Mahidra TUV 300 User manual

Owner’s Manual
T4, T4+, T6, T6+, T6+ AMT, T8, T8 AMT
____________________________________________________________________________________
Original Issue Date: August 2015
Revision Date: September 2015
NOTE:
Carefully read, understand and follow the instructions provided in this manual, and keep it in a safe place for future reference. If you have any
doubt whatsoever regarding the use or care of your vehicle, please visit your Mahindra Dealer for assistance or advice.
This Owner's Manual should be considered as an integral part of the vehicle and should remain with the vehicle.

__________________________________________________________________________________
MAHINDRA & MAHINDRA LTD., GATEWAY BUILDING, APOLLO BUNDER, MUMBAI - 400 039
www.mahindra.com

1 INTRODUCTION AND SAFETY PRECAUTIONS ........................ 1-1
Introduction.............................................................................1-1
Safety Symbols .......................................................................1-2
General Safety Information and Instructions .................. 1-3
To Owner’s of a Mahindra Vehicle..................................... 1-4
Audio/Infotainment Manual................................................1-7
2 GENERAL ..........................................................................................2-1
Feature Matrix........................................................................2-1
Lubricants and Capacities...................................................2-4
Dimensions..............................................................................2-6
Bulb Specification ..................................................................2-7
Fuses and Relays...................................................................2-7
Flat Tire ................................................................................. 2-12
Jack Points........................................................................... 2-15
Technical Specifications.................................................... 2-19
Vehicle Identification Number (VIN)................................ 2-21
3 VEHICLE OVERVIEW.......................................................................3-1
Front Overview........................................................................3-1
Rear Overview.........................................................................3-2
Instrument Panel Overview .................................................3-3
4 INSTRUMENT CLUSTER OVERVIEW.......................................... 4-1
Instrument Cluster................................................................4-1
Warning Lamps Overview....................................................4-2
Warning Lamps ....................................................................4-3
5 SEATS AND SEAT BELTS..............................................................5-1
Driver seat...............................................................................5-1
Head Restraint.......................................................................5-4
Second Row Bench Seat......................................................5-5
Third Row Seats.....................................................................5-5
General Warnings and Instructions- Seat Belts............. 5-6
Fastening the Seat Belt........................................................5-9
Child Restraint System (CRS) .......................................... 5-11
6 SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (if
equipped) ..........................................................................................6-1
Airbags.....................................................................................6-1
Introduction.............................................................................6-1
7 LOCKS AND KEYS ..........................................................................7-1
Locks and Keys.......................................................................7-1
Table of Contents

Central Locking System........................................................7-3
Remote Keyless Entry (RKE) System ................................ 7-5
Engine Immobilizer System............................................... 7-10
8 FEATURES AND CONTROL...........................................................8-1
Power Windows.....................................................................8-1
Butterfly Window (Rear Quarter Window) ...................... 8-2
Outside Rear View Mirror (ORVM) .................................... 8-3
Interior Mirror ........................................................................ 8-5
Exterior Lamps.......................................................................8-5
Follow-Me Home (FMH) RKE............................................ 8-11
Follow-Me Home (FMH) Non RKE................................... 8-12
Lead Me to Vehicle (LMV) (RKE) ..................................... 8-12
Interior Lamps..................................................................... 8-13
Power Outlet........................................................................ 8-14
Windshield Wipers............................................................. 8-16
Utility Holders ...................................................................... 8-20
Horn....................................................................................... 8-22
Instrument Cluster............................................................. 8-23
Instrument Cluster Gauges.............................................. 8-24
Warning Lamps Overview................................................. 8-29
Warning Lamps in the Instrument Cluster .................. 8-30
Voice Messaging System(VMS) (If equipped)............... 8-34
Mike(If equipped)................................................................. 8-34
Reverse Parking Assist System (RPAS)(If
equipped) .............................................................................. 8-34
Brake Energy Regeneration Technology(If
equipped) .............................................................................. 8-40
Micro Hybrid Technology (Engine Stop/Start System,
ESS)(If equipped) ................................................................. 8-42
Radio Frequency ID (RFID) Tag........................................ 8-47
9 STEERING AND BRAKES............................................................... 9-1
Steering....................................................................................9-1
Tilt Steering.............................................................................9-2
Steering Controls - Audio Control System (if
equipped) ................................................................................. 9-2
Brakes...................................................................................... 9-4
Anti-Lock Brake System (ABS) (if equipped) .................... 9-6
Table of Contents

