Lytx SF Series User manual

©2022 Lytx, Inc. - Confidential & Proprietary. Page 1 of 45
(North America Edition)
Lytx® SF-Series Event Recorder
Installation Instructions
(North America Edition)
Last updated: 2022 November 14
THE DEVICE SHOULD BE INSTALLED AND MAINTAINED BY QUALIFIED TECHNICIANS. Only a properly qualified technician
should install and maintain the SF-Series device(s). Any electrical work should be performed only by an MECP-certified or
equivalent technician with an expertise in installing and troubleshooting advanced vehicle onboard components including
multiplexed circuits. Lytx, Inc. disclaims all responsibility for any damages arising from improper installation and
maintenance of the SF-Series device(s).
This guide is protected as confidential and proprietary information of Lytx, Inc. Copying and use of this guide for any
purpose other than installing SF-Series devices in vehicles of Lytx, Inc.’s customers is expressly prohibited. Information
contained in this guide was in effect as of the date set forth above and is subject to change without notice or liability. Lytx,
Inc. reserves the right to revise the information presented or to discontinue the production of parts described at any time.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 2 of 45
(North America Edition)
Contents
Safety Instructions............................................................................................................................................. 3
Device Installation Overview............................................................................................................................. 7
Installation Warnings.............................................................................................................................................7
Before You Begin...........................................................................................................................................................7
Materials...................................................................................................................................................................8
Required Tools ..................................................................................................................................................... 11
Optional Tools....................................................................................................................................................... 11
Optional Parts....................................................................................................................................................... 11
Device Features ................................................................................................................................................... 12
SF-Series Installation Procedures ................................................................................................................. 13
Pre-Installation Vehicle Check................................................................................................................................ 13
Mount the Bracket and Event Recorder ................................................................................................................ 13
Mounting Preparation......................................................................................................................................... 13
Attach the Bracket and Event Recorder.......................................................................................................... 16
Connect Electrical Wiring......................................................................................................................................... 17
Electrical Connection Overview........................................................................................................................ 18
Wiring and Termination Suggestions for Vehicle Interface Cable ............................................................ 24
Event Recorder Electrical Connections........................................................................................................... 26
Connect to the Vehicle J1939 Network ........................................................................................................... 28
Connect Turn Signals (ER-SF300/ER-SF400 + J1939 only)....................................................................... 29
Route the Device Power Cable.......................................................................................................................... 30
Register the Device and Complete Installation ................................................................................................... 31
Complete Installation.......................................................................................................................................... 31
Conduct Final Checks.......................................................................................................................................... 32
Installation of Optional Parts................................................................................................................................... 33
Overhead Mounting Bracket Installation Procedures.................................................................................. 33
Extended Mounting Arm Installation............................................................................................................... 35
Remote Push Button Installation...................................................................................................................... 38
Maintenance & Troubleshooting ..................................................................................................................... 39
Maintenance................................................................................................................................................................ 39
Troubleshooting Installation Issues ...................................................................................................................... 39
Troubleshooting Issues After Installation ............................................................................................................ 40
Initiate Diagnostic Mode..................................................................................................................................... 40
Troubleshooting in Diagnostic Mode ............................................................................................................... 41
Uninstalling the Device............................................................................................................................................. 43
Materials................................................................................................................................................................ 43
Instructions........................................................................................................................................................... 43
Contact Technical Support .............................................................................................................................. 45

©2022 Lytx, Inc. - Confidential & Proprietary. Page 3 of 45
(North America Edition)
Safety Instructions
Installation Safety Warnings
Read and follow the instructions and precautions in this guide and all documents referenced in this
guide when installing this device. Always refer to the vehicle manufacturer’s service manual for proper
installation and wiring of any aftermarket devices, including the SF-Series device. Failure to do so may
result in property damage and/or personal injury.
WARNING: Park the vehicle on a level surface before beginning any maintenance or installation.
Block the wheels to prevent the vehicle from moving. Never work under a vehicle supported only by
jacks as jacks can slip and fall over.
