Macrom KIT7WBR User manual

USER MANUAL
KIT7WBR
7-inch monitor kit + magnetic wireless rear view camera with built-in battery
KITKIT
WIRELESSWIRELESS

- 2 -
• Before completing the installation, temporarily connect the wiring and make sure it works
properly.
• Use only the parts included with the unit to ensure proper installation.
Using parts not included in the package may cause malfunctions.
• This product must be installed by an authorized reseller to qualify for warranty.
• Install the unit in a location that will not harm the driver or passenger to avoid collision in the
event of a sudden stop such as an emergency stop.
• Avoid installing the unit in places subject to high temperatures, such as direct sunlight, hot air,
or where it would be subject to dust dirt or excessive vibration.
• Be sure to remove the front protective film after installing the unit.
Installation
Monitor setup
Choose the position of the monitor in the vehicle so that it does not block your view and complies
with local laws for safe driving.
1. Dashboard
2. Support 1
2
Magnetic camera installation
Choose the position of the camera on the vehicle and make sure that the surface on which it will be
placed is metal.
To ensure proper adhesion, do not place the camera on uneven or rough surfaces.
However, it is good practice to clean the surface before applying the magnetic camera.
Note:
Before drilling the holes in the dashboard necessary for fixing the U-shaped support, make sure
there are no obstacles such as ventilation pipes underneath or electrical wiring.

- 3 -
Connections
Wifi Antennas
1. Connect the Wifi antennas paying attention to the operating frequency indicated on the antenna
( A ), 2.4 Ghz, ( B ), 433 Mhz,
A
BAB
Power Supply
1. Connect the monitor harness to your vehicle’s cigarette lighter.
2. Press the (Power) button on the top of the cigarette lighter to turn the monitor on or off.
3. As an alternative to the cigarette lighter wiring, a direct connection can be made to the car’s
ignition switch. Make sure there is a 10 Ampere protection fuse.
4. To charge the battery of the camera it is necessary to connect the USB type C to a charger with
an output voltage of DC 5V and a current of 2A.
NOTE: Before using the camera, make sure it is fully charged.
Charging time may vary depending on the actual charge of the product.
Maximum recharge time about 9 hours.
The battery charger is not supplied.
1
3
2
4
Power button and charging indicators
2. On the side of the camcorder you will find the Power button and
battery charge indicators
3. Power button (On/Off)
4. Battery charge indicators 25%-50%-75%-100% 2
34
Power connection via
cigarette lighter wiring
Connections Power via ACC
USB charging cable

- 4 -
Front panel
1. Power Key (On/Off)
2. Key Previous / Decrease brightness
3. Key Next / Increase brightness
4. Rear view camera channel selection key
5. Menu key
6. SEL / Record & Stop key
7. Wi-Fi antennas
Product overview
Warning:
The images in this manual are indicative only and may differ from the actual product. Please refer to the actual device unit.
12 3 4 5 6
7
Remote control
1. Start button for Recording / Stop (Note: SD card is required to be inserted)
2. Power key
3. Guidelines shortcut key
4. - Decrease brightness
- Key Previous
5. Menu access key
6 - Increase brightness
- Key Next
7. - Change channel
- CH1---CH2---CH3---CH4 (Screen split)
8. Displays the CH1 channel screen
9. Displays the CH3 channel screen
10. Displays the CH2 channel screen
11. Displays the CH4 channel screen
1
4
8
9
2
3
6
11
10
5
7

- 5 -
Important
Before proceeding with the use of the monitor it is necessary to pair a rear view camera using the
pairing function.
Note
Before using and pairing the camera make sure it is fully charged.
Charging time may vary depending on the actual charge of the product.
Maximum recharge time about 9 hours
Rear view camera pairing
1. Using the key (CH) select the channel to which you want
to connect the camera.
2. Enter the menu and select PAIRING to pair.
Press the SEL key to confirm the procedure.
3. The monitor shows the pairing procedure via “countdown”
on the screen
4. At the end, the image of the previously paired camera will
be displayed.
NOTE:
If you need to pair more cameras, please repeat the above procedure again selecting the
corresponding channel.

