MAD REVOLVE User manual

123 4 5
678 9 10 11 12 13 14 15 16 17 18
3
4
2
1
7
8
6
5
11
12
10
9
15
16
14
13
17
18
Sleeve
Cooling Unit
Mouthpiece
DRC Airflow Tube
Secondary Cooling Unit
Cooling Fins
Airport
Reclaim Filter Screen
Reclaim Filter Posts
Cooling Helix
Adjustable Airport
DRC Aperture
Adjustment Ring
DRC Indicator
DRC Internal Aperture
O-ring Locking Groove
O-ring Storage / SCU Lock
Secondary DRC Indicator
ADDITIONAL INFORMATION
• Please be aware that the Cooling Fins may get hot during use. This is
intentional, they are designed to dissipate heat from your vapor.
• Before removing the Cooling Unit do a full turn on the Adjustment Ring to
remove the excess reclaim from the side of the spirals. This will help with
removing and re-inserting the Cooling Unit when it’s done without cleaning.
• If the Cooling Unit is difficult to turn or remove from the Sleeve then try
warming it up with another session, heat can help loosen the build-up. Alterna-
tively soak in isopropyl alcohol.
• NEVER try to move the DYNAVAP Tip side-to-side when removing it from the
Glass Sleeve, it might break it. Only pull and twist.
•If your DYNAVAP Tip is loose or does not have enough friction, switch the grey
o-rings for the black o-rings for a slightly tighter fit.
• To remove the inner o-ring that is located behind the Adjustment Ring, please
use a needle or sharp tweezers.
• The Mouthpiece is compatible with 10mm WP connections.
• The 12mm wide Glass Sleeve may be used with other vaporizers that has
12mm WPA connection.
•If your Stem needs cleaning, you may try the other Airflow Tube for a clean
vapor path.
BEFORE FIRST USE
Please clean each part of your Stem thoroughly with isopropyl alcohol to remove
every trace of residue from the machining and coating process.
You will need to provide your own DYNAVAP Tip and Cap combination to
complete the Revolve Stem.
CLEANING AND CARE
Soak the Stem in isopropyl alcohol for at least 30 minutes using the cleaning /
storage tube or a zip-lock bag. Shake it periodically for a thorough clean. If you
are cleaning the Glass Sleeve, only shake it carefully to protect the glass from
accidental damage. Drain the solution, rinse the parts with hot water and dry
them completely before reassembling.
You can soak the DYNAVAP Tip alongside the Stem, but never submerge a
DYNAVAP Cap in any cleaning solution
For a quick clean, dip the Cooling Unit in cleaning solution and use a paper towel
to ‘twist off’ the spiral. Then use q-tips with some cleaning solution to clean the
rest of the parts.
We recommend that you only remove the Cooling Unit from the Sleeve when you
intend to clean it. Do not remove the o-rings when cleaning the Stem, they are
isopropyl alcohol safe.
Do not soak Wood Sleeves in cleaning solution, just clean the metal liner with a
q-tip or pipe cleaner. Regularly apply a small amount of wood wax to the outside
of the Wood Sleeve to avoid cracking.
WARNING
MAD Heaters products and accessories are only intended for individuals who are
18 years of age or older. If you experience any side effects or possible side effects,
stop using the product immediately and consult a physician. Please be
responsible and keep out of reach of children and pets.
USE OF THIRD PARTY TERMS
DYNAVAP is a registered trademark of Dynavap LLC and is only used here in
accordance with fair use policies.
REVOLVE
USER MANUAL
madheaters.co.uk
TECHNICAL SPECIFICATIONS
•Length: 80mm / 109mm with Tip (XL Size)
•Width: 12mm (at widest point)
•Material: Grade 5 Titanium
•Weight: 18.5g / 0.65oz
•O-rings: Heat resistant, isopropyl alcohol safe

Cooling Flavor Sleeve temperature
The guide values are based on a scale of 5. Your experience might differ.
DIRECT AIRFLOW OPTIONS (OPTIONAL)
You can expand the capabilities of your Revolve Stem even further with the
optional Direct Airflow Tube. It will remove the DRC options entirely to give
you improved flavor and cooler Sleeve temperature, but with warmer vapor.
