WELCOME TO MALAGUTI
Thank you for choosing this vehicle. This model is safely designed, durably manufactured and excellent for
daily use. The unique vehicle design represents your excellent personal taste.
This owner's manual explains the correct and safe use of the vehicle and simple inspections.
If you have any questions about the operation or maintenance of the vehicle, please contact your authorised
dealer.
Please read the owner's manual carefully.
INTRODUCTION

4 XAM
ENG
These operating instructions use the following symbols to draw attention to important information:
WARNING
Is a WARNING that must be followed! Failure to do so may result in serious injury or death to the rider or
others involved.
NOTE
Is a NOTICE of important information which, if not followed, may result in damage to the vehicle.
NOTE
• The owner's manual should always be carried with the vehicle so that it is available for entries during
maintenance by your authorised dealer. When selling the vehicle, please hand over the operating
instructions with the vehicle to the new owner.
• The owner's manual contains all important information about the vehicle. However, the manufacturer
is constantly making improvements which may lead to deviations from these operating instructions.*
Please contact your authorised dealer directly with any questions.
WARNING
• For your own safety, please read these operating instructions carefully before operating the vehicle.
• Do not drive until you are fully familiar with the vehicle.
• Regular inspections and maintenance as well as good driving skills guarantee safe driving and the
reliability of this vehicle.
*Product and specifications are subject to change without notice.
EXPLANATION

XAM 5
ENG
For single-track vehicles, driving safety depends largely on the driving skills of the user. The following requirements
should be met before starting to drive.
The driver should:
• Be familiar with all vehicle functions and adequately trained on the vehicle before driving.
• Have read and understood all inspection and maintenance instructions in this book.
• Have sufficient driving skills to drive a single-track vehicle and hold a valid driving licence.
• Visit a workshop with basic expertise and detailed knowledge of this vehicle to ensure adequate and accurate
inspection and maintenance of the vehicle.
SAFE RIDE
Always check your vehicle for various defects before setting off. Never exceed the maximum permissible gross
weight. Accidents often occur because car drivers do not see motorcyclists and scooter riders. Therefore, the rider
should do everything possible to be noticed by car drivers.
For example:
• Wear conspicuous clothing and drive carefully.
• Flash your lights when changing lanes and adjust your speed.
• Keep your distance from other road users and draw attention to yourself.
• Respect your limits.
• Do not lend the vehicle to unqualified people.
• Always obey the speed limits and traffic rules.
• Correct posture is important for balance.
• Sit upright and hold the handlebars firmly with both hands.
• The passenger must hold on tightly and stand with both feet on the footrests.
• Driving under the influence of alcohol or drugs is prohibited.
Protective clothing
Proper clothing protects against possible dangers:
• Always wear a safety helmet.
• Wear a face shield to protect the eyes from dust and rain.
• Wear a suitable jacket, shoes, gloves, etc. to protect yourself from the consequences of accidents.
• Do not wear loose clothing. This can get caught in the vehicle and cause accidents.
• Wear off-road gloves with joint and knuckle protection features to reduce the extent of hand injuries in the
event of an accident.
• Professional, rugged off-road boots with high soles are required to improve leg and foot protection and
driving safety.
Modifications
Modifications to this vehicle not approved by the manufacturer or removal of original components may make it
unsafe and result in serious injury. Modifications may also result in loss of type approval.
SAFETY INSTRUCTIONS

6 XAM
ENG
Load capacity and accessories
Adding accessories or carrying loads can change the weight distribution and affect steering and balance. This can
easily lead to an accident.
Payload
The total weight of the rider, passenger (if allowed), accessories and load must not exceed the maximum load.
When loading within the restriction, please remember the following:
• The centre of gravity should be kept as low as possible.
• Distribute the weight as evenly as possible to maintain balance.
• The load must be securely fastened.
• Do not hang heavy or bulky loads on the handlebars, fork or mudguard. This can lead to imbalance and
slowed steering response.
Accessories
Only use original accessories from the manufacturer for your vehicle. Please contact your authorised dealer. The
manufacturer declines responsibility for unapproved accessories from other manufacturers. The responsibility for
this lies solely with you.
When mounting accessories, please remember the following:
• Do not install any accessories or transport any loads that obstruct or restrict ground clearance, suspension
travel, steering, lights, indicators or reflectors.
• Accessories on the handlebar or front suspension affect steering behaviour. Keep mounted accessories as
light as possible.
• Do not mount luggage racks that affect the stability of the vehicle in crosswinds.
• Have electrical accessories fitted by an authorised dealer to match the capacity of the electrical system.
Improper installation may cause lighting malfunction, low engine power and damage to the vehicle.
Further safety instructions
• Always signal when turning and changing lanes.
• Drive slowly and brake carefully on rain-soaked roads or slippery surfaces.
• Drive carefully past cars to avoid being hit by suddenly opening doors.
SAFETY INSTRUCTIONS