10 HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM
(HVAC)............................................................................................ 10-1
HVAC Overview.................................................................... 10-2
Center/Side Vents............................................................. 10-3
HVAC Controls .................................................................... 10-3
Air Distribution Control...................................................... 10-4
Blower Speed Control........................................................ 10-5
Temperature Control......................................................... 10-5
Air Intake Mode Control.................................................... 10-6
Air-Conditioner ON.............................................................. 10-6
HVAC Air Filter (Cabin Air Filter) ..................................... 10-7
Rapid Cabin Cooling............................................................ 10-8
Rapid Cabin Heating........................................................... 10-8
Defogging/De-misting and Defrosting .......................... 10-9
11 STARTING AND DRIVING THE VEHICLE................................. 11-1
Safety Tips - Before Starting your Vehicle..................... 11-1
Ignition Switch...................................................................... 11-2
Pedals.................................................................................... 11-3
Starting the Engine............................................................. 11-3
Stopping the Engine ........................................................... 11-5
Manual Transmission (If Equipped)................................. 11-5
Automated Manual Transmission (AMT) (If
Equipped) .............................................................................. 11-7
Driving Your Vehicle.........................................................11-14
Fuel.......................................................................................11-18
Tips for Better Fuel Economy.........................................11-20
12 WHEELS AND TYRES ................................................................. 12-1
Tyre Information.................................................................. 12-1
Tyre Rating........................................................................... 12-1
Tyre Label (Vehicle Placard)............................................. 12-2
Tire Pressure....................................................................... 12-3
Tire Rotation Recommendations.................................... 12-6
13 EMERGENCIES.............................................................................. 13-1
Hazard Warning Lamp...................................................... 13-1
Vehicle Does not Start - Checks...................................... 13-1
Vehicle Overheating............................................................ 13-2
Jump Starting...................................................................... 13-3
Towing ................................................................................... 13-7
Table of Contents

Limp Home Mode............................................................... 13-9
14 MAINTENANCE ............................................................................ 14-1
General Owners Information............................................ 14-1
Opening/Closing the Hood............................................... 14-4
Identifying Components in the Engine
Compartment...................................................................... 14-6
General Maintenance ........................................................ 14-7
In the Engine Compartment............................................. 14-8
Maintenance - Inside the Vehicle ..................................14-14
Maintenance-Outside the Vehicle .................................14-14
Battery.................................................................................14-15
Appearance Care and Protection.................................14-16
Air Conditioning System Maintenance.........................14-20
Vehicle Storage.................................................................14-20
Winter Care.......................................................................14-20
Bulb Replacement ............................................................14-22
Scheduled Maintenance..................................................14-22
Maintenance Schedule Chart ........................................14-24
Table of Contents

© Copyright Mahindra & Mahindra Ltd. 082015 1-1
1 INTRODUCTION AND SAFETY PRECAUTIONS
1.1 Introduction
Dear Customer,
Congratulations on purchasing Mahindra TUV3OO. Your vehicle has
been designed to provide years of safe and dependable service, as
long as it is used and maintained in accordance with the
instructions provided in this manual.
All persons who will use and/or maintain this vehicle must read,
understand and follow all warnings and instructions provided in this
manual. This Owner's Manual should be considered an integral part
of the vehicle and should remain with the vehicle. However, nothing
in this manual, and none of the safety devices installed in the
vehicle, are a substitute for careful operation and common sense.
Always make sure that your vehicle is in optimum working order,
and take note of the road and weather conditions under which you
are using your vehicle.
If you have any questions concerning the proper use or
maintenance of your vehicle, please call your Authorized Mahindra
Dealer. A list of dealers can be found in the Dealer Directory
Supplement.
Alternatively you can contact Mahindra at,
• 1800-209-6006 (Toll free)
• [email protected]
We extend our best wishes for safe and pleasurable motoring.
Sincerely,
MAHINDRA & MAHINDRA LTD.
INTRODUCTION AND SAFETY PRECAUTIONS

