
Page 16 of 54 Ethernet - DMX8 / WiFi

➢Merged DMX input
If one of the odd outlets (1, 3, 5 or 7) is set as merged input, then the
corresponding e en outlet (2, 4, 6 or 8) is automatically set as input. For
this input you ha e to configure the merging policy and start address
offset (for HTP and LTP only).
Enable
Yes Enables the outlet
No Disables the outlet
Mode (mer ed)
HTP Merges the channels from this outlet starting at the offset into the
pre ious outlet input, using Highest Takes Precedence (HTP) policy. The
highest alue of 2 merged channels will be used.
LTP Merges the channels from this outlet starting at the offset into the
pre ious outlet input, using Latest Takes Precedence (LTP) policy. The
latest changed alues will end up in the merge result.
BACKUP This outlet will function as a input backup of the pre ious outlet. When
in alid or no DMX is recei ed on the primary (pre ious) outlet, this outlet
will automatically take o er. The primary outlet takes o er again as soon
as alid data is a ailable again.
CUSTOM This mode requires the use of a Web browser. It is the most complete
one as all policies listed abo e are a ailable for each channel. A complete
softpatch can thus be created by using the table a ailable through the
built-in Web ser er. See page 28 for more details.
Offset
Sets the offset address of where the merging of the second outlet has to start. This
option is not applicable in BACKUP and mode.
Ethernet - DMX8 / WiFi Page 17 of 54
Set merge policy: HTP, LTP, BACKUP or
CUSTOM
Set the channel offset from which start
address this outlet has to be merged in
with the pre ious outlet (1)
Enter
> > > > > >
<< < < < <
+
Enter
> > > >
<< < <
Enter
N O
YES Enter
Enter
Enter
> >
<<
Enter Enter
DMX Config
Out et route >
DMX Config
< FrameRate >
DMX Config
< Break Time >
DMX Config
< MAB Time >
DMX Config
Out et : 1 >
DMX Config
< Out et : 2 >
DMX Config
< Out et : 8
Out et : 2
Enab e : YES
Out et : 2
Mode : HTP
Out et : 2
Offset: 001
Save setup ?
CONFIRM >
Save setup ?
< CANCEL

Frame rate setting
The frame rate setting determines the DMX refresh rate. The refresh rate
is set for all outlets similar. The frame rate can be set from 20 to 40 FPS
(Frames Per Second).
Break time setting
The break time of the DMX signal can be set from 92 – 352 us. This is the
idle time between 2 DMX packets of 512 channels.
ark After Break ( AB) time setting
The MAB time of the DMX signal can be set from 12 – 88 us. This is the
time after the idle time to indicate a new DMX packet start.
Page 18 of 54 Ethernet - DMX8 / WiFi
>> > > > > >> >>
<< << << < < <<
+
Enter
Enter
>>
<<
Enter Enter
DMX Config
< Out et Route >
DMX Config
< FrameRate >
DMX Config
< Break time >
DMX Config
< MAB time >
DMX Config
< Output time
DMX Config
Break : 210 uS
Save setup ?
CONFIRM >
Save setup ?
< CANCEL
Enter
> > > > > > > >
< < < < < < < <
+
Enter
Enter
> >
< <
Enter Enter
DMX Config
Out et route >
DMX Config
< FrameRate >
DMX Config
< Break Time >
DMX Config
< MAB Time >
DMX Config
< Output Time
DMX Config
FPS : 36
Save setup ?
CONFIRM >
Save setup ?
< CANCEL
Use Up and Down keys to change the DMX
frame rate setting (20-44 fps).
Use Up and Down keys to change the
DMX break time setting (92 -352
uS).
>> > > > > >> >>
<< << << < < <<
+
Enter
Enter
>>
<<
Enter Enter
DMX Config
< Out et Route >
DMX Config
< FrameRate >
DMX Config
< Break time >
DMX Config
< MAB time >
DMX Config
< Output time
DMX Config
MAB : 50 uS
Save setup ?
CONFIRM >
Save setup ?
< CANCEL
Use Up and Down keys to change the DMX
MAB setting (12-88 uS).

D X output time setting
The DMX output time is used to set the amount of time an output has to
transmit its latest recei ed DMX data from ArtNet onto the DMX outlets.
The output time can be set continuously or from 1 – 10 minutes.
Ethernet - DMX8 / WiFi Page 19 of 54
>> > > > > > >
<< << << < <
+
Enter
Enter
>>
<<
Enter Enter
DMX Config
< FrameRate >
DMX Config
< Break time >
DMX Config
< MAB time >
DMX Config
< Output time
DMX Config
Output: Contin.
Save setup ?
CONFIRM >
Save setup ?
< CANCEL
Use Up and Down keys to change the DMX
output time setting (continuously or 1-10
minutes).

•Global settings
The global settings contains the Profile Manager. Here you can recall and
sa e complete routings and network settings into a profile.
Space is pro ided to hold 40 different profiles. Already 11 most used
profiles are pro ided with the firmware.
Profile Description
1 Default All outlets as disabled output
2 1 in + 7 out 1 input at 0(00) and 7 outputs starting at 1(01) to 7(07)
3 All out 0 All outlets as single output starting at 0(00) to 7(07)
4 All out 8 All outlets as single output starting at 8(08) to 15(0F)
5 All in 0 All outlets as normal input starting at 0(00) to 7(07)
6 All in 8 All outlets as normal input starting at 8(08) to 15(0F)
7 1.7 Hub 1 input and 7 output all at 0(00)
8 2x1.3 Hub 2 inputs and 3 outputs for e ery input at 0(00) and 1(01)
9 4 x MergeHtp 4 x 2 merged inputs in HTP mode at 0(00) to 3(03)
10 4 x MergeLtp 4 x 2 merged inputs in LTP mode at 0(00) to (03)
11 4 x Backup 4 x 2 backup inputs at 0(00) to 3(03)
Page 20 of 54 Ethernet - DMX8 / WiFi
>> > > > > > >
< < < < < <
+ + + +
-
>> > > > >
< < < < < <
+
Enter
>>
< <
+
.: Eth-DMX8 :.
ID: 001 >
1:Node 1
<2.0.0.2 >
2:Node 2
<2.0.0.3 >
Eth 12345678
< ........ >
Configuration
Network >
Configuration
< DMX >
Configuration
< G oba Set.
Firmware ver.
< 3.0.0
Profi es
Reca >
Profi es
< Store
