Rotel RSX-972 User manual

Technical
Manual
SURROUND SOUND RECEIVER
RSX-972
Table of Contents
Appearance......................................2
Wiring Diagram.................................3
Chassis Layout.................................15
Adjustment........................................16 - 17
Conversion........................................18
Case Outlines...................................19 - 20
PCB Assembly..................................21 - 25
Schematic Diagram..........................26 - 34
Disassembly Diagram.......................4
Disassembly Diagram List.................5
Specifications....................................6
Parts List...........................................7 - 14
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Serial. NO.
Beginning
®
Quality Uncompromised
Y-331B-0009/W4
THE ROTEL CO., LTD.
See Page 22 for Backup Memory Cap Location

2VIDEO INTAPE
INPUT
1 43 5IN
CD OUT 2
L
R
VIDEO OUT
2
DIGITAL INPUT
11 32
COAXIALOPTICAL
COAXIAL OPTICAL DIGITAL OUPUT
1 3
32
COMPOSITE IN
14352
COMPOSITE OUT
13
2S-VIDEO IN 14352
S-VIDEO OUT
13
L
R
CENTER
SUB
WOOFER
ZONE
OUT ZONE REM
IR
OUT
12
EXT
REM 12V
TRIGGER
OUT
REAR FRONT
L
R
MONITOR
OUT
CENTER
SUB
WOOFER
REAR FRONT
L
R
5.1 CH INPUT
ANTENNA
OUTPUT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS: RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR
WARNING: SHOCK HAZARD DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTICAL SHOCK,
DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
Manufactured under license from Digital Theater
System, Inc. US Pat. No. 5,451,242 and other
world-wide patents, issues and pending. "DTS",
DTS Digital surround", are trademarks of Digital
Theater System, Inc. Copyright 1996 Digital
Theater System, Inc. All rights reserved.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
21
Y
CR
CB
COMPONENT VIDEO
IN MONITOR
OUT
POWER
SURROUND SOUND RECEIVER RSX-972
12345
67890
MEMORY DIRECT
BAND
TUNING
MONO
BASS
TREBLE
VOLUME
CD TUNER TAPE 1 VIDEO1 VIDEO2 VIDEO3 VIDEO4 VIDEO5
2CH 3
STEREO PRO
LOGIC DSP 5.1CH
INPUT DYNAMIC RANGE RECZONE
Manufactured under license from Dolby Laboratories Licensing Corporation. "Dolby", "Pro Logic"
and the double-D symbol are trademarks of Dolby Laboraties Licensing Corporation. Confidential
unpublished works © 1992-1997 Dolby Laboraties, Inc. All rights reserved.
SPEAKERS FRONT
R
REAR
L
R
CENTER
AM
LOOP
SURROUND SOUND RECEIVER
MODEL NO. RSX-972
POWER CONSUMPTION: 300 WATTS
RSX-972
L
IN 1
2
SPEAKER IMPEDANCE
8 OHMS MINIMUM
COAXIAL
OPTICAL
O S D
2
1
34
5.1ch
MEMORY
MODE
AUTO
DSP
dts
TUNED
PTY
TP
EONRT PRESET
RDS
D.RANGEDIGITAL
TA ST
3StereoPro Logic
Appearance
2

3

Disassembly Diagram
4

DISASSEMBLY PARTS LIST
1 8645000211 KNOB ROTARY, AL A6063S-T5 55 2408218001 OPTO JACK RX-8A
2 8543000211 KNOB MAIN, AL A6063S-T5 56 4438100530 JACK RCA 3P(B)
3 8602000611 FRONT PANEL, AL A6063S-T5 57 4438100920 JACK RCA 2P(B,B WOOFER)
4 8545000511 BEZEL RING(47F), ABS RED SPRAY 58 4408101010 SPEAKER TERMINAL 4P
5 8523000210 CAP SIDE, ABS BLACK 59 4408101110 SPEAKER TERMINAL 2P
8555000510 60 4438101220 JACK RCA 9P(GR,BL,R)
(019 C-4525A00T) 61 4438300210 JACK MINIATURE 2P(3.5mm) BLACK
8543000510 62 4438100120 JACK RCA 2P(W,R)
(012 TB3-18A00) 63 4408000320 TERMINAL ANT(GND),SC0210586N
8 8555000411 WINDOW DISPLAY. ACRYL 5.0t 64 6102000611 CH.BACK,SECC1.0t
8545000110 65 436302200047 ASS'Y INLET
(012 RV4-09A00) 66 2028416122 TR NPN 2SC3519A W/ACC
8545000710 67 2008622110 TR NPN 2SC4137 FOR BIAS
(019 C-4525A00T) 68 2028116108 TR PNP2SA1386A W/ACC
6555600110 69 2381851712 LED RED1X5 (034SEL 1124R)
(019 4TR-1988A#2)
6305000110
(019 4TTL-15)
13 6725000110 FELT VR(TONE)F20
14 6725000120 FELT VR(TONE)F52
15 6122200110 CH FRONT, SECC1t
16 8535000310 FILTER FL ,ACRYL1.0t WINE
17 4628000110 POWER SWITCH, TV-5
18 4658000210 SW TACT SKHVBHD010 S1 8109430083 SCREW #B BTT 3X8B
19 2408000190 REMOCON SENSOR SBX3010-52B S2 8129430083 SCREW #2FTC 3X8B
20 6515000110 HOLDER FIP, ABS BLACK S3 8159430061 SCREW #B WPTT 3X6Y
21 2328000302 FIP SVR08LM02 S4 8069130064 SCREW #WPMS 3X6NI
22 3218000410 VR ENCODER WITH DETENT EC16B2420431 S5 8159440083 SCREW #WSAM 4X8B
23 3218000310 VR ENCODER WITHOUT DETENT,EC16B243040H S6 8179430121 SCREW HEAT SINK
24 6133100110 FOOT, ABS BLACK S7 8199430103 SCREW G.N.D
25 6715000110 BUMPON S8 8159430181 SCREW #B WPTT 3X18Y
26 6121600120 MAIN CHASSIS, SECC1.2t
27 6515000210 SPACER PCB, ABS BLACK
28 6505000120 BKT H/SINK(M3 TAP), SECC1.0t
29 6528000210 CLAMP WIRE
30 6505000310 BKT PCB,SECC 1.0t
31 7502000110 POWER HEAT SINK, AL A6063S-T5 9007000710 INSTRUCTION MANUAL FOR RSX972
32 6505000110 BKT H/SINK, SECC1.0t 2608207360 AM ANT LOOP
33 436102102031 ASS'Y POSISTOR 4348000110 FM ANT
34 7505000610 H/SINK SPRING 9087000010 WARRANTY CARD
35 6122000110 TOP COVER, VCM 0.95t 4428400110 MATCHING TRANS
36 6715000210 SPONGE, 260X20X1t 9705000110 POLY BAG
37 6122600120 FRAME T/F, SECC 1.0t 9057000010 FUSE LABEL
38 2828000107 T/F MAIN 9057000020 GRAPHIC LABEL
39 6715000310 SPONGE, 50X40X5t 9722000110 CUSHION POLY
40 2828000097 T/F STANDBY 9605000115 BOX CARTON(INNER)
41 6535000310 STUD SPACER(H:35mm),MBsBE1 9625000115 BOX CARTON(OUT)
42 6535000110 STUD SUPPORT(H:35mm),MBsBE1 9715000110 FILM SOFT PE ( BAG TYPE)
43 6535000120 STUD SUPPORT(H:45mm),MBsBE1 9057000110 LABEL UL(30X27 ))
44 7505000410 BRIDGE DIODE H/SINK 9057000210 LABEL 120V~60Hz
45 7505000310 H/SINK REG TR(46X12X30), AL 9057000220 LABEL 230V~50H z (CE)
46 7505000330 H/SINK REG TR(46X12X60), AL
47 6715000520 SPONGE PCB BTM, 70X30X12t
48 6715000810 SPONGE, 10X5X3t
49 4438100520 JACK RCA 3P(Y), VIDEO
50 4438100320 JACK RCA 6P(WWW,RRR)
51 4438100220 JACK RCA 4P(W,R)
52 4438500210 JACK RCA 3P, S-VHS
53 4438100730 JACK RCA 1P (B)
54 2408008001 OPTO JACK TOTX178A
PARTS NO. DESCRIPTIONNO. PARTS NO. DESCRIPTION NO.
6 WINDOW SENSOR ,ACRYL WINE
7 BUTTON 16KEY, ABS BLACK
SCREW
PACKING & LABELS
9 BUTTON F14, ABS BLACK
12 BTN CONNECTOR PUSH, ABS BLACK
BUTTON POWER RING, ABS BLACK10
11 SPRING BTN,SUS
5

AM Tuner
Sensitivity
500 uV/m
m
Signal to Noise Ratio
40 dBf
Output level
500 mV
Antenna Input
Loop Antenna
General
Power Consumption:
850 watts
Power Requirements (AC)
115 volts, 60Hz (USA)
230 volts, 50Hz (CE)
Weight
15 Kg/33 lb.
Dimensions (W x H x D)
445 x 160 x 400 mm
171/2 " x 6 1/4 " x 15 3/4 "
All specifications are accurate at the time of
printing.
Specifications
Audio
Continuous Amplifier Power
(all channels driven)
75 watts/ch (20-20k Hz, <0.09% THD, 8 ohms)
100 watts/ch (1kHz, <1.0% THD, 8 ohms, DIN)
Total Harmonic Distortion
<0.09%
Intermodulation Distortion (60 Hz:7kHz)
<0.09%
Frequency Response
10 Hz - 20 kHz, ±1 dB (line level)
10 Hz - 20 kHz, ±0.3 dB (digital level)
Signal to Noise Ratio (IHF A-weighted)
92 dB (Stereo) Analog
90 dB (Dolby Digital, dts) 0dBFs
Input Sensitivity/Impedance
Line Level: 200 mV/47 kohms
Tone Controls (Bass/Treble)
±8 dB at 100 Hz/10 kHz
Line Output Level
600 mV (200 mV Input)
Video
Frequency Response
3 Hz-10 MHz, ± 3 dB
Signal to Noise Ratio
45 dB
Input Impedance
75 ohms
Output Impedance
75 ohms
Output Level
1 volt
FM Tuner
Usable Sensitivity
14.2 dBf
Signal to Noise Ratio (at 65 dBf)
70 dBf
Harmonic Distortion (at 65 dBf)
0.03%
Stereo Separation (1 kHz)
45 dB
Output level
1 V
Antenna Input
75 ohms unbalanced
6