1-2 © Copyright Mahindra & Mahindra Ltd.082015
Servicing and Summary Data
• For all issues concerning the vehicle and for any need of spare
parts, contact only the Authorized Mahindra network
• We recommend you always use genuine Mahindra spare parts
when performing repairs on the vehicle
• We suggest that you record the vehicle data in the Warranty
Information & Maintenance Guide for future references
1.2 Safety Symbols
Carefully read, understand and follow the safety symbols/
instructions given in this manual.
Legend of the Symbols
To emphasize information and procedures regarding safety, use,
maintenance, etc., the following symbols are used throughout the
manual.
DANGER indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury and/or
property damage.
NOTICE indicates important information relevant to the vehicle,
the vehicle's use or to sections of this manual to which
particular attention must be paid for optimum use of the
vehicle.
If you see this symbol, it indicates “no”, “do not,” “do not do this,” or
“never”.
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082015 1-3
1.3 General Safety Information and Instructions
Failure to follow the warnings and instructions provided in this
manual could result in failure of the vehicle, an accident and/or
serious personal injury.
1. Carefully read, understand and follow the warnings and
instructions given in this manual. This manual is an essential
part of the product. Keep it in the vehicle glove box for future
reference
2. Spare bulb and first aid kit are placed in the glove box of the
vehicle. Ensure they are not taken out of the vehicle at any
point of time.
3. Please note that throughout this manual, reference is made
that “an accident” could occur. An accident could cause you or
a bystander to sustain severe personal injury, or result in
property damage
4. Never use a mobile phone or personal music device while
driving. This may take your focus off the road and lead to
accidents
5. Please be advised that many service and repair tasks require
specialized knowledge, tools and experience. General
mechanical aptitude may not be sufficient to properly service
or repair your vehicle. If you have any doubt whatsoever
regarding your ability to properly service or repair your vehicle,
please contact your Authorized Mahindra Dealer or a qualified
technician
6. Inspect the seat belt system periodically, checking for cuts,
frays or wear in the seat belt webbing, or loose buckles,
retractors, anchors or other loose parts. Damaged parts
must be replaced immediately
7. Always start and operate the engine in a well-ventilated area. If
in an enclosed area, vent the exhaust to the outside. Do not
modify or tamper with the exhaust system
8. Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread and check sidewalls for any cuts, cracks, or
other signs of wear. Replace as necessary
9. Always maintain the safety labels affixed to your vehicle in a
good legible condition
10. All signal lamps, buzzers, shields, guards and other protective
safety devices must always remain in place and in good,
proper working condition
11. The life span of Mahindra products depend on many factors.
Improper use, abuse or harsh use in general may compromise
the integrity of the vehicle and significantly reduce its life span.
The vehicle is also subject to wear over a period of time.
Please have your vehicle regularly inspected by an Authorized
Mahindra Dealer or a qualified mechanic. If the inspection
reveals any damage or excessive wear, immediately replace or
have the component serviced
INTRODUCTION AND SAFETY PRECAUTIONS

1-4 © Copyright Mahindra & Mahindra Ltd.082015
12. We recommend that you use only genuine parts supplied by
Mahindra. The use of non-Mahindra parts will not be covered
by warranty
13. Never crawl under or be in close proximity to the vehicle when
it is lifted off the ground (by a jack), unless the vehicle is
properly supported with jack stands, wheel chocks and other
appropriate safety devices
14. Never attempt any repairs or adjustments to any component
while the vehicle is in motion. Always switch off the engine, and
wait for the engine to come to a complete stop before
performing any repairs or adjustments
15. The vehicle identification plates are the only legal identification
reference, hence it is necessary to keep them in good
condition. Never modify data on the plates or remove them.
The customer is responsible for any possible tampering with
the plates, which will immediately void the warranty
16. Do not attempt sharp turns, abrupt maneuvers, or other
unsafe driving actions that can cause loss of vehicle control.
When the vehicle is fully loaded, drive at a slow speed,
especially when turning. Note that the center of gravity of the
vehicle increases as the vehicle is fully loaded on the roof
carrier
1.4 To Owner’s of a Mahindra Vehicle
When first driving the vehicle after long periods of non-use, you may
experience a temporary drive disturbance. This is a characteristic
of the tires and should be no reason for concern. The condition
should correct itself within 5-15 kms. of driving. If the disturbance
persists, have the tires checked by an Authorized Mahindra Dealer.
Driving and Alcohol
Your driving ability can be seriously impaired by alcohol even if the
blood alcohol level is far below the legal minimum. Drunken driving
is one of the most frequent causes of accidents.
Never drink and drive. Drinking and driving will lead to an
accident resulting in serious personal injury.
Driving and Drugs/Medication
Your driving ability can be seriously impaired through the use of
prescription or non-prescription drugs or medication (even cough
syrup). If you are taking any sort of drug or medication, be sure that
it will not affect your driving ability.
Mobile Phones Warning
Use of electrical devices such as mobile phones, computers,
portable radios or other by the driver while driving is dangerous. If
use of a mobile phone is necessary despite this warning, use a
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082015 1-5
hands free system to at least leave the hands free to drive the
vehicle.
Please comply with the legal regulations concerning the use of
communication equipment in vehicles in your country.
Driving Long Distances
When you are driving over long distances, follow these tips so that
you have a safe journey;
• Lack of sleep or fatigue may impact your ability to drive safely.
• Exercise your eyes by shifting the focus of your eyes to different
parts of the road.
• Use stimulating beverages such as coffee or tea.
• Relax and stay calm.
Protecting Our Environment
Every one of us should play our part in protecting our environment.
Judicious vehicle usage and disposing hazardous waste (including
cleaning and lubrication fluids) are important steps towards this
initiative.
Mahindra vehicles confirm to existing emission norms (standards).
Adhering to the periodical maintenance schedule and using
Mahindra genuine parts will help retain emission performance of
the vehicle and is a pre-requisite to emissions warranty coverage.
Servicing
If you have any questions concerning the proper use or
maintenance of your vehicle, please call your Authorized Mahindra
Dealer. A list of dealers can be found in the Dealer Directory
Supplement or on the Internet.
Alternatively you can contact Mahindra on 1800-209-6006 /
[email protected].
Running-in
Driving smoothly during first 1000 kms. will help to prevent
premature failures and abnormal system wear improving the life of
drivetrain and vehicle components.
A new engine may consume more oil during the first 1000 kms. of
running. This should be considered as a normal part of break-in and
not interpreted as any problem with the engine.
Mahindra Genuine Parts
Mahindra uses high quality parts for building vehicles.
In the event that any parts need replacement, we recommend that
you use only Mahindra genuine parts.
Non-Mahindra parts may harm vehicle performance and will not be
covered by your Mahindra warranty.
INTRODUCTION AND SAFETY PRECAUTIONS

