made for movement NF-walker User manual

USER
MANUAL
ENGLISH
NF-WALKER

1. Introduction 01
2. Intended use 01
2.1 Contraindications 01
3. Warnings/safety 02
4. Using NF-Walker 02
4.1 Period of use 02
4.2 Getting the user into NF-Walker 03
4.2.1 Shoes 03
4.2.2 Preparatory steps 03
4.2.3 Getting the user into the brace 03
4.2.4 Securing the user 04
4.2.5 Getting the user onto the chassis without lifting straps 05
4.2.6 Getting the user onto the chassis using lifting straps 06
CONTENT
NF-walker

4.3 Getting the user out of NF-Walker 07
4.3.1 Without lifting straps 07
4.3.2 Using lifting straps 08
5. Equipment and adjustments 09
5.1 Individual adjustment 09
5.2 Extra equipment 09
6. Technical information 10
6.1 Data and dimensions for NF-Walker M5 10
6.2 Tests and approvals for NF-Walker M5 10
6.3 Data and dimensions for NF-Walker XR5 11
6.4 Tests and approvals for NF-Walker XR5 11
7. Waste disposal 11
8. Cleaning and maintenance 12
9. Warranty 12

1
1. INTRODUCTION
Congratulations on choosing an NF-Walker aid. Everyone has the right to be able to move around, and at
Made for Movement we make it our mission to offer opportunities for movement to people with restricted
movement or who are only able to move on their own to a limited extent. NF-Walker offers users with limited
ability to stand or walk independently the opportunity of dynamic standing, walking and movement.
NF-Walker can be adjusted to suit the needs of most users. These instructions provide an introduction to
using NF-Walker.
2. INTENDED USE
NF-Walker is an aid intended to allow dynamic standing, walking and movement. NF-Walker M5 is suitable for
persons between 70 cm and 1.50 m with a maximum weight of 50 kg.
NF-Walker XR5 is suitable for persons between 1.30 and 1.80 m with a maximum weight of 80 kg.
. CONTRAINDICATIONS
The user’s therapist, doctor or the person prescribing NF-Walker is in all cases responsible for
evaluating any risks and benefits associated with using the aid.
The following should be observed in order to assess possible contraindications:
•Fixed contractures
•Unstable bone structure
•Open wounds on the skin in areas of
the body that come into contact with
parts of NF-Walker
•Circulatory disorders
•Respiratory disorders
•Heart complaints
•Epilepsy

2
3. WARNINGS/SAFETY
•Must only be used when the user is under the
supervision of a responsible person. Particularly
close supervision is recommended when used
outdoors because of uneven surfaces etc
•Is a personal aid and must not be used by
persons for whom it has not been
specially adjusted
•Must not be adjusted by persons not qualified
to do so
•Must not be used without regular follow-ups
•Must only be used with shoes compatible with the
Made for Movement shoe clips supplied by Made
for Movement
•Must be stored in such a way that children or
unauthorised persons cannot use it as a toy
or tamper with the settings
•Must be stored in a dry place
•Must be appropriately secured during transport
so as to avoid transport damage or damage to the
interior of the vehicle
Make sure that there is always a piece of clothing between the user’s skin and places on the body that are in
contact with the product. This is important to minimise the risk of allergic reactions and to prevent blisters
during use. All the materials used in NF-Walker have, however, been tested and approved as non-allergenic.
4. USING THE NFWALKER
. PERIOD OF USE
How long an individual should use NF-Walker is assessed on the basis of physical condition and state of health.
The user’s therapist/doctor is responsible for assessing usage on a regular basis.
NF-Walker

NF-WALKER USER MANUAL • ENGLISH
3
. GETTING THE USER INTO NFWALKER
The following section assumes that NF-Walker has been adjusted for the user by an aid consultant from
Made for Movement or another qualified person approved by Made for Movement. The user’s carers should
also have undergone the necessary training in using the product. The information below describes a number of
methods for getting the user into and out of NF-Walker.
.. SHOES
NF-Walker must only be used with shoes compatible with the Made for Movement shoe clips supplied by
Made for Movement. Check regularly to ensure that the shoes/sandals are a good fit. Ensure that you tighten
the laces/Velcro so that the shoes fit snugly. If you are in any doubt as to the appropriate type of shoe/size,
contact Made for Movement.
.. PREPARATORY STEPS
Remove the brace from the chassis and place on a mat or firm surface. Ensure all the buckles are undone
before placing the user in the brace.
.. GETTING THE USER INTO THE BRACE
The user can be
moved using a
hoist or lifted
into the brace
and positioned
as illustrated.
The user’s pelvis
should be placed
in the centre of
the bottom broad
strap
(the hip belt).

4
.. SECURING THE USER
Avoid folding the trousers at the front of the leg before fastening the calf bow,
in order to avoid pressure marks. Tighten the strap on the calf bow securely.
It should be sufficiently tight that the carer can only get one finger between the
calf bow and the back of the user’s leg when the user is in the standing position.
Fasten the shoes to the brace first.
Bend the user’s knee and hold the heel down.
Bend the brace at the knee joint, place the
two fasteners in the notch and screw tight.
Pull the chest straps gently to ensure the user is secure in the belt then tighten
the belt. Don’t forget to secure the yellow safety strap.
Check that the pelvis is horizontal
before fastening the hip belt.