Parts List 1/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
CR212 3479347181 CAP E SG 470uF/63V
4002000200 PCB Assembly CSL212 3479347181 CAP E SG 470uF/63V
CC209 3519181935 CAP C AXIAL 180PF/50V J CSR212 3479347181 CAP E SG 470uF/63V
CL209 3519181935 CAP C AXIAL 180PF/50V J C216 3479347071 CAP E SG 47uF/50V
CR209 3519181935 CAP C AXIAL 180PF/50V J CP201 4428510416 CNT PLUG ST GIL-S-10P-S2T2-EF
CSL209 3519181935 CAP C AXIAL 180PF/50V J LC201 2648601470 COIL INDUCTOR 0.5UH
CSR209 3519181935 CAP C AXIAL 180PF/50V J LL201 2648601470 COIL INDUCTOR 0.5UH
CC202 3519271935 CAP C AXIAL 270PF/50V J LR201 2648601470 COIL INDUCTOR 0.5UH
CL202 3519271935 CAP C AXIAL 270PF/50V J LSL201 2648601470 COIL INDUCTOR 0.5UH
CR202 3519271935 CAP C AXIAL 270PF/50V J LSR201 2648601470 COIL INDUCTOR 0.5UH
CSL202 3519271935 CAP C AXIAL 270PF/50V J CN204 436502122167 CTJ 0212 201,210 DL #18 P7.92
CSR202 3519271935 CAP C AXIAL 270PF/50V J CN202 436502452166 CTJ 0245 201,210 DL #18 P3.96
CC203 3519391935 CAP C AXIAL 390PF/50V J CN203 436503302166 CTJ 0330 201,210 DL #18 P3.96
CL203 3519391935 CAP C AXIAL 390PF/50V J CN205 436103083525 CTM 0308 5263,5394 DL #26 P2.5
CR203 3519391935 CAP C AXIAL 390PF/50V J DC201 2058322101 DIODE 1N4148
CSL203 3519391935 CAP C AXIAL 390PF/50V J DL201 2058322101 DIODE 1N4148
CSR203 3519391935 CAP C AXIAL 390PF/50V J DR201 2058322101 DIODE 1N4148
CC207 3519569935 CAP C AXIAL 5.6PF/50V J DSL201 2058322101 DIODE 1N4148
CL207 3519569935 CAP C AXIAL 5.6PF/50V J DSR201 2058322101 DIODE 1N4148
CR207 3519569935 CAP C AXIAL 5.6PF/50V J DC202 2058322101 DIODE 1N4148
CSL207 3519569935 CAP C AXIAL 5.6PF/50V J DL202 2058322101 DIODE 1N4148
CSR207 3519569935 CAP C AXIAL 5.6PF/50V J DR202 2058322101 DIODE 1N4148
CC211 3479310071 CAP E SG 10uF/50V DSL202 2058322101 DIODE 1N4148
CL211 3479310071 CAP E SG 10uF/50V DSR202 2058322101 DIODE 1N4148
CR211 3479310071 CAP E SG 10uF/50V ZD201 2258599120 DIODE ZENER T-72 UZ12V
CSL211 3479310071 CAP E SG 10uF/50V 4235007410 GND PLATE MET37-0002
CSR211 3479310071 CAP E SG 10uF/50V RC228-229 3029101270 RES MF 100 1/4W J
CC214 3479310071 CAP E SG 10uF/50V RL228-229 3029101270 RES MF 100 1/4W J
CL214 3479310071 CAP E SG 10uF/50V RR228-229 3029101270 RES MF 100 1/4W J
CR214 3479310071 CAP E SG 10uF/50V RSL228-229 3029101270 RES MF 100 1/4W J
CSL214 3479310071 CAP E SG 10uF/50V RSR228-229 3029101270 RES MF 100 1/4W J
CSR214 3479310071 CAP E SG 10uF/50V R237 30291003910 RES MF 100K 1/5W F
CC204 3479310971 CAP E SG 1uF/50V RC210 30291002910 RES MF 10K 1/5W F
CL204 3479310971 CAP E SG 1uF/50V RL210 30291002910 RES MF 10K 1/5W F
CR204 3479310971 CAP E SG 1uF/50V RR210 30291002910 RES MF 10K 1/5W F
CSL204 3479310971 CAP E SG 1uF/50V RSL210 30291002910 RES MF 10K 1/5W F
CSR204 3479310971 CAP E SG 1uF/50V RSR210 30291002910 RES MF 10K 1/5W F
C215 3479310971 CAP E SG 1uF/50V RC221-222 30291200910 RES MF 120 1/5W F
C217 3479310971 CAP E SG 1uF/50V RL221-222 30291200910 RES MF 120 1/5W F
CC206 3479322121 CAP E SG 220uF/10V RR221-222 30291200910 RES MF 120 1/5W F
CL206 3479322121 CAP E SG 220uF/10V RSL221-222 30291200910 RES MF 120 1/5W F
CR206 3479322121 CAP E SG 220uF/10V RSR221-222 30291200910 RES MF 120 1/5W F
CSL206 3479322121 CAP E SG 220uF/10V RC203-204 30291509910 RES MF 15 1/5W F
CSR206 3479322121 CAP E SG 220uF/10V RL203-204 30291509910 RES MF 15 1/5W F
CC205 3479322031 CAP E SG 22uF/16V RR203-204 30291509910 RES MF 15 1/5W F
CL205 3479322031 CAP E SG 22uF/16V RSL203-204 30291509910 RES MF 15 1/5W F
CR205 3479322031 CAP E SG 22uF/16V RSR203-204 30291509910 RES MF 15 1/5W F
CSL205 3479322031 CAP E SG 22uF/16V RC209 30291500910 RES MF 150 1/5W F
CSR205 3479322031 CAP E SG 22uF/16V RL209 30291500910 RES MF 150 1/5W F
CC201 3479347971 CAP E SG 4.7uF/50V RR209 30291500910 RES MF 150 1/5W F
CL201 3479347971 CAP E SG 4.7uF/50V RSL209 30291500910 RES MF 150 1/5W F
CR201 3479347971 CAP E SG 4.7uF/50V RSR209 30291500910 RES MF 150 1/5W F
CSL201 3479347971 CAP E SG 4.7uF/50V R243 30291503910 RES MF 150K 1/5W F
CSR201 3479347971 CAP E SG 4.7uF/50V RC201 30291001910 RES MF 1K 1/5W F
CC210 3479347181 CAP E SG 470uF/63V RL201 30291001910 RES MF 1K 1/5W F
CL210 3479347181 CAP E SG 470uF/63V RR201 30291001910 RES MF 1K 1/5W F
CR210 3479347181 CAP E SG 470uF/63V RSL201 30291001910 RES MF 1K 1/5W F
CSL210 3479347181 CAP E SG 470uF/63V RSR201 30291001910 RES MF 1K 1/5W F
CSR210 3479347181 CAP E SG 470uF/63V RC207 30291001910 RES MF 1K 1/5W F
CC212 3479347181 CAP E SG 470uF/63V RL207 30291001910 RES MF 1K 1/5W F
CL212 3479347181 CAP E SG 470uF/63V RR207 30291001910 RES MF 1K 1/5W F
AMPLIFIER PCB 4002000200
7