WARNING: All wires that carry electrical current to the Lytx device(s) must be fused. Failure to fuse
the power, ground, and ignition wires can lead to serious personal injury and/or property damage. If any
wires or cables containing fuses/fuse boxes need to be cut or otherwise shortened, always be certain to
replace such fuses/fuse boxes or install new ones.
WARNING: Wire Protection: Take all necessary measures to protect all wire runs through a metal
surface with a grommet or other device and all wire runs outside the vehicle cab with a loom. Always
protect against wire fatigue and harness abrasion by properly attaching wires at closely spaced
intervals, while avoiding contact with sharp edges or doing anything else that might result in exposed
wires. All wires should be secured with tie wraps at least every one foot (30 cm/300 mm) or less. Do not
over-tighten any tie wraps.
EXPLOSION HAZARD: Do not disconnect equipment unless power has been removed and the area is
known to be non-hazardous.
WARNING: Substituting or supplementing components may impair suitability and performance. If you
are missing any components contact Lytx Technical Support Center at 925.732.4246 or email
[email protected].
WARNING: Wear safe eye protection to prevent serious eye injury when you perform vehicle
maintenance or service.
Driver Safety Warnings
WARNING: In order to reduce the potential danger of injuries, the driver and front passenger must
always be correctly seated with seat belts correctly fastened when operating the vehicle.
DISCLAIMER: The Lytx Event Recorder is a driver aid only, not a substitute for a safe, conscientious
driver. The Lytx Event Recorder cannot compensate for a driver who is distracted, inattentive or impaired
by fatigue, drugs or alcohol. Whether or not the Lytx Event Recorder is in use, it is always the
responsibility of the driver to take appropriate corrective action. Never wait for the device to provide a
warning before taking measures to avoid an accident. Failure to do so can result in serious personal
injury or death or severe property damage.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 4 of 45
(North America Edition)
Always, it is the driver’s responsibility to:
•Use safe driving techniques
•Exercise proper judgment
•Maintain a safe speed and distance between vehicles
•Take measures to avoid an accident
•Comply with all applicable laws and regulations
WARNING: In certain conditions, including inclement weather, low visibility, certain road conditions
(including poor lane markings, construction zones, dirt roads, heavy or complicated traffic, and curvy and
winding roads), the Lytx Event Recorder may have limited to no functionality. The Lytx Event Recorder
may not detect certain objects such as motorcyclists, bicyclists or pedestrians even in the most ideal
conditions. Always keep the lens and view of the Lytx Event Recorder unobstructed and properly
calibrated so as not to inhibit function. Driving in certain conditions or any interference with the Lytx
Event Recorder can result in false, few or no warnings. The driver must always monitor traffic and
surroundings and take measures to avoid an accident; failure to do so can result in serious personal
injury or death or severe property damage.
WARNING: If the Lytx Event Recorder is not functioning properly at any time, please contact your
supervisor and have the device inspected immediately to correct the issue. Whether or not the Lytx Event
Recorder is functioning, it is the driver’s responsibility to maintain vehicle control; failure to do so can
result in serious personal injury or death or severe property damage.
CAUTION: While cleaning the device or the vehicle cab, do not apply compressed air or cleaning solutions
(such as Windex) to the Lytx device. Usage of these products may cause damage to the device.
WARNING: The optional livestream feature may have an approximate delay of 10 seconds.
Livestream should never be used to assist the driver in operating the vehicle. The driver is
responsible for the safe operation of the vehicle at all times and must always take measures to avoid
a collision.
Adherence to Applicable Local, State and Federal Laws
WARNING: Some countries/regions/jurisdictions have adopted, or may in the future adopt, laws that
prohibit objects from being mounted on a vehicle’s windshield or other locations in a vehicle. Always
refer to any applicable laws that concern mounting devices on vehicle windshields before choosing a
mounting location. You are responsible for complying with such laws, as Lytx, Inc. does not accept
responsibility for your failure to do so.
USA Federal Communications Commission (FCC) Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAUTION: Changes or modifications to this product not expressly approved by Lytx, Inc. could void the
user's authority to operate this equipment.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 5 of 45
(North America Edition)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
CAUTION: Exposure to Radio Frequency Radiation. To comply with FCC RF exposure compliance
requirements, for mobile configurations, a separation distance of at least 20 cm must be maintained
between the antenna of this device and all persons.
