Mäktig 710035 User manual

1
800A JUMPSTARTER
OWNER’S MANUAL
Read carefully and understand all ASSEMBLY AND
OPERATION INSTRUCTIONS before operating. Failure
to follow the safety rules and other basic safety
precautions may damage the equipment and result in
serious personal injury.
Part No 710035

2
Keep away from WATER – FIRE - SMOKE!
Recharge the unit before using it!
TABLE OF CONTENTS
CONVENTIONS …………………………………………… 2
1. INTRODUCTION ………………………..…………….. 3
2. SCOPE OF DELIVERY ……………………..………… 3
3. IMPORTANT SAFETY INSTRUCTIONS …………… 3
4. FEATURES ……………………………………..……… 4
5. OPERATION …………………..………………..……… 6
6. RECHARGING …….…………………………..………. 8
7. 12V DC OUTLET ……………..………………...……… 11
8. TROUBLESHOOTING ………………………..………. 13
9. SPECIFICATIONS …………………………..………… 13
CONVENTIONS USED
The following conventions are used in this manual.
WARNING: Warnings identify conditions that could result in personal
injury or loss of life.
CAUTION: Cautions identify conditions or practices that could result in
damage to the unit or to other equipment.
NOTE: Notes describe an important action item or an item that you must
pay attention to.
Abbreviations and Acronyms
A Ampere
AC Alternating Current
Ah Amp-hours
DC Direct Current
mA Milli-Ampere
V Volt
LED Light-emitting diode

3
1. INTRODUCTION
Congratulations on your purchase of this quality Mäktig product!
Easy-to-use and designed for reliable service, this 800A jumpstarter can
run many DC appliances whenever you need power for work or play, at
home or on the road. The 800A jumpstarter has an internal battery, and is
designed to jumpstart vehicles such as SUVs, trucks, and vans. This unit:
Powers 12V DC appliances
Jumpstarts vehicle engines up to 800A
Has an overload protection for 12V DC outlet
Includes a LED light for emergency lighting.
Please read the manual before use and follow the included instructions!
2. SCOPE OF DELIVERY
NO. DESCRIPTION
1 Jump Starter with Jumpstart cables. It is the main body of
the unit.
2 AC charging adapter. Lets you recharge the unit from a standard AC wall outlet and can only be used to recharge the
internal battery of the unit.
3 Owner’s instructions. Read the instructions carefully before
using the unit.
3. IMPORTANT SAFETY INSTRUCTIONS
This Jumpstarter generates up to 800A. Operating the Jumpstarter
incorrectly or misusing it may damage the equipment or create hazardous
conditions for the user.
NOTE: Before using your Jumpstarter, be sure to read and save
these safety instructions.
CAUTION: This unit is not intended for use as a UPS (Uninterrupted
Power Supply).

4
WARNINGS
Before starting the vehicle, be sure that the clamps are connected in
the right way and the green indicator light is on.
This Jumpstarter contains components that tend to produce arcs or
sparks. To prevent fire or explosion, do not operate the Jumpstarter in
locations containing batteries or flammable materials, or in locations
that require ignition-protected equipment.
This product contains a sealed, non-spillable lead-acid battery which
must be recycled or disposed of properly.
Working in the vicinity of a lead-acid battery is dangerous. During
normal operation, this type of battery releases hydrogen gas which is
explosive and poisonous. Before using the unit, you must carefully
read and follow these instructions and those published by the
manufacturer of the battery or any equipment you intend to use in the
vicinity of the battery.
Protect the unit from direct sunlight or excessive heat and moisture.
This unit contains electrical circuitry that is not water-resistant. Do not
submerge the unit in water.
Never attempt to jump start or re-charge a frozen battery.
The jump start power switch controls power to the output terminals. To
prevent accidental shorting, keep this switch in the off position for all
operations, unless for jump starting or using the outing terminals to
power a 12V DC appliance.
Do not smoke, use matches or cigarette lighter, or allow any spark or
flame near battery or engine.
Put the clamps back on the holder after use to avoid sparking.
4. FEATURES
Front view

