Magic-Pro MP-7VIP User manual

MP-7VIP
Motherboard
User’s Manual
Product Name:MP-7VIP
Manual Revision:English, 1.00
Release Date:January, 2000

POST-CONSUMER
RECYCLED PAPER
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
wThis device may not cause harmful interference
wThis device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy. If this equipment is not installed and
used in accordance with the manufacturer's instructions, it may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
wReorient or relocate the receiving antenna.
wIncrease the separation between the equipment and receiver.
wConnect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
wConsult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required to
assure compliance with FCC regulations. Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user's authority to operate
this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for audio noise emissions from
digital apparatusses set out in the Radio Interference Regulations of the Canadian
Department of Communications.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a
commitment on the part of the vendor. No warranty or representation, either expressed or implied,
is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
The manufacturer reserves the right to make changes to the content of this document and/or the
products associated with it at any time without obligation to notify any person or organization of such
changes. In no event will the manufacturer be liable for direct, indirect, special, incidental or
consequential damages arising out of the use or inability to use this product or documentation, even
if advised of the possibility of such damages. This document contains materials protected by
copyright. All rights are reserved. No part of this manual may be reproduced or transmitted in any
form, by any means or for any purpose without expressed written consent of it's authors. Product
names appearing in this document are mentioned for identification purposes only. All trademarks,
product names or brand names appearing in this document are registered property of their
respective owners.
Copyright Magic-Pro Computer Co., LTD.
All rights reserved
Author : Raymond
Printed in Taiwan January 2000

MAGIC-PRO MP-7VIP
2
CONTENT
Chapter 1: Introduction .......................... 4
1-1 CPU .................................................................................... 4
1-2 CHIPSET ............................................................................ 4
1-3 L1 / L2 CACHE ................................................................... 4
1-4 MAIN MEMORY .................................................................. 5
1-5 BIOS ................................................................................... 5
1-6 MULTI-I/O FUNCTION ........................................................ 5
1-7 AC97 CODEC FUNCTION ................................................ 5
1- MISCELLANOUS ............................................................... 6
1-9 MAINBOARD LAYOUT ....................................................... 7
1-10 MAINBOARD CHIPSETS DIAGRAM ...............................
1-11 SYSTEM MEMORY CONFIGURATION ...........................
Chapter 2: Hardware Setup .................... 9
2-1 CPU FSB SELECT ............................................................. 9
2-2 JUMP SETTINGS ..............................................................11
2-3 CONNECTORS ................................................................ 16
2-4 DRIVER INSTALLATION .................................................. 17
Chapter 3: BIOS Setup ......................... 19
3-1: INTRODUCE THE BIOS. ................................................ 19
3-2: WHAT IS SETUP ............................................................. 19
3-3: HOW TO RUN SETUP .................................................... 20
3-4: WHAT IS THE CMOS ...................................................... 20

MAGIC-PRO MP-7VIP
3
3-5: WHAT IS POST ............................................................... 20
3-6 STANDARD CMOS FEATURES ...................................... 22
3-7 ADVANCED BIOS FEATURES SETUP ........................... 25
3- ADVANCED CHIPSET FEATURES ................................. 30
3-9 INTEGRATED PERIPHERALS ........................................ 34
3-10 POWER MANAGEMENT SETUP .................................. 39
3-11 PnP/PCI CONFIGURATION SETUP .............................. 46
3-12 PC Health Status ........................................................... 50
3-13 FREQUENCY/VOLTAGE CONTROL ............................ 51
3-14 LOAD FAIL-SAFE DEFAULTS ....................................... 53
3-15 LOAD OPTIMIZED DEFAULTS ..................................... 53
3-16 SUPERVISOR/USER PASSWORD ............................... 54
3-17 SAVE & EXIT SETUP .................................................... 55
3-1 EXIT WITHOUT SAVING................................................ 55
Appendix A
Flash Memory Up ate Installation .......................... 56
Appendix B
Driver installation ..................................................... 57
Appendix C
The Usage of RT2 .................................................... 59

