M3 Mobile M3 BLACK User manual

1
User Manual
For Accessories
Version 1.0 ©2015

2
M3 BLACK Device
LCD Touch Screen
IO Connector
Reset Button
Scanner Button
Volume Button
Barcode Scan Window
Camera Button
Scanner Button

3
UL10 Device
Standard Battery
Stylus Pen
String
Quick Manual
Items in the box
Basic Accessories

4
Batteries
Standard Battery
Capacity, 3,700mAh
Extended Battery
Capacity, 5,100mAh

5
Single Slot Cradle
M3 Black single slot USB/Serial/charging cradle with spare battery charging.
Requires power supply (A-1CA-DI54-320-R00; sold separately) and country specific AC Line Cord.
For USB communication to a host computer purchase USB cable(A-UTU-B2A0-170-R00)
AC Line Cord
Power Supply

6
4 Slot Cradle
M3 BLACK single slot charging only cradle with spare battery charging.
Requires power supply (A-4CA-DC17-320-R00; sold separately) and country
specific AC Line Cord。
AC Line Cord
Power Supply

7
Snap-On
M3 BLACK USB/Serial/Charging Snap-on.
Requires power supply (A-1CA-DI54-320-R00; sold separately) + country specific AC Line
Cord, or Auto Charger Cable(A-VCJ-DI52-320-R00).
For USB communication to a host computer purchase USB cable A-UTU-A2A0-110-R00
AC Line Cord
Power Supply

8
Vehicle Cradle
M3 BLACK Serial/charging cradle in a vehicle.
Requires vehicle mount(A-0RM-SQZ0-000-R00 or A-0RM-FIX0-000-R00;sold separately)
and Auto Charge Cable(A-VCJ-DI52-320-R00)
Auto Charger Cable:
Input 12-24VDC / Output 5VDC, 2A
(Cigarette Lighter Adapter)
Provides power to the vehicle cradle or
Snap-on
Vehicle Mount for
Vehicle Cradle by RAM®
Install in a vehicle by
suction.
Vehicle Mount for
Vehicle Cradle by RAM®
Install in a vehicle by
screw.

9
Micellaneous
Stylus Pen with String
USB Cable
PistolGrip