XAM 7
ENG
Safety and hazard information in the form of stickers on the vehicle
This illustration shows you where to find the various safety and danger notices in the form of
stickers on your vehicle. Please read them carefully and do not remove them. If you notice that
you have lost the sticker or the writing has become illegible, contact your dealer and ask for a
replacement.
SAFETY INSTRUCTIONS

8 XAM
ENG
CE Version: L1e Version:
Safety and hazard information in the form of stickers on the battery
SAFETY INSTRUCTIONS

XAM 9
ENG
VEHICLE IDENTIFICATION NUMBER (VIN)
1
The vehicle identification number (VIN) (1) is stamped on the head tube of the frame.
Vehicle identification number:
NOTE
Please make a note of the VIN (vehicle identification number) in order to order spare parts from your dealer
or in case the vehicle is stolen. The vehicle identification number is used to identify your vehicle and can be
used for registration with the registration authorities in your region.
MANUFACTURER
Name: Zhejiang Apollo Sports Technology Co., Ltd.
Address: No.12-14, Jinheng Second Road, Jinyanshan Industrial
Zone, Quanxi Town, Wuyi County, Jinhua City, Zhejiang
Province, China
URL: www.apollovehicle.com
L1e VIN Plate
CE VIN Plate
DISTRIBUTOR
Name: KSR Group GmbH
Address: Im Wirtschaftspark 15, 3494 Gedersdorf
URL: www.ksr-group.com
Inverkehrbringer
KSR-Group GmbH
Im Wirtschaftspark 15
3494 Gedersdorf
Österreich
CUSTOMER INFORMATION

10 XAM
ENG
REPRESENTATION OF THE VEHICLE
1
4
14
13
11
125
9
7
6
8
10
3
2
15
16
20
17
18
19
21
1. Charging connection 8. Suspension fork 15. Handlebar
2. Battery lock 9. Motor control 16. Brake lever front brake
3. Frame 10. Lithium battery pack 17. Dashboard
4. Rear mudguard 11. Side stand 18. Rear brake lever
5. Rear shock absorber 12. Swing arm 19. Throttle
6. Front wheel 13. Rear brake system 20. Ignition lock
7.Front brake system 14. Rear wheel 21. Seat
INSTRUMENTS & OPERATION

XAM 11
ENG
IGNITION LOCK
The ignition lock controls the ignition and lighting
system and is used to lock the steering.
Power switched on-
When you turn the key to this position, and fold in the
side stand, the READY lettering on the speedometer
lights up and you can start riding.
NOTE
When the side stand is folded out, it is not possible
to drive off
Power switched off -
All electrical systems are turned off. The key can be
removed.
Handlebar lock -
The steering is locked and all electrical systems are
switched off. The key can be removed.
INSTRUMENT CLUSTER (L1E-VERSION)
698
4 2 3 1
75
1� Rocket mode
In rocket mode, the vehicle runs at maximum power.
Note, however, that continuous operation in rocket
mode greatly reduces the range.
2� Tortoise mode
The icon lights up when the tortoise mode is active.
3� Rabbit mode
This icon light is on when the rabbit mode is active.
4� Reverse mode
This icon light is on when the reverse mode is active.
5� READY control lamp
When the side stand is folded in and the Main Switch
is switched on, hold the brake lever for 2 seconds,
the READY icon lights up and you can start riding.
6� Odometer
The total odometer shows the total distance travelled
by the vehicle.
If there is a fault, the odometer numbers change to a
flashing fault code indicating the specific fault.
7� Charge level indicator
This icon light shows the charge level of the battery.
INSTRUMENTS & OPERATION