5
1. Battery level button – When pressed, you can see the battery
level according to the battery level indicators.
2. Battery power level indicators
Value of the battery Display mode
U<10.5±0.4V Only red LED indicator lights.
（10.5±0.4V）<U<（12.5±0.4V）Only yellow LED indicator lights.
U>12.5±0.4V Only green LED indicator lights.
Note: It is recommended that you look over the battery power level
after every 30 minutes charging.
3. LED light – High High brightness LED light for emergency use.
4. LED light switch.
5. Connection Status Indicator – When you connect the clamps to
the battery correctly (red clamp to the positive and black clamp
to the negative), the green LED lights up. When the clamps are
not connected correctly, the red LED lights up.
6. Charging jack – you can charge the battery in the unit by
inserting the attached AC charging adapter into this jack.
7. Two-color charging/charged indicator – When the battery is
being charged, this LED indicator lights red, when the battery is
full charged, this LED indicator light turns green.
8. 12V DC socket – It is an input or output easy-access port. You
can insert the cigarette plug into it to charge the internal battery
or power 12V accessories.
Note：The 12V DC socket contains 15A fuse for over current
protection.
Note：It is recommended that you use the unit to power 12V
accessories less than 8A.
9. Black battery clip
10. Portable handle
11. Red battery clip
Note: Be sure that the switch is on off position and the clips are
connected in the right way, that is red to positive polarity, and black
to negative polarity.

6
12. Jumpstart power switch – It is a
manual rotary switch. When you
jumpstart a vehicle, you should
turn off the switch and the
vehicle engine and connect the
unit to the vehicle. Then you
can turn on the switch.
Executing these steps in the
right order is extremely
important.
13. 15A replaceable fuse
14. AC charging adapter
Input voltage: 110V AC
Output voltage: 13.5V DC
Input current: 0.5A
Note: it is recommended that you use the AC charging adapter to
charge the battery.
5. OPERATION
The unit should be operated only in locations that meet the following
requirements:
Dry Do not allow water or other liquids to drop or splash on the
unit.
Cool Ambient air temperature should be between -10Ԩand 40Ԩ
(14°F and 104°F) – the cooler the better within this range.
Ventilated Leave at least 2” (5cm) clearance around the Jumpstarter for
air flow. Ensure that the ventilation openings are not
obstructed.
Safe Do not operate the unit in the same compartment as batteries
or in any compartment capable of storing flammable liquids
like gasoline.
Protected
from battery
gases
Do not operate the unit where it will be exposed to battery
gases. These gases are very corrosive and prolonged
exposure will damage the Jumpstarter

7
WARNING: Fire Hazard
Never allow jumpstart cables’ red and black clamps to touch each other or
another common metal conductor. This could cause damage to the unit
and/or create a sparking/explosion hazard.
WARNING
The connection of the jumpstart cables to the vehicle’s battery terminals
must be positive to positive (red clamp to battery “+”) and negative to
negative (black clamp to battery “-“). A reverse polarity connection may
cause damage to the unit and/or create a sparking/explosion hazard.
NOTE: Closely follow these instructions to jumpstart your vehicle
as they may be different from the instructions supplied with other
jumpstart products or jumpstart cables.
HOW TO JUMPSTART A VEHICLE
1. Turn off the vehicle and all accessories.
2. Place the Jumpstarter on a flat and stable surface near the battery
which need to be started. Ensure that the Jumpstart power switch is
“OFF”.
3. Connect the red positive (+) clamp of the cables to the positive (+)
terminal of the engine battery.
4. Connect the black negative (-) clamp of the cables to the engine block,
cylinder head, or other stationary heavy metal part of the motor. If the
red “Reverse Polarity” LED illuminates, then reverse polarity has been
detected. Correct polarity must be established before proceeding.
Disconnect the Jumpstart clamps from the vehicle’s battery and repeat
steps (3) and (4).
5. Switch the Jumpstart power switch to ON. Before starting the engine,
make sure the Jumpstarter and the cables are clear of metal parts and
other moving components.
6. Crank the engine for 5 seconds or until it starts, whichever is first.
WARNING: Fire Hazard
Do not crank the engine for more than 5 seconds. The Jumpstart
feature is designed for short term operation only. Operating the
Jumpstart feature for more than 5 seconds may cause damage to the
unit. Allow the Jumpstarter to cool down for at least 3 minutes after
each boost.
7. Switch off the Jumpstart power switch.

