Owner’s Guide
For Models:
PE1BTWZ
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
APSRS
RF Upgrade Kit

2APSRS PE1BTWZ Owners revB
Table of Contents
Using Your Remote Control.................................................................... 3
Locking the Vehicle Doors................................................................. 3
Arming the Security System .............................................................. 3
Unlocking the Vehicle Doors ............................................................. 3
Disarming the Security System ......................................................... 3
User Selectable Notication Chirps................................................... 3
User Selectable LED ......................................................................... 4
Programmed Transmitter Notication................................................ 4
Valet Mode ........................................................................................4
Manually Overriding the Security System ......................................... 4
Using Your Remote Vehicle Starter ....................................................... 5
Remote Starting Your Vehicle............................................................ 5
Remote Start Shutdown .................................................................... 5
Entering Your Vehicle while it is Running via Remote Start .............. 5
Preheating or Precooling the Vehicle’s Interior ................................. 5
Remote Start Safety Features........................................................... 5
Remote Start Ready Mode................................................................ 6
Enter & Exiting the Vehicle - Remote Start Ready Mode .................. 6
Cancelling Remote Start Ready Mode .............................................. 7
Using the “Quick-Stop” Feature......................................................... 7
Turbo Timer Mode (optional) ............................................................. 7
Status LED, Light Flashes and Siren/Horn Indications ....................... 8
Replacing Remote Control Batteries..................................................... 9
Warranty Information ............................................................................ 10

32019 Voxx Electronics Corporation. All rights reserved.
Arming the Security System (Optional)
To arm the system, exit the vehicle, close all doors, then press the button. The
parking lights will ash 1 time, indicating the system is armed, has locked the doors
(if equipped and connected) and activated the starter disable feature. The LED status
indicator will blink steadily, once per second.
NOTE: The system is equipped with a feature called Silent Choice. If enabled,
the system requires a second press of the button to activate an audible arming
response from the vehicle.
*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 3 seconds.
Using Your Remote Control
Disarming the Security System (Optional)
To disarm the system press the button 2 times. The parking lights will ash 1
time, indicating the system is disarmed and has unlocked the doors (if equipped and
connected).
NOTE: The system is equipped with a feature called Silent Choice. If enabled,
the system requires a second double press of the button to activate an audible
disarming response from the vehicle. If your system is set up for 2 step unlock, a third
press of unlock will activate the audible response.
Door Lock
To lock the vehicle doors press and release the button.
Door Unlock
To unlock the vehicle doors press and release the button 2 times.
User Selectable Notication Chirps
System ARM/DISARM chirps can be toggled ON or OFF without entering the
programming feature banks.
1. Turn the ignition ON then OFF.
2. Press and release the valet/programming button 3 times. The system
will respond with 1 chirp for ON or 2 chirps for OFF.

4APSRS PE1BTWZ Owners revB
Programmed Transmitter Notication
As a security precaution each time the vehicle’s ignition is turn on the status LED
light with ash the number of transmitters programmed into the system. This helps
to identify unauthorized transmitters from accessing your vehicle. If you believe an
unauthorized transmitter has been programmed to your system, contact your installing
dealer for assistance.
Valet Mode
When valet mode is activated the status LED will light solid, and all security and
remote start functions will be disabled. To enter or exit valet mode simply follow the
steps outlined below:
1. Turn the vehicle’s ignition ON.
2. Push and hold the programming/valet button.
3. The LED will turn on solid when valet mode is active
4. Release the programming/valet button.
User Selectable LED
This feature will control whether the LED is ON or OFF when the system is Armed/
Locked and can be toggled ON or OFF without entering the programming feature
banks.
1. Turn the ignition ON, OFF, ON, OFF.
2. Press and hold the valet/programming button for 5 seconds. The system
LED will respond with 1 ash for ON or 2 ashes for OFF.
Manually Overriding the Security System
Your system can be disarmed without the use of the transmitter. This is necessary to
operate your vehicle if the transmitter is lost or its battery fails. To by-pass the alarm
system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the ON position.
3. Within 10 seconds, press and release the valet push button switch.
The alarm system will stop sounding and enter the (by-passed) mode. You can now
start and operate the vehicle normally.