NF-WALKER USER MANUAL • ENGLISH
5
.. GETTING THE USER ONTO THE CHASSIS WITHOUT LIFTING STRAPS
Roll the user onto one side and lift
the user holding the brace.
Hold down the button on the pelvic plate and lower
the quick bolt into the hole on the column.
Fasten the elastics front and back, then release the brake.

6
.. GETTING THE USER ONTO THE CHASSIS USING LIFTING STRAPS
It is important that the lifting straps are inside the chest
belt and on the front of the user’s shoulders. Fasten the
lifting loops to the hoist (inner or outer loop depending
on weight of the user).
Lift the user using the hoist and lower onto the
chassis. Check the user’s position so that the
quick bolt goes into the hole on the column.
Hold down the button.
Fasten the elastics front and back then release the brake.

NF-WALKER USER MANUAL • ENGLISH
7
. GETTING THE USER OUT OF NFWALKER
.. WITHOUT LIFTING STRAPS
Apply the brake and loosen
the elastics front and back.
Stand alongside the user,
facing forwards.
Take hold of the hip bows
and press the button using
your thumb. Support the
child’s upper body against
your body and lift the child,
in the brace, out of the
chassis.
It is important to bend at
the knees and use the large
muscle groups for lifting.
Move the user to a firm
surface or mat.
Once the user is in a safe
position, loosen all the
straps and the shoe clips.
Roll the user on to one side
and remove the brace.

Fasten the lifting loops to the hoist (inner or
outer loop depending on weight of the user).
NB! The lifting straps must be inside the chest
belt and on the front of the user’s shoulders.
.. USING LIFTING STRAPS
Hold down the button and lift the user using
the hoist. The user is now free of the chassis
and can be lifted onto a firm surface.
Once the user is in a safe position, loosen all
the straps and the shoe clips. Roll the user
on to one side and remove the brace.
Apply the brake and loosen the elastics front and back.

NF-WALKER USER MANUAL • ENGLISH
5. EQUIPMENT AND ADJUSTMENTS
. INDIVIDUAL ADJUSTMENT
•NF-Walker is a personal aid, and must only be used by the person for whom it has been specially adjusted
•NF-Walker must only ever be adjusted by aid consultants from Made for Movement or other qualified
persons approved by Made for Movement
•NF-Walker requires regular follow-ups, normally three times a year
•NF-Walker must only be used with shoes compatible with the Made for Movement shoe clips supplied by
Made for Movement
. EXTRA EQUIPMENT
Various items of standard extra equipment are available for NF-Walker, such as a table, support handle, head
support, steering, abduction joint, etc. customised extra equipment may also be used.
For more detailed information, please contact Made for Movement or visit www.madeformovement.com
9

10
6. TECHNICAL INFORMATION
. DATA AND DIMENSIONS FOR NFWALKER M
. TESTS AND APPROVALS FOR NFWALKER M
CE marked in accordance with the Medical Devices Directive 93/42/EEC
TÜV approved in accordance with EN 1985:1999 and EN ISO 11199-2:2000
Max Height 950 mm
Max Length 770 mm
Max Widith 560 mm
Wheels 175 x28 mm
Max weight of user 50 kg
Height of user 70 – 1.50 cm

NF-WALKER USER MANUAL • ENGLISH
11
. DATA AND DIMENSIONS FOR NFWALKER XR
6.4 TESTS AND APPROVALS FOR NF-WALKER XR5
CE marked in accordance with the Medical Devices Directive 93/42/EEC
TÜV approved in accordance with EN 1985:1999 and EN ISO 11199-2:2000
Max Height 1260 mm
Max Length 1070 mm
Max Widith 800 mm
Wheels 175 x28 mm
Max weight of user 80 kg
Height of user 1.30-1.80 m
7. WASTE DISPOSAL
All parts of NF-Walker are recyclable. The brace and chassis should be delivered to an approved waste
disposal site. Straps, elastics, padding and buckles can be treated as ordinary waste.

12
8. CLEANING AND MAINTENANCE
NF-Walker should be cleaned using a cloth dampened in mild soapy water. Do not use solvents, high-pressure
washers or other “aggressive” cleaning methods. The same applies to straps and padding. If NF-Walker is used
outdoors, any sand and dirt should be brushed off after use.
Check regularly to ensure all buckles, elastics and straps are intact. Check that all the joints of the brace are
moving freely, and that the wheels are rolling as they should.
Check for loose screws, and tighten if necessary. Do not change the settings; this should only be done by
qualified staff.
9. WARRANTY
Made for Movement provides a two-year warranty on all new NF-Walkers.
The warranty does not cover additional equipment produced by a company other than Made for Movement.
The following criteria must be satisfied in order for the warranty to be valid:
•Adjustment and servicing have been carried out by Made for Movement or other qualified persons approved
by Made for Movement.
•Repairs under warranty must be approved in advance by Made for Movement
•NF-Walker has undergone regular safety checks and servicing
•NF-Walker has been subjected to normal treatment and used as described in these instructions
Should NF-Walker not work satisfactorily, contact Made for Movement direct by calling
[phone] or e-mailing [e-mail]

Tel. [phone]
[e-mail]
www.movementsn.com
Copyright © 2011 Made for Movement Group. All rights reserved.
Innowalk and NF-Walker are trademarks of Made for Movement Group.
Photos are for illustrative purposes only and persons depicted may be models.
