M-Nav 800 English
This Magellan receiver is a vehicle-navigation aid designed to
assist you in arriving to your selected destinations. When using
this Magellan product, these safety rules must be followed to
prevent accidents that can result in injury or death to yourself or
others:
• Please check with your state or local law enforcement for
applicable regulations regarding mounting to the windshield.
• When driving, the need to view the display is minimal. Voice
prompts will guide you to your destination. The driver should
enter data or program the Magellan receiver only when the
vehicle is stopped. Only a vehicle passenger should enter
data or program the receiver while the vehicle is moving.
• It is your responsibility to comply with all traffic laws.
• Every attempt is made to ensure that the database is
accurate. However, roadways, points of interest (POIs), and
business and service locations may change over time. The
database does not include, analyze, process, consider, or
reflect any of the following: legal restrictions (such as
vehicular type, weight, height, width, load and speed
restrictions); road slope or grade; bridge height, width,
weight, or other limits; population density; neighborhood
quality or safety; availability or proximity of law enforcement,
emergency rescue, medical, or other assistance;
construction work zones or hazards; road or lane closures;
road, traffic, or traffic facilities’ safety or condition; weather
conditions; pavement characteristics or conditions; special
events; traffic congestion. It is your responsibility to
disregard any unsafe, hazardous, or illegal route
suggestions.
Navman Wireless.fm Page 3 Monday, November 7, 2011 11:18 AM

• Keep the receiver safe from extreme temperature conditions.
For example, do not leave it exposed to direct sunlight for an
extended period of time. The maximum operating
temperature is 140°F (60°C).
• Take care when mounting the receiver in your vehicle,
whether using the windshield mount or other mount or
accessories, that it does not obstruct the driver's view of the
road, interfere with the operation of the vehicle's safety
devices such as air bags, or present a hazard to occupants
of the vehicle should the receiver be dislodged while driving.
You assume the risks associated with damage to your
vehicle or vehicle occupants as the result of your choices in
mounting the receiver.
• The battery is rechargeable and should not be removed.
Navman Wireless.fm Page 4 Monday, November 7, 2011 11:18 AM

Installation
Choose a Location. The Magellan RoadMate receiver needs a clear
view of the sky to receive signals from the GPS satellites so choose a
location with an unobstructed view of the sky, commonly on or near the
windshield.
Clean the Surface. Clean the area on the windshield and allow the
surface to dry before attaching the mount.
Attach the Car Cradle. Pivot the cradle up from the bottom of the
receiver. To permanently attached the receiver to the cradle use the two
small 5.5mm x 10mm screws to attach the cradle to the receiver. If you
want to be able remove the receiver for security purposes, do not use
the two screws to attach the cradle to the receiver. Use the four 7mm x
12mm screws to attach the pivot plate to the cradle.
Attach the Receiver Assembly to
the Mount. The ball end of the
mount snaps into the pivot plate that
was just attached. Use the tightening
ring to secure the receiver assembly
to the mount but do not tighten firmly
yet. After the entire assembly is
attached to the windshield you will
want to adjust the position of the
receiver for optimum viewing.
After the mount and the receiver are
assembled, place the suction cup of
the mount firmly against the area it is to be attached to and push the
mounting lever towards the base of the mount.
When the assembly is attached to the windshield, you can use the pivot
point on the arm of the mount or the pivot ring on the back of the cradle
to adjust the receiver for optimum viewing.
Navman Wireless.fm Page 5 Monday, November 7, 2011 11:18 AM

Attach the DB-9 Power Cable.
The DB-9 cable connects the receiver
to the Navman Wireless assembly.
Attach the DB-9 connector to the
receiver cradle and RJ45 to the
Navman Wireless Power/Serial
Module.
The additional connector is used
to connect to an external antenna
(not included) to receive traffic information.
Magellan RoadMate
Power On
Press and hold the power button 2 - 3 seconds to turn the receiver on or
off. Press and hold the power button for more then 5 seconds to reset
the receiver should you have a problem with the receiver and are
instructed to reset the receiver.
The first time you use the Magellan RoadMate it may take up to 4
minutes to compute your location under normal conditions. With
adverse conditions (not having a clear view of the sky) the time to
compute your location the first time can greatly increase.
A - Power Button
B - Micro-SD slot
(under protective
cover)
C - Mini USB for
optional power or
connecting to a PC
AB
C
Navman Wireless.fm Page 6 Friday, November 18, 2011 9:38 AM

If you are not getting your current location, use these tips to improve
satellite signal reception.
Leave the garage or parking structure so the GPS receiver has a
clear view of the sky.
Satellite signals can be blocked by tall buildings, trees or
mountains. You may intermittently see a drop in signal strength
in these types of environments.
Pairing Bluetooth®
The instructions shown here are for pairing a phone during normal use.
The first time you use Bluetooth in your Magellan RoadMate receiver,
the receiver will automatically ask you if you want to pair a phone.
After selecting Yes the receiver is in pairing mode. Follow the
instructions in your phone manual to set it in pairing mode. After the
phone has searched for new devices, select “Magellan Roadmate” from
the list.
Your phone will ask for a passcode. Enter ‘1234’.
Tap Yes on the Magellan RoadMate.
A screen will confirm the successful pairing.
Navman Wireless.fm Page 7 Monday, November 7, 2011 11:18 AM

Battery
The Magellan RoadMate receiver has an internal battery that is charged
when it is being powered by the Navman Wireless device. It is
estimated that a receiver can operate for 2 hours from a fully charged
battery.
To view the battery strength indicator, access the Main menu. The
battery strength is shown below the signal strength indicator.
It can take up to 4 hours to fully charge the battery, depending on the
battery level. However, the battery does not need to be fully charged to
use the Magellan RoadMate receiver.
Traffic Notice
Traffic notifications are available as an optional service and require
connection to an FM antenna (not included).
Satellite Signal Strength
To view the satellite signal strength indicator, tap on the Menu button
while viewing the Map screen. The signal strength indicator can be
found in the upper right corner.
4 bars green:
Strong signal
Blank: No satellite
signals. Unable to
compute position.
Navman Wireless.fm Page 8 Monday, November 7, 2011 11:18 AM

Map Screen while Routing
ADisplays next turn instruction, distance until turn and street
for next maneuver. Tap to repeat last instruction.
BSpeed warning.
C(Optional Service) Traffic icon with the route delay time if
traffic warnings appear on route. (Requires FM antenna not
included.)
DDisplays ETA (estimated time of arrival). Tap to select
distance to destination, arrival time, speed or time
remaining in the route.
EZoom Out/In
FAccess Main Menu
GPress to display POIs found on next few highway exits.
(Displayed only while traveling on a highway.)
HAccess Volume/Mute and Brightness Controls
IAccess Bluetooth
JAccess OneTouch Menu
KCurrent Position Icon
A
B
C
D
EF
G
H
I
J
K
Navman Wireless.fm Page 9 Monday, November 7, 2011 11:18 AM

Menu
Main Menu. Tap on the MENU button on the Map screen to access the
Main Menu.
Access your
Address Book.
Create a route
to an address.
Create a route to a
point of interest.
Access User Setting
options.
View Map
screen.
Create a route
to a street
intersection.
Vehicle Profile.
Create a route
to nearby
emergency
centers.
Additionally if
Routing:
Cancel Trip.
Detour. Turn List.
Edit the Trip.
Create a multileg
route.
Create a route
to a previous
destination.
Access
wireless
information