MAGIC-PRO MP-7VIP
4
Chapter 1: Introduction
1-1 CPU
 Supports AMD Althon Slot-A 550/ 600/ 650/ 700/ 750/ 800MHz CPUs.
 Supports CPU voltag Auto-D t ct circuit.
1-2 CHIPSET
 VIA KX133 chips t includ s VT8371 syst m controll r (North Bridg )
and VT82C686A PCI to ISA bridg (South Bridg ).
 Supports 32-bit PCI and 32-bit AGP int rfac s.
 VIA VT82C686A includ s UltraDMA-33/66, 4 USB ports, Int grat d
Sup r-I/O, AC97 / MC97 link, Hardwar Monitoring, Pow r
Manag m nt, and K yboard / PS-2 Mous Int rfac s plus RTC /
CMOS on chip.
 Supports s parat ly pow r d 3.3V (5V tol rant) int rfac to syst m
m mory, AGP, and PCI bus.
 Modular pow r manag m nt and clock control for advanc d syst m
pow r manag m nt.
 100MHz DDR (Doubl Data Rat ) transf r on K7 CPU addr ss and
data bus s.
 Supports 66MHz 1x, 2x and 4x mod s for AD and SBA signaling.
 Pip lin d split-transaction long-burst transf rs up to 1GB/s c.
 Supports Sid Band Addr ssing (SBA) mod .
 Windows 95 OSR-2 VxD and int grat d Windows 98 / Windows 2000
miniport driv r support.
 AGP v2.0 compliant.
1-3 L1 / L2 CACHE
 Th AMD Athlon proc ssor on-chip L1 cach is 128KB.
 Th AMD Athlon proc ssor on-chip L2 cach is 512KB.

MAGIC-PRO MP-7VIP
5
1-4 MAIN MEMORY
 Supports PC100 and PC133 MHz SDRAM, VCM SDRAM, and
ESDRAM m mory up to 3 DIMMs.
 Diff r nt DRAM timing for ach bank.
 Supports mix d 1M/2M/4M/8M/16M/32MxN DRAMs.
 Supports up to 1.5GB m mory spac (256MB DRAM t chnology).
 Supports 3pcs 168pin DIMM sock ts ( 64-bit data width and 3.3V
DRAM int rfac with 5V-tol rant inputs).
 Two-bank int rl aving for 16Mbit SDRAM support.
 Two-bank and four bank int rl aving for 64Mbit SDRAM support.
1-5 BIOS
 Award BIOS.
 Supports Plug & Play (PnP).
 FLASH MEMORY for asy upgrad .
 Supports Advanc d Pow r Manag m nt (APM) R v 1.2 function.
 Supports Advanc d Configuration Pow r Manag m nt Int rfac
(ACPI) R v 1.0 function.
 Y ar 2000 compliant.
1-6 MULTI-I/O FUNCTION
 On floppy port supports up to 2.88MB.
 4x Built-in USB conn ctors.
 Ultra ATA33/66 bus mast r IDE supports up to 4 IDE d vic s.
(Including ZIP / LS-120 floppy d vic s)
 2x 16550A Built-in fast UART compatibl s rial port conn ctors.
 Built-in SPP / EPP / ECP parall l port conn ctors.
 Built-in standard IrDA TX / RX h ad r.
 P riph rals boot function with ATX pow r.
1-7 AC97 CODEC FUNCTION
 SoundBlast Pro Hardwar and Dir ct Sound R ady AC97 Digital
Audio Controll r.

MAGIC-PRO MP-7VIP
6
1- MISCELLANOUS
 ATX form factor.
 Mainboard siz : 19mm X 30.5mm.
 Provid s 5x PCI slots, 1x ISA slot, 1x AMR slot, 1x AGP slot and 3x
DIMM sock ts.
 AGP 2.0 int rfac with 1x 2x / 4x data transf r and 2x / 4x fast writ
capability.
 AGP Univ rsal Conn ctor supports via dual mod buff rs.
 Supports SCSI, CD-ROM, ZIP, LS-120 boot up function.
 Supports Wak On LAN (WOL) boot up function.
 Supports k yboard pow r on function.
 Supports BIOS Writing Prot ction.
 Supports BIOS CPU Cor Voltag s tting.
 Provid s DIP switch for asy s tting.
 Supports Hardwar Monitor function.
NOTE: To use Wake On LAN (WOL) function, the ATX
power supply must pro ide at least 5V/720mA
standby current capacity.

