Lynx ZAP 210 Zero User manual

Information
Frame Weight: 150 g
Materials: Pure Carbon Fiber
Size: 210mm
Maximum Propeller: 5 inch
Motor mount: 13xx motor, 18xx motor, 22xx motor.
Flight controller mount: 30.5mm x 30.5mm
FPV Camera mount: can be adjusted from 0
to 45
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 1

LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 2

DR2215
ZAP 210_ Main frame
6 x CTCE2.5x6
Flat hex socket screw M2.5x6
(Loctite 242)
2 x DR2216
ZAP 210_Battery support
2 x DR2220
ZAP 210_Frame support
DR1879
XT60 Clamping
2 x CTCE2.5x6
Flat hex socket screw
M2.5x6
(Loctite 242)
Power distribution board
(Not included)
XT 60 Connector
(Not included)
4 x ESCs
Use shrink tubing or double
tape to keep ESCs
(Not included)
M3 Nylon Black Hex M-F
Spacers/ Screws/ Nuts
(Not included)
STEP 1
STEP 2
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 3

4 x CTCE2X4
Flat hex socket M2x4
(Loctite 242)
DR2218
ZAP 210_ Carbon CAM Plate
2 x CAM Mount support
TBES2X8
M2x8 Hex cap screw self tapping
Fat Shark 600TVL FPV
Tuned CMOS Camera
(Not included)
2 x TBES2X8
M2x8 Hex cap screw self tapping
(Not included)
Not included
2 x TBES2X8
M2x8 Hex cap screw self tapping
2 x Oring 1.5x1.25
4 x CTCE2.5x6
Flat hex socket screw M2.5x6
(Loctite 242)
2 x TCEM2X6
Hex cap screw M2X6
2 x DR0307
Washer 2x5x0.75
STEP 3
STEP 3.1 CAM Mount
This step is assembled in
factory with loctite ready to
use
This Cam mount could be used for
many Cams
# 1
# 2
# 3
For Sony HS1185 CCD 700TVL
FPV Camera Plastic Case
STEP 4
If you don't want to use our CAM mount.
you can use STD CAM Mount
First removed the 2 STD
screws and leave the
CAM plate in place
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 4

4 x Motors
(Not included)
4 x DR2221
ZAP 210_Zap 210 landing
gear skids
16 screws
(Not included)
Flight controller
(Not Included)
Not included
TBEM2.5X8]
Bottom Hex socket screw M2.5x8
(Loctite 242)
(Not included)
4 x CTCE2.5x6
Flat hex socket screw
M2.5x6 (Loctite 242)
DR2224
ZAP 210_Antenna mount
DR2217
ZAP 210_Battery tray
VTX
(Not included)
STEP 5
STEP 6
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 5

6 x CTCE2.5x6
Flat hex socket screw M2.5x6
(Loctite 242)
DR2214
ZAP 210_ G10 recorder CAM tray
Receiver
(Not included)
(Not Included)
Not included
Self lock nut M5
CW
CW
5035 Lynx Racer Propeller CCW + CW
Set
CCW
CCW
STEP 6
STEP 7
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 6

NOTE:
If you don't want to used the battery O ring . you
can use Electronic Hook & Loop to keep your
battery
Electronic hook and loop
2 x Battery Oring
Recorder CAM
(Not included)
Battery
(Not included)
FULL ASSEMBLY
Electronic hook and loop
STEP 8
LYNX MANUAL DOC .REV .A 02-08-2016
LX1908 - ZAP 210 ZERO
INSTRUCTION MANUAL
Page 7