Canada –Industry Canada Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil est conforme aux normes RSS exemptes de licence d'Industrie Canada. Son utilisation est
soumise aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences nuisibles et
(2) cet appareil doit accepter toute interférence reçue, y compris les interférences susceptibles de
provoquer un fonctionnement indésirable.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR
d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
CAUTION: Exposure to Radio Frequency Radiation. To comply with RSS 102 RF exposure compliance
requirements, for mobile configurations, a separation distance of at least 20 cm must be maintained
between the antenna of this device and all persons.
Pour se conformer aux exigences de conformité 102 RSS RF exposition, pour des configurations
mobiles, une distance de séparation d'au moins 20 cm doit être maintenue entre l'antenne de cet
appareil et toutes les personnes.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 6 of 45
(North America Edition)
Suppliers Declaration of Conformance
We, Lytx, Inc., hereby declare that the product listed below, to which this Declaration of Conformity
relates, is in conformity with the Standards and other Normative Documents listed below:
Manufacturer’s Name & Address:
Lytx, Inc.
9785 Towne Centre Drive
San Diego, CA 92121 USA
Declares that the following product: Product Name: Video Event Recorder Product Model:
•ER-SF1 (DC-6000-001)
•ER-SF64 (DC-6000-001)
•ER-SF200 (DC-6000-030)
•ER-SF300 (DC-6000-030)
•ER-SF400 (DC-7000-002)
The product specified above carries the marking, by complying with the essential requirements
and provisions. Conformity is based upon the following standards:
Manufacturer’s Contact:
Lytx, Inc.
9785 Towne Centre Drive
San Diego, CA 92121 USA
Phone Number: [phone]
Fax Number: [phone]
EMC & Radio:
CFR Title 47 FCC Part 15, Subpart B and C, Class B
Industry Canada ICES-003, Class B
Industry Canada RSS-Gen
Industry Canada RSS-210 (applicable only to cellular modem variant)
Industry Canada RSS-247
Mexico IFETEL
Mexico NOM-001-SCFI-1993

©2022 Lytx, Inc. - Confidential & Proprietary. Page 7 of 45
(North America Edition)
Device Installation Overview
Installation Warnings
THE DEVICE SHOULD BE INSTALLED AND MAINTAINED BY QUALIFIED TECHNICIANS. Only a properly
qualified technician should install and maintain the Lytx device(s). Any electrical work should be
performed only by an MECP-certified or equivalent technician with an expertise in installing and
troubleshooting advanced vehicle onboard components including multiplexed circuits. Lytx, Inc. disclaims
all responsibility for any damages arising from improper installation and maintenance of the Lytx
device(s).
THIS GUIDE IS NOT A SUBSTITUTE FOR A QUALIFIED TECHNICIAN.
THE DEVICE SHOULD NOT INTERFERE WITH THE VEHICLE’S COMPUTER SYSTEMS. The SF-Series device
interfaces with the vehicle’s computer systems to capture data for safety analysis. However, it should not
interfere with any of the vehicle’s computer systems. If there is a malfunction of the vehicle’s computer
systems after installation, contact Lytx Technical Support Center at 925.732.4246 or email
[email protected] immediately. Lytx recommends that you do not drive the vehicle until the malfunction
is resolved. Lytx, Inc. disclaims all responsibility for any damages arising from improper installation and
maintenance of the SF-Series device(s).
Before You Begin
Read and understand all instructions and procedures provided for the vehicle and the SF-Series
device(s). This guide must be read in conjunction with the vehicle manufacturer’s service manual, the
Mounting Regulations, all instructions and procedures issued by Lytx, Inc., and any applicable federal,
state, provincial and local laws that prohibit mounting devices on vehicle’s windshield or other locations in
a vehicle.
Read and observe all warnings, cautions, and safety notices in the instructions and procedures. They
provide information to avoid serious personal injury, damage to components or both.
Follow the vehicle’s maintenance, service, installation and diagnostic guidelines provided by the
manufacturer of the vehicle.
