Mac allister MGT45028 Instruction Manual

MGT45028
Original Instructions_MNL_MGT45028_V1_211025
WARNING: Read the instructions before using the product!
EN
Grass Trimmer
450W 28cm

EN
02
Let’s
Getting started...
In more detail...
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Safety information
Your product
Before you start
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
02
03
14
15
18
19
23
28
33
34
35
37
39

EN
03
MGT45028 by MacAllister
Getting started...
Safety information
Safety warnings
General safety warnings
1. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
2. Children shall not play with the appliance.
3. Cleaning and user maintenance shall not be made by
children without supervision.
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
General power tool safety warnings
Work area safety
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.

EN
04
MGT45028 by MacAllister
Getting started...
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
Safety warnings
Safety information

EN
05
MGT45028 by MacAllister
Getting started...
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
power tools with your nger on the switch or energising
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
Safety information

EN
06
MGT45028 by MacAllister
Getting started...
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
Safety warnings
Safety information

EN
07
MGT45028 by MacAllister
Getting started...
control of the tool in unexpected situations.
Service
1. Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
Electrically powered grass trimmer safety warnings
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Training
1. Read the instructions carefully. Be familiar with the
controls and the proper use of the product.
2. Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience and\
knowledge or people unfamiliar with these instructions to
use the product. Local regulations may restrict the age of
the operator.
3. Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
Preparation
1. The machine should be supplied via a residual current
device (RCD) with a tripping current of not more than 30
mA.
2. Before use check the supply and extension cord for
signs of damage or aging. If the cord becomes damaged
during use, disconnect the cord from the supply
immediately. DO NOT TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use the
machine if the cord is damaged or worn.
3. Before use, always visually inspect the machine for
damaged, missing or misplaced guards or shields.
Safety information

EN
08
MGT45028 by MacAllister
Getting started...
4. Never operate the machine while people, especially
children, or pets are nearby.
Operation
1. Keep supply and extension cords away from cutting means.
2. Wear eye protection and stout shoes at all times while
operating the machine.
3. Avoid using the machine in bad weather conditions
especially when there is a risk of lightning.
4. Use the machine only in daylight or good articial light.
5. Never operate the machine with damaged guards or
shields or without guards or shields in place.
6. Switch on the motor only when the hands and feet are
away from the cutting means.
7. Always disconnect the machine from the power supply
(i.e. remove the plug from the mains, remove the
disabling device or removable battery)
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating abnormally.
8. Take care against injury to feet and hands from the
cutting means.
9. Always ensure that the ventilation openings are kept
clear of debris.
Maintenance and storage
1. Disconnect the machine from the power supply (i.e.
remove the plug from the mains, remove the disabling
device or removable battery) before carrying out
maintenance or cleaning work.
Safety warnings
Safety information

EN
09
MGT45028 by MacAllister
Getting started...
2. Use only the manufacturer’s recommended replacement
parts and accessories.
3. Inspect and maintain the machine regularly. Have the
machine repaired only by an authorized repairer.
4. When not in use, store the machine out of the reach of
children.
5. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and these
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions
and keep it well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user to
vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. fingers going white; as well as specific
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Safety information

EN
10
MGT45028 by MacAllister
Getting started...
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage to
property.
2. Switch the product off and disconnect from the
power supply if there are malfunctions. Have the
product checked by a qualied professional and repaired,
if necessary, before you operate it again.
Safety warnings
Safety information

EN
11
MGT45028 by MacAllister
Getting started...
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by ying
objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Safety information

EN
12
MGT45028 by MacAllister
Getting started...
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarise yourself with them
to reduce hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) Hz Hertz
/min or Per minute W Watt
min-1 kg Kilogram
g Gram cm Centimeter
mm Millimetre m Metre
dB(A) Decibel (A-rated) m/s² Metres per second squared
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction Note / Remark.
manual.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Wear hearing protection. Wear eye protection.
Wear a dust mask. Wear protective gloves.
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
Do not expose the product to rain or wet conditions (moisture).
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must not
come near the area where the product is.
Safety information

EN
13
MGT45028 by MacAllister
Getting started...
Symbols
Inspect the area where the product is to be used and remove all
objects which can be thrown by the product. If objects are hidden
while operating stop the motor and remove the object.
Keep other people out of working area during operation. A distance
of at least 15 m must be observed.
Disconnect the product from the mains plug if the cord is damaged or
entangled. DON’T TOUCH THE CORD BEFORE DISCONNECTING
THE SUPPLY.
Contact of the guide bar tip with any object should be avoided.
Guaranteed sound power level value in 96 dB.
The product is of Protection class II. That means it is equipped with
enhanced or double insulation.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Safety information
96

EN
14
MGT45028 by MacAllister
Getting started...
Your product
15
15a
7
6
5
13
2
4
8
9
9a
10
11
12
13
14
12a
12b
12c
12d
12e
12g
11a
12h
11b
Your product
1. Main handle
2. On/off switch
3. Power cord with plug
4. Rear safeguard
5. Cord retainer
(rotatable)
6. Upper pole
7. Unlock button for
angle adjustment
8. Locking sleeve for
length adjustment
9. Lower pole
a. Cord retainer(xed)
10. Unlock button for tilt
adjustment
a. Indicator*
b. Indication line*
11. Guard
a. Screw
b. Knife
c. Screw hole*
d. Knife protector*
12. Trimmer head
a. Cover
b. Release latch (x2)
c. Trimming spool
d. Trimming line (x2)
e. Housing
f. Sliding slot (x2)*
g. Release push
button
h. Eyelet
i. Screw hole*
13. Plant protector
14. Motor housing
15. Auxiliary handle
a. Lock button
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.

