Magnatone TWILIGHTER User manual

TWILIGHTER®
MAGNATONEUSA.COM
TRUE DIMENSIONAL SOUND

WELCOME TO MAGNATONE
Welcome to the proud family of Magnatone owners.
We are excited to have you join this group that consists
of the world’s great guitarists — including iconic players
of yesterday and today — who have masterfully used
Magnatone’s True Dimensional Sound to create a trademark
sound all their own.
Completely made in the USA, every detail of the Twilighter
has been meticulously fashioned for the discerning user
– from the hand-wired chassis to the solid pine finger-
jointed cabinet. Built to meet the demands of touring
professionals, it delivers consistent, reliable performance
night after night and will sound great for decades to come.
Built on the classic platform of a 12AX7 front end
coupled with a 6V6 power section, the Twilighter also
features tube reverb and tube rectification. The original
Magnatone true Pitch-Shifting Vibrato circuit is nestled
between the preamp & power amp. This configuration
delivers full-bodied clean tones and natural overdrive,
all while letting you dial in the perfect “chime.”
The Twilighter has plenty of muscle for any size gig and
performs with a range of tone greater than any amp in
its class. The exclusive Magnatone pitch-shifting vibrato
will elevate your musical experience to a new level.
If you have questions regarding your Twilighter or
any other Magnatone product, email us at
[e-mail]
or reach us by mail at:
Magnatone USA
3283 Ivanhoe Ave.
St. Louis, MO 63139
FEATURES
• Original varistor-based Pitch-Shifting Vibrato that gives
you True Dimensional Sound — a Magnatone exclusive
• Classic sound artfully updated and brought into the
21st century
• Vibrato and tremolo both available via the
FM/AM switch
• This is electronic Americana that oozes classic tone — a
tribute to its ancestor with modern power and reliability
• Completely made in the USA

INPUTS
Input 1: High Sensitivity
Use this input for max pickup output and frequency response
Input 2: Low Sensitivity (6dB)
Use this input for hotter pickups. For expanded Dimensional
Sound, plug your instrument into Input 1, then plug an instrument
cable into Input 2 and connect it to the input of a second
amplifier. Use a “dry” sound on the second amplifier to enhance
the effect.
VOLUME
Controls overall Gain/Volume - Typically, breakup will begin
to occur around 3-4 on the dial. Higher setting may require
less bass.
TREBLE
Controls high frequency response centered around 2Khz.
BASS
Controls low frequency response centered around 60hz.
REVERB
Controls the amount of reverberation effect. The drive and
recovery circuits have been optimized for a smooth reverb decay.
INTENSITY
Controls the amount of modulation effect. A good balance of
effect should be maintained for normal use.
FM/AM SWITCH
Controls whether the effect is exclusive Magnatone pitch
shifting vibrato (FM) or conventional tremolo (AM).
AM– Tremolo
FM– Vibrato
REMOTE PEDAL
Connect the optional Magnatone remote pedal here.
Use any 1/4” mono or stereo guitar cable. When connected,
the front panel speed control is disabled. The remote pedal
works with both FM and AM settings.
SPEED
Controls the rate or speed of the selected effect.
The exclusive Magnatone design allows for extremely slow
“choral” settings not attainable from the original design.
When the remote pedal is connected, the front panel
control is inactive.
REMOTE SPEAKERS
External 8 Ohm speaker connects here. Note that internal
speaker remains live.
LINE OUT
Line level outputs. Speaker response compensated for DI use.
Always maintain a speaker load while using the line output.
STANDBY SWITCH
Allow the amplifier 1 minute to warm up before engaging.
POWER SWITCH
Turns the amplifier on and off. Always make sure you are
plugged into a proper grounded outlet.
PANEL CONTROLS (VIEW FROM REAR OF AMPLIFIER)

