Heavy Guitars
Quick Start Guide

3
SO N I C I M P L A N T S • C ERTIFIED O R G A N I C S O U N D L IBRARIES
Heavy Guitars Documentation
Thank you for choosing Sonic Implants sound libraries, the most organic sound libraries on the market. We are pleased to offer
EXS24, HALion, Kontakt, MachFive, and Reason users this premium instrument library. For more sampled instrument collections, visit
www.sonicimplants.com.
Les Paul Power Rock Guitar — A heavily distorted but smooth electric guitar for the serious rock musician. This sample set features a
Les Paul Guitar with Tom Anderson Humbucker pickups run through a big, fat 1978 Marshall Amplifier. Mutes, Tones, Harmonics, Power
Chords, Chord Chunks and more make these the most authentic playable guitar samples available.
Paul Reed Smith Electric Guitar — Guitarists know the Paul Reed Smith name. It’s synonymous with some of the best sounding (and
most expensive) electric guitars available. But save your money! We’ve sampled this Hollow Body 2 beauty through a classic Marshall
Amp to overdrive your lead lines and distort your chord progressions.
Creamy Fuzz Guitar — A custom Stratocaster Guitar run through a Fulltone Soul Bender fuzz pedal and into a Mesa Boogie DC-5 amp.
It’s reminiscent of the British fuzz guitar sound made famous in the late ‘60’s, though it takes advantage of the Soul Bender’s internal
contour control to produce a silkier, creamier tone than was possible at that time.
Keyboard Layout
Each key on a piano keyboard has a name and octave delineation. For example, middle C is C4. One octave above middle C is C5, etc.
(See diagram above.) This is useful in determining how our instruments are laid across a MIDI keyboard.
Note: Middle C is C4, which is the standard for most MIDI keyboards, although on some applications or keyboards refer to middle C as
C3 (Yamaha) or C5.
Mute and Pick Tones
All programs are laid out from E2-E6 (except for the Slides & FX program, which is laid out from C2-C6). Programs range from 1 to
4 layers. The samples switch via velocity, typically starting with a mute, then a tone, followed by one or two more articulations. The
Program names indicate what is included. To familiarize yourself with the programs, we recommend playing through them at multiple
velocities.
Diatonic Chords
Diatonic chords are laid out diatonically across the keyboard. This allows you to select the diatonic instrument that matches the musical
key that your song is in. For example, if your song is in the key of C, try selecting the “C Diatonic Chord” instrument. There is a program
for each root key, with the chords laid out in the following manner: Major, Major, minor, Major, minor, Major, minor, Major, Major, minor,
Major, minor.
For example, for C diatonic, you will have:
C Major, C# Major, D minor, D# Major, E minor, F Major, F# minor, G Major, G# Major, A minor, A# Major, B minor.
For D diatonic, you will have:
D Major, D# Major, E minor, F Major, F# minor, G Major, G# minor, A Major, A# Major, B minor, C Major, C# minor etc.
Downstrokes are laid out starting from C3-B3. Upstrokes start from C4-B4. The root note moves up the keyboard as you move through
the different programs, with the B diatonic program going from B3-A#4 and B4-A#5, the C diatonic program going from C3-B3 and C4-
B4, and so on. Also included are various stopped chords, from C6-G6 (white notes only). Hint: Try playing both the down and up chords
at the same time for a fuller sound.
3