1-6 © Copyright Mahindra & Mahindra Ltd.082015
To avoid counterfeit parts and to protect our brand image,
Mahindra genuine parts are packed in a branded carton. Look for
the “Mahindra Genuine Parts” logo.
Any unauthorized modifications or alterations to this vehicle or
failure to use appropriate specification and quality spare parts
could seriously affect vehicle road worthiness and safety
leading to an accident, resulting in serious injury
Mahindra Genuine Accessories
A wide selection of quality accessories is available through your
authorized Mahindra dealership. These accessories have been
specifically engineered to allow you to personalize your vehicle to
suit your requirements and compliment its style and aerodynamic
appearance.
Each accessory is made from high quality materials and meets
Mahindra's rigid engineering and safety specifications. Every
Mahindra accessory installed according to the Mahindra
installation provisions comes with the respective accessory
warranty.
Consult your Mahindra authorized dealer for detailed information
about accessories available for your specific model variant.
For maximum vehicle performance and safety considerations
always keep the following information in mind.
• When adding accessories, equipment, passengers and
luggage to your vehicle, do not exceed the total weight
capacity of the vehicle or of the front and rear axle. Consult
Mahindra authorized dealer for specific weight information.
• Bull bars and nudge guards are not recommended for
variants with an airbag.
• Accessories causing any change in vehicle specifications like
wheel rims, bull bars, etc., may affect the performance of
safety systems.
• Mobile communication systems such as two way radios,
telephones and theft alarms that are equipped with radio
transmitters and installed in your vehicle should comply with
the local regulations and should be installed only by a your
Authorized Mahindra Dealer
Vehicle Safety
When leaving your vehicle unoccupied;
• Always remove the ignition key when you park the vehicle
• Close all the windows completely and lock all the doors
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082015 1-7
• Do not leave any valuables in your vehicle. If you must leave
something in your vehicle, hide them and securely lock all the
doors
1.5 Audio/Infotainment Manual
Please refer the Audio/Infotainment user manual available in the
vehicle for details regarding;
• Audio/Infotainment functions
• Bluetooth functions
• Hands free call
INTRODUCTION AND SAFETY PRECAUTIONS

© Copyright Mahindra & Mahindra Ltd. 082015 2-1
2 GENERAL
2.1 Feature Matrix
In view of our policy of continuously improving our products, we
reserve the right to alter specifications, designs or features
without prior notice and without liability.
We recommend you contact the nearest Authorised Mahindra
Dealer for the latest features applicable to your vehicle.
Feature T4 T4+ T6 T6+ T6+ AMT T8 T8 AMT
Technology
Micro Hybrid Technology (Engine Start/Stop) ü
Automated Manual Transmission (AMT)- "autoSHIFT" ü ü
Intellipark ü ü
Digital Immobiliser ü ü ü ü ü ü ü
Voice Messaging System (VMS) ü ü ü ü ü
Remote Lock & Keyless Entry (RKE) ü ü ü ü ü
Infotainment System With Display Screen, 2 DIN Music System,
Bluetooth, USB, AUX ü ü ü ü ü
Driver Information System (DIS) ü ü
Static Bending Head Lamps ü ü
Safety
Airbag Driver side ü ü ü ü ü
Airbag Co-driver side ü ü ü ü ü
Anti-Lock Braking System (ABS) with EBD ü ü ü ü ü ü
GENERAL

