2Mace® LED CC TV Security Surveillance Monitors
Specifications
Model Number: MAC-MON-17LED MAC-MON-19LED
Video inputs (1) HDMI, (1) VGA, (2) Composite BNC
Video outputs (2) Composite BNC
Audio inputs (1) VGA PC Audio, (2) RCA Composite Audio
Speakers 2 × 1.5W (rear projection)
Display modes HDMI, VGA PC, AV1, AV2
Multi-window support PIP, POP, Off (AV or VGA sub sources)
OSD control Picture Mode, Contrast, Brightness, Tint, Saturation,
Sharpness, Color Temp, DNR, Position, Sound, PIP
OSD languages English, German, French, Italian, Spanish, Russian,
Turkish, Polish, Dutch, Czech
Auto adjustment Yes (Only for VGA mode)
Wall mount Removable stands, VESA mount-ready case
Max resolution 1280 × 1024
Response time 5 ms
Color depth 16.7 million colors
Pixel pitch 0.264 × 0. 264 mm 0.294 × 0. 294 mm
Display area (H ×
V) 13.3 × 10.64 in
(337.9 × 270.3 mm)
14.81 × 11.85 in
(376.3 × 301.06 mm)
Viewing angle Vertical –80° ~ 80°; Horizontal –85° ~ 85°
Power
AC 100 ~ 240V 50/60Hz 12VDC Power Adapter
15W max. in “ON” Mode
Under 3W in Power Saving Mode ( 100 VAC)
Under 5W in Power Saving Mode (240 VAC)
Temperature
Operation: 32° ~ 104°F (0° ~ 40°C)
Storage: 14° ~ 140°F (–10° ~ 60°C)
Humidity: 10% ~ 90%
Dimensions (W × H × D) 15.16 × 15 .12 × 6.5 in
(385 × 384 × 165 mm)
16.69 × 16.34 × 6.5 in
(424 × 415 × 165 mm)
Weight 7.5 lbs (3.4 Kgs) 11.7 lbs (5. 3 Kgs)
Included accessories Power Supply Adapter, VGA Cable, User Guide
Regulatory compliance FCC, CE, RoHS
19"
17"