MAGIC-PRO MP-7VIP
7
1-9 MAINBOARD LAYOUT
 Mainboard d fault s tting: For AMD AthlonTM 100MHz CPU Clock.
NOTE: Under 100MHz / 133MHz FSB, the SDRAM spec m st complaint PC-100 / PC-
133 spec.
3 1
1 3
JBAT1
3 1
JP9
JP2
1 3
1 3
1 3
1 3
JP5
JP6
JP7
JP8
1 3
1 3
JP3
JP4
JP1
JWOL1
FAN3
JFAN1
HDD/LED
SPK RESET PWR_LED SUSLED
IR PWR SMI
1 1
J2 J3
ATX POWER
4x AGP
Li
Battery
SLOT A
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
ISA
FLASH BIOS
DIMM1 DIMM2 DIMM3
FDD
IDE1 IDE2
VIA
VT8371
VIA
686A
RT2
USB0 USB1 PS/2
MOUSE PS/2 K/B
LPT1
COM2 COM1
upper
lower
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
upper
lower
SW1
ON DIP
1 2 3 4
ZD1
CD_IN1
CD_IN2
1 4
1 4
AMR
AC'97
Codec
USB2
9 16
1 8
Clock
Generator

MAGIC-PRO MP-7VIP
8
1-10 MAINBOARD CHIPSETS DIAGRAM
1-11 SYSTEM MEMORY CONFIGURATION
6his VIA KX133 (AMD K7) moth rboard supports 168 pin DIMM of
4MB, 8MB, 16MB, 32MB, 64MB, 128MB or 256MB to form a
m mory siz b tw n 8MB to 1.5GB (SDRAM). VIA KX133 chips ts
provid  Tabl Fr  function. It m ans that us rs can install DRAM
with any configuration and in any bank, and that is why th DRAM
tabl is not n d d but do r m mb r that th DRAM must b 3.3V
unbuff r d, 4 clock typ .
KX133
VT8371
North Bridge
516 BGA
South Bridge
352 BGA
VT82C
686A
Super South
Power Plane & Peripheral Control
GPIO and ACPI Events
Hardware Monitoring Inputs
Keyboard / PS2 Mouse
Serial Ports 1 and 2
Parallel Port
Floppy Drive Interface
MIDI / Game Ports
RTC Crystal
PCLK
SMBus
Clock
Generator
PCISTP#
CPUSTP#
MCLK
In
Data
Address
Out
SDRAM
Clock
Buffer
GCLK
CFWDRST CONNECT
PROCRDY
GCKRUN#
AGP Bus
PCI Bus SUSCLK,
SUSST1#
PCKRUN#
ATA 33 / 66
USB Ports 0 - 3
ISA Bus
AC97 Link
Memory Bus
CKE
HCLK
PCLK
SYSCLK, SYSCLK#
INTR, NMI, SMI#, STPCLK#,
IGNNE#, FERR#, A20M#,
PWROK, INIT#, RESET#
Slot-A (AMD K7)
Host CPU
3D Graphics
Controller
MC97 Modem Codec
AC97 Audio Codec
BIOS ROM
KX133 System Block Diagram Using the VT82C686A South Bridge

MAGIC-PRO MP-7VIP
9
1234
ON DIP
66MHz
1234
ON DIP
83MHz
1234
ON DIP
100MHz (default)
1234
ON DIP
110MHz
1234
ON DIP
115MHz
1234
ON DIP
124MHz
1234
ON DIP
129MHz
1234
ON DIP
133MHz
SW1 FSB
NOTE Due to the Bus Ratio is internal inside the Athlon CPU, so
that there is no any external jumper for user to set the Bus
Ratio value.
Chapter 2: Hardware Setup
2-1 CPU FSB SELECT

MAGIC-PRO MP-7VIP
10
WATCH OUT !!!
1. Please refer to your processor installation or other
documentation attached with your CPU for detailed
installing instruction.
2. Installing a heat sink and cooling fan is necessary
for proper heat dissipation from your CPU. Uncor-
rected installation may result in overheating and
damage of your CPU.
3. Before changing the setting of CPU Vcore from
BIOS program, user SHOULD make sure of correct
specification both of CPU CLOCK and RATIO.
Uncorrected setting may cause damage to your
CPU.

