Lynx Zap 180 Zero LX1909 User manual

Information
Frame Weight: 103g
Materials: Pure Carbon Fiber
Size: 180mm
Maximum Propeller: 4 inch
Motor mount: 13xx motor, 18xx motor, 22xx motor.
Flight controller mount: 30.5mm x 30.5mm
FPV Camera mount: can be adjusted from 0
to 45
LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 1

LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 2

DR2234
ZAP 180_Main frame
6 x CTCE2.5x6
Flat Head Socket Cap Screw M2.5x6
(Loctite 242)
6 x DR2235
ZAP 180_Standoff 5x25 M2.5
4 x ESCs
Use shrink tubing or double
tape to keep ESCs(Not included)
Power distribution board
(Not included)
4 x DR2233
ZAP 180_Landing gear skid
4 x TBEM2.5X6
Button-Head Socket Cap
Screws M2.5x6(Loctite 242)
STEP 1
STEP 2
LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 3

DR2231
ZAP 180_Carbon CAM Mount
DR2227
ZAP 180_ Alu CAM mount
4 x CTCE2X4
FLat hex cap crew M2x4
(Loctite 242)
2 x O-Ring ID 1.5 - W 1.25
For Sony HS1185 CCD 700TVL
FPV Camera Plastic Case
(Not included)
Step 3.1
2 x TBES2X8
M2x8 Head Socket cap
self tapping screw
2 x CTCE2.5x6 Flat-Head Socket
Cap Screw M2.5x6
(Loctite 242)
2 x TBEM2X5
Button-Head Socket
Cap Screws M2x5
DR2228
ZAP 180_ Standoff 5x32xM2.5
STD screw M2 (Not
included)
Step 3
2 x DR2236
ZAP 180_Carbon CAM support
STEP 3
STEP 3.1
STEP 3.2
STEP 4
LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 4

Flight controller
(Not Included)
4 x Motors
(Not included)
Not included
Motor's screw
(Not included)
VTX
(Not included)
Receive
(Not included)
DR2229
ZAP 180_Antenna mount
Not included
2 x CTCE2.5x6
Flat-Head Socket
Cap Screw M2.5x6
(Loctite 242)
4 x TBEM2.5X6
Button-Head Socket
Cap Screws (Loctite 242)
DR2230
ZAP 180_Baterry tray
2 x TBEM2X5
Button-Head Socket
Cap Screws (Loctite 242)
DR2243
ZAP 180_ Carbon XT 60
Clamp
XT 60
(Not included)
DR2242
ZAP 180_ ALu XT60 Clamp
STEP 5
STEP 6
LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 5

2 x TBEM2.5X6
Button-Head Socket Cap Screws
(Loctite 242)
DR2237
ZAP 180_Alu frame support
DR2232
ZAP 180_Recoder Cam tray
CTCE2.5x6
Flat-Head Socket Cap Screw M2.5x6
(Loctite 242)
Nut M5 (Not included)
4045 Lynx Racer
Propeller CCW + CW
Set
STEP 8
STEP 9
LYNX MANUAL DOC .REV .A11-10-2016
LX1909- ZAP 180 Zero
INSTRUCTION MANUAL
Page 6

Not included
HOOK AND LOOP
Not included
STEP 10