4
Major and Minor Chord Layouts
Some guitars only have Major and Minor chords. Downstrokes go from E2-D#3 and upstrokes from E3-D#4. These programs also
include the same stopped chords from C6-G6, white notes only.
Major and Major Sus Chord Layouts
The Major and Major Sus chords have Major downstrokes from E2-D#3, Major upstrokes from E3-D#4, Major Sus downstrokes from
E4-D#5, and Major Sus upstrokes from E5-D#6. The stopped chords range from E6-C7, white notes only.
Dominant 7th Chords and Dominant 9th Chords
The Dom7 and Dom9 chords are laid out from E3-D#4. Also included are the same stopped chords from C6-G6 and the FX program
that are found in the diatonic file.
Power Chords
The Power chords are laid out from A2-G#3. Also included are the same stopped chords from C6-G6 and the FX programs that are
found in the diatonic file.
FX Program Layout
The FX program has a variety of different scrapes, slides, squeals, and more—all laid out chromatically across the keyboard.
Instrument List
1. Fuzz A Major Diatonic 16. Fuzz KS_f0-b0_All 31. Les Paul Chunks 46. PRS FX
2. Fuzz A# Major Diatonic 17. Fuzz KS_F0-G0_Pick-Ham 32. Les Paul Harmonics 47. PRS G Diatonic
3. Fuzz B Major Diatonic 18. Fuzz Majors and Major Sus 33. Les Paul Mute Chords 48. PRS G# Diatonic
4. Fuzz C# Major Diatonic 19. Fuzz Majors Only 34. Les Paul Mutes 49. PRS Heavy Pick
5. Fuzz D Major Diatonic 20. Fuzz Minors Only 35. Les Paul Sustains 50. PRS Light Pick
6. Fuzz D# Major Diatonic 21. Fuzz Mutes Only 36. PRS A Diatonic 51. PRS Multi Pick
7. Fuzz Dom 7 Chords 22. Fuzz MW_Mute-Pick 37. PRS A# Diatonic 46. PRS FX
8. Fuzz Dom 9 Chords 23. Fuzz MW_Pick-Hammers 38. PRS B Diatonic 47. PRS G Diatonic
9. Fuzz E Major Diatonic 24. Fuzz Pick Feedback 39. PRS C Diatonic 48. PRS G# Diatonic
10. Fuzz F Major Diatonic 25. Fuzz Pick Only 40. PRS C# Diatonic 49. PRS Heavy Pick
11. Fuzz F# Major Diatonic 26. Fuzz Power Chords 41. PRS D Diatonic 50. PRS Light Pick
12. Fuzz G Major Diatonic 27. Fuzz Slides & FX 42. PRS D# Diatonic 51. PRS Multi Pick
13. Fuzz G# Major Diatonic 28. Fuzz Triple Velocity 43. PRS E Diatonic
14. Fuzz Hammers Only 29. Les Paul All Tones 44. PRS F Diatonic
15. Fuzz Harmonics Only 30. Les Paul Chords 45. PRS F# Diatonic

5
SO N I C I M P L A N T S • C ERTIFIED O R G A N I C S O U N D L IBRARIES
Contact
If you have any questions, comments or suggestions about this or any M-Audio product, we invite you to contact us by using the
following information:
M-AUDIO U.S. -
5795 Martin Road, Irwindale, CA 91706-6211, U.S.A.
M-AUDIO Deutschland (Germany) -
Kuhallmand 34, D-74613 Ohringen, Germany
Sales Information: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .626-633-9050
Sales (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 626-633-9070
Sales Information (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Tech Support (phone): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 626-633-9055
Tech Support (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Tech Support (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .626-633-9060
Internet Home Page: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .http://www.m-audio.com
Sales Information: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Sales Information (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Technical Support: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Technical Support (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Technical Support (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Internet Home Page: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . http://www.m-audio.de
M-AUDIO U.K. -
Floor 6, Gresham House, 53 Clarendon Road, Watford, WD17 1LA, United Kingdom
M-AUDIO Canada -
1400 St-Jean Baptiste Ave. #150, Quebec City, Quebec G2E 5 B7, Canada
Sales Information (phone): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 (0) 1923 204010
Sales Information (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 (0) 1923 204039
Sales Information (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Technical Support (PC): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 (0) 1309 671301
Technical Support (Mac): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 (0) 1765 650072
Technical Support (email): . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Internet Home Page: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .http://www.maudio.co.uk
Technical Support (e-mail): . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Technical Support (PC): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Technical Support (Mac): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-800-638-2120
Technical Support (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Sales (e-mail): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
Sales (phone): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [phone]
Sales (fax): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .[phone]
Internet Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . http://www.m-audio.ca
M-AUDIO France -
Floor 6, Gresham House, 53 Clarendon Road, Watford, WD17 1LA, United Kingdom
M-AUDIO Japan -
株式会社エムオーディオジャパン：460-0002 愛知県名古屋市中区丸の内 2-18-10
Assistance Technique (aucune questions reliées aux ventes)
courriel (assistance PC): . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
courriel (assistance Mac): . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
téléphone (assistance PC): . . . . . . . . . . . . . . . . .0820 000 731 (0,12 Euros par minute)
téléphone (assistance Mac): . . . . . . . . . . . . . . . 0820 391 191 (0,12 Euros par minute)
télécopieur/fax: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01 72 72 90 52
Ventes (aucun appels d’assistance technique)
téléphone: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0810 001 105 (Numero Azur)
courriel: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . [e-mail]
télécopieur/fax: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01 72 72 90 52
テクニカルサポート（電話）：................................... 052-218-0859
テクニカルサポート（Macintosh 環境での email）：........[e-mail]
テクニカルサポート（Windows 環境での email）：..........[e-mail]
テクニカルサポート（OS に依存しない製品での email）：......[e-mail]
テクニカルサポート（英語での email ／ EnglishOnly）：........ [e-mail]
テクニカルサポート（Fax）：.................................... 052-218-0875
Web サイト（ホームページ）：...........................http://www.m-audio.com
