MadgeTech QuadTemp Reference guide

MadgeTech, Inc.
PO Box 50 lWarner, NH 03278
Phone [phone] lFax 603.456.2012
www.madgetech.com l[email protected]
Red 485
Dark Blue Pantone 289
Light Blue 58% of Pantone 289
REV F 2010.04.15
To view the full MadgeTech product line,
visit our website at www.madgetech.com.
QuadTemp
4-Channel Thermocouple Based Temperature Recorder
Red 485
Dark Blue Pantone 289
Light Blue 58% of Pantone 289
Product Information Card
QuadTemp and OctTemp
OctTemp
8-Channel Thermocouple Based Temperature Recorder
Product Quick Reference Card
Part Number QuadTemp OctTemp
Internal Channel
Temperature Sensor Semiconductor
Internal Channel
Temperature Resolution 0.05°C
Internal Channel Accuracy +0.5°C
Remote Channel Temperature
Sensor Range, Resolution & Accuracy *See Table for Details
Cold Jct. Compensation Automatic
Channels 1 internal & 4 remote 1 internal & 8 remote
Memory 500,000/channel 500,000/channel
Sample Rate 4 seconds up to 24 hours
LED Indicator None
Required Interface Package IFC110 or IFC200
Baud Rate 115,200
Typical Battery Life 18 months typical
Operating Environment –20 to +60°C, 0 to 95%RH (Non–Condensing)
Material Anodized aluminum
Dimensions 7.24” x 2.7” x 1.02”
(183mm x 68mm x 26mm)
7.24” x 2.7” x 1.26”
(183mm x 68mm x 32mm)
Approvals CE
Specifications subject to change.
See MadgeTech’s terms and conditions at www.madgetech.com
Device Maintenance
Battery Replacement
Materials:
3/32” HEX Driver (Allen Key)
Replacement Battery (U9VL-J)
- Remove the cover from the device by unscrewing the four
screws.
- Remove the battery from its compartment and unsnap it
from the connector.
- Snap the new battery into the terminals and verify it is secure.
- Replace the cover taking care not to pinch the wires. Screw
the enclosure back together securely.
Note: Be sure not to over tighten the screws or strip the threads.
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT
SHORT CIRCUIT, CHARGE, FORCE OVER DISCHARGE, DISASSEMBLE,
CRUSH, PENETRATE OR INCINERATE. BATTERY MAY LEAK OR
EXPLODE IF HEATED ABOVE 60°C (140°F).
Recalibration
The QuadTemp or OctTemp standard calibration is one point
at 25°C for the internal temperature sensor and 0mVs for the
thermocouple channels.
Pricing:
Recalibration traceable to NIST $60.00
Recalibration $40.00
Additional:
As Found Data $15.00 per parameter/channel
Verification Point $15.00 per point
Channel (1st) $30.00 at 25°C
$45.00 at custom point
Additional Channels $3.00 at 25°C
$4.50 at custom point
To send the devices back, visit www.madgetech.com, select
Services then RMA Process.
* Remote Channel Range, Resolution & Accuracy
Thermocouple Range (°C) Resolution Accuracy
J -210 to +760 0.1°C +0.5°C
K -260 to +1370 0.1°C +0.5°C
T -260 to +400 0.1°C +0.5°C
E -260 to +980 0.1°C +0.5°C
R -50 to +1760 0.5°C +2.0°C
S -50 to +1760 0.5°C +2.0°C
B +60 to +1820 0.5°C +2.0°C
N -260 to +1300 0.1°C +0.5°C

QuadTemp and OctTemp Product Quick Reference Card
Wiring the Data Logger
Wiring Diagrams
The QuadTemp has four SMP connections and the OctTemp
has eight. These connections allow the user to insert
subminiature thermocouple plugs into the connectors on
the device. The diagrams below show how to connect the
individual thermocouples for each of the devices.
Warning: Note the polarity instructions. Do not attach wires to
the wrong terminals.
Product Notes
Thermocouples and the Software
To change the thermocouple type in the MadgeTech software:
- Select Thermocouple Type from the Device Menu.
- Click on the Change button in the Thermocouple Type window.
- Select the correct thermocouple type from the drop down list.
- Click on the Save button to store the thermocouple type in
the device.
- Click OK.
Please note that the same thermocouple type must be used on
all of the channels.
LED Function
Green LED - Blinks to indicate that the device is armed
and/or running.
Red LED - Low battery or low memory.
Blue LED on Thermocouple channels - Blinks at the reading
rate (but no more than once every other second).
Installation Guide
Installing the Interface cable
- IFC200, IFC202 or IFC300
Refer to the “Quick Start Guide” included in the package.
- IFC110, IFC102 or IFC103
Plug the serial cable into the port and verify it is secure.
- USB-1 or USB-101
Install the USB drivers from the CD provided in the kit, than
plug the USB cable into the computer and the serial cable into
the serial port.
Installing the software
Insert the Software CD in the CD-ROM Drive. If the autorun
does not appear, locate the drive on the computer and double
click on Autorun.exe. Follow the instructions provided in the
Wizard.
Connecting the data logger
- Once the software is installed and running, plug the interface
cable into the data logger.
- Click the Communication Menu, then Auto Configure Port.
- After a moment, a box similar to the following will appear;
- Click OK. The Device Status box will appear. Click OK.
- At this point, communications have been configured for your
logger. These settings can be found under the Communication
Menu.
Note: For additional installation instructions refer to your “Data
Logger & Software Operating Manual”.
Device Operation
Starting the data logger
- Click Device Menu then
Start Device.
- Choose the desired start
method.
- Choose the start parameters
by selecting a Reading Rate
suitable for your application.
- Enter in any other desired
parameters and click Start.
- A box will appear stating the
data logger has been started.
Click OK.
- Disconnect the data logger from the interface cable and
place it in the environment to measure.
Note: The device will stop recording data when the end of
memory is reached or the device is stopped. At this point the
device cannot be restarted until it has been re-armed by the
computer.
Downloading data from a data logger
- Connect the data logger to the interface cable.
- Click the Device Menu then Read Device Data. This will
offload all recorded data onto the PC.
Technical Support
Visit www.madgetech.com, or call [phone].
Technical support is also available by e-mailing
[email protected]
Additional product information is available by e-mailing
[email protected].