12 XAM
ENG
8� Headlight control lamp
This icon light is on when the light is on.
9� Speed display
The current speed is shown here.
HANDLEBAR SWITCH (L1E VERSION)
6
2
1
3
5
4
1� Rocket mode
When you press this button, the vehicle runs at
maximum power. Note, however, that continuous
operation in rocket mode greatly reduces the range.
2� Drive mode switch
Switch between tortoise and rabbit mode. Press
once to switch between tortoise and rabbit mode.
When charge level indicator is <20 %, the vehicle
automatically switches to tortoise mode.
3� Reversing switch
With the vehicle stationary, press this button for two
seconds to switch to reverse mode. The maximum
reversing speed is <9 km/h.
4� Horn
Press the button to activate the horn.
5� High beam and low beam
To switch on, press the button for 2 seconds.
6� Indicator
To turn right, slide the indicator switch to the right.
To turn left, slide the indicator switch to the left. To
switch off the indicator, push the switch back to the
centre position.
INSTRUMENT CLUSTER (CE-VERSION)
5
6
1
2
3
4
7
1� Rocket mode
In rocket mode, the vehicle runs at maximum power.
The mode is maintained for 9 seconds each time and
then automatically changes to the original mode.
2� Tortoise mode
The icon lights up when the tortoise mode is active.
3� Rabbit mode
This icon light is on when the rabbit mode is active.
4� Reverse mode
This icon light is on when the reverse mode is active.
5� READY control lamp
When the side stand is folded in and the ignition is
switched on, hold the brake lever for 2 seconds, the
READY indicator lights up and you can start riding.
6� Odometer
The total odometer shows the total distance travelled
by the vehicle. If there is a fault, the odometer
numbers change to a flashing fault code indicating
the specific fault.
7� Charge indicator
This icon light shows the battery charge level.
If there is an error in the battery communication, the
power supply indicator flashes red.
INSTRUMENTS & OPERATION

XAM 13
ENG
HANDLEBAR SWITCH (CE VERSION)
2 3
1
1� Rocket mode
When you press this button, the vehicle runs at
maximum power for 9 seconds. After that, the vehicle
returns to the original mode.
2� Drive mode switch
Switch between tortoise and rabbit mode. Press
once to switch between tortoise and rabbit mode;
when charge level indicator is <20 %, the vehicle
automatically switches to tortoise mode.
3� Reversing switch
With the vehicle stationary, press this button for two
seconds to switch to reverse mode. The maximum
reversing speed is <9 km/h.
HANDLEBAR LEVER
Front brake
The brake lever for the front brake is located on the
right-hand side of the handlebar.
Rear brake lever
The brake lever for the rear brakes is located on the
left side of the handlebar.
SIDE STAND
1
The side stand (1) is located on the left side of the
vehicle. Fold out the side stand with your foot to park
the vehicle. The vechile enters the P-gear without
power output state when the side stand is open and
rest for 3 mins. Hold the brake lever for 2s to unlock
the vehichle into forward gear.
NOTE
When the side stand is folded out, the READY
indicator does not light up and you cannot start
riding. Do not use the side stand for parking on a
slope or on soft or uneven ground.
INSTRUMENTS & OPERATION

14 XAM
ENG
CHARGER
The vehicle is equipped with a battery charger. If only a red indicator remains lit on the meter, please charge the
vehicle immediately. Only the factory-supplied battery charger may be used to charge the battery.
CHARGING CONNECTION
1
The charging connection is located on the battery (1). The battery can be charged in the vehicle or when
removed. Always cover the charging port with the dust caps to prevent foreign objects from entering and
damaging the charging port or corroding the port.
NOTE
The indicator light of the charger has the function of status display and error display.
Nr.: Charge
status
Battery voltage Charging
current
Status display
1Charge level
empty
Battery not connected Charge indicator ashing
2 Charging
process
10A charging current The charge level indicator consists of 5 bars.
Depending on the charging status, 0-5 bars light up.
3 Battery fully
charged
The charge indicator go out, all bars on the display
light up.
4 Error display Battery voltage too low or short circuit
(battery voltage is lower than 44V)
The display for 20% and 40% battery capacity
ickers faster.
Battery overvoltage (battery voltage is
higher than 85V)
The display for 20%, 40% and 60% battery capacity
ickers faster
Battery disconnected or overheated alarm The indicator for 20%, 40%, 60% and 80% of
battery capacity ickers faster
Charger malfunction (overvoltage,
overcurrent, overheating of the power
supply unit)
The indicator for 20%, 40%, 60%, 80% and 100%
of battery capacity ickers faster
E-SYSTEM