52019 Voxx Electronics Corporation. All rights reserved.
Using Your Remote Starter
Remote Starting Your Vehicle
To activate the remote start function, press and hold the button for 3 seconds. The
system will sound, the parking lights will ash 1 time and the system will check the
vehicle to ensure it is safe to start. If all safety parameters are correct, the vehicle will
start. The vehicle’s parking lights will turn on (or ash depending on system settings)
as a visual indication that the vehicle has started and is running.
If your vehicle stalls or does not start, the system will pause 5 seconds, then try
3 more times to start the vehicle (a total of 4 attempts). The system will pause 5
seconds between each start attempt.
Remote Start Shutdown
Press and hold the button for 3 seconds again to turn the vehicle o󰀨.
Entering the Vehicle while it is Running via Remote Vehicle Start (Optional)
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
Remote Start Safety Features
For safety and security reasons, the system will shutdown or prevent the remote
vehicle starter from activating if any of the following occur:
1. The vehicle’s hood is open.
2. The brake pedal is pressed prior to turning the ignition key to the ON
position.
3. The engine is over-revved (tach checking only).
4. Valet Mode is active. Refer to the Valet Mode section of this manual on
page 5.
5. Remote Start Ready Mode is not set. Manual transmission vehicle’s only.

6APSRS PE1BTWZ Owners revB
To Enter & Exit the Vehicle while (Manual Transmission) Remote Start Ready
Mode is already active without cancelling Remote Start Ready Mode.
If ready mode has already been activated and you need to enter the vehicle, possibly
to retrieve an item, and will exit the vehicle without driving it, you can keep ready
mode active by following the steps below.
1. With Ready Mode already previously set, activate the remote start.
2. While under control of the remote start open vehicle door to retrieve
items.
3. Exit the vehicle and close all doors.
4. Press the button, the unit waits 3 seconds and then shuts down,
the system will verify all doors have been closed then will emit the 2
short/1 long tone and light ash pattern indicating Manual Transmission
Ready Mode is active.
Note: If the 2 short/1 long tone is not heard then Ready Mode has not been
set.
Remote Start Ready Mode - Manual Transmission Vehicles Only
To activate the remote start function, the system must rst be in Remote Start Ready
Mode. Follow the steps below to enter remote start ready mode.
1. While the engine is running by the ignition key;
a. Place the transmission in neutral.
b. Set the parking brake
2. With your foot o󰀨 the brake pedal, press and old the button to
activate the remote start. The remote will beep 4 times and the parkinglights
will turn on to conrm the system has remote started.
3. Remove the keys from the ignition, the vehicle will remain running.
4. Exit the vehicle and close all vehicle doors.
5. Within 1 minute of step 1, press the 1 time button to lock the vehicle’s
doors. The vehicle will shutdown and sound 2 short chirps then 1 long chirp
to conrm ready mode is set.
Remote Start Ready Mode must be enabled if your vehicle is equipped with a
manual transmission.

72019 Voxx Electronics Corporation. All rights reserved.
Using the “Quick-stop” Feature (Optional)
If you want to make a short stop and keep your vehicle running (to keep the interior
warm or cool), the quick-stop feature allows you to do this while keeping your vehicle
secure and your keys with you.
To engage Quick Stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot o󰀨 the brake pedal, press and hold the button
times within 2 seconds. The LED will ash 3 times to conrm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Press the
button to lock the vehicle’s doors if desired.
Note: Do not leave children or animals unattended in the vehicle when using the
quick-stop feature.
Cancelling Remote Start Ready Mode - Manual Transmission Vehicles Only
The system will exit remote start ready mode if any of the following occur:
Open any door
Open the hood or trunk (if connected)
Press the brake
Release the parking brake
Turn the ignition ON
Turbo Timer (Optional)
This option will keep the engine running to allow the vehicle’s turbo to properly cool
down before shutting the engine o󰀨.
To engage the Turbo Timer feature:
1. With the vehicle running via the ignition key and your foot o󰀨 of the
brake pedal.
2. Engage the vehicle’s parking brake.
3. The vehicle’s parking lights will turn on to verify the Turbo Timer
feature has been activated.
4. Turn the ignition key OFF, the vehicle will continue to run until the pre-
programmed time has elapsed (1, 3, or 5 minutes)
To disengage the turbo timer feature, press the vehicle’s brake pedal.