2-2 © Copyright Mahindra & Mahindra Ltd.082015
Feature T4 T4+ T6 T6+ T6+ AMT T8 T8 AMT
Collapsible Steering Column ü ü ü ü ü ü ü
Tubeless Tyres ü ü ü ü ü ü ü
Style
Wheels Steel Rims Steel Rims Wheel Caps Wheel Caps Wheel Caps Alloys Alloys
Roof—top Ski Racks ü ü ü ü ü
Front Fog Lamps ü ü
Side and Rear Foot Step ü ü ü ü ü
Comfort & Convinience
Tiltable Steering ü ü ü ü ü ü ü
Individual Armrest for Driver & Co-driver Seats ü ü
Driver Seat Height Adjust ü ü
Lumbar Support (Driver & Co-Driver Seat) ü ü
Second Row Seat Fold ü ü
Electric ORVM ü ü
Power Steering ü ü ü ü ü ü ü
Power Windows ü ü ü ü ü ü ü
Central Locking ü ü ü ü ü ü ü
Mobile Charging Point Front Row only Front & Second Row
Rear Wipe & Wash ü ü ü ü ü
Rear Defogger ü ü ü ü ü
Lead-me-to-Vehicle Head lamps —LMV (RKE) ü ü
Follow-me-Home Head lamps ü ü
Lighting of the glove box ü ü ü ü ü
GENERAL

© Copyright Mahindra & Mahindra Ltd. 082015 2-3
Feature T4 T4+ T6 T6+ T6+ AMT T8 T8 AMT
Steering Mounted Audio & Phone Controls ü ü
Eco Mode ü ü ü ü ü
Storage Tray Below Driver's Seat ü ü
GENERAL

2-4 © Copyright Mahindra & Mahindra Ltd.082015
2.2 Lubricants and Capacities
System Lubricant Capacity Specifica-
tion Remarks
ENGINE mHawk 80 MAHINDRA “MAXIMILE Feo”
NEW GENERATION GENUINE ENGINE FLUID 6. 0 liters Special
Engine Fluid
Always use "MAXIMILE FEO" new generation Mahindra genuine
engine oil. This is specially developed for your engine’s optimum
performance and fuel efficiency
In extreme cases of emergency and non-availability of above oil, we
suggest Engine Oil meeting minimum API CH-4 SAE 15W-40
specification can be used and replaced at 6000 km. This alternate
oil or other Brand will not provide equivalent performance of above
Genuine oil
TRANSMISSION MAHINDRA “MAXIMILE
SYNTEC F2”
NEW GENERATION GENUINE TRANSMISSION FLUID 2.00 liters
Special
Manual
Transmis-
sion Fluid
Other Transmission Oils meeting API GL-4 SAE 80W-90
Specifications, Drain Interval should change to 20000km. Other
Brand may not provide equivalent performance of recommended
oil
AMT HYDRAULIC OIL AMT HYDROMATIC
(0701HAD00030N) 0.7
Special
Hydraulic
Fluid
Special super clean oil recommended for AMT hydraulic unit. No
other oil recommended or to be used. Alternate oil usage may
harm the performance and cause unit failure
REAR AXLE MAHINDRA “MAXIMILE ELITE”
NEW GENERATION GENUINE DIFFERENTIAL FLUID 2.0 liters
Special
Differential
Fluid
Other Axle Oils meeting API GL-5 SAE 80W-90 Specifications,
Drain Interval should change to 20000km. Other Brand may not
provide equivalent perfomance of recommeded oil
POWER STEERING SHELL “SPIRAX S3 ATF MD3”
Part No. (1102EAA00470N) 0.8 liters Alternately CALTEX MAKE "TEXAMATIC 1888"BRAND can be used . NO OTHER
BRAND SHOULD BE USED
BRAKE AND CLUTCH
MAHINDRA “MAXIMILE DOT
4”
Genuine Brake fluid 0.9 liters
If Maximile DOT 4 brake fluid is not used and in emergency conditions, use Brake
Fluid Meeting SAE J1703 FMVSS NO.116 DOT 4 OR IS 8654 TYPE-2
Specification and change it at 30,000 km or 2 years whichever earlier
GENERAL