V1-12AX7
ECC83
V2-12AX7
ECC83
V5-12AX7
ECC83
V3-12AX7
ECC83
V4-12AU7
ECC82
V6-6V6 V8-GZ34 V7-6V6
SPEAKER
FOOT SWITCH BIAS
CONTROL
REVERB
SEND
REVERB
RETURN
TUBE LAYOUT (VIEW FROM REAR OF AMPLIFIER)
TECH SPECS
TUBE COMPLEMENT (4) 12AX7, 12AU7, (2) 6V6, GZ34
INPUTS High Sensitivity -1 MOhms
Low Sensitivity -120 KOhms
POWER OUTPUT 22 Watts Push/Pull Class AB
GAIN 80 dB
TREBLE 14 dB range at 2 kHz
BASS 12 dB range at 60 Hz
REVERB Accutronics Tube-Driven Long Pan; 4 Springs
VIBRATO True Pitch-shifting Varistor Vibrato
Switchable to Conventional Tremolo
SPEAKER Magnatone Custom USA 12” Ceramic Magnet
FUSE T2A (120VAC Model); T1A (220-240VAC Model)
V1 First and Second Gain Stage
V2 Phase Splitter
V3 Reverb Drive and Recovery
V4 Vibrato Modulator
V5 Third Gain Stage/LFO Amp
V6 Power Tube
V7 Power Tube
V8 Rectifier Tube
WARRANTY
All Magnatone amplifiers are warranted to the original
purchaser to be free of defects in materials and workmanship
for three years from the date of purchase, providing that:
•The purchaser emails ([email protected]) or mails
a photocopy of the original purchase receipt to Magnatone
Amplifiers within thirty days of purchase.
•Problems are not the result of normal wear, misuse, abuse,
user error, shipping damage, tampering, circuit modification,
improper voltage, improper tube installation (incorrect
orientation of the tubes can damage the amp), spilled
beverages, or attempt to repair by purchaser or a non-
authorized service center; any of these will void the warranty.
•The amplifier is shipped to Magnatone Amplifiers or an
authorized Magnatone Service Center in the original packing
materials, or materials of equal quality, with freight paid by
the purchaser. (Note: if the amplifier failed within thirty days
of use, shipping will be reimbursed to purchaser by
Magnatone, less any transaction fees incurred by purchaser).
Tubes, speakers, and reverb tanks carry a ninety-day warranty and
are subject to the same terms and conditions as stated above.
REGISTER YOUR MAGNATONE ONLINE
To insure that your warranty is in place, take a minute
and register your amplifier online.
Just go to magnatoneusa.com and select
“Product Registration” under the “Support” tab. Fill in the
required information and submit. Very quick and easy.
FOOT SWITCH
• Use the supplied TRS cable to
connect to the foot switch.
• Always unplug foot switch after
use and make sure both lights
are off.
• Foot switch uses a 9V battery;
a standard DC power jack
is included.
• Light On: Effect On
• Pulsating light shows Vibrato/Tremolo speed
and Tremolo Frequency
021017

MAGNATONEUSA.COM
TRUE DIMENSIONAL SOUND
MADE IN THE USA
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
AMPLIFIER TO RAIN OR MOISTURE. TO REDUCE
THE RISK OF ELECTRIC SHOCK, DO NOT OPEN
AMPLIFIER CHASSIS. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE.
CAUTION
WARNING
• THERE ARE NO USER SERVICEABLE PARTS INSIDE. DO NOT ATTEMPT
TO SELF REPAIR TAKE TO QUALIFIED TECHNICIAN OR CALL YOUR
DEALER IF WITHIN THE WARRANTY PERIOD.
• DO NOT TURN AMPLIFIER ON WITHOUT SPEAKER CONNECTED.
MAKE SURE YOUR SPEAKER OR CABINET MATCHES IMPEDANCE
(8 OHM SPEAKER OR CAB INTO THE 8 OHM JACK).
• CLEAN ONLY WITH LINT-FREE DAMP CLOTH AND DO NOT
USE CLEANING AGENTS.
• ONLY CONNECT POWER CORD TO A POLARIZED, SAFETY GROUNDED
OUTLET WIRED TO CURRENT ELECTRICAL CODE AND COMPATIBLE
WITH VOLTAGE, POWER, AND FREQUENCY REQUIREMENTS STATED ON
THE REAR PANEL OF THE APPARATUS.
• TO REDUCE THE RISK OF ELECTRICAL SHORT OR FIRE,
DO NOT EXPOSE THE UNIT TO RAIN, MOISTURE, OR BEVERAGES.
• SERVICE MUST BE PERFORMED BY QUALIFIED PERSONNEL.
• OUR AMPLIFIERS ARE CAPABLE OF PRODUCING HIGH SOUND PRESSURE
LEVELS. CONTINUED EXPOSURE TO HIGH SOUND PRESSURE LEVELS CAN
CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS
ADVISED AND EAR PROTECTION RECOMMENDED IF UNIT IS OPERATED
AT A HIGH VOLUME.
This symbol represents
a hot surface. When this
symbol is displayed, nearby
components (vacuum tubes)
are extremely hot and
care must be taken in their
vicinity.