8APSRS PE1BTWZ Owners revB
Status LED, Light Flashes, and Siren/Horn Indications
Status LED Flash Indications
LED Flashes Function
OFF Disarmed
Slow Flash Armed
Fast Flash Passive Arming Countdown
ON (Solid) Valet Mode
1 Flash / Disarmed Zone 1 Trigger, Shock Sensor
2 Flashes / Disarmed Zone 2 Trigger, Trunk / Hood
3 Flashes / Disarmed Zone 3 Trigger, Door
Siren/Horn Chirp Indications
Chirps Function
1 Arm
2 Disarm
3 Door Ajar Upon Arming
4 Disarm / Triggered
Parking Light Flash Indications
Flashes Function
1 Arm
2 Disarm
3 Disarm / Triggered
ON (Solid or Slow Flash) Remote Started
Remote Start Shutdown Diagnostics
Parking Light Flashes Shutdown Zone
1 Flash Runtime Expired
2 Flashes Remote Shutdown
3 Flashes Brake ON
4 Flashes Manual Transmission Ready Mode
5 Flashes Hood Open
6 Flashes Low Tach Signal
7 Flashes Tach / Crank Average not learned
8 Flashes High Tach Signal

92019 Voxx Electronics Corporation. All rights reserved.
 2WayRemoteControlNotications
FUNCTION BEEPS / LED FLASHES
Lock 1 Beep / Flash
Unlock 2 Beeps / Flashes
Remote Start Activation RS Activation Melody
Conrm Remote Start 4 Beeps / Flashes
Remote Start Running 1 Flash per 5 seconds for duration run time
Remote Start Shutdown RS Shutdown Melody
Alarm Trigger Event 2 Beeps / LED Flash per 3 seconds -
Repeats 9 times

10 APSRS PE1BTWZ Owners revB
Replacing Remote Control Batteries
1 Button Remote Control - Model 181SP
The CR2032 battery inside each remote control should last approximately 1 year under
normal use. When the batteries become weak you will notice the remote control range
(the distance from the vehicle the remote control will work) deteriorate and the small LED
on the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
1 Button Remote Control - Model 181TWSP
The CR2450 battery inside each remote control should last approximately 1 year under
normal use. When the batteries become weak you will notice the remote control range
(the distance from the vehicle the remote control will work) deteriorate and the small LED
on the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
Remote Control Programming
1. Cycle vehicle’s ignition to ON.
2. Press and release the vale/programming button 3 times.
2. Press button of each transmitter you wish to program, the system will
beep to conrm each transmitter.
3. Turn the ignition OFF.
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.

112019 Voxx Electronics Corporation. All rights reserved.
LIMITED LIFETIME WARRANTY
Applies to Prestige Series Control Modules, Sirens, Sensors, and Relays.
Voxx Electronics Corporation (the Company) warrants to the original purchaser of this
product that should this product or any part thereof, (other than transmitters) under nor-
mal use and conditions, be proven defective in material or workmanship during the life-
time of the vehicle, in which it was originally installed from the date of original purchase
such defect(s) will be repaired or replaced with new or reconditioned product, (at the
Company’s option) without charge for parts or repair labor. A transmitter is warranted for
12 months from the date of original purchase.
To obtain repair or replacement within the terms of this Warranty, the product is to
be delivered with proof of warranty coverage (e.g. dated bill of sale), specication of
defect(s), transportation prepaid, to an approved warranty station. This Warranty is not
transferable.
This Warranty does not cover damage to the vehicle’s electrical system or costs
incurred for removal or reinstallation of the product. This Warranty does not cover bat-
teries, broken LCD or OLED display screens, nor apply to any product or part thereof
which, in the opinion of the Company, has su󰀨ered or been damaged through alteration,
improper installation, mishandling, misuse, abuse, neglect, accident, or by removal or
defacement of the factory serial number/bar code label(s).
This Warranty is in lieu of all other express warranties or liabilities. ANY IMPLIED WAR-
RANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, SHALL
BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. IN NO CASE
SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY. No person or rep-
resentative is authorized to assume for the Company any liability other than expressed
herein in connection with the sale of this product.
The company does not warrant that this product cannot be compromised or circum-
vented. THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY
IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO
EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID
BY PURCHASER FOR THE PRODUCT WITHOUT COST OF INSTALLATION.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damage so the above limitations or
exclusions may not apply to you. This Warranty gives you specic legal rights and you
may also have other rights which vary from state to state.
Voxx Electronics Corporation, 180 Marcus Blvd., Hauppauge, New York 11788 / 1-800-645-4994

12 APSRS PE1BTWZ Owners revB
Voxx Electronics Corporation.
Customer Service 1-800-225-6074
WWW.VOXXELECTRONICS.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