MAGIC-PRO MP-7VIP
11
2-2 JUMP SETTINGS
JP3 / JP4: AC97 Codec Control
AC97 Codec JP3 / JP4
Disabled
1 3
1 3
JP3
JP4
Enabled (default)
1 3
1 3
JP3
JP4
FA # FU CTIO
JFA 1 CPU FA
JFA 2 SYSTEM FA
JFA #: Onboard FA (12V) Connector.
JP1: Keyboard Power On
Keyboard Power On JP1
1 3
Enabled
1 3
ormal (default)
JP5 / JP6: USB Port Select (1)
USB Port Select JP5 / JP6
Redirect USB port3 to
USB2 connector (default)
Redirect USB port3 to
AMR

MAGIC-PRO MP-7VIP
12
USB Port Select JP7 / JP8
Redirect USB port2 to
USB2 connector (default)
1 3
1 3
JP7
JP8
Redirect USB port2 to
AGP
1 3
1 3
JP7
JP8
JP7 / JP8: USB Port Select (2)
JBAT1: Clear CMOS Data
Before you clear the CMOS data, its necessary to turn the power off first
(including +5V standby power). Otherwise, the system may wor
abnormally or malfunction.
CMOS Status JBAT1
1
3
Retain Data (default)
1
3
Clear CMOS Data
JP9: Power Lost Resume
This feature must wor with BIOS. Please refer to the BIOS Power On
After PWR-Fail sector.
Power Lost Resume JP9
1
3
ormal (default)
1
3
Enabled
RT2: Thermal Sensor Connector
a: Connect to RT2.
b: Connect this thermal sensor to
particular device which
generates lots of heat such as
Hard Dis , VGA chip, etc.
When connected, user could
observe the temperature
change from the BIOS
program.

MAGIC-PRO MP-7VIP
13
CD_I 1/CD_I 2: CD-ROM Audio Connector
GAME/MIDI Port:
Connect joystic or MIDI to this connector.
MIC :Microphone Jack
Connect to microphone device.
LI E I : Audio In Jack
Connect audio line in.
LI E OUT/SPEAKER OUT: Audio Out Jack
Connect audio line out or spea er out.
ZD1: Display DIMM Module Power Status
ON: DO NOT ta e out the DIMM module from DIMM soc et when ZD1 is
on, because the system is still in power on status (may be in suspend
mode or STR mode).
OFF: User can remove the DIMM module when ZD1 is off.
JWOL1: Wake On LA (WOL) Connector
This connector is designed to boot up system via LAN. Connect the wa e
on signal form the LAN card to this connector.
***For support WOL, the ATX power supply has to ha e at least 5V/720mA
standby current.***
Left Channel
PIN 1 Left Channel
CD_IN1PIN # CD_IN2
GND
PIN 2 GND
GND
Right Channel
PIN 3 GND
PIN 4
Right Channel

MAGIC-PRO MP-7VIP
14
PIN1~PIN4: HDD DISK LED CONNECTOR
Connect cable from the chassiss H.D.D to this connector.
PIN6~PIN10: IR (INFRARED) CONNECTOR
Connect cable from the chassiss IR to this connector.
PIN12~PIN13: ATX POWER SWITCH CONNECTOR
Connect cable from the chassiss POWER to this connector.
PIN14~PIN15: SMI CONNECTOR
J2 SIGNAL DESCRIPTIONPIN
HDD LED CONNECTOR
+5V
1
HDD LED SIGNAL
2
HDD LED SIGNAL
3
+5V
4
NO CONNECTION
5
N.C.
NO CONNECTION
11
N.C.
ATX POWER SWITCH
SMI CONNECTOR
GND
12
ATX POWER SWITCH
13
SMI Signal
14
GND
15
INFRARED CONNECTOR
INFRARED TRANSMIT SIGNAL
6
GND
7
INFRARED RECEIVE SIGNAL
8
NO CONNECTION
9
+5V
10

MAGIC-PRO MP-7VIP
15
PIN1~PIN4: SPEAKER CONNECTOR
Connect cable from the chassiss SPEAKER to this connector.
PIN5~PIN6: RESET SWITCH
Connect cable from the chassiss RESET to this connector. User can
use this function to ma e a hardware re-boot. Press and hold this switch
at least one second to re-boot.
PIN8~PIN10: POWER LED CONNECTOR
Connect to Power LED.
PIN14~PIN15: SUSPEND LED CONNECTOR
Connect to Suspend LED.
J3 SIGNAL DESCRIPTIONPIN
SPEAKER CONNECTOR
SPEAKER SIGNAL
1
NO CONNECTION
2
GND
3
+5V
4
SUSPEND LED
15
SUSPEND LED
NO CONNECTION
7
N.C.
N.C.
RESET SWITCH
NO CONNECTION
11
GND
12
RESET SIGNAL
5
GND
6
POWER LED CONNECTOR
+5V
8
NO CONNECTION
9
GND
10
NO CONNECTION
13
+5V
14

