Magenta Cyan User manual

.
HDMI/DVI Extender
Quick Reference
&
Setup Guide

CYAN HDMI EXTENDER Contents
Chapter Page
1. Specifications...................................................................................................2
2. Introduction ........................................….........................................................3
2.1 Overview................................................................................….................3
2.2 Equipment You May Also Need..........................................................…....3
2.3 Compatible Cabling ........................................................................…...….3
3. Setup and Installation.......................................… ......................................….4
3.1 Cabling Considerations...............................................................................4
3.2 Making the Connections.....................................................................…....5
3.2.1 Connections and Setup in General .......................................……......5
3.2.2 Connections on the Transmitter and Receiver…..............………..…..5
4. Troubleshooting...........................................................................................…6
4.1 Common Problems ....................................................................................6
Appendix A. Cabling Pinouts.........................................….....................................6
© 2008 by Magenta Research All rights reserved.
Magenta Research
128 Litchfield Rd
New Milford, CT. 06776 USA
This document and the Magenta Research products to which it relates, and the copyright in each, is the
property of Magenta Research. Neither the document nor the products may be reproduced by any
means, in whole or in part, without the prior written permission of Magenta Research. Magenta Research
makes no warranty or representation, either expressed or implied, with respect to this software or
documentation, including the quality, performance, merchantability, or fitness for a particular purpose.
As a result, this software or documentation are licensed "as is" and you, the licensee, are assuming the
entire risk as to the quality and performance.
In no event will Magenta Research be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use of or inability to use the software or documentation.
Cyan and the Cyan logo are trademarks of Magenta Research.
All other brands, product names, and trademarks are the property of their respective owners
1

.
1.Specifications
Cable Required: Category 5, 5e, 6 twisted pair (UTP)
Video Support: HDMI/DVI Video modes
Maximum
Resolution and
Refresh Rate: 1080P, 1600x1200 (UXGA)
Bandwidth: 4.95 Gbps
Connectors: (1) HDMI type A, (2) RJ-45, (1) DC power inlet
Temperature
Tolerance: Operating: 32 to 104°F (0 to 40°C);
Storage: -4 to +140°F (-20 to +60°C)
Humidity
Tolerance: Up to 80% noncondensing
Enclosure: Metal
Power: +5 VDC @ 260 mA max each unit
Consumption: 1.3 watts maximum each unit
Size: 0.88"H x 2.62"W x 3.06"D (2.2 x 6.6 x 7.9 cm) each unit
Weight: 0.41 lb. (0.18 kg) - each unit
Recommended maximum cable lengths:
Cat5 Cat6
1080P 50 ft (15.2m) 100 ft (30.5m)
1080I 100 ft (30.5m) 150 ft (45.7m)
720P 150 ft (45.7m) 150 ft (45.7m)
UXGA 50 ft (15.2m) 100 ft (30.5m)
Specifications
2

CYAN HDMI EXTENDER
2. Introduction
2.1 Overview
The Cyan HDMI extenders extend HDMI or DVI signals over Category 5/5e/6
cable.
WARNING
This equipment is not intended for, nor does it support, distribution
through an Ethernet network. Do not connect these devices to any sort
of networking or telecommunications equipment!
2.2 Equipment You May Also Need
• HDMI cables
• HDMI to DVI adapter cables
2.3 Compatible Cabling
Cyan HDMI extender products are compatible with Cat5/5e/6 data cabling.
CAT5/5e/6 cabling for the Cyan HDMI extender must be pinned to the TIA-EIA
T568B wiring specification (see appendix A) We also highly recommend that all
CAT5/5e/6 cables be pre-terminated and tested. Cables terminated on-site or in an
existing infrastructure should be tested before use to ensure compliance with the
TIA-EIA T568B specification. Using incorrectly terminated CAT5/5e/6 cables can
damage the units.
3