Parts List 2/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
RSL207 30291001910 RES MF 1K 1/5W F RL227 30294300910 RES MF 430 1/5W F
RSR207 30291001910 RES MF 1K 1/5W F RR227 30294300910 RES MF 430 1/5W F
RC226 30291201910 RES MF 1K2 1/5W F RSL227 30294300910 RES MF 430 1/5W F
RL226 30291201910 RES MF 1K2 1/5W F RSR227 30294300910 RES MF 430 1/5W F
RR226 30291201910 RES MF 1K2 1/5W F RC211 30294302910 RES MF 43K 1/5W F
RSL226 30291201910 RES MF 1K2 1/5W F RL211 30294302910 RES MF 43K 1/5W F
RSR226 30291201910 RES MF 1K2 1/5W F RR211 30294302910 RES MF 43K 1/5W F
R244 3029122470 RES MF 1K2 1W J RSL211 30294302910 RES MF 43K 1/5W F
R245 3029122470 RES MF 1K2 1W J RSR211 30294302910 RES MF 43K 1/5W F
RSL212 30291501910 RES MF 1K5 1/5W F RC214-220 30295600910 RES MF 560 1/5W F
RSR212 30291501910 RES MF 1K5 1/5W F RL214-220 30295600910 RES MF 560 1/5W F
RC212 30291501910 RES MF 1K5 1/5W F RR214-220 30295600910 RES MF 560 1/5W F
RL212 30291501910 RES MF 1K5 1/5W F RSL214-220 30295600910 RES MF 560 1/5W F
RR212 30291501910 RES MF 1K5 1/5W F RSR214-220 30295600910 RES MF 560 1/5W F
RC235 30291801910 RES MF 1K8 1/5W F RC208 30296809910 RES MF 68 1/5W F
RL235 30291801910 RES MF 1K8 1/5W F RL208 30296809910 RES MF 68 1/5W F
RR235 30291801910 RES MF 1K8 1/5W F RR208 30296809910 RES MF 68 1/5W F
RSL235 30291801910 RES MF 1K8 1/5W F RSL208 30296809910 RES MF 68 1/5W F
RSR235 30291801910 RES MF 1K8 1/5W F RSR208 30296809910 RES MF 68 1/5W F
RC223-224 30292202910 RES MF 22K 1/5W F R238 30296802910 RES MF 68K 1/5W F
RL223-224 30292202910 RES MF 22K 1/5W F RC238 30296801910 RES MF 6K8 1/5W F
RR223-224 30292202910 RES MF 22K 1/5W F RL238 30296801910 RES MF 6K8 1/5W F
RSL223-224 30292202910 RES MF 22K 1/5W F RR238 30296801910 RES MF 6K8 1/5W F
RSR223-224 30292202910 RES MF 22K 1/5W F RSL238 30296801910 RES MF 6K8 1/5W F
RC245 30292202910 RES MF 22K 1/5W F RSR238 30296801910 RES MF 6K8 1/5W F
RL245 30292202910 RES MF 22K 1/5W F RC205-206 30297500910 RES MF 750 1/5W F
RR245 30292202910 RES MF 22K 1/5W F RL205-206 30297500910 RES MF 750 1/5W F
RSL245 30292202910 RES MF 22K 1/5W F RR205-206 30297500910 RES MF 750 1/5W F
RSR245 30292202910 RES MF 22K 1/5W F RSL205-206 30297500910 RES MF 750 1/5W F
RC236 30292001910 RES MF 2K 1/5W F RSR205-206 30297500910 RES MF 750 1/5W F
RL236 30292001910 RES MF 2K 1/5W F RC237 30299100910 RES MF 910 1/5W F
RR236 30292001910 RES MF 2K 1/5W F RL237 30299100910 RES MF 910 1/5W F
RSL236 30292001910 RES MF 2K 1/5W F RR237 30299100910 RES MF 910 1/5W F
RSR236 30292001910 RES MF 2K 1/5W F RSL237 30299100910 RES MF 910 1/5W F
RC230 30293300910 RES MF 330 1/5W F RSR237 30299100910 RES MF 910 1/5W F
RL230 30293300910 RES MF 330 1/5W F RC233 3059027763 RES MPR 0.27X2 5W J
RR230 30293300910 RES MF 330 1/5W F RL233 3059027763 RES MPR 0.27X2 5W J
RSL230 30293300910 RES MF 330 1/5W F RR233 3059027763 RES MPR 0.27X2 5W J
RSR230 30293300910 RES MF 330 1/5W F RSL233 3059027763 RES MPR 0.27X2 5W J
RC202 30293302910 RES MF 33K 1/5W F RSR233 3059027763 RES MPR 0.27X2 5W J
RL202 30293302910 RES MF 33K 1/5W F QC209 2008607106 TR NPN 2SC3424(O/Y)
RR202 30293302910 RES MF 33K 1/5W F QL209 2008607106 TR NPN 2SC3425(O/Y)
RSL202 30293302910 RES MF 33K 1/5W F QR209 2008607106 TR NPN 2SC3426(O/Y)
RSR202 30293302910 RES MF 33K 1/5W F QSL209 2008607106 TR NPN 2SC3427(O/Y)
RC213 30293302910 RES MF 33K 1/5W F QSR209 2008607106 TR NPN 2SC3428(O/Y)
RL213 30293302910 RES MF 33K 1/5W F QC211 2028316100 TR NPN 2SC4883A-Y
RR213 30293302910 RES MF 33K 1/5W F QL211 2028316100 TR NPN 2SC4883A-Y
RSL213 30293302910 RES MF 33K 1/5W F QSL211 2028316100 TR NPN 2SC4883A-Y
RSR213 30293302910 RES MF 33K 1/5W F QSR211 2028316100 TR NPN 2SC4883A-Y
RC239-242 30293909910 RES MF 39 1/5W F QR211 2028316100 TR NPN 2SC4883A-Y
RL239-242 30293909910 RES MF 39 1/5W F Q216 2238006104 TR NPN KRC107M
RR239-242 30293909910 RES MF 39 1/5W F QC205-206 2208606108 TR NPN KTC3200(GR/BL)
RSL239-242 30293909910 RES MF 39 1/5W F QL205-206 2208606108 TR NPN KTC3200(GR/BL)
RSR239-242 30293909910 RES MF 39 1/5W F QR205-206 2208606108 TR NPN KTC3200(GR/BL)
R246 30293301910 RES MF 3K3 1/5W F QSL205-206 2208606108 TR NPN KTC3200(GR/BL)
RC231-232 30293308910 RES MF 3R3 1/5W F QSR205-206 2208606108 TR NPN KTC3200(GR/BL)
RL231-232 30293308910 RES MF 3R3 1/5W F QC215 2208606108 TR NPN KTC3200(GR/BL)
RR231-232 30293308910 RES MF 3R3 1/5W F QL215 2208606108 TR NPN KTC3200(GR/BL)
RSL231-232 30293308910 RES MF 3R3 1/5W F QR215 2208606108 TR NPN KTC3200(GR/BL)
RSR231-232 30293308910 RES MF 3R3 1/5W F QSL215 2208606108 TR NPN KTC3200(GR/BL)
RC227 30294300910 RES MF 430 1/5W F QSR215 2208606108 TR NPN KTC3200(GR/BL)
8

Parts List 3/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
QC208 2008207101 TR PNP 2SA1360(O/Y) C03 3479333971 CAP E SG 3.3uF/50V
QL208 2008207101 TR PNP 2SA1360(O/Y) C27 3479333971 CAP E SG 3.3uF/50V
QR208 2008207101 TR PNP 2SA1360(O/Y) C26 3479347971 CAP E SG 4.7uF/50V
QSL208 2008207101 TR PNP 2SA1360(O/Y) C28 3479347971 CAP E SG 4.7uF/50V
QSR208 2008207101 TR PNP 2SA1360(O/Y) C41 3479347971 CAP E SG 4.7uF/50V
QC212 2028016100 TR PNP 2SA1859A-Y C05 3479347031 CAP E SG 47uF/16V
QL212 2028016100 TR PNP 2SA1859A-Y C11 3479347031 CAP E SG 47uF/16V
QR212 2028016100 TR PNP 2SA1859A-Y C31 3679332120 CAP MYLAR 0.0033uF/100V J
QSL212 2028016100 TR PNP 2SA1859A-Y C30 3679223120 CAP MYLAR 0.022uF/100V J
QSR212 2028016100 TR PNP 2SA1859A-Y C48 3679223120 CAP MYLAR 0.022uF/100V J
QC201-204 2208206104 TR PNP KTA1268(GR/BL) C32 3679393120 CAP MYLAR 0.039uF/100V J
QL201-204 2208206104 TR PNP KTA1268(GR/BL) C15 3615471110 CAP POLY 470PF/50V J
QR201-204 2208206104 TR PNP KTA1268(GR/BL) CP100 4428505416 CNT PLUG ST GIL-S-5P-S2T2-EF
QR201-204 2208206104 TR PNP KTA1268(GR/BL) T03 2638231001 COIL AM IFT A7MC-K672713N4-KR
QSL201-204 2208206104 TR PNP KTA1268(GR/BL) T02 2628231001 COIL AM OSC 7BR-K111027X2-KR
QSR201-204 2208206104 TR PNP KTA1268(GR/BL) T01 2618231001 COIL AM-ANT1 M7ZN-K5643A-KR
QC207 2208206104 TR PNP KTA1268(GR/BL) T04 2838501111 COIL FM-DET-A1 292BCA-K5713FKG
QL207 2208206104 TR PNP KTA1268(GR/BL) T05 2838501112 COIL FM-DET-B1 292BCA-K5714X
QL207 2208206104 TR PNP KTA1268(GR/BL) L01 2648601430 COIL INDUCTOR 20.8mH
QR207 2208206104 TR PNP KTA1268(GR/BL) TL06 2658031001 COIL MPX LPF 253AGG-K5001-KR
QSL207 2208206104 TR PNP KTA1268(GR/BL) TR06 2658031001 COIL MPX LPF 253AGG-K5001-KR
QSR207 2208206104 TR PNP KTA1268(GR/BL) CN502 436208103524 CTG 0810 S08,T08 DL #26 P2.0
Q217 2208206104 TR PNP KTA1268(GR/BL) D02 2058322101 DIODE 1N4148
VD01-VD02 2258817101 DIODE VARACTOR SVC321SPA-C
ZD01 2258599519 DIODE ZENER T-72 UZ5V1
4002002300 PCB TUNER 197*197 FR-1 ZD03 2258599519 DIODE ZENER T-72 UZ5V1
C04 3536103122 CAP C 2012 CHIP 0.01uF/50V J CF04 3908001020 FILTER BFU450C4N
C07 3536103122 CAP C 2012 CHIP 0.01uF/50V J CF01-CF03 3908011071 FILTER FM IF SFE10.7MA5
C23 3536103122 CAP C 2012 CHIP 0.01uF/50V J FE01 3928101870 FRONT-END FTA4-460H
C10 3536101122 CAP C 2012 CHIP 100PF/50V J IC04 2169202101 IC BU1920F RDS
CLU52 3536100122 CAP C 2012 CHIP 10PF/50V J IC02 2168017128 IC LA1266 IF
CRU52 3536100122 CAP C 2012 CHIP 10PF/50V J IC03 2168417120 IC LA3401 MPX
CL50 3536121122 CAP C 2012 CHIP 120PF/50V J IC01 2138017136 IC LM7001 PLL
CR50 3536121122 CAP C 2012 CHIP 120PF/50V J JLE/U100 4428804966 JUMPER HEADER 4P P2.5 H3.0
C54 3536271122 CAP C 2012 CHIP 270PF/50V J JRE/U100 4428804966 JUMPER HEADER 4P P2.5 H3.0
C36 3536331122 CAP C 2012 CHIP 330PF/50V J C01 3536223122 CAP C 2012 CHIP 0.022uF/50V J
C43 3536681122 CAP C 2012 CHIP 680PF/50V J C06 3536223122 CAP C 2012 CHIP 0.022uF/50V J
CL52 3536680122 CAP C 2012 CHIP 68PF/50V J C12-C13 3536223122 CAP C 2012 CHIP 0.022uF/50V J
CR52 3536680122 CAP C 2012 CHIP 68PF/50V J C17-C18 3536223122 CAP C 2012 CHIP 0.022uF/50V J
CLU50 3536820122 CAP C 2012 CHIP 82PF/50V J C21-C22 3536223122 CAP C 2012 CHIP 0.022uF/50V J
CRU50 3536820122 CAP C 2012 CHIP 82PF/50V J C24-C25 3536223122 CAP C 2012 CHIP 0.022uF/50V J
C38 3579101530 CAP C RADIAL 100PF/50V J C29 3536223122 CAP C 2012 CHIP 0.022uF/50V J
C16 3528150210 CAP C RADIAL 15PF/50V(CH) J C34 3536223122 CAP C 2012 CHIP 0.022uF/50V J
C08-C09 3528180210 CAP C RADIAL 18PF/50V(CH) J C40 3536223122 CAP C 2012 CHIP 0.022uF/50V J
C58-C59 3528270210 CAP C RADIAL 27PF/50V(CH) J C02 3536473122 CAP C 2012 CHIP 0.047uF/50V J
C37 3579820530 CAP C RADIAL 82PF/50V J C42 3536473122 CAP C 2012 CHIP 0.047uF/50V J
C57 3536104122 CAP CHIP 2012 0.1uF/50V J 4448402966 JUMPER SHUNT 2P P2.5
C46 3479322871 CAP E SG 0.22uF/50V J11,J20,J30 OPEN OPEN
C14 3479310131 CAP E SG 100uF/16V R16 3099101170 RES CHIP 2012 100 J
C35 3479310131 CAP E SG 100uF/16V R34 3099101170 RES CHIP 2012 100 J
C44 3479310131 CAP E SG 100uF/16V R39 3099101170 RES CHIP 2012 100 J
C20 3479310071 CAP E SG 10uF/50V R01 3099104170 RES CHIP 2012 100K J
C39 3479310071 CAP E SG 10uF/50V R04 3099104170 RES CHIP 2012 100K J
C49 3479310071 CAP E SG 10uF/50V R06 3099104170 RES CHIP 2012 100K J
C53 3479310071 CAP E SG 10uF/50V R07 3099103170 RES CHIP 2012 10K J
C55-C56 3479310071 CAP E SG 10uF/50V R27 3099103170 RES CHIP 2012 10K J
CL51 3479310071 CAP E SG 10uF/50V R11 3099181170 RES CHIP 2012 180 J
CR51 3479310071 CAP E SG 10uF/50V R10 3099102170 RES CHIP 2012 1K J
C33 3479310971 CAP E SG 1uF/50V R17-19 3099102170 RES CHIP 2012 1K J
C45 3479310971 CAP E SG 1uF/50V R38 3099102170 RES CHIP 2012 1K J
C47 3479310971 CAP E SG 1uF/50V RL57 3099152170 RES CHIP 2012 1K5 J
TUNER PCB ASSEMBLY
9

