LS-28DRSM Multi-Mode Modular Receiver
Quick-start Manual
Document: USM-28M-01-001-02
Editor: T. Rem her
Date: 12/14/2016
Release: -----
Lumistar, Inc.
2270 Camino ida Roble, Suite L
Carlsbad, California 92011
[phone]
www.lumistar.net

Lumistar LS-28M Quick Start Manual - R2
This document is the intellectual ro erty of Lumistar, Inc. The document contains ro rietary and
confidential information. Re roduction, disclosure, or distribution of this document is rohibited
without the ex licit written consent of Lumistar, Inc.
This document is rovided as is, with no warranties of any kind. Lumistar, Inc. disclaims and excludes all
other warranties and roduct liability, ex ressed or im lied, including but not limited to any im lied
warranties of merchantability or fitness for a articular ur ose or use, liability for negligence in
manufacture or shi ment of roduct, liability for injury to ersons or ro erty, or for any incidental,
consequential, unitive or exem lary damages. In no event, will Lumistar, Inc, be liable for any lost
revenue or rofits, or other indirect, incidental and consequential damages even if Lumistar, Inc. has
been advised of such ossibilities, as a result of this document or the usage of items described within.
The entire liability of Lumistar, Inc. shall be limited to the amount aid for this document and its
contents.
RESTRICTED RIGHTS LEGEND
Use, du lication, or disclosure by the Government is subject to restrictions set forth in sub aragra h
(c)(1)(ii) of the rights in Technical Data and Com uter Software clause in DFARS 252.227-7013.
®Lumistar, Inc. and its logo are trademarks of Lumistar, Inc. Brand names and roduct names
contained in this document are trademarks, registered trademarks, or trade names of their res ective
holders.
®Microsoft, Encarta, MSN, and Windows are either registered trademarks or trademarks of
Microsoft Cor oration in the United States and/or other countries.
This document is an inde endent ( ublication) and is not affiliated with, nor has it been authorized,
s onsored, or otherwise a roved by Microsoft Cor oration.
© 2016 Lumistar, Inc. All rights reserved.
Lumistar Inc.
2270 Camino Vida Roble, Suite L
Carlsbad, CA 92011
[phone]
[phone] Fax
www.lumistar.net

Lumistar LS-28M Quick Start Manual – R2
1 | P a g e
Lumistar, Inc. December 14, 2016
1Introduction
1.1 General Information
The following document contains a rocedure for connecting the Lumistar LS-28M device to an
Ethernet control and status network. The manual will cover the following to ics:
1.) The mechanical interfaces and interconnects to the LS-28M device.
2.) The installation of the su lied LS28A user software a lication.
3.) The setu and modification of the Lumistar LS-28M device network interface configuration.
4.) The connection of the device in a Microsoft Windows 7 or Windows 10 firewall environment.
5.) A general overview of the LS28A User GUI o erations.
This manual is limited in sco e to the configuration of the modular unit in a “standalone” configuration
and does not take into account integrated and delivered systems that contain LS-28M devices as core
receiving elements. Manuals relating s ecifically to network configurations on integrated systems will
be included with the associated deliveries.
Table 1-1 below rovides general s ecifications for electrical, mechanical, and o erational
characteristics of the LS-28M roduct line.