Check for laws or regulations that prohibit objects from being mounted on a vehicle’s windshield or
other locations in a vehicle. You are responsible for complying with such laws and regulations, and Lytx,
Inc. does not accept responsibility for your failure to do so.
Use special tools and safety equipment to avoid serious personal injury and damage to components.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 8 of 45
(North America Edition)
Materials
Included in Every SF-Series Event Recorder kit
SF-Series Unit
Standard Mounting Bracket
Two (2) T-27 Security Torx Screws
Alcohol Wipe
SF64/SF200/SF300/SF400 installations with J1939 9-pin connections
Device Power Cable
Vehicle Interface Cable with inline fuses:
Red and Black wires = 5-amp fuses
Brown wire = 1-amp fuse
9-Pin Y Cable
Tamper Prevention Clip

©2022 Lytx, Inc. - Confidential & Proprietary. Page 9 of 45
(North America Edition)
For power-only installations (SF1/SF64 only)
Non-ECM, Device Power Only Cable with inline
fuses:
Red and Black wires = 5-amp fuses
Brown wire = 1-amp fuse
Tamper Prevention Clip
For SF64/SF200/SF300/SF400 installations with J1939 connections
Device Power Cable
Vehicle Interface Cable with inline fuses:
Red and Black wires = 5-amp fuses
Brown wire = 1-amp fuse
J1939 CAN Coupler
Only included in kits for J1939 networks
Tamper Prevention Clip

©2022 Lytx, Inc. - Confidential & Proprietary. Page 10 of 45
(North America Edition)
For SF64/SF200/SF300/SF400 installations with OBD-II connections
Device Power Cable
Vehicle Interface Cable with inline fuses:
Red and Black wires = 5-amp fuses
Brown wire = 1-amp fuse
OBD-II Data Only Cable
Only included in kits for OBD-II networks
Tamper Prevention Clip
If you are missing any materials, contact the Lytx Technical Support Center at 925.732.4246 or email
[email protected] to obtain the necessary materials before beginning installation. Supplementing or
substituting shipped materials could impair suitability and performance.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 11 of 45
(North America Edition)
Required Tools
In addition to all guides and reference documents that you should read before beginning installation,
the following tools are required for installation:
⚫Wire cutter
⚫Wire crimper
⚫Voltmeter or multimeter
⚫Vehicle panel removal tool
⚫Flat-blade screwdriver
⚫Cable ties
⚫Phillips screwdriver
⚫Electric tape
Consult the vehicle’s maintenance, service, installation, and diagnostic guidelines provided by the
manufacturer of the vehicle for any additional tools needed.
Optional Tools
The following tools are not required for installation but can be helpful:
•Cordless driver
•Add-a-circuits or vehicle-specific connectors
•Grommets and looms
•Flashlight
•Paper towels/shop towel
•Utility knife
•Vehicle-specific panel clips
•Heating torch
•Heat shrink
Optional Parts
The following optional parts may be purchased from Lytx:
•Overhead Mounting Bracket
•Extended Mounting Arm
•Remote Push Button (Standard)
•Power Cable Extension (20-ft)
⚫Tape measure
⚫Marking pen
⚫T-27 security Torx bit
⚫T-8 security Torx bit
⚫Micro USB cable
⚫Vehicle manufacturer recommended tools
⚫Internet-ready phone or tablet

©2022 Lytx, Inc. - Confidential & Proprietary. Page 12 of 45
(North America Edition)
Device Features
ER-SF1 and ER-SF64
1. Interior-facing lens
2. Microphone
3. LED status lights
4. Manual record buttons
5. Serial number (on side of device)
6. Exterior-facing lens
7. Micro-USB port
8. Device Power Cable port
9. SIM card port
ER-SF200, ER-SF300, ER-SF300W, ER-SF400
1. Interior-facing lens
2. Microphone
3. Ambient light sensor
4. LED status lights
5. Manual record buttons
6. Serial number (on side of
device)
7. Exterior-facing lens
8. Micro-USB port
9. Device Power Cable port
10. SIM card and SD card port

©2022 Lytx, Inc. - Confidential & Proprietary. Page 13 of 45
(North America Edition)
SF-Series Installation Procedures
Pre-Installation Vehicle Check
Before beginning the installation, turn the vehicle on. Verify that no Check Engine lights, error codes, or
warnings appear on the gauge console, dashboard, or vehicle display. It may be necessary to cycle
through displayed messages or screens to verify. If any Check Engine lights, error codes, or warnings
appear, report these to the site contact before proceeding.
