USER MANUAL
EQ4-500
WITH AIR BAND®
We will keep the model number and date of
purchase of your new Mäag Audio product on
of an insurance claim such as loss or theft.
CLICK HERE TO REGISTER NOW
PRODUCT REGISTRATION
PROTECT YOUR EQUIPMENT
Please complete the product registration form
for your Mäag Audio equipment to be
registered for warranty and product updates.
GENERAL SAFETY
• Please read these instructions.
• Take heed of all warnings.
• Adhere to all provided instructions.
• Avoid using this apparatus near water.
• Ensure this apparatus is not exposed to rain or moisture.
• Clean exclusively with a dry cloth.
• Prevent obstruction of any ventilation openings.
• Install in accordance with the instructions from the rack
manufacturer.
• Note that there are no user-adjustable or user-serviceable
items on this apparatus.
• Any adjustments or alterations to this apparatus may impact
its performance, potentially leading to a failure to meet safety
and/or international compliance standards.
• Refrain from using this apparatus in safety-critical
applications.
CAUTION
• This apparatus should not be used outside
of the scope of 500VPR racks.
• Do not operate this apparatus with any covers removed.
• To reduce the risk of electric shock, do not perform any
servicing other than that contained in these Installation
Instructions unless you are qualied to do so. Refer all
servicing to qualied service personnel.
SAFETY & INSTALLATION
This page provides denitions, warnings, and practical information to establish a secure working
environment. Prior to installing or using this apparatus, we encourage you to take a moment to read
through this page.
INSTALLATION
• Make sure to disconnect power from the rack before installing or removing this apparatus.
• Utilize the panel xing screws provided with the rack to securely fasten this apparatus into place.
CONFORMANCE TO STANDARDS
This device is intended for installation and operation in Mäag Audio 500 series compatible racks with
a CE mark. The CE mark on the rack indicates that the manufacturer arms its compliance with both
the EMC and the Low Voltage Directive (2006/95/EC).
OPERATION NOTESOPERATION NOTES
Because of the Maag Audio EQ4’s unique design, phase
shift is very minimal. This helps the user maintain the
integrity of the original sound and enhance the “Airy”
frequencies, while tonally shaping the sound from the top
to the bottom. The lack of phase shift and the AIR BAND®
make theEQ4® great on anything that needs EQ shaping.
The EQ4’s band passes all interact with each other.
Increasing the AIR BAND® gain will also increase the overall
gain to a small extent. This is normal and is a necessary
by product of the design. This happens because of the
interaction (summing) of the AIR BAND® with all of the other
band passes. This interaction is a necessary part of the design
toensuretheintegrityofthesoundismaintained. Tocompen-
sate for the added overall gain, simply turn down each of
the 5 band pass knobs equal amounts. An example would
be two clicks down on all 5 knobs. The EQ will remain the same
shape, but the overall gain will be lowered. This compensates
for the extra gain added from the interaction of the boosted
band passes. This is the correct way to get the desired results
from the Maag Audio EQ4®. Here is another way to look at it:
If lifting a desired frequency, you may want to consider
bringing down the level of the other band passes above
and or below; always remembering the band passes inter-
act with each other. This is a dierent approach from other
typical equalizers.
OVERVIEW & OPERATION NOTES
Understanding how the band passes and the AIR BAND® interact in the Maag Audio EQ4®, will help
you better shape your sound; providing unparalleled transparency and top end presence while
maintaining the true natural sound behind the source.
The Maag Audio EQ4®(500 Series) is a one channel 6 band equalizer with AIR BAND®(shelf
boost from 2.5 to 40kHz), compatible with the API 500-6B lunchbox® and 500VPR rack systems.
Following its EQ3 and EQ3-D predecessors, the EQ4® provides unparalleled transparency and top end
presence while maintaining the true natural sound behind the mix. EQ adjustments are obtained with
minimal phase shift and detent controls allow for easy recallable settings.
Presented in the agship lunchbox® portable format, the EQ4® oers the legendary AIR BAND®and
ve other sonically superior band passes. Maag Audio is an ocial member of the VPR Alliance.
AIR BAND®
frequencies below the shelf peaks
transitional slope.
FUNCTIONS & TECH SPECS
PEAK
2.5 kHz
Fixed boost and cut shelf
AIR GAIN
Gain control for the AIR BAND
160 Hz
Fixed boost and cut bell
650 Hz
Fixed boost and cut bell
40 Hz
Fixed boost and cut bell
IN/OUT
Engages and disengages EQ
SUB (10 Hz)
Fixed boost and cut bell
SIGNAL
presence. Illumination starts
*Specication
Frequency Response
Nominal Input Impedance (XLR)
Nominal Output Impedance (XLR)
TECHNICAL SPECIFICATIONS
Value
-2dB points, 10Hz & 75kHz
48 K Ohms, balanced
50 Ohms, balanced
Value
+25 dBu
< 0.005%
*Specication
Headroom
THD + Noise
*Specications subject to change without notice.
PRODUCT WARRANTY
Maag Audio expressly warrants its products for a
period of one (1) year from the date of purchase.
Products will be free of manufacturing defects.
Within the warranty period, a product will be
tested, repaired or replaced at the sole discre-
tion of Maag Audio, free of charge. All warranty
service will be conducted through authorized
Maag Audio dealers only. The end user is re-
quired to provide proof of purchase (receipt or
invoice) of the product. This warranty is oered
solely to the original purchaser of the product
from an authorized Maag Audio dealer and is
not transferable. This warranty does not include
the shipping charges to and from the author-
ized Maag Audio dealer from whom the product
was purchased. Maag Audio will pay for shipping
costs between the dealer and Maag Audio. All
warranty service requires a Maag Audio issued
RMA number. Please conduct warranty service
communication with an authorized Maag Audio
dealer.
WARRANTY EXCLUSIONS
The foregoing express warranty is made in lieu
of all other product warranties, expressed and
implied, including merchantability and tness
for a particular purpose which are specically
disclaimed. The express warranty will not apply
to defects or damage caused by post purchase
shipping and transportation, storage, careless
handling, nor damage caused by misuse, hot
swapping, accidents, neglect, alterations, oper-
ator error, or failure to properly maintain prod-
ucts.
WARRANTY & REGISTRATION
CLICK HERE TO REGISTER NOW
PRODUCT REGISTRATION
Please complete the product registration form
for your Mäag Audio equipment to be
registered for warranty and product updates.