. CHAPTER 3: SETUP & INSTALLATION
4
3. Setup and Installation
3.1 Cabling Considerations
• We recommend mounting and connecting all cabling to the Cyan HDMI
components before applying power.
• Make sure that the CAT5/5e/6 cable you intend to use has been tested to comply
with the T568B wiring specification (See Appendix A).
3.2 Making the Connections
3.2.1 CONNECTIONS AND SETUP IN GENERAL
This section contains figures showing connections with the specific Cyan HDMI
units. In general, however, the connection and setup procedure at both transmitter
and receiver ends is as follows: NOTE:
All units should be cabled and powered on prior to turning on the video source
device and display. It is recommended to cable/power on receiver unit, transmitter
unit, then the display, and lastly the video source.
At the transmitter end:
1. Connect the source video to the Cyan transmitter HDMI INPUT port using an
HDMI type A cable (If using DVI video an HDMI to DVI adapter is required).
2. Connect the CAT5/5e/6 cables to the transmitter. PORT 1 is the video signal
and PORT 2 is the DDC data channel. If you do not need HDCP or DDC data,
a single CAT5/5e/6 cable can be used on PORT 1. Note that protected content
will not be displayed in this case.
3. Apply power to the transmitter. The LED’s on the RJ45 sockets will come
on (see Figure 3-3 for LED status modes)
At the receiver end :
1. Connect the display to the HDMI OUTPUT connector of the receiver (If a
DVI connector is on the display, an HDMI to DVI adapter is required).
2. Connect the CAT5/5e/6 cables to the UTP connection. PORT 1 is the video
signal and PORT 2 is the DDC data channel. If you do not need HDCP or DDC
data, a single CAT5/5e/6 cable can be used on PORT 1. Note that protected
content will not be displayed in this case.
3. Apply power. The LED’s will come (see Figure 3-3 for LED status modes)

CYAN HDMI EXTENDER
5
3.2.2 CONNECTIONS ON THE CYAN HDMI EXTENDER:
Figure 3-1 shows the Transmitter connections, and Figure 3-2 shows the Receiver
connections.
Figure 3-1. Connections on the Transmitter
Figure 3-2. Connections on the Receiver
Figure 3-3. LED Status Indicators
1— HDCP/DDC Activity
2— Receiver Link Detected
3— HDMI Source Detected
4— Power Indicator
Transmitter
1 2 3 4
Receiver
1 2 3 4
1— HDCP/DDC Activity
2— HDCP/DDC Activity
3— Transmitter Link Detected
4— Power Indicator

. CHAPTER 4: Troubleshooting
6
4. Troubleshooting
4.1 Common Problems
THERE ARE NO USER CONFIGURABLE SETTINGS FOR THE CYAN HDMI EXTENDERS
In most cases, nearly every issue with the Cyan HDMI Extenders can be resolved by
checking the CAT5/5e/6 termination and making sure that it’s pinned to the T568B
wiring specification. However, there may be other problems that cause the system to
not perform as it’s designed. Below are solutions to the most common installation
errors.
Problem: No video or poor video quality.
Solution: • Check that both units are powered.
• Power units in the sequence noted in section 3.2.1.
• Make sure the CAT5 cable is terminated correctly per the
T568B wiring specification.
• Screened Cat5/5e/6 cable (ScTP) may be required for noisy EMI
environments. Ensure the shield is properly connected at each
RJ45 end.
• Is the display device powered on and functioning?
• Some HDMI sources can take up to 5 minutes to initialize and will
not output video signals during this time.
• Cell phones may cause interference at close range (3 ft) and cause
the video signal to be interrupted or lost. All devices may need to be
power cycled if video is lost.
Appendix A. Cabling Pinouts
Table A-1. T568B CAT5 pinout

CYAN HDMI EXTENDER
Magenta Research
128 Litchfield Road, New Milford, CT 06776 USA
[phone] FAX [phone]
www.magenta-research.com
PN: 5310223-01, Rev 02, 03/2009