For installations with OBD-II network connections: The SF-Series device cannot be connected to the OBD-
II network if another 3rd-party device is also connected to the same network. To proceed with the
installation, verify that no other 3rd-party devices are connected to the OBD-II diagnostic port.
Mount the Bracket and Event Recorder
WARNING: Before mounting the bracket and event recorder, consult the vehicle manufacturer's
recommendations and any applicable federal, state, provincial and local laws that restrict mounting devices
on a vehicle’s windshield or other locations in a vehicle.
Mounting Preparation
CAUTION: An improperly positioned event recorder can reduce program effectiveness.
The event recorder should be mounted in a location that
provides an unobstructed view of the driver and the
road in front of the vehicle.
1. Interior-Facing Lens View: Should span from the
outside shoulder of the driver to the outside
shoulder of a front seat passenger. If possible, it
should show the lap band of the seatbelt.
2. Exterior-Facing Lens View
a. Should be inside the path of the wiper
blades.
b. Should capture a clear view of everything in
front of the vehicle, beginning as close to
the front of the vehicle as possible without
cutting off the horizon.
To temporarily gauge the best position, first loosen the
Torx screws so the event recorder can rotate in the bracket. Then hold it up to the windshield.
If windshield mounting is not possible/permitted in the vehicle or jurisdiction, alternative mounting
methods are available under Installation of Optional Parts.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 14 of 45
(North America Edition)
Mounting Location Recommendations and Restrictions
WARNING: Some countries/regions have adopted laws that restrict locations where objects can be attached
to the vehicle windshield. Always refer to any applicable federal, state, provincial and local laws that
concern mounting devices on vehicle windshields or other locations in a vehicle before choosing a
mounting location.
For those vehicles that are subject to U.S. Department of Transportation, Federal Motor Carrier
Safety Administration (FMCSA) regulation, the following figures provide guidelines for mounting the
Lytx event recorder on the vehicle windshield that work within regulations set by the FMCSA*.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 15 of 45
(North America Edition)
CAUTION: To mount the device, the air temperature must be at least 50°F (10°C). The ideal temperature
range is 70-100°F (21-38°C).
CAUTION: Do not use a heat torch to heat up the windshield or adhesive on the bracket as this may reduce
bracket adherence. If additional heat is required, use the vehicle heating system for the windshield.
CAUTION: Steps 1-3, cleaning the area and drying it, are critical to prevent the bracket from falling off later.
CAUTION: Do not peel the backing from the bracket's adhesive in this section.
1. Apply isopropyl alcohol on the windshield mounting area and dry it off with a clean cloth, removing
any debris. This is the area behind the rear view mirror on the passenger side or the equivalent
area if there is no rear view mirror (see below).
2. Clean the mounting area again with the Lytx-
supplied alcohol wipe.
3. Wait 2 minutes for the mounting area to air dry
before applying the device bracket. Do not dry
it with a cloth.
4. Following the mounting location guidelines
above, hold the assembly in place and trace
the outline of the bracket on the windshield
with a marker. Make sure the traced guide
marks are level.
5. Remove the event recorder from the mounting
bracket.
6. Check the fit of the bracket against the windshield. If the windshield is curved, you may gently
bend the bracket so it lies flush against the glass.
Best practice: Select a surface location with minimal curvature.
7. Check again to make sure you’ve selected the best mounting location.
a. Sit in the driver’s seat while holding the device up. Make sure it doesn’t block the driver’s
view of the road.
b. Turn on the wipers and rotate mirrors, sun visors, and other objects near the device to make
sure they cannot block either lens.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 16 of 45
(North America Edition)
Attach the Bracket and Event Recorder
CAUTION: The adhesive is very sticky. Once applied, it will not easily come off. Take care to attach the
bracket to the mounting location properly.