XAM 15
ENG
BATTERY
The battery is located under the seat.
NOTE
Please observe the warnings on the battery,
including: Battery charging temperature range:
0~45°C, Battery discharging temperature range:
-20°C~55°C.
It is recommended to charge the battery every 30
days when not in use. The battery may go into sleep
mode if it is not used for more than 90 days. After
going into sleep mode, the battery can be activated
via the charger: First connect the charger to the
battery and then connect it to the mains.
WARNING
• Do not disassemble or bump the battery.
• Do not leave the battery in an environment where
the temperature is not in the range of -25 to 70°C.
• Do not place the battery with unconnected or
unsealed terminals in liquids such as water, acid,
alkali, salt water, etc.
• Please read the warning label on the battery
carefully before use.
The charge level indicator has 10 cells, with each cell
corresponding to 10% of the power and decreasing
from right to left.
Charge level
indicator
CE version
Charge level
indicator
L1e version
If the second cell lights up yellow, the battery still has
20% energy. The 3rd to 10th cells indicate 30-100%
energy.
NOTE
• Please charge the battery regularly
• Avoid completely discharging the battery.
• Do not switch on the battery while it is being
charged in the vehicle.
WARNING
• If the battery power drops below 20 %, the power
is limited and the vehicle forcibly switches to
tortoise mode.
• Please charge the battery immediately when the
power drops below 10 %. Otherwise, irreparable
damage may occur.
CHARGING THE BATTERY
1. Switch off the vehicle.
2. Connect the charger plug to the battery.
3. Insert the main plug into a 220 V socket.
4. The charging indicator lights up while the
battery is charging.
5. When the battery is fully charged, the charger's
power indicator lights up fully and the operating
noise is reduced.
6. Disconnect the plug.
NOTE
For storage, keep the battery charged between
30% and 70%. Check the SoC every few weeks
and recharge if necessary. Never store the battery
fully charged.
E-SYSTEM

16 XAM
ENG
NOTE
• Charge the battery regularly to prevent
the battery from becoming completely
discharged.
• Do not switch on the battery while it is
being charged in the vehicle.
WARNING
Please note that the battery must never be completely
discharged, otherwise it will be permanently damaged.
A damaged battery caused by over-discharge due to
improper operation cannot be repaired and must be
replaced at the user's expense.
REMOVE BATTERY
1. Remove the bench seat
2. Open the locking mechanism
3. Remove the battery cover
4. Unplug the communication connector
5. Unplug the power supply
6. Remove the battery
Insert the battery in reverse order.
1
2
3
5
4
6
1
2
3
5
4
6
1
2
3
5
4
6
1
2
3
5
4
6
1
2
3
5
4
6
1
2
3
5
4
6
E-SYSTEM

XAM 17
ENG
SUSPENSION FORK ADJUSTMENT
The rotary knob above the front shock absorber is
used to adjust the rebound damping. The rebound
damping knob controls the damping during rebound.
When the knob is turned clockwise, the suspension
fork rebounds more slowly. When the knob is turned
anticlockwise, the suspension fork rebounds faster.
The knob below the front shock absorber is
for adjusting the compression damping. The
compression damping adjustment knob controls
the damping during compression. When the knob
is turned clockwise, the compression of the shock
absorber becomes harder. When the knob is turned
anticlockwise, the compression of the damper
becomes softer.
ADJUSTING THE SHOCK ABSORBER
To adjust the spring preload of the damper, please
turn the adjusting nut on the top of the damper.
The rebound damping adjustment knob is located on
the bottom of the damper. The compression damping
adjustment knob is located on the top of the damper.
When the knob is turned clockwise, the springing
out of the damper is slower. When the knob is
turned anticlockwise, the spring element springs
out faster. The compression damping adjustment
knob controls the damping during compression.
When the knob is turned clockwise, the compression
of the damper becomes harder. When the knob is
turned anticlockwise, the compression of the damper
becomes softer.
NOTE
For your safety, you should check the condition
of your vehicle before each use to avoid safety-
related incidents due to vehicle failure.
WARNING
• If any part of the vehicle is found to be defective,
do not drive the vehicle.
• The manufacturer does not guarantee against
problems caused by negligence on the part of
authorised dealers or lack of care and maintenance
on the part of the vehicle user, and does not
guarantee against damage to the vehicle or safety
accidents resulting from incorrect operation.
CHASSIS