Lumistar LS-28M Quick Start Manual - R2
2 | P a g e
Lumistar, Inc. December 14, 2016
Table 1-1 General Specifications
Category:
Specifications:
Details:
Mechanical
nvelope Dimensions (all slices)
6.00”(L) x 4.00”(W) x 1.672” (H) Slice 1
-
4
Form Factor
Modular Brick
Weight
~ 32oz.
Electrical
Individual power requirements
9
-
42VDC
Nom. +24VDC @ 2.875A
Total Power (both
Channels)
~ 60 Watts (mode and data rate dependent)
Performance
RF Tuner
RF Input Bands
Typ. Config. up to 5 Bands + 70MHz
Band range: 70MHz
–
6.2GHz
Alt. Config. allows up to 6 RF Bands (future)
Tuner Resolution
50kHz (Typical); 2Hz minimum
Frequency Accuracy
0.002% (Max.) 0.001% (Typical)
RF Input AGC Range
+10dBm to
–
110dBm
Input Level without Damage
+28dBm ( in “Protect mode”)
Receiver Input P
1dB
+10dBm (typical)
Receiver Noise Figure
<= 5dB (typical @ threshold)
70MHz Phase
Noise @ 1kHz
<=
-
84.2dBc (typical)
70MHz Phase Noise @ 10kHz
<=
-
97.8dBc (typical)
70MHz Phase Noise @ 100kHz
<=
-
105.5dBc (typical)
70MHz Phase Noise @ 1MHz
<=
-
124.5dBc (typical)
Receiver OIP
3
> +15dBm (typical)
70MHz Output Level
Typ. 0
dBm (+/
-
1dBm); Adjustable
SAW IF 3dB Bandwidths Available
(used for Adjacent Channel
Rejection)
250kHz, 500kHz
,
1MHz
,
2MHz, 5MHz
,
10MHz
,
20MHz, 40MHz
Demodulation
Types
Analog AM, Video FM, SS
-
PCMFM, MS
-
PCMFM,
BPSK, QPSK, OQPSK, AUQPSK, AQPSK, UQPSK,
Direct PM, MH-CPM, Sub-Carrier PM
w/BPSK/QPSK
Video FM De
-
emphasis
Bypass, NTSC, PAL
AM
-
3dB Frequency Response
50kHz (AM Low
-
pass Bypass Mode)
AM Low
-
pass Filters
32 Software Selectable
AM
-
3dB Bandwidths
50, 100, 200, 300, 400, 500, 600, 700, 800,
900,
1K, 1.1K, 1.2K, 1.3K, 1.4K, 1.5K, 1.6K, 1.7K, 1.8K,
1.9K, 2K, 3K, 4K, 5K, 6K, 7K, 8K, 9K, 10K, 15K,
20K, 50K Hz
Connectors
xternal Reference Input/Output
(1) SMB Jack
RF Signal Input
(2) SMA Jack Receptacle
IF Signal Output
(2) SMB Jack
Receptacle
Analog I/O Connector
(2) MicroDSub
-
15 Plug
Digital I/O Connector
(3) MicroDSub
-
25 Plug
Power/Digital I/O Connector
(1) MicroDSub
-
25 Receptacle
Environmental
Temperature, Operational
-
40
°
to 85
°
Celsius (Commercial)
Temperature, Storage
-
40
°
to 125
°
Celsius
Humidity, non
-
condensing
<40
°
C 0
-
90%, >40
°
C 0
-
75%

Lumistar LS-28M Quick Start Manual - R2
3 | P a g e
Lumistar, Inc. December 14, 2016
1.2 Mechanical Information
Figure 1-1 below shows the mechanical outline and foot rint of the LS-28M modular receiver unit. The
unit’s weight is a roximately 1.9 ounds (0.86 kg). The unit rovides free-fit #6 clearance holes at
each corner for mounting.
Figure 1-1Mechanical Outline
1.3 Electrical and Thermal Information
The LS-28M unit can be owered via a single su ly between 9 and 42VDC. It is recommended that the
unit be owered from sources in the 18-32VDC for o timal current voltage load balancing. Caution

Lumistar LS-28M Quick Start Manual - R2
4 | P a g e
Lumistar, Inc. December 14, 2016
should be used in roviding a ro riate cabling to the device for current handling. The ower
interface rovides three ower ins as well as three ower returns.
All six power related pins should be utilized to ensure proper current provisions for the Micro-D
contact ratings.
The LS-28M ower consum tion is o tion and mode de endent but varies between a roximately 40
and 60 watts. Pressurized cooling should be used to dissi ate the device heat load which is rimarily
assed to the sides of the modular ackage.
Insufficient cooling provisions can damage or destroy the unit. Ensure that there is proper
airflow to the device and monitor the unit temperature via the LS28App User GUI on the INFO
tab. Sufficient airflow should be provided to keep the unit below 65 degrees Celsius.
1.4 Cable interfaces
The LS-28M unit is delivered with 6 cable assemblies, one for each of its front anel Micro-DSub
interfaces. Figure 1-2 illustrates the front IO anel connection ma of the unit. Figures 1-3 thru 1-8
de ict the cables rovides and their associated in-outs. SMA connectors are rovided for the RF
in uts and SMB connectors are rovided for IF signal out uts as well as the reference clock in uts.
Figure 1-2IO Face Panel Connector Designators