EN
15
MGT45028 by MacAllister
Getting started...
Before you start
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
You will need
Setup
(items not supplied)
Suitable personal protective equipment
Suitable crosshead screwdriver
(items supplied)
Guard (11)
Screw (11a)
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to battery pack (20) before it is completely
assembled!

EN
16
MGT45028 by MacAllister
Getting started...
Before you start
Setup
Guard
1. Turn the trimmer head (12) upside down.
2. Put out the plant protector (13) rstly (Fig. 1, step 1), then align and slide
the guard (11) onto the sliding slots (12f) of the trimmer head (12) (Fig. 1,
step 2). Fully insert the guard (11) and make sure that the screw holes (11c,
12i) are well aligned.
3. Secure the guard (11) with the screw (11a) in clockwise (Fig. 1, step 3).
13
11a
11c
11
12
12i
11
12f
11c
2.
1.
3.
Fig. 1
WARNING! Never use the trimmer head (12) without the guard (11)
properly tted.
NOTE: Always remove knife protection (11d) before use.

EN
17
MGT45028 by MacAllister
Getting started...
Before you start
Connection to power supply
NOTE: The product is equipped with a power cord with the length of
10 m. If a proper extension cord is required for operation. Observe the
technical requirements for this product when purchasing an extension
cord.
Always use a residual current supply (RCD) protected supply.
1. Rotate the cord container (rotatable) (5) and make sure that the tip of cord
container (rotatable) (5) is pointed forward.
2. Double the power cord (3) back, about 60 cm from the power guard and
lead the loop through the hole of the rear safeguard (4). Pull it over the cord
retainer (5) and gently tug on the power cord (3) to ensure that it is firmly
secured (Figs. 2, 3).
3
4
5
Fig. 2
3
4
5
Fig. 3
3. Connect the plug of power cord (3) with a suitable socket.
WARNING! Check the voltage! The voltage must comply with the
information on the rating label!
If using an extension cord it must be suitable for outdoor use with
sockets protected against water splashing.
Ensure the extension cord is of the proper size and type for your
product:
· 1.5 mm2for up to 60 m
· 2.5 mm2for up to 100 m
4. Your product is now ready to be used.

18
EN MGT45028 by MacAllister
In more detail...
In more
detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
19
23
28
33
34
35
37
39

EN
19
In more detail...
MGT45028 by MacAllister
Intended use
Auxiliary handle adjustment
This electric grass trimmer MGT45028 is designated with a rated power input of
450 Watts.
The product is intended for cutting weed, grass or similar soft vegetation in
areas that are hard to reach, e. g. under bushes, on slopes and edges. It may
not be used to work on unusual thick, dry or wet grass, e. g. pasture grass, or
to shred leaves.
For safety reasons it is essential to read the entire instruction manual before
rst operation and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
15
15a
2.
1.
Fig. 4
Adjust the angle of the auxiliary handle (15)
to t the intended application.
1. Press down the lock button (15a) and
hold it in position, then rotate the auxiliary
handle (15) upward or downward to adjust
the angle (Fig. 4).
2. Release the lock button (15a), and
continue to gently swing the auxiliary
handle (15) until it locks in place. Ensure
the tooth system locks in place.
Length adjustment
9
8
3.
2.
1.
Fig. 5
Adjust the pole length to t the body height.
1. Loosen the locking sleeve (8) in clockwise
(Fig. 5, step 1).
2. Pull the lower pole (9) out or push it
together to adjust the desired length
(Fig. 5, step 2).
3. Tighten the locking sleeve (8) in anticlockwise
(Fig. 5, step 3).
Product functions

EN
20
In more detail...
MGT45028 by MacAllister
Adjust the main handle (1) to either 0° for trimming or 90° / 180° for edging.
1. Slide the unlock button (7) downward and turn the main handle (1) clockwise
while holding lower pole (9) to adjust the trimmer head (12) to an angle of
90° or 180° (Fig. 6). Release the unlock button (7) and keep turning the main
handle (1) until it locks in place. Ensure the unlock button (7) snaps into place.
2. Slide the unlock button (7) downward and turn the main handle (1)
anticlockwise while holding lower pole (9) to adjust the trimmer head (12) to
an angle of 0° (Fig. 7 A, B). Release the unlock button (7) and keep turning
the main handle (1) until it locks in place. Ensure the unlock button (7) snaps
into place.
Main handle angle adjustment
9
7
1
12
2.
1.
Fig. 6 (initial position 0°)
1
7
9
2.
1.
Fig. 7 A (initial position 90°)
1
9
7
2.
Fig. 7 B
(initial position 180°)
WARNING! Always ensure that the unlock button (7) snaps into place
after adjusting the main handle in one of the end positions! Never
adjust to an intermediate position!
Trimmer head tilt adjustment
Tilt the angle of trimmer head (12) to t the ground conditions for trimming
or edging use by aligning the indicator (10a) with the indication line (10b) (Fig. 8).
12
10b10a
90° 75° 60° 45°
Product functions