18 XAM
ENG
CHECKLIST
It is the owner's sole responsibility to keep the vehicle in optimum condition. The driver must check the vehicle
through simple but thorough inspections to ensure optimum vehicle condition. Before each journey, some
important parts must be inspected quickly to avoid serious vehicle malfunctions that could lead to serious
accidents.
NOTE
A short inspection should be carried out before each ride. This only takes a short moment and is for your
own safety.
WARNING
If any component of the vehicle is found to be faulty during inspection, have the vehicle repaired by an
authorised dealer. In the event of negligence on the part of the vehicle owner, such as lack of care and
maintenance, operation of the vehicle with defective or improperly maintained parts, the manufacturer will
not accept any warranty.
Components Activities
Brake system
• When you apply the brake, the brake lever should not touch the handlebar.
• The brake system must operate at a constant pressure. If the required braking force is only
achieved after pulling the brake lever several times, contact an authorised dealer to have
the brake system checked.
• Check the brake lines for fluid leaks.
• Check the brake pads. If the brake pads are only 1 mm thick at any point, replace them.
Tyres
• Check if the wheels are running properly.
• Check if the tyres are damaged and if the tread depth is sufficient.
• Check tyre pressure and correct if necessary
Throttle grip • Check that the throttle grip operates normally and turns smoothly without jamming. Check
that the return position is normal.
Side stand • Check the operating status. When the vehicle is switched on and the throttle grip is
operated, the side stand must be folded in.
Fixing elements on
the chassis
• Make sure that all visible nuts and bolts are properly tightened. Retighten if necessary.
Chassis
• Check the function of the shock absorbers by compressing them several times. Also check
the front and rear shock absorbers for leaks and dirt.
• Apply the front brakes and push down on the handlebars several times to check that the front
shock absorbers are working properly. Press down hard on the seat several times to check
if the rear shock absorber is working properly.
Display and lighting • Check that all lights on the display and on the vehicle are working properly. This is
especially important to be visible to other road users.
Battery • Make sure that the battery is always fully charged before use.
Steering • Check that there are no faults and, if necessary, lubricate the pivot point of the steering.
INSPECTION BEFORE DEPARTURE

XAM 19
ENG
START VEHICLE
NOTE
Make sure the battery is inserted correctly and fully
charged.
Turn the key to
DRIVE OFF
1. Fold in the side stand.
2. Sit on the seat.
3. Press and hold the brake lever for more than
2 seconds and the display shows the Ready
status.
4. Slowly turn the throttle lever (right) to start
driving.
ACCELERATE & DECELERATE
B
A
The speed is controlled with the throttle grip. To
accelerate, turn the handle in direction (a) and to
decelerate, turn the handle in direction (b) or release
the handle.
BRAKES
Pull the front and rear brakes at the same time,
increase the brake pressure evenly.
WARNING
• Avoid abrupt or sharp braking. You could
skid.
• Level crossings, tram tracks, steel plates in
construction areas and manhole covers are
particularly dangerous when they are wet.
Reduce your speed and cross these hazards
with extreme caution.
• Remember that braking is more difficult on
wet roads.
• When going downhill, please drive slowly.
Braking when going downhill is particularly
difficult.
DRIVE MODE

20 XAM
ENG
SELECTING A DRIVING MODE
Use the driving mode button to select between three
modes:
• Tortoise mode: In this mode, the power
output is limited and the tortoise symbol on the
meter lights up.
• Rabbit mode: In this mode, the available
power is higher and the rabbit symbol on the
meter lights up.
• Rocket mode: Press the rocket button to
activate this mode. After the mode is switched
on, it continues to output the maximum power,
and the rocket icon on the instrument is
dynamically flashing
PARKING
To park:
• Switch off the engine using the ignition lock.
• Put the vehicle on the side stand.
• Remove the key.
WARNING
Make sure that the vehicle is parked on a stable and level
surface.
FIRST MAINTENANCE
The safety and condition of your vehicle are affected
by proper maintenance, regular inspections,
adjustments and lubrication. On the following
pages you will find the relevant instructions.
The maintenance information can help you with
preventive maintenance and minor repairs. However,
some maintenance work requires special tools.
WARNING
Do not carry out any maintenance work with which you
are not familiar or which could affect the warranty service.
Modifications to your vehicle that are not approved
by the manufacturer may alter the performance of
the vehicle and affect driving safety. If the customer
makes such modifications without the manufacturer's
approval, the warranty will be void.
MAINTENANCE AND SERVICING