Parts List 4/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
RR57 3099152170 RES CHIP 2012 1K5 J C118 3519103915 CAP C AXIAL 0.01uF/16V J
R35 3099182170 RES CHIP 2012 1K8 J C100 3519473935 CAP C AXIAL 0.047uF/50V J
R29 3099220170 RES CHIP 2012 22 J C112-C113 3519473935 CAP C AXIAL 0.047uF/50V J
R37 3099220170 RES CHIP 2012 22 J C101-C104 3519101935 CAP C AXIAL 100PF/50V J
R28 3099223170 RES CHIP 2012 22K J C106-107 3519101935 CAP C AXIAL 100PF/50V J
R41 3099223170 RES CHIP 2012 22K J C119-C121 3519101935 CAP C AXIAL 100PF/50V J
R43 3099223170 RES CHIP 2012 22K J C108-C111 3519821935 CAP C AXIAL 820PF/50V J
R08 3099271170 RES CHIP 2012 270 J C114 3479310971 CAP E SG 1uF/50V
R21 3099271170 RES CHIP 2012 270 J C117 3479347971 CAP E SG 4.7uF/50V
RR46 3099274170 RES CHIP 2012 270K J CP109 4428502415 CNT PLUG AN GIL-S-2P-S2L2-EF
RR47 3099274170 RES CHIP 2012 270K J CN403 436205403524 CTG 0540 S05,T05 DL #26 P2.0
RL46 3099274170 RES CHIP 2012 270K J CN106 436208403524 CTG 0840 S08,T08 DL #26 P2.0
RL47 3099274170 RES CHIP 2012 270K J CN104 436210083524 CTG 1008 S10,T10 DL #26 P2.0
RR48 3099272170 RES CHIP 2012 2K7 J D101-D104 2058322101 DIODE 1N4148
RL48 3099272170 RES CHIP 2012 2K7 J ESW102-103 3218000410 EC16B2420431(WITH DETENT)
R56 3099225170 RES CHIP 2012 2M2 J ESW101 3218000310 EC16B243040H(W/O DETENT)
R20 3099331170 RES CHIP 2012 330 J FIP100 2328000302 FIP SVR08LM02(LEAD 15MM)
R13 3099332170 RES CHIP 2012 3K3 J 6715000620 SPONGE FIP(30x15X5T)RSX972
R33 3099332170 RES CHIP 2012 3K3 J IC100 2138322010 IC OTP CXP828P60Q-1
R42 3099332170 RES CHIP 2012 3K3 J J??? 1508400602 JUMPER
RL49 3099332170 RES CHIP 2012 3K3 J RMC101 2408000190 REMOCON SENSOR SBX3010-52B
RR49 3099332170 RES CHIP 2012 3K3 J R127-R142 3099124170 RES CHIP 2012 120K J
R31 3099392170 RES CHIP 2012 3K9 J R114-R119 3029103970 RES MF 10K 1/8W J
R05 3099471170 RES CHIP 2012 470 J R121 3029181970 RES MF 180 1/8W J
R15 3099471170 RES CHIP 2012 470 J R101-R104 3029102970 RES MF 1K 1/8W J
R22 3099471170 RES CHIP 2012 470 J R123-R126 3029102970 RES MF 1K 1/8W J
R26 3099473170 RES CHIP 2012 47K J R120 3029470970 RES MF 47 1/8W J
R36 3099473170 RES CHIP 2012 47K J R105-R108 3029473970 RES MF 47K 1/8W J
R40 3099473170 RES CHIP 2012 47K J R110-R113 3029473970 RES MF 47K 1/8W J
R44 3099473170 RES CHIP 2012 47K J R122 3029472970 RES MF 4K7 1/8W J
R24 3099472170 RES CHIP 2012 4K7 J SW117-132 4658000210 SW TACT SKHVBHD010
R30 3099472170 RES CHIP 2012 4K7 J X101 3938124010 RESONATOR CST10.0MTW-TF01
R09 3099561170 RES CHIP 2012 560 J Q101 2208606104 TR NPN KTC3198Y-AT
R12 3099561170 RES CHIP 2012 560 J
R14 3099561170 RES CHIP 2012 560 J
R02 3099562170 RES CHIP 2012 5K6 J 4002002410 PCB KEY B'D ( PCB Front )
R32 3099562170 RES CHIP 2012 5K6 J CP104 4428510416 CNT PLUG ST GIL-S-10P-S2T2-EF
R03 3099623170 RES CHIP 2012 62K J SW101-116 4658000210 SW TACT SKHVBHD010
R50 3099681170 RES CHIP 2012 680 J
R25 3099683170 RES CHIP 2012 68K J
X02 3938131600 RESONATOR CSB-456F15 4002002420 POWER SW B'D ( PCB Front )
J??? 1508400602 TAPING JUMPER 0.6mm CS100 3549472109 CAP C 0.0047UF/400V AC
ANT01 4408000320 TERMINAL ANT(GND),SC0210586N CNT105 436502402147 CTJ 0240 201,210 DL #22 P7.92
QL08 2238422100 TR NPN DTC323TSTP SW100 4628000110 SW PWR SDDLB15700
QR08 2238422100 TR NPN DTC323TSTP
Q03 2208406103 TR NPN KTC3194Y(KTC1923Y)
Q01-Q02 2208606104 TR NPN KTC3198Y-AT 4002002430 SUB-D1 B'D ( PCB Front )
Q07 2208606104 TR NPN KTC3198Y-AT CP200-CP201 4428811526 CNT BtoB HOUSING MO 42140-2211
Q04-06 2238006103 TR PNP KRA107M CP202 4428807526 CNT BtoB HOUSING MO 42140-2207
Q09 2238006103 TR PNP KRA107M IC203 2168020107 IC NJU7312AL ANALOG SWICH
TC01 3838001000 TRIMMER 10PF TZ03-T110FR(WHT)
VR03 3248022443 VR SEMI 220K(B)-H RH063MCJ5R
VR02 3248047343 VR SEMI 47K(B)-H RH063MCS4R 4002002440 SUB-D2 B'D ( PCB Front )
VR01 3248047243 VR SEMI 4K7(B)-H RH063MCS3R CPT600-601 4428811526 CNT BtoB HOUSING MO 42140-2211
X03 3908111690 X-TAL 4.332MHZ CPT602 4428807526 CNT BtoB HOUSING MO 42140-2207
X01 3908101030 X-TAL 7.2MHZ IC606 2168020109 IC TC9163AN ANALOG SWITCH
4002002400 PCB FRONT 330*247 X1 FR1 4002002450 SUB-D3 B'D ( PCB Front )
6515000110 HOLDER FL, ABS BLACK XR-401 CP200A-201A 4428811526 CNT BtoB HOUSING MO 42140-2211
C115 3519103915 CAP C AXIAL 0.01uF/16V J CP202A 4428807526 CNT BtoB HOUSING MO 42140-2207
KEY B'D PCB ASSEMBLY (PCB FRONT)
POWER SW B'D PCB ASSEMBLY (PCB FRONT)
SUB-D1 B'D PCB ASSEMBLY (PCB FRONT)
SUB-D2 B'D PCB ASSEMBLY (PCB FRONT)
CONTROL B'D PCB ASSEMBLY (PCB FRONT) SUB-D3 B'D PCB ASSEMBLY (PCB FRONT)
10