MAGIC-PRO MP-7VIP
16
2-3 CONNECTORS
J2, J3:
A. : PS/2 MOUSE
C. : LPT1 PORT
E. : PS/2 KEYBOARD
G. : COM1
I. : LINE/SPK OUT
K. : MIC
B. : USB 0
D. : GAME/MIDI PORT
F. : USB 1
H. : COM2
J. : LINE IN
A.
E. F. G. H. I. J. K.
B. C. D.
1
1
15
15
J2
J3
A.
E. F. G. H. I.
B. C. D.
A. : HDD LED
C. : POWER SWITCH
E. : SPEAKER
G. : POWER LED
I. : SUSPEND LED
B. : INFRARED (IR)
D. : SMI
F. : RESET SWITCH
H. : NO CONNECTION

MAGIC-PRO MP-7VIP
17
2-4 DRIVER INSTALLATION
Onboard AC97 Audio Cod c Controll r Driv r Installation for Win-
dows95 / Windows98:
1. Go to CD-ROM driv r, w sugg st th CD-ROM titl is D: .
2. Find and run D:\MB\VIA\AUDIO\SETUP.EXE
3. Th n th s tup program will d t ct your O.S. to install r lativ fil s
into your syst m.
4. R boot your comput r.
NOTE 1: IF USER WANTS TO USE EXTERNAL SOUND CARD, USER
MUST RUN BIOS PROGRAM TO DISABLE Onchip Sound
option in the Chipset Feature Setup and Onboard
Legacy Audio option in the Integrated Peripherals.
NOTE 2: UNDER WINDOWS95, USER MUST INSTALL Direct X FOR
AGP ENVIRONMENT.
NOTE 3: User can also install 4in1 Dri er from CD instead of the
following dri ers. (For a oid CD-ROM compalibility issue,
user can ignore the IDE dri er)
1. Put th CD into your CD-ROM.
2. Th r app ars a w lcom window.
(If doesnt, it means that your CD-ROM auto-run function does not
enable, but you still can browser the CD via Windows Explorer and
change the directory to where your CD-ROM directory is. Then run the
autorun.exe)
3. S l ct MP-7VIP .
4. S l ct VIA Service Pack 4 .
5. S l ct Install 4in1 Driver.
6. Th n th program will automatically s tup all driv rs your
syst m n ds.
7. Finally, th syst m will r -boot.

MAGIC-PRO MP-7VIP
18
SuperCops III Hardware Monitor Installation
Windows95 / Windows98:
1. Go to CD-ROM driv r, w sugg st th CD-ROM titl is D: .
2. Find and run D:\SUPERCOP\SC3\SETUP.EXE
3. S l ct VIA Hardware Monitor , th n it will automati-
cally install this program.

MAGIC-PRO MP-7VIP
19
Chapter 3: BIOS Setup
3-1: INTRODUCE THE BIOS.
BIOS stands for Basic Input Output Syst m. It is som tim s call th
ROM BIOS b caus it is stor d in a R ad-Only M mory (ROM)
chip on th moth rboard. BISO is th first program to run wh n you
turn on your comput r. It p rforms th followin functions:
 initializing and t sting hardwar in your comput r (a proc ss call d
POST, for Pow r On S lf T st)
 loading and running your op rating syst m.
 managing SETUP for making chang s in your comput r.
 h lping your op rating syst m and application programs to manag
your PC hardwar by m ans of a s t of routin ss call d BIOS Run-
Tim S rvic s.
3-2: WHAT IS SETUP
SETUP is an int ractiv BIOS program that you n d to run wh n:
 Changing th hardwar on your syst m. (for xampl : installing a n w
Hard Disk, tc.)
 Modifying th b havior of your comput r. (for xampl : changing th
syst m tim or dat , or turning sp cial f atur s on or off, tc.)
 Enhancing your comput rs b havior. (for xampl : sp ding up
p rformanc by turning on shadowing or caching.)
