LuxenHome WHF614 User manual

Product Name:
Resin 3-Tier Stone Finish Outdoor Fountain
SKU #:
WHF614
Contact: [e-mail]
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains
important safety and operating instructions for power units.
Thank you for purchasing this LuxenHöme product. This product has been manufactured with the highest
standards of safety and quality.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged
parts. If any parts are missing or damaged, do not attempt to assemble or use the product.
CARTON CONTENTS:
Description
Quantity
Fountain Base
1
Fountain Tiers
4
Pump 1
Nuts 2
Compatible Pumps for this fountain:
Pump Model No.
JR600
JB650
YH560
Tools required for assembly: No tools required for assembly.
Assembly Instructions:
1. Unpack the contents of the box and check to make sure that all items are accounted for and in good
condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. Place Part A upside down, and attach the Part B base by turning Part B clockwise. Make sure it is tightened
and secure, and carefully turn the fountain right side up.
4. From the opening at the center of the fountain base, insert the water supply tube into the pump outlet.
Place the pump upright in the basin and draw the pump power cord out of the fountain base.
5. Place and insert the tube at the base of Part C to the pump. Attach Part C to Part B by aligning the bolts in
Part B with Part C’s openings, and use nuts to secure the parts together. Do not overtighten the nuts to
avoid stripping.
6. Place and insert Part D to the tube of Part C, and Part E to the tube of Part G.
7. Add clean water to the fountain. The water level should be approximately 30mm lower than the edge of the
basin.
8. Connect the power cable to outlet. If installed properly, water flow in the fountain will begin shortly.
9. Please do not use the electrical plug in wet weather conditions. Please note: On first use, there may be air in
the pump. It may take several minutes until all the air escapes.

Product Name:
Resin 3-Tier Stone Finish Outdoor Fountain
SKU #:
WHF614
Contact: [e-mail]
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains
important safety and operating instructions for power units.
10. To eliminate the possibility of water damage around your fountain, check for leaks and excessive splashing
after the initial setup of your fountain. It is highly recommended that this fountain be placed in an area
where it cannot be damaged.
11. Do not leave your fountain running for extended periods of time when no one is present to observe the
performance.
12. Check the area around your fountain on a regular basis to ensure that there is no leakage.
13. Please refresh the fountain with water each week to ensure it in good condition.
14. Do not add any harmful chemicals to the water as it may alter the finish.

Product Name:
Resin 3-Tier Stone Finish Outdoor Fountain
SKU #:
WHF614
Contact: [e-mail]
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains
important safety and operating instructions for power units.
Note: The above diagram is for illustrative purposes only.

Product Name:
Resin 3-Tier Stone Finish Outdoor Fountain
SKU #:
WHF614
Contact: [e-mail]
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains
important safety and operating instructions for power units.
MAINTENANCE OF YOUR PUMP:
•Keep the water clean – clean water will prolong the useful life of your pump.
•Use a pre-filter on your pump if available.
•Regular cleaning of the pump will be necessary depending upon the environment in which it is operated.
Clean the pump when it is visibly soiled or when a noticeable drop in performance is detected. Failure to
clean the pump will result in overheating of the pump and the voiding of the warranty!
•Before cleaning, always disconnect the pump from the power source.
•Disassemble the pump by removing the inlet screen & the impeller housing. Remove the impeller/rotor
assembly by gently pulling on the impeller blades. Use a soft cloth or brush to clean the area inside of the
pump where the impeller/rotor assembly was. Clean the inlet screen, impeller housing & impeller in warm
soapy water. Reassemble the pump and inspect for proper operation.
MAINTENANCE OF YOUR FOUNTAIN:
•Unplug the pump from electric power before servicing, cleaning, or moving.
•Keep water clean - using clean water will reduce mineral deposits and improve water clarity.
•Clean the fountain periodically to prevent mineral deposits and contamination. Use warm soapy water and a
stiff brush for heavily stained surfaces. Do not use harsh chemicals as this will damage the finished
surface and void the warranty.
•Add clean water periodically to ensure that the pump is fully submersed in water.
•Disconnect the power and empty the basin if the fountain will not be used for an extended time.
•If installed outdoors and in a freeze-area of the country, ensure that all water is removed and the unit is
completely dry. This product is NOT to be operated below 41℉(5℃) freeze damage may occur.
Special Warnings and Cautions:
CAUTION:
•The pump has been evaluated for use with water only.
•Do not use the pump in water exceeding 35ºC / 95ºF.
•Do not use the pump in flammable liquids.
•Do not use the pump for industrial purposes.
•Do not use the pump in vehicles or on ships or aircraft or swimming pools.
•Do not use the pump in location where special conditions prevail, such as the presence of a corrosive or
explosive atmosphere (dust, vapor or gas).
•Do not let the pump run dry. Pump must be completely submerged for proper operation and cooling.
•Do not lift the pump by its power cord.
•Keep the plug dry. Do not expose the plug to water or steam.
•Before connecting to the power source, make sure that the pump is assembled and completely submerged in
water.

Product Name:
Resin 3-Tier Stone Finish Outdoor Fountain
SKU #:
WHF614
Contact: [e-mail]
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains
important safety and operating instructions for power units.
•Check the water level regularly to ensure the pump is completely submerged during operation. The pump
should be fully submerged during operation. Do not add water while operating the product. Always disconnect
the pump from the power source before adding water.
WARNINGS:
•To reduce the risk of electric shock, connect only to a properly grounded, grounding type receptacle.
•To reduce the risk of electric shock, use only on portable self-contained fountains no larger than 5 feet in any
dimension.
•Do not exceed the voltage shown on the pump.
•Always disconnect the pump from the power source prior to beginning any maintenance or work on the pump
or fountain.
•Inspect the power cord for damage before installation and/or maintenance. Replace the entire pump if
damage is found.
•For pumps with a 3-prong, grounded type plug, do not remove the grounding pin from the plug on the power
cord.
TIPS AND TROUBLESHOOTING:
1. Ensure that the pump’s flow control switch is set to maximum (+) before operating. Once the flow is
established, the pump can be adjusted downward to the desired level.
2. If the pump operates, but there is no flow, check to ensure the pump is fully submerged.
3. If the pump operates, but there is no flow, check the supply tubing for kinks and correct.
4. If the pump operates, but there is no flow, and if the pump is submerged and there are no kinks in the supply
tubing, lift the pump from the water. Remove supply tubing at pump outlet and clean tubing inside and out if
necessary. Reset pump in water (outlet side up) and once water begins to flow, re-attach the supply tubing.