CAUTION: Do not apply excessive pressure as it may cause the windshield to break.
CAUTION: After removing the backing from the bracket's adhesive, apply the bracket to the windshield
immediately. If you leave the adhesive exposed for too long, it may be compromised.
1. Remove the backing from the adhesive side of the
bracket. Carefully attach the bracket to the
windshield.
a. The bracket has slightly longer and shorter legs.
Orient the bracket so the shorter legs are facing
down.
b. Place the left edge of the bracket against the
windshield, aligned with the marks, and make
sure it is level.
c. Press the bracket firmly against the windshield
starting at the left and pressing downward to the
right.
2. Check from outside the vehicle for large air bubbles
under the bracket. If you find any:
a. Apply additional pressure to the bracket.
b. Slide a pin between the bracket and windshield to let out the air.
3. Wait 10 minutes to allow the bracket's adhesive to bond.
4. Place the event recorder in the bracket.
5. Adjust the event recorder so it hangs vertically (plumb).
See Figure C.
6. Secure the event recorder in the bracket using the two T-
27 Torx screws.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 17 of 45
(North America Edition)
Connect Electrical Wiring
WARNING: Only approved wire connection methods are recommended. Refer to the vehicle
manufacturer’s service manual to determine if soldering, sealing crimp connections, Add-A-Circuit, Posi-
Tap, sealing butt connections, or OEM connections to open connection ports are approved. Never use plier
tap products such as insulation displacement connectors (i.e. ScotchLoc connectors) when installing the
SF-Series device(s).
WARNING: Never wire the SF-Series device(s) in a manner that shares a connection with another
aftermarket product in the vehicle. Independent connections should always be used.
WARNING: All wires that carry electrical current to the SF-Series device(s) must be fused. Failure to
fuse the power, ground, and ignition wires can lead to serious personal injury and/or property damage.
If any wires or cables containing fuses/fuse boxes need to be cut or otherwise shortened, always be
certain to replace such fuses/fuse boxes or install new ones.
WARNING: Wire Protection: Take all necessary measures to protect all wire runs through a metal surface
with a grommet or other device and all wire runs outside the vehicle cab with a loom. Always protect
against wire fatigue and harness abrasion by properly attaching wires at closely spaced intervals, while
avoiding contact with sharp edges or doing anything else that might result in exposed wires. All wires
should be secured with tie wraps at least every one foot (30 cm/300 mm) or less. Do not over-tighten any
tie wraps.
WARNING: Cable Routing: Make certain that neither the cable nor your installation activities interferes
with any airbag-related mechanisms or otherwise risks affecting airbag deployment. Consult the
vehicle manufacturer for the location of any airbag sensors and systems and restrictions that may apply.

©2022 Lytx, Inc. - Confidential & Proprietary. Page 18 of 45
(North America Edition)
Electrical Connection Overview
The following diagrams cover all available cable solutions for the SF-Series device. Only one cable
solution will be applicable to each device install.
Installations with Default J1939 9-pin Diagnostic Cables
*For optional remote push button

©2022 Lytx, Inc. - Confidential & Proprietary. Page 19 of 45
(North America Edition)
Installations with 9-pin Diagnostic Port Cable
1. Route the Cable
Plug the power cable into the device. Route and tuck the cable into the side door and floor.
2. Connect Power
Locate the vehicle diagnostic port. Remove it from the panel where it’s
mounted. Plug the male connector of the 9-pin cable assembly into the
vehicle port and properly secure it in the dash area. Also gets ground
from this connection.
3. Replace Diagnostic Port
Mount the spare port from the cable assembly into where the vehicle
port was originally located. Use one of the provided fitting brackets to
mount it. For more detail, refer to the “Fitting Brackets” section on the
last page. Secure the connections and reinsert the vehicle panel. By the
end, the panel should look the same as when you started.
Additional J1939 9-pin Install instructions are available in the Support Center.
9-pin Fitting Brackets

©2022 Lytx, Inc. - Confidential & Proprietary. Page 20 of 45
(North America Edition)
Installations with J1939 Connections
SF64, SF200, SF300, or SF400