Lumistar LS-28M Quick Start Manual - R2
5 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-3 P4 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
6 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-4 P5 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
7 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-5 P8 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
8 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-6 P9 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
9 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-7 P11 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
10 | P a g e
Lumistar, Inc. December 14, 2016
Figure 1-8 P12 Cable Assembly Pinout

Lumistar LS-28M Quick Start Manual - R2
11 | P a g e
Lumistar, Inc. December 14, 2016
2Introduction
2.1 LS28App Software Installation
The unit is delivered with a user level software a lication that will run on any Windows 7-x86/x64 or
Windows 10-x86/x64 latform. To install the software, erform the following ste s:
Ste 1:Insert the rovided disk into a DVD drive and launch the setu a lication on the disk. Based on
security settings of the host PC, the following warning may be observed (Note: a lication version
numbers will vary over time):
If this warning is observed, select the YES o tion to continue.
Ste 2:Click NEXT to continue at the following screen:

Lumistar LS-28M Quick Start Manual - R2
12 | P a g e
Lumistar, Inc. December 14, 2016
Ste 3:Click NEXT to continue at the following screen:
Ste 4: Click NEXT to continue at the following screen:

Lumistar LS-28M Quick Start Manual - R2
13 | P a g e
Lumistar, Inc. December 14, 2016
Ste 5: Check the box acce ting the license terms and click the INSTALL to continue at the following
screen:
Ste 6: Click FINISH to continue at the following screen:

Lumistar LS-28M Quick Start Manual - R2
14 | P a g e
Lumistar, Inc. December 14, 2016
Ste 7: Click FINISH to continue at the following screen:
2.2 LS28App Network/Interface Information
The LS-28M device receives controls and status by serial interface methods only. This includes RS-232,
USB 2.0, and 10/100/1000Mb s Ethernet.
Utilizing the RS-232 and USB 2.0 interfaces, all device controls are rovided to the user but only critical
status values are returned to the user. Gra hical dis lay com onents such as s ectral dis lays,
baseband eye atterns, and IQ constellation dis lays exceed the bandwidth ca acity and real-time
o erational as ects of the slower serial interface formats and thus are disabled. The 10/100/1000Mb s
Ethernet interface rovides all dynamic and static dis lays in addition to all standard controls as well as
o tional streaming data out ut ca abilities.
The interface for general controls and status on the Ethernet network utilizes both TCP and UDP
rotocols through one of sixteen orts. The resent evolution of device software is designed for
Unicast mode and thus there is only one controlling agent on a given network. TCP is utilized for
controls and high-level status. UDP orts are utilized for a number of status and data functions. These
include:
1.) S ectral Dis lay Data Packets
2.) Signal Baseband Eye Pattern Data Packets
3.) Signal IQ Constellation Data Packets
4.) Streaming Data Sources (o tional)
5.) Test Data Packets (factory use)
By default, the factory defined ort socket assignments of the LS-28M are as follows:

Lumistar LS-28M Quick Start Manual - R2
15 | P a g e
Lumistar, Inc. December 14, 2016
Port # Format Direction Payload
5002 UDP Out ut S ectral Dis lay Packet Data – Channel 1
5003 UDP Out ut S ectral Dis lay Packet Data – Channel 2
5004 UDP Out ut Streaming Data – Channel 1
5005 UDP Out ut Streaming Data – Channel 2
5007 UDP Out ut Constellation Dis lay Packet Data – Channel 1
5008 UDP Out ut Constellation Dis lay Packet Data – Channel 2
5009 UDP Out ut Constellation Dis lay Packet Data – Combiner
5010 UDP Out ut Eye Pattern Packet Data – Channel 1
5011 UDP Out ut Eye Pattern Packet Data – Channel 2
5012 UDP Out ut Eye Pattern Packet Data – Combiner
5016 TCP Bidirectional Command and Status
UDP data that is streamed from the device to the dis lay a lication requires a “kee -alive”
command/res onse via the TCP socket. This rotection technique is a means of reventing the device
from continuously s awning UDP traffic on a network in the absence of the control a lication. Thus, if
the controlling host is either offline, or has closed the a lication unex ectedly, the UDP traffic from the
LS-28M will continue to be delivered for a eriod of a roximately 90-120 seconds. If after that time-
out eriod, no host communications is established, the UDP sockets will closed automatically. They
may be re-established by restarting the LS-28M a lication.
The LS-28M isdelivered configured with a StaticIP Address. The default address is 192.168.16.220.If
the user desires that the unit be switched to a different static IP address or to Dynamic Host
Configuration Protocol (DHCP) mode, a controlling host set to the same sub-net mask will be
requiredalong with a network switch with two available orts (or a cross-over cable) to form
connections between the host and the device.
If the user wishes to have the device delivered with Dynamic Host Configuration Protocol (DHCP)
enabled, contact sales rior to delivery for s ecific assignments. In DHCP mode, a DHCP IP address
service is required on the attached network to assign an IP address to the device.
Configuring hosts communication between various network configurations is o erating system
de endent and is beyond the sco e of this manual. However, an exam le of how to configure a
common Windows network Host Controller to o erate in either Static or DHCP modes is described in
sections 2.2.1 and 2.22 res ectively.
NOTICE: Network configuration, connection and security typically require consent and access privileges
from a network system administrator. The sections that follow attempt to describe the necessary steps
that need to be taken in a rather “ pen” network environment. Specific requirements in terms of network
security and connection routing are the user’s responsibility. Please contact your system administrator
before going further.

Lumistar LS-28M Quick Start Manual - R2
16 | P a g e
Lumistar, Inc. December 14, 2016
2.2.1 Modification of a Windows Hostcontroller to Static IP mode
To modify the controlling host’s network configuration to static IP mode, erform the following ste s:
Ste 1: Connect the LS-28M to the target host machine either directly with a Ethernet crossover cable
or by connecting both the device and the host to an Ethernet switch using standard Ethernet cables.
Ste 2: On the target host a lication machine, access the Windows Control Panel.
Ste 3: From Windows Control Panel, select the Network and Sharing Center.
Ste 4: From Network and Sharing Center, select the “Change ada ter settings” o tion from the left-
hand menu.
Ste 5: The Network Connections window shows the available connections the target host can use.
Right-click on the local area connection that is connected to the LS-28M and select “Pro erties”.

Lumistar LS-28M Quick Start Manual - R2
17 | P a g e
Lumistar, Inc. December 14, 2016
Ste 6: From the Local Area connection Pro erties window, double-click on “Internet Protocol Version
4 (TCP/IPv4)”.
Ste 7: To set the unit to a static IP address, select the “Use the following IP address:” o tion. Then
enter the desired IP address in the designated field. A suggestion is to use the IP address
192.168.16.200 as shown below. Once the IP address is filled, the Subnet mask field will automatically
o ulate.
WARNING: The static IP address of the host machine cannot be identical to any device on the
connected network.

Lumistar LS-28M Quick Start Manual - R2
18 | P a g e
Lumistar, Inc. December 14, 2016
Ste 8: From the Internet Protocol Version 4 (TCP/IPv4) Pro erties window, click “OK”.
Ste 9: From the Local Area Connection Pro erties window, click “OK”.
Ste 10: Launch the LS-28M a lication. If the network configuration is setu u ro erly, the
a lication will find the device.
2.2.2 Modification of a Windows Host controller to DHCP Mode
To modify the controlling host’s to the DHCP network configuration, erform the following ste s:
Ste 1: Connect the target host to a DHCP enabled network.
Ste 2: On the target host a lication machine, access the Windows Control Panel.
Ste 3: From Windows Control Panel, select the Network and Sharing Center.
Ste 4: From Network and Sharing Center, select the “Change ada ter settings” o tion from the left-
hand menu.
Ste 5: The Network Connections window shows the available connections the target host can use.
Right-click on the local area connection that is connected to the DHCP enabled network and select
“Pro erties”.