- 6 -
Video Recording / Playback
Recording mode
Before proceeding with the recording it is necessary to format
the new SD card.
Select the Recording mode using the cursor < / > and
confirm the "Format" selection by pressing the SEL key.
Confirm again to format the SD cards.
To make a recording, press the SEL key, a flashing red dot
appears on the screen
To end the recording, press SEL again.
Insert an SD card
Using a Phillips screwdriver, open the SD card door on the back
of the monitor and insert the SD card.
It is recommended to use a class 10 high-speed TF card (minimum)
or higher. Maximum allowed capacity of 128Gb.
Note:
The recording of the video signal relates only to the image of the camera/s displayed on the screen. If you
want to make multiple recordings, you need to display multiple cameras on the screen at the same time
so that the monitor can simultaneously record multiple channels.
Circular Registration
If you want to overwrite the entries, you must activate the
"Circular logging" function.
Select the Recording mode using the cursor < / > and confirm
the selection "Circular recording" by pressing the SEL key and
confirm again to activate the function.
Note:
When the function is active, the symbol appears on the
screen to confirm that overwriting has been activated.
Note:
When the SD is inserted, the symbol appears on the screen which
confirms the presence of the SD card. If the symbol turns out to be red, the
class of the SD does not comply with the specific requests of the product.
Video playback
If you want to view the recordings you need to access the Play
function. The video list will be shown in sequence of date and
time of recording.
Note:
Each recording segment has a maximum duration
of 60 seconds.
Each file is approximately 4 megabits in size.

- 7 -
System settings
Image settings
Access the menu and select image using the cursor < / > and
confirm the selection using the SEL key.
Select the Brightness / Contrast / Color functions using the
cursor < / > and confirm your selection by pressing the SEL
key.
Modify the desired value of the selected function and press
menu to exit the configuration.
Image rotation
Enter the menu and select Mirrors using the cursor < / > and
confirm the selection using the SEL key.
Select the rotation of the desired image using the cursor < / >
and confirm the selection by pressing the SEL key. Press menu
to exit setup.
Split mode setting
Enter the menu and select Mode using the cursor
< / >
and
confirm the selection using the SEL key.
Select the viewing mode of the screen with the images you wish
to view using the cursor
< / >
and confirm your selection by
pressing the SEL key.
Press menu to exit setup.
Impostazione della fotocamera
Enter the menu and select Mode using the cursor < / > and
confirm the selection using the SEL key.
Select the viewing mode of the screen with the images you
wish to view using the cursor < / > and confirm your selection
by pressing the SEL key.
Press menu to exit setup.
Note: it is possible to set the automatic rotation cycle of the
display (1-2-3-4) and the desired time.
System setup
Access the system settings and select image using the
cursor < / > and confirm the selection using the SEL key.
Select the functions: Date-Time / Language / Trigger
/ Guidelines / System Reset using the cursor < / > and confirm
your selection by pressing the SEL key.
Modify the desired value of the function select and press menu
to exit the configuration.
Note it is possible to set the automatic rotation cycle of the
display (1-2-3-4) and the desired time.

- 8 -
Specifications
Monitor
Screen .............................................................................................................................. 7’’ AHD IPS
Resolution ................................................................................................................ 1024xRGB*600P
Contrast ..................................................................................................................................... 600:1
Power Supply .................................................................................................................... DC12V-36V
Maximum current level ................................................................................................................ 10A
System....................................................................................................................PAL/NTSC (AUTO)
Connection ...................................................................................................................................WiFi
Registration
Mode.......................................................................................................QUAD-Vision 4 retrocamera
Video..............................................................................................................................................Mp4
Images........................................................................................................................................... JPG
Support
Typology ...................................................................................................................... Full SD HC/XC
Maximum capacity.................................................................................................................... 128Gb
Speed ................................................................................................................ Class 10 (minimum)
Bus SD....................................................................................................................................... UHS-I
Category ................................................................................................................... High Endurance
Note:
The Endurance category guarantees a greater amount of overwriting than traditional SD.
WiFi
Integrated Wi-Fi.............................................................................................................2.4G wireless
Network range............................................................................................................ 2403-2480MHz
Distance ............................................................................................................ ≤200m in open field
Camera
Sensor ................................................................................................................................. 1/3’’ AHD
Risolution ........................................................................................................................... 1280*720P
Viewing angle............................................................................................................. 110°[H] 140°[D]
Waterproof ................................................................................................................................... IP68
Night lighting ...................................................................................................................IR (infrared)
Night vision distance ............................................................................................................5 meters
Battery
Battery capacity ...................................................................................................................6700mAH
Charging time ............................................................................................................................. 9 ore
Operating time .......................................................................................................................... 16 ore
Charging power supply....................................................................................................USB Type-C
Type of battery charger ..................................................................................................... DC 5V - 2A
Battery charge indicators ................................................................................25%-50%-75%-100%
Installation .............................................................................By magnet wrapped with rubber case