Parts List 5/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
IC204 2168020107 IC NJU7312AL ANALOG SWICH C951-C954 3679473120 CAP MYLAR 0.047uF100V J
C967-C970 3679472120 CAP MYLAR 0.0047uF100V J
CT202 4428502646 CNT PLUG ST JE202A-1 T-2 P3.96
4002002470 GUIDE B'D ( PCB Front ) CT910 4428502646 CNT PLUG ST JE202A-1 T-2 P3.96
J272-J277 1508400602 JUMPER CT203 4428503646 CNT PLUG ST JE202A-1 T-3 P3.96
CT911 4428503646 CNT PLUG ST JE202A-1 T-3 P3.96
CNT951 436502132166 CTJ 0213 201,210 DL #18 P3.96
4002002480 GUIDE B'D ( PCB Front ) 4002002600 PCB SPEAKER 197*163 FR1
J266-J271 1508400602 JUMPER R951-R954 3029100570 RES MF 10 2W J
JAK951-952 4408101010 SPEAKER TERMINAL 4P(RB,RB)
J19-J20 1508400602 TAPING JUMPER 0.6mm
4002002460 S-VIDEO B'D ( PCB Front)
C601-C602 3479310123 CAP E SG 100uF/10V
C603-C604 3519104935 CAP C AXIAL 0.1uF/50V J C966 3679472120 CAP MYLAR 0.0047UF100V J
C605-C606 3479310123 CAP E SG 100uF/10V C955 3679473120 CAP MYLAR 0.047UF/100V J
C607-C608 3519104935 CAP C AXIAL 0.1uF/50V J CT951 4428502646 CNT PLUG ST JE202A-1 T-2 P3.96
C609-C612 3479347041 CAP E SG 47uF/25V R955 3029100570 RES MF 10 2W J
C613-C620 3479310123 CAP E SG 100uF/10V 4002002610 CENTER B'D PCB ( PCB SPEAKER )
C621 3479347121 CAP E SG 470uF/10V JAK953 4408101110 SPEAKER TERMINAL2P(R,B)
C622 3479310123 CAP E SG 100uF/10V
C623 3479347121 CAP E SG 470uF/10V
C624 3479310123 CAP E SG 100uF/10V 4002002620 TERMINAL B'D PCB ( PCB Speaker )
C625 3479347121 CAP E SG 470uF/10V C867 3519104935 CAP C AXIAL 0.1uF/50V J
C626 3479310123 CAP E SG 100uF/10V C869 3519104935 CAP C AXIAL 0.1uF/50V J
C627 3479347121 CAP E SG 470uF/10V C161-C166 3519101935 CAP C AXIAL 100PF/50V J
C628 3479310123 CAP E SG 100uF/10V C863-C866 3479310123 CAP E SG 100uF/10V
C629 3519103915 CAP C AXIAL 0.01uF/16V J C868 3479310123 CAP E SG 100uF/10V
C630 3479322971 CAP E SG 2.2uF/50V C861-C862 3479347041 CAP E SG 47uF/25V
C631 3479310971 CAP E SG 1uF/50V CN407 436211163524 CTG 1116 S11,T11 DL #26 P2.0
C632 3479310071 CAP E SG 10uF/50V D181-183 2058322101 DIODE 1N4148
CN404 436209143524 CTG 0914 S09,T09 DL #26 P2.0 CP108 4428503416 CNT PLUG ST GIL-S-3P-S2T2-EF
CNP600-CNP601 4428811620 CNT PIN BASE 11P P2.5 H20 CP107 4428505416 CNT PLUG ST GIL-S-5P-S2T2-EF
CNP602 4428807620 CNT PIN BASE 7P P2.5 H20 CP602 4428508416 CNT PLUG ST GIL-S-8P-S2T2-EF
CP601 4428510416 CNT PLUG ST GIL-S-10P-S2T2-EF IC861 2168020109 IC TC9163AN ANALOG SWITCH
D601-D604 2058322101 DIODE 1N4148 IC862 2169525001 IC TSH94IN QUAD VIDEO AMP
IC601 2168020109 IC TC9163AN ANALOG SWITCH JAK957-959 4438300210 JACK 2P(φ3.5)HSJ1002-01-1020
IC602-603 2169525001 IC TSH94IN QUAD VIDEO AMP JAK955 4438100920 JACK RCA 2P (B,B WOOFER)
J??? 1508400602 JUMPER JAK956 4438100120 JACK RCA 2P(W,R)
JK601-JK603 4438500220 JACK S-VIDEO 3P YKF51-5520 JAK954 4438100220 JACK RCA 4P(WW,RR)
Q600 2208206120 TR PNP KTA1271 JAK960 4438101220 JACK RCA 9P(GR,BL,R)
Q601 2208206105 TR PNP KTA1266Y IC101,IC103 2408000136 OPTO. COUPLER LTV-817
Q602 2238006103 TR PNP KRA107M R185-R186 3029100970 RES MF 10 1/8W J
Q603-Q605 2238006104 TR NPN KRC107M R180-R181 3029101970 RES MF 100 1/8W J
R600 3029470970 RES MF 47 1/8W J R874 3029101970 RES MF 100 1/8W J
R601-R616 3029750970 RES MF 75 1/8W J R880 3029101970 RES MF 100 1/8W J
R617-R618 3029680970 RES MF 68 1/8W J R886 3029101970 RES MF 100 1/8W J
R627-R630 3029221970 RES MF 220 1/8W J R157-R162 3029104970 RES MF 100K1/8W J
R631 3029333970 RES MF 33K 1/8W J R873 3029103970 RES MF 10K 1/8W J
R632 3029222970 RES MF 2K2 1/8W J R879 3029103970 RES MF 10K 1/8W J
R633 3029560970 RES MF 56 1/8W J R885 3029103970 RES MF 10K 1/8W J
R634 3029473970 RES MF 47K 1/8W J R167-172 3029102970 RES MF 1K 1/8W J
R635 3029272970 RES MF 2K7 1/8W J R183-R184 3029102970 RES MF 1K 1/8W J
R637 3029123970 RES MF 12K 1/8W J R871-R872 3029102970 RES MF 1K 1/8W J
R638 3029103970 RES MF 10K 1/8W J R877-R878 3029102970 RES MF 1K 1/8W J
R639 3029181970 RES MF 180 1/8W J R883-R884 3029102970 RES MF 1K 1/8W J
R641-R648 3029101970 RES MF 100 1/8W J R887 3029102970 RES MF 1K 1/8W J
R649-R656 3029103970 RES MF 10K 1/8W J R867-R868 3029221970 RES MF 220 1/8W J
R657-R672 3029102970 RES MF 1K 1/8W J R869 3029223970 RES MF 22K 1/8W J
R673-R674 3029103970 RES MF 10K 1/8W J R875 3029223970 RES MF 22K 1/8W J
R881 3029223970 RES MF 22K 1/8W J
R193-R194 3029472970 RES MF 4K7 1/8W J
TERMINAL B'D PCB ASSEMBLY (PCB SPEAKER)
SPEAKER B'D PCB ASSEMBLY (PCB SPEAKER)
GUIDE B'D PCB ASSEMBLY (PCB FRONT)
GUIDE B'D PCB ASSEMBLY (PCB FRONT)
S-VIDEO B'D PCB ASSEMBLY (PCB FRONT)
CENTER SPKR B'D PCB ASSEMBLY (PCB SPEAKER)
11