8
8. Remove the red positive (+) clamp and then the black negative (-)
clamp from the engine battery.
6. RECHARGING
WARNING
Do not charge the unit in wet or moist locations because it may cause
severe electric shock and injury may result.
WARNING
Do not charge the unit immediately after any severe discharge or heavy
usage. Wait half an hour to let the battery of the unit cool down first.
NOTE: Recharge the Jumpstarter after each use. When the
Jumpstarter is not in use, it should be recharged every 3 months!
WARNING
Make sure that no 12V DC appliance is connected to the Jumpstarter
during charging!
RECHARGING THE BATTERY WITH THE AC CHARGING ADAPTER
1. Turn the rotary switch to the “OFF” position.
2. Plug AC charging adapter into charging jack.
3. Plug AC charging adapter into 110V AC electrical socket.
4. Do not stop until the battery is fully charged (about 28 hours).
Features: Input voltage 13.5V, Input current 0.5A, protected.
CAUTION
The 28-hour charging time for the unit is based on an input of 110V from
the AC wall outlet. If the voltage is lower than 110V AC, recharging may
take more than 28 hours.
Once fully charged, the charging current automatically reduces to a
floating charge mode, and the unit can be left permanently connected to
the AC charger.

9
RECHARGING THE BATTERY WITH THE JUMPSTART CLIPS
WARNING: Fire Hazard
Never allow cables’ red and black clamps to touch each other or another
common metal conductor. This could cause damage to the unit and/or
create a sparking/explosion hazard.
The connection of the cables to the power source must be positive to
positive (red clamp to battery “+”) and negative to negative (black clamp to
battery “-“). A reverse polarity connection may cause damage to the unit
and/or create a sparking/explosion hazard.
To recharge with the jumpstart clips:
1. Ensure that the jumpstart power switch is “OFF”.
2. Connect the red positive (+) clamp of the cables to the positive (+)
terminal of power source.
3. Connect the black negative (-) clamp of the cables to the negative (-)
terminal of power source. If the red “Reverse Polarity” LED illuminates,
then reverse polarity has been detected. Correct polarity must be
established before proceeding. Disconnect the jumpstarting clamps
from the vehicle’s battery and do the steps 2 and 3 again.
4. Turn on the jumpstart power switch.
5. Turn on the power source to charge the battery.
Features: Input voltage 13.5V, Input current 2A (recommended), not
protected.
7. 12V DC OUTLET
This option allows you to use optional 12V power accessories with the
cigarette lighter plug. Use the portable power outlet for power supply,
fishing and camping trips, extended running for mobile phones,
camcorders, computers and so on by combining your unit with an inverter
provides 110V AC power.
NOTE: There is no 12V cigarette plug with this unit!

10
8. TROUBLESHOOTING
Problem Cause Solution
Jumpstarter
can not jump
start vehicle
The internal battery in the
jumpstarter is not fully
charged Charge for at least 28 hours
The jumpstarter’s battery
has been damaged Replace jumpstarter battery
Jumpstarter
does not
recharge
Accessories connected to
12V DC socket Disconnect accessories
110V AC charger
damaged Replace 110V AC charger
Not charged after
previous use
The battery could possibly be
damaged due to not been
recharged after previous uses.
Plug-in
appliance does
not work
Battery has discharged to
10V Recharge the jumpstarter
Fuse blown Replace fuse
The appliance power is
over standard. Use an appliance the power is lower than standard.
9. SPECIFICATIONS
Boost Ampere 800 instantaneous cranking amps
Battery Max22Ah Sealed Lead-acid Battery
Adapter 110V AC/13.5V DC/500mA
Jump start cables (size/length) 4AWG/1m
Cigarette lighter plug maximum
current 15A
Output voltage 12V DC
Dimensions L*W*H 11.42*7.29*9.1inch (290*185*231mm）
Weight 16.5lb/7.5kg
