luminii DDMX-5CH-RDM-PRO User manual

Page 1 of 4
DMX Decoder 5 Channel - Installation Instructions
Model DDMX-5CH-RDM-PRO
Please read all instructions prior to installation and keep for future reference!
1. Ensure power to power supply is off before installing!
2. Use only with Class 2 power supply.
7777 Merrimac Ave
Niles, IL 60714
T 224.333.6033
F 224.757.7557
[email protected]
www.luminii.com
*LUMINII RESERVES THE RIGHTS TO CHANGE SPECIFICATIONS WITHOUT NOTICE
2 4
3
15
4 2
3
51
GND
D-
D+
D-
D+
5/W2-
4/W1-
3/B-
2/G-
1/R-
+
V+
V+
V-
V-
8765432187654321
DMX in/out DMX in/out
DMX signal
female
DMX signal
male
Back Enter Up Down
5 pin male & female XLR terminal
DMX512 signal input & output
DMX512 input & output
Display
2 x RJ45 terminal:
DMX512 signal input & output
24VDC input
REV0.1 09252019