Parts List 6/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
R861-R866 3029750970 RES MF 75 1/8W J C921 3479347071 CAP E SG 47uF/50V
R870 3029750970 RES MF 75 1/8W J C922-934 3679103120 CAP MYLAR 0.01uF/100V J
R876 3029750970 RES MF 75 1/8W J CP900 4428525810 CNT LV PIN BASE 1P
R882 3029750970 RES MF 75 1/8W J CN200 4428811627 CNT PIN BASE 11P P2.5 H27
J??? 1508400602 TAPING JUMPER 0.6mm CN201 4428811627 CNT PIN BASE 11P P2.5 H27
CN202 4428807627 CNT PIN BASE 7P P2.5 H27
CP906 4428502526 CNT PLUG ST MO 5267-02
4002002500 PCB MAIN 330*247 X1 FR1 CP903 4428503526 CNT PLUG ST MO 5267-03
C825 3579103530 CAP C RADIAL 0.01uF/50V J CP908 4428503526 CNT PLUG ST MO 5267-03
C200 3579223530 CAP C RADIAL 0.022uF/50V J CP904 4428507526 CNT PLUG ST MO 5267-07
C814-815 3579104530 CAP C RADIAL 0.1uF/50V J CN901 436202083524 CTG 0208 S02,T02 DL #26 P2.0
C828 3579104530 CAP C RADIAL 0.1uF/50V J CN108 436203203524 CTG 0320 S03,T03 DL #26 P2.0
C832 3579104530 CAP C RADIAL 0.1uF/50V J CN405 436204103524 CTG 0410 S04,T04 DL #26 P2.0
C917 3579104530 CAP C RADIAL 0.1uF/50V J CN100 436205123524 CTG 0512 S05,T05 DL #26 P2.0
C201-248 3579101530 CAP C RADIAL 100PF/50V J CN107 436205263524 CTG 0526 S05,T05 DL #26 P2.0
C267-268 3579101530 CAP C RADIAL 100PF/50V J CN602 436208143524 CTG 0814 S08,T08 DL #26 P2.0
C273-274 3579101530 CAP C RADIAL 100PF/50V J CN601 436210103524 CTG 1010 S10,T10 DL #26 P2.0
C289-290 3579101530 CAP C RADIAL 100PF/50V J CN402 436212103524 CTG 1210 S12,T12 DL #26 P2.0
C295-296 3579101530 CAP C RADIAL 100PF/50V J CN401 436215103524 CTG 1510 S15,T15 DL #26 P2.0
C301-302 3579101530 CAP C RADIAL 100PF/50V J D901-914 2258128002 DIODE 1N4004
C357-359 3579101530 CAP C RADIAL 100PF/50V J D918 2258128002 DIODE 1N4004
C362-365 3579101530 CAP C RADIAL 100PF/50V J D801-803 2058322101 DIODE 1N4148
C824 3579101530 CAP C RADIAL 100PF/50V J D915-917 2058322101 DIODE 1N4148
C829 3579101530 CAP C RADIAL 100PF/50V J D919 2058322101 DIODE 1N4148
C830-831 3528330210 CAP C RADIAL 33PF/50V(CH) J D930 2058322101 DIODE 1N4148
C819-820 3528560210 CAP C RADIAL 56PF/50V(CH) J D922 2258599120 DIODE ZENER T-72 UZ12V
C826 3479347871 CAP E SG 0.47uF/50 D920 2258599270 DIODE ZENER T-72 UZ27V
C906 3409310331 CAP E SG 10000uF/16V D923 2258599439 DIODE ZENER T-72 UZ4V3
C901 3419510241 CAP E SG 1000uF/25V D921 2258599919 DIODE ZENER T-72 UZ9V1
C805-808 3479310123 CAP E SG 100uF/10V D924 2258599919 DIODE ZENER T-72 UZ9V1
C812-813 3479310123 CAP E SG 100uF/10V D932 2258599919 DIODE ZENER T-72 UZ9V1
C816-817 3479310123 CAP E SG 100uF/10V CP905 4428504416 CNT PLUG ST GIL-S-4P-S2T2-EF
C827 3479310123 CAP E SG 100uF/10V CP106 4428508416 CNT PLUG ST GIL-S-8P-S2T2-EF
C833 3479310123 CAP E SG 100uF/10V F903-904 5508322433 FUSE LT5 T2A/250V RADIAL
C909 3479310131 CAP E SG 100uF/16V GND01 4235007410 GND PLATE MET37-0002
C809 3479310071 CAP E SG 10uF/50V HS1 7505000310 H/SINK REG TR (46X12X30)
C919 3479310071 CAP E SG 10uF/50V HS2 7505000330 H/SINK REG TR (46X12X60)
C821-822 3479310971 CAP E SG 1uF/50V HS4 7505000330 H/SINK REG TR (46X12X60)
C910-916 3479310971 CAP E SG 1uF/50V IC901-903 2168602105 IC KIA7805P REG.
C823 3479322971 CAP E SG 2.2uF/50V IC905 2168602106 IC KIA7806PI REG
C904-905 3409322231 CAP E SG 2200uF/16V IC907 2168602109 IC KIA7815PI REG.
C908 3479322141 CAP E SG 220uF/25V IC904 2168602113 IC KIA7906PI MOLD REG
C920 3479322071 CAP E SG 22uF/50V IC906 2168602115 IC KIA7915PI MOLD REG
C902-903 3409333261 CAP E SG 3300uF/35V IC801 2168222113 IC KS5520 OSD
C265-266 3479347971 CAP E SG 4.7uF/50V IC205-209 2168220135 IC NJM5532D DUAL OPAMP
C271-272 3479347971 CAP E SG 4.7uF/50V IC302-303 2168220135 IC NJM5532D DUAL OPAMP
C275-277 3479347971 CAP E SG 4.7uF/50V IC201-202 2168020107 IC NJU7312AL ANALOG SWICH
C288 3479347971 CAP E SG 4.7uF/50V IC802 2168020109 IC TC9163AN ANALOG SWITCH
C291-294 3479347971 CAP E SG 4.7uF/50V IC301 2138007110 IC TC9459N DIP ELEC. VOL
C297-300 3479347971 CAP E SG 4.7uF/50V IC803 2169525001 IC TSH94IN QUAD VIDEO AMP
C303-304 3479347971 CAP E SG 4.7uF/50V L802 2648610082 INDUCTOR AXIAL LAL02TB 100K
C355-356 3479347971 CAP E SG 4.7uF/50V L801 2648610182 INDUCTOR AXIAL LAL02TB 101K
C360-361 3479347971 CAP E SG 4.7uF/50V JK801-803 4438100520 JACK RCA 3P(Y)
C366-367 3479347971 CAP E SG 4.7uF/50V JK201 4438100220 JACK RCA 4P(WW,RR)
C801-804 3479347121 CAP E SG 470uF/10V JK202-204 4438100320 JACK RCA 6P(WWW,RRR)
C935 3479347121 CAP E SG 470uF/10V R843 3029100970 RES MF 10 1/8W J
C249-264 3479347041 CAP E SG 47uF/25V R808-810 3029101970 RES MF 100 1/8W J
C351-354 3479347041 CAP E SG 47uF/25V R802 3029101970 RES MF 100 1/8W J
C368-369 3479347041 CAP E SG 47uF/25V R249-250 3029104970 RES MF 100K1/8W J
C810-811 3479347041 CAP E SG 47uF/25V R253-254 3029104970 RES MF 100K1/8W J
C918 3479347041 CAP E SG 47uF/25V R259-260 3029104970 RES MF 100K1/8W J
MAIN PCB ASSEMBLY
12

Parts List 7/8
SYMBOL PART NO. DESCRIPTION SYMBOL PART NO. DESCRIPTION
R265-266 3029104970 RES MF 100K1/8W J R826 3029470970 RES MF 47 1/8W J
R271-272 3029104970 RES MF 100K1/8W J R854 3029470970 RES MF 47 1/8W J
R277-278 3029104970 RES MF 100K1/8W J R907 3029470970 RES MF 47 1/8W J
R283-284 3029104970 RES MF 100K1/8W J R902-903 3029470970 RES MF 47 1/8W J
R289-290 3029104970 RES MF 100K1/8W J R909 3029470970 RES MF 47 1/8W J
R295-296 3029104970 RES MF 100K1/8W J R912 3029470970 RES MF 47 1/8W J
R301-302 3029104970 RES MF 100K1/8W J R251-252 3029472970 RES MF 4K7 1/8W J
R357-358 3029104970 RES MF 100K1/8W J R261-262 3029472970 RES MF 4K7 1/8W J
R368-369 3029104970 RES MF 100K1/8W J R273-274 3029472970 RES MF 4K7 1/8W J
R374-375 3029104970 RES MF 100K1/8W J R285-286 3029472970 RES MF 4K7 1/8W J
R838 3029104970 RES MF 100K1/8W J R297-298 3029472970 RES MF 4K7 1/8W J
R801 3029103970 RES MF 10K 1/8W J R306 3029472970 RES MF 4K7 1/8W J
R803 3029103970 RES MF 10K 1/8W J R359-360 3029472970 RES MF 4K7 1/8W J
R811-813 3029103970 RES MF 10K 1/8W J R372-373 3029472970 RES MF 4K7 1/8W J
R911 3029103970 RES MF 10K 1/8W J R379 3029472970 RES MF 4K7 1/8W J
R821 3029121970 RES MF 120 1/8W J R841 3029472970 RES MF 4K7 1/8W J
R800 3029123970 RES MF 12K 1/8W J R905 3029472970 RES MF 4K7 1/8W J
R834 3029181970 RES MF 180 1/8W J R824-825 3029563970 RES MF 56K 1/8W J
R847 3029181970 RES MF 180 1/8W J R840 3029512970 RES MF 5K1 1/8W J
R201-224 3029102970 RES MF 1K 1/8W J R827 3029680970 RES MF 68 1/8W J
R232-236 3029102970 RES MF 1K 1/8W J R822-823 3029682970 RES MF 6K8 1/8W J
R247-248 3029102970 RES MF 1K 1/8W J R921 3029682970 RES MF 6K8 1/8W J
R257-258 3029102970 RES MF 1K 1/8W J R804-807 3029750970 RES MF 75 1/8W J
R267-270 3029102970 RES MF 1K 1/8W J R849-853 3029750970 RES MF 75 1/8W J
R279-282 3029102970 RES MF 1K 1/8W J Q301-302 2238422100 TR NPN DTC323TSTP
R291-294 3029102970 RES MF 1K 1/8W J Q201-208 2238422100 TR NPN DTC323TSTP
R303-305 3029102970 RES MF 1K 1/8W J Q213 2208606104 TR NPN KTC3198Y-AT
R355 3029102970 RES MF 1K 1/8W J Q304 2208606104 TR NPN KTC3198Y-AT
R356 3029102970 RES MF 1K 1/8W J Q902-905 2208606104 TR NPN KTC3198Y-AT
R361-363 3029102970 RES MF 1K 1/8W J Q803-804 2208606120 TR NPN KTC3203
R366-367 3029102970 RES MF 1K 1/8W J Q209-212 2238006103 TR PNP KRA107M
R370-371 3029102970 RES MF 1K 1/8W J Q303 2238006103 TR PNP KRA107M
R376-377 3029102970 RES MF 1K 1/8W J Q901 2208206105 TR PNP KTA1266Y
R814-820 3029102970 RES MF 1K 1/8W J Q801-802 2208206120 TR PNP KTA1271
R835-837 3029102970 RES MF 1K 1/8W J Q805 2208206120 TR PNP KTA1271
R855-857 3029102970 RES MF 1K 1/8W J X801 3938201950 X-TAL 14.31818MHZ
R904 3029102970 RES MF 1K 1/8W J
R906 3029102970 RES MF 1K 1/8W J
R910 3029102970 RES MF 1K 1/8W J
R923 3029102970 RES MF 1K 1/8W J
R845 3029122970 RES MF 1K2 1/8W J
R924 3029152970 RES MF 1K5 1/8W J
R255-256 3029182970 RES MF 1K8 1/8W J
R846 3029105970 RES MF 1M 1/8W J
R848 3029109970 RES MF 1R 1/8W J
R913-914 3029109970 RES MF 1R 1/8W J
RW905 3029109470 RES MF 1R 1W J
R839 3029204970 RES MF 200K 1/8W J
R830,831 3029220970 RES MF 22 1/8W J
R901 3029220470 RES MF 22 1W J
R225-230 3029221970 RES MF 220 1/8W J
R237-246 3029221970 RES MF 220 1/8W J
R351-354 3029221970 RES MF 220 1/8W J
R364-365 3029221970 RES MF 220 1/8W J
R832-833 3029221970 RES MF 220 1/8W J
R842 3029223970 RES MF 22K 1/8W J
R828-829 3029222970 RES MF 2K2 1/8W J
R908 3029222970 RES MF 2K2 1/8W J
RW901-904 3029229470 RES MF 2R2 1W J
R378 3029332970 RES MF 3K3 1/8W J
R844 3029392970 RES MF 3K9 1/8W J
13