(DIRECT) OPEN
Air intake at the Airport is directed to the Mouthpiece for a blast of fresh air
while the vapor heads through the center.
(DIRECT) BYPASS
Fresh air is drawn around the Helix to cool the Sleeve and the Cooling Unit
before mixing with the vapor which then travels through the center.
(DIRECT) CLOSED
The Airport is closed for a hotter, more direct vapor experience.
ADJUSTABLE AIRPORT
When using the OPEN or BYPASS mode you can control the maximum air intake
at the Adjustment Ring with the help of our fully adjustable Airport.
2.5 43.5
24.5 2
153.5
DRC AIRFLOW OPTIONS
Align the line on the Adjustment Ring to the Airport to choose from the
following options with the Draw Resistance Control (DRC) Airflow Tube:
OPEN
Fresh air is drawn into the Airport and through the center of the Cooling Unit
before mixing with the vapor and passing over the Helix.
BYPASS
The air intake at the Airport is directed straight to the Mouthpiece for a blast of
cool air that bypasses the Helix.
CLOSED
The Airport is closed. Not adding any fresh air will produce denser clouds while
still cooling the vapor. Perfect for mouth-to-lung use.
4 3.5 3.5
4.5 3.5 5
3 4 5
LOCKABLE SPINNING MOUTHPIECE
The Revolve is a breeze to use with a lighter thanks to its built in
smooth-spinning Mouthpiece. If you are using a heater or just want to fix the
Mouthpiece you can lock or unlock the mechanism with a quick adjustment.
LOCKED MODE
Pull out the Airflow Tube from the Mouthpiece and roll the o-ring from its
storage position into the locking groove as shown above. The o-ring will create
friction on the inner side of the Mouthpiece which will stop it from spinning.
SPINNING MODE
Remove the o-ring completely from the Airflow Tube OR roll it down to the
storage position as shown above to store it for on the go. To remove the o-ring
from its locking position, pinch the o-ring to create a bulge and push it off
sideways with your fingernail until it begins to rise up out of the groove.
DRAW RESISTANCE CONTROL
To adjust the DRC slowly start pulling out the Mouthpiece until it locks into
position as shown below. Locate the triangle on the Airflow Tube, then rotate
and adjust with your fingernail from the top grooves.
SECONDARY COOLING UNIT (SCU)
The SCU will increase the cooling capabilities of your Revolve Stem even further,
and it is especially useful with the Direct Airflow Tube.
To install, first remove the o-ring from the Storage Position, push the SCU in
place, then replace the o-ring.
If you would like to install the SCU and lock the spinning Mouthpiece at the
same time, use a second small o-ring (5x1mm) in the Locking Groove.
The SCU will provide the following modifiers to the guide values:
With DRC Airflow Tube: + 0.5 Cooling, - 0.5 Flavor
With Direct Airflow Tube: + 1 Cooling, - 0.5 Flavor
ALTERNATIVE SLEEVE OPTIONS
The Sleeves will affect the Cooling, Flavor and Sleeve temperature as follows:
GLASS SLEEVE
With DRC Airflow Tube: + 0.5 Flavor, - 2 Sleeve temp.
With Direct Airflow Tube: - 1 Sleeve temp.
WOOD SLEEVE
With DRC Airflow Tube: - 0.5 Cooling, - 3 Sleeve temp.
With Direct Airflow Tube: - 2 Sleeve temp.
RECLAIM FILTER SCREEN
The optional removable Screen acts as a particulate filter as well as a collector
for some of the reclaim before it has a chance to condense on the Cooling Unit.
This extends the number of sessions before deep cleaning is required.
To insert the Screen, remove the Cooling Unit from the body and ‘snap’ the
Screen into position between the two posts at the end of the Cooling Unit .
Replace or clean regularly for the best experience.
MTLDL
Choose either mouth-to-lung (MTL)
for slower and tighter draws or
direct-lung (DL) for powerful and
long draw with increased airflow.
The DL side has a single long deep
line, the MTL setting has 3 graduated
lines (deeper equals more open).
Pro tip - When the Screen is full you can place the whole thing in your next bowl for
a cheeky reclaim bonus.
Try the MTL side with the CLOSED option to further reduce the airflow.
Drawing too hard with MTL can cause excess condensation in the DRC tube.