Parts List (8/8)
SYMBOL PARTS NO. DESCRIPTION SYMBOL PARTS NO. DESCRIPTION
4002002800 PCB DIGITAL IC402 2408008001 OPTO JACK TOTX178A
L401-405,L503-505 2648702148 BEAD COIL CHIP 2012 CIM 21J 102 R526,528,535-536,539,C417,C422 3099000170 RES CHIP 2012 0R J
L501,L502 2648702149 BEAD COIL CHIP 2012 CIM 21P 110 R425,428,431,436,452-455,508 3099100170 RES CHIP 2012 10 J
C553 3439210415 CAP BACK-UP 0.1F/5.5V R404,411,418,435,438-444, 3099101170 RES CHIP 2012 100 J
C402,406,410,418,423,C514, 3536223122 CAP C 2012 CHIP 0.022UF/50V J 513-515,552,RA401,402
CSW502,503 RC714,RF715,RS710,RSW725, 3099104170 RES CHIP 2012 100K J
CSW706,710 3536563122 CAP C 2012 CHIP 0.056UF/50V J RF716,RS711,RC715,RSW726,
CAL/R404,CAL/R406,CD501, 3536101122 CAP C 2012 CHIP 100PF/50V J RF716,RS711,RC715,RSW726,
CDL/R502,CFL/R505,CFL/R703-704, R405,412,419,RC507,702,705, 707, 3099104170 RES CHIP 2012 100K J
CML/R702-703,CC505,702,703,707 709,712,RDL/R501,RDL/R503,
708,CS/R505,CSL/R702-703, RFL/R507,RFL/R703,RFL/R706,
C404,408,412,CAL/R408,CSW707 3536222122 CAP C 2012 CHIP 2200PF/50V J RFL/R708-709,RFL/R711,RFL/R720,
CSL/R502-503,CFL/R502-503, 3536271122 CAP C 2012 CHIP 270PF/50V J RML/R702,RML/R704,RSL/R507,
CC502-503 RSL/R702,RSL/R705,RSL/R707,
C443,444,CFL/R713 3536270122 CAP C 2012 CHIP 27PF/50V J RSL/R709,RSL/R712,RSW507,702,
CFL/R501,CSL/R501,CC501, 3536331122 CAP C 2012 CHIP 330PF/50V J 704,707,710,712, 715,716,718,720,
C411,C407,C403 3536470122 CAP C 2012 CHIP 47PF/50V J 723
CSW711 3536822122 CAP C 2012 CHIP 8200PF/50V J R407,410,414,417,421,424,426, 3099103170 RES CHIP 2012 10K J
C415,419,421,424,426,427,432, 3536104122 CAP CHIP 2012 0.1UF/50V J R427,429,430,451,500-507,510,
433,435,438,440,442,446-449,450- 516,518,519,521,522,524,531-533,
454,500-513,515,518,519,522-524, 561-562,567-573,RAL/R401,402,
554,703,704,CAL/R402,CC710, RAL/R404,RC703,RSL/R703,
CCW501,503,505,506,510,CD506, EML/R703,RSW703,714,R574
507,CF501,503,505,506,510,CS501 RSW721 3099183170 RES CHIP 2012 18K J
503,505,506,510,707,709, R409,416,423,R558,703-705, 3099102170 RES CHIP 2012 1K J
C552 3479322871 CAP E SG 0.22UF/50V RF707,712-714,RC506,701,706,708,
C420,425,428,434,436,437,439, 441, 3479310071 CAP E SG 10uF/50V 713,RFL/R701-702,RFL/R707,
CAL/R401,CAL/R403,CC504,701, RFL/R710,RML/R701,RCW705-707,
CC704-706,CC709,CDL/R501, RS705-707,RSLR506,RSL/R701,
CDL/R503,CFL/R504,CFL/R701-702, RSL/R706,RSL/R708,RSL/R713,
CFL/R705-708,CFL/R715,CML/R701, RF705,706,RSW506,701,705,706
CML/R704,CSL/R504,CSL/R701, 711,717,719,724
CSL/R704, RFL/R717 3099122170 RES CHIP 2012 1K2 J
CS509,CF509,CCW509,C445 3479310071 CAP E SG 10uF/50V RSW722 3099182170 RES CHIP 2012 1K8 J
C520,C521,CFL/R714 3479310971 CAP E SG 1uF/50V R406,413,420,432,433,701,702, 3099221170 RES CHIP 2012 220 J
C517 3479322971 CAP E SG 2.2UF/50V RC508,509,RCW701-704,708,
C551 3479333971 CAP E SG 3.3UF/50V 709,RD501-507,RF501,502,
CA401,402,C516,CCW502,504, 3479347041 CAP E SG 47uF/25V 701-704,708,709,RM701,702,RS501,
507,508,701-706,CM701,702,CD502, 502,701-704,708,709
503,CS502,504,CS507,508,CS701- RFL/R715 3099273170 RES CHIP 2012 27K J
706,CD504,505,CF502,504,507,508, RFL/R721-722 3099222170 RES CHIP 2012 2K2 J
701-708,C701,702,CSW730,731 RAL/R408-409,R434 3099331170 RES CHIP 2012 330 J
CFL/R711 3679272120 CAP MYLAR 0.0027UF/100V J RFL/R712 3099393170 RES CHIP 2012 39K J
CFL/R710 3679123120 CAP MYLAR 0.012UF/100V J RSL/R711,RC711,RSW709 3099392170 RES CHIP 2012 3K9 J
CFL/R712 3679223120 CAP MYLAR 0.022UF/100V J RFL/R718 3099474170 RES CHIP 2012 470K J
CFL/R709 3679683120 CAP MYLAR 0.068UF/100V J RAL/R403 3099473170 RES CHIP 2012 47K J
CP407 4428511416 CNT PLUG ST GIL-S-11P-S2T2-EF R408,415,422,511,512,517,520, 551, 3099472170 RES CHIP 2012 4K7 J
CP551 4428512416 CNT PLUG ST GIL-S-12P-S2T2-EF RAL/R405-407,RDL/R502,
CP554 4428515416 CNT PLUG ST GIL-S-15P-S2T2-EF RFL/R704-705,713,RSL/R704,RC704,
CP557 4428502416 CNT PLUG ST GIL-S-2P-S2T2-EF RSW713,R554-557
CP555 4428504416 CNT PLUG ST GIL-S-4P-S2T2-EF RSW730,731 3099560170 RES CHIP 2012 56 J
CP553 4428505416 CNT PLUG ST GIL-S-5P-S2T2-EF RF503,RS503,RC510,RF710,711 3099561170 RES CHIP 2012 560 J
CP556 4428508416 CNT PLUG ST GIL-S-8P-S2T2-EF RFL/R714 3099564170 RES CHIP 2012 560K J
CP552 4428509416 CNT PLUG ST GIL-S-9P-S2T2-EF R446,RC501-505,RFL/R501-505, 3099562170 RES CHIP 2012 5K6 J
CN406 (NOTE! CURRENT) 436210307724 CTG 1030 S10,T10 DL #26 P2.0 SHIELD RSL/R501-505,RSW501-505,
SILK: CP406 RFL/R716,
D551-556,D558 2257103110 DIODE CHIP KDS184RTK RSW713 3099682170 RES CHIP 2012 6K8 J
D400-403 2257104100 DIODE CHIP KDS226RTK R401-403 3099750170 RES CHIP 2012 75 J
IC412-413, IC504 2108019128 IC 74HCT125 RFL/R719 3099823170 RES CHIP 2012 82K J
IC403-405,407 2138001135 IC 74HCU04 R445,RSW708,RSL/R710,RC710, 3099912170 RES CHIP 2012 9K1 J
IC501-502 2109001150 IC 74VHC 574M RSW714
IC414 2109001100 IC 74VHC157M--210802112 74HC157 XT551 3938124010 RESONATOR CST10.0MTW-TF01
IC411 2139214001 IC AK4110-96kHz/24bit DIR Q400-404,555 2207606010 TR CHIP NPN KRC107S
IC506-508 2139214003 IC AK4324-96kHz/24bit DAC Q551-554,QC703,QFL/R701, 2207606011 TR CHIP NPN KRC231S
IC410 2139214002 IC AK5351-20bit ADC QSL/R701,QSW703,Q556
IC503 2138408003 IC AT27C020-70PC PROM QSW703,Q556
IC514 2168639100 IC BA033FP-E2 REG. QC702,QF702,QS702,QSW702 2207206010 TR CHIP PNP KRA107S
IC505 2138112002 IC CS492604-CL XT401 3908101130 X-TAL 12.288MHZ
IC408-409,IC509-512,IC701-705, 2168220142 IC NJM5532M DUAL OPAMP
IC710-712
IC513,713 2168020108 IC NJU7311AM ANALOG SWICH
IC709 2138007130 IC TC9184P ELECT TONE
IC706-708 2138007120 IC TC9459F ELECT VOL
4438100730 JACK RCA 1P(B)
4438100920 JACK RCA 2P (B,B WOOFER)
4438100530 JACK RCA 3P(B)
4438100220 JACK RCA 4P(WW,RR)
H551 4428806966 JUMPER HEADER 6P P2.5 H3.0
4448402966 JUMPER SHUNT 2P P2.5
IC515 ( RSX-972 ONLY ) 2138322012 Masking CXP819P60Q-4
IC400-401 2408218001 OPTO JACK RX-8A
DIGITAL BOARD PCB ASSEMBLY
14

15

Tuner Adjustment Method
FM Section
* Necessary measurement equipment
RDS/STEREO Multiplexer, FM/AM Signal Generator, Audio Analyzer, Oscilloscope, Digital Volt Meter (DVM)
(A) Center adjust
RDS/STEREO Multiplexer Setting
- MODE : MONO - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 98.1MHz - Output Level : 66dB
RSX972 Setting
- FM Frequency : 97.9MHz - FM MODE : MONO
1. Turn FM Signal Generator Modulation on
2. Connect DVM (+)(-) terminals to Jumper J7 and J8 and measure the volt.
3. If measured voltage is not adjusted within ±10mV, Make this measured volt '0' by adjusting T04 (FM-DET-A Coil).
: The adjustment should be within ± 10mV
4. After this adjustment, measure THD(Total Harmonic Distortion) with Audio Signal Generator
5. Adjust THD to minimum point with T05(FM-DET-B Coil). : THD shuold be within 0.5%
(B) Channel Separation adjust
RDS/STEREO Multiplexer Setting
- MODE : STEREO ( ONLY L-CH Signal OUT ) - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 98.1MHz - Output Level : 66dB
RSX972 Setting
- FM Frequency : 98.1MHz - FM MODE : STEREO
1. Turn FM Signal Generator Modulation on after modulating only L-CH (or only R-CH) at STEREO Multiplexer.
2. Confirm if 'STEREO'indicator is turned 'ON' on the display
3. Measure output level via Audio Signal Analyzer and make the level as standard.
4. Turn FM Signal Generator Modulation on after modulating only R-CH (or only L-CH) at STEREO Multiplexer.
5. Measure output level via Audio Signal Analyzer (measure per a dB)
6. If meaured output level is not lower than -40dB, Adjust output level to minimum position with VR03 ( CH-SEPA. ADJ.).
: lower than -40dB
(C) TUNED Level adjust
RDS/STEREO Multiplexer Setting
- MODE : STEREO - Audio Frequency : 1KHz
FM Signal Generator Setting
- Deviation : 75KHz - Radio Frequency : 98.1MHz - Output Level : 26dB
RSX972 Setting
- FM Frequency : 98.1MHz - FM MODE : STEREO
1. Turn FM Signal Generator Modulation 'ON' (confirm if output level is 26dB)
2. Change the output level of the Generator from 20dB to 30dB
and Confirm if 'STEREO' & 'TUNED' indicator of the DISPLAY turns on at 26db(±5 dB)
3. If these indicators do not turn on at higher than 26dB(±5dB) or do not turn off at lower than 26(±5dB) ,
Adjust VR02 ( FM-ADJ ) up to the moment where 'STEREO' & 'TUNED' indicator turns OFF & ON at 26dB.
4. Confirm if 'STEREO' & 'TUNED' turns OFF when decreasing the output level slowly from 26dB to 25dB, 24dB ~~~.
(Repeat the above 3. if not OFF in lower than 24dB.)
5. Push RSX-972's TUNE UP or DOWN button "long" at Signal Generator Output Level 26dB and start Auto search.
Confirm if search stops at FM Frequency 98.1MHz.
(Examine both of High Freq. -> 98.1MHz search , Low Freq. -> 98.1MHz search)
16

AM Section
* Necessary measurement equipment :
AM Signal Generator, Audio Signal Analyzer, Dummy Load, Oscilloscope, Digital Volt Meter (DVM)
(A) VT adjust
AM Signal Generator Setting
1. Adjust AM Frequency of RSX-972 to 522KHz. (or 520KHz)
2. Connect (-) terminal of DVM with GND ( or chassis ) and connect (+) terminal
with Jumper J3 ( VT CHECK ) and mesaure voltage. ( Low Freq. VT)
3. Adjust VT to 1.1V with T02 (AM-OSC Coil).
* In case of USA version, AM freq. range is 520KHz ~ 1710KHz. So, adjust as below.
at 520KHz, VT = 1.1V ( Low Freq. VT)
(B) Output Level adjust
AM Signal Generator Setting
- Modulation : 30% - Audio Frequency : 400Hz - Output Level : 100dB
- Radio Frequency : 603KHz (or 600KHz )
RSX-972 Setting
- AM Frequency : 603KHz/1404KHz/999KHz (or 600KHz/1400KHz/1000KHz)
1. Turn AM Signal Generator Modulation ON
2. Adjust RSX-972 AM Freq. to 603KHz (or 600KHz) and measure output level with Audio Signal analyzer.
3. Adjust output level to maximum point with T01 ( AM-ANT ).
4. Adjust AM Signal Generator & RSX-972 AM Frequency to 1404KHz (or 1400KHz) and measure output level.
5. Adjust output level to maximum point with TC01 (White Trimmer).
6. Repeat above 2.~ 5. steps 2 ~ 3 times until adusting to best output level.
7. Adjust AM Signal Generator & RSX-972 AM Frequency to 999KHz (or 1000KHz) and measure output level.
8. Adjust level to maximum position with T03 (AM-IFT).
(C) TUNED Level adjust
AM Signal Generator Setting
- Modulation : 30% - Audio Frequency : 400Hz - Radio Frequency : 999KHz (or 1000KHZ)
- Output Level : 84dB
RSX-972 Setting
- AM Frequency : 999KHz (or 1000KHz)
1. Turn AM Signal Generator Modulation ON ( Make sure if Output level is 84dB )
2. If 'TUNED' indicator does not turn on at higher than 80~86dB(Generator output),
Adjust VR01 ( AM-ADJ ) up to the moment where 'TUNED' indicator tunrs OFF & ON again
3. Confirm if 'TUNED' turns OFF when decreasing the output level of AM Signal Generator slowly from 84dB to 80dB.
4. Push RSX-972 TUNE UP or DOWN button "long" at AM Signal Generator Output Level 84dB and start AUTO search.
Confirm if search stops at AM Frequency 999KHz (or 1000KHz).
< Check with both of High Freq. -> 999KHz(or 1000KHz) search , Low Freq. -> 999KHz(or 1000KHz) search >
17

RSX972 Conversion < TUNER B'D VERSION OPTION > < POWER B'D VERSION OPTION>
FOR 01 VERSION (USA)
- INSERT FOLLOWING PARTS 115V JUMPER 3POINT(435502042147) F901 FUSE (7A/250V) F902 FUSE (315mA/250V)
USA/TAIWAN FOR 24 VERSION (EUROPE)
- INSERT FOLLOWING PARTS 230V JUMPER 2POINT (435502042147) F901FUSE (T4A/250V) F902FUSE (T250mAL/250V)
EUROPE/AUSTRALIA/CHINA
10K
H
HH H
9KH
z
zz z
200K
H
HH H
50K
H
HH H
VERSION SELECTOR
10K
H
HH H
200KH
HH H
9KH
z
zz z
50KH
HH H
VERSION SELECTOR
H551
CPU
USA EUROPE/AUSTRALIA/CHI
FM : 200KHz /
STEP
STEPSTEP STEP
AM : 10KHz /
FM : 50KHz / AM : 9KHz /
DIGITAL
B'D
B'DB'D B'D
JLU100
JLE100
JRE100
JRU100
JLU100
JLE100
JRE100
JRU100
JLU100
JLE100
JRE100
JRU100
TUNER
B'DB'D
FRONT-END
ANT-TERMINAL
230
V
FIL901 T901
R901
115
V
115
V
230
V
115
V
18

Case Outlines
KBPC2504W
2SA1386A
2SC3519A
KIA7905
KIA7915
KIA7906
KIA7805
KIA7815
KIA7806
2SA1859A
2SC4883A
2SA1360
2SC3423
2SC4137
DTC323
DTC107
DTA107
KTA1268
KTA1271
BTKA1266
KTC3198
KTC3200
KTC3203
NJM5532F PC817 NJM5532D
KS5520TSH94INNJU7311A
BA033
74HCT125
74HCU04
74VHC157 74VHC574 LM7001
BU1920F
AK5351VF
AK4324VF
AK4110VF TC9154F TC9184AP LA3401 LA1266
CXP81960-573Q
CXP82832-309Q
CS4926 AT27020 (PROM) TC9459N
TC9163AN
NJU7312AL
19

Meno
20
