SERVICE STATION MANUAL
STELVIO 1200 NTX
This manual provides the main information to carry out regular maintenance operations on your vehicle.
This manual is intended to Moto Guzzi Dealers and their qualified mechanics; several concepts have
been deliberately omitted as they are considered unnecessary. As it is not possible to include complete
mechanical notions in this manual, users should have basic mechanical knowledge or minimum
knowledgeabouttheproceduresinvolvedwhenrepairingmotorcycles.Withoutthisknowledge,repairing
orcheckingthevehiclemaybeinefficientorevendangerous.Asthevehiclerepairandcheckprocedures
are not described in detail, be extremely cautious so as not to damage components or injure individuals.
In order to optimise customer satisfaction when using our vehicles, Moto Guzzi s.p.a. commits itself to
continually improve its products and the relative documentation. The main technical modifications and
changes in repair procedures are communicated to all Moto Guzzi Sales Outlets and its International
Subsidiaries. These changes will be introduced in the subsequent editions of the manual. In case of
need or further queries on repair and check procedures, consult Moto Guzzi CUSTOMER
DEPARTMENT, which will be prepared to provide any information on the subject and any further
communications on updates and technical changes related to the vehicle.
NOTE Provides key information to make the procedure easier to understand and carry out.
CAUTION Refers to specific procedures to carry out for preventing damages to the vehicle.
WARNING Refers to specific procedures to carry out to prevent injuries to the repairer.
Personal safety Failure to completely observe these instructions will result in serious risk of personal
injury.
Safeguarding the environment Sectionsmarked with thissymbol indicate thecorrect use of the vehicle
to prevent damaging the environment.
Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious
damage to the vehicle and sometimes even the invalidity of the guarantee.
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

INDEX OF TOPICS
CHARACTERISTICS CHAR
SPECIAL TOOLS S-TOOLS
MAINTENANCE MAIN
ELECTRICAL SYSTEM ELE SYS
ENGINE FROM VEHICLE ENG VE
ENGINE ENG
POWER SUPPLY P SUPP
SUSPENSIONS SUSP
CHASSIS CHAS
BRAKING SYSTEM BRAK SYS
BODYWORK BODYW
PRE-DELIVERY PRE DE
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

INDEX OF TOPICS
CHARACTERISTICS CHAR
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Rules
Safety rules
Carbon monoxide
If you need to keep the engine running while working on the vehicle, please ensure that you do so in
an open or very well ventilated area. Never run the engine in an enclosed area. If you do work in an
enclosed area, make sure to use a fume extraction system.
CAUTION
EXHAUSTEMISSIONSCONTAINCARBON MONOXIDE,A POISONOUSGAS WHICHCAN CAUSE
LOSS OF CONSCIOUSNESS AND EVEN DEATH.
Fuel
CAUTION
THE FUEL USED TO POWER INTERNAL COMBUSTION ENGINES IS HIGHLY FLAMMABLE AND
MAY BE EXPLOSIVE UNDER CERTAIN CONDITIONS. IT IS THEREFORE RECOMMENDED TO
CARRY OUT REFUELLING AND MAINTENANCE PROCEDURES IN A VENTILATED AREA WITH
THEENGINESWITCHED OFF.DONOT SMOKEDURINGREFUELLING ORNEARFUEL VAPOUR.
AVOIDANYCONTACTWITHNAKED FLAME, SPARKS OROTHERHEATSOURCESWHICH MAY
CAUSE IGNITION OR EXPLOSION.
DO NOT ALLOW FUEL TO DISPERSE INTO THE ENVIRONMENT.
KEEP OUT OF THE REACH OF CHILDREN
Hot components
The engine and the exhaust system components become very hot and remain hot for some time after
the engine has been switched off. When handling these components, wear insulating gloves or wait
until the engine and the exhaust system have cooled down.
Used engine oil and transmission oil
CAUTION
IT IS ADVISABLE TO WEAR LATEX GLOVES WHEN SERVICING THE VEHICLE.
THE ENGINE OR GEARBOX OIL MAY CAUSE SERIOUS INJURIES TO THE SKIN IF HANDLED
FOR PROLONGED PERIODS OF TIME AND ON A REGULAR BASIS.
WASH YOUR HANDS CAREFULLY AFTER HANDLING OIL.
HAND THE OIL OVER TO OR HAVE IT COLLECTED BY THE NEAREST USED OIL RECYCLING
COMPANY OR THE SUPPLIER.
DO NOT DISPOSE OF OIL IN THE ENVIRONMENT
KEEP OUT OF THE REACH OF CHILDREN
Brake and clutch fluid
STELVIO 1200 NTX Characteristics
CHAR - 7
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAINTED SURFACES.
WHEN SERVICING THE BRAKING SYSTEM OR THE CLUTCH SYSTEM PROTECT THESE COM-
PONENTS WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING
THESE SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR
EYES. IN THE EVENT OF ACCIDENTAL CONTACT WITH YOUR EYES, RINSE THEM IMMEDI-
ATELY WITH ABUNDANT COLD, CLEAN WATER AND SEEK MEDICAL ADVICE.
KEEP OUT OF THE REACH OF CHILDREN
Battery electrolyte and hydrogen gas
CAUTION
THE BATTERY ELECTROLYTE IS TOXIC, CORROSIVE AND, AS IT CONTAINS SULPHURIC
ACID, MAY CAUSE BURNING IF IT COMES INTO CONTACT WITH THE SKIN. WHEN HANDLING
BATTERY ELECTROLYTE, WEAR TIGHT-FITTING GLOVES AND PROTECTIVE APPAREL. IN
THE EVENT OF SKIN CONTACT WITH THE ELECTROLYTIC FLUID, RINSE WELL WITH PLENTY
OF CLEAN WATER. IT IS PARTICULARLY IMPORTANT TO PROTECT YOUR EYES BECAUSE
EVEN TINY AMOUNTS OF BATTERY ACID MAY CAUSE BLINDNESS. IN THE EVENT OF CON-
TACT WITH THE EYES, RINSE WITH PLENTY OF WATER FOR FIFTEEN MINUTES AND CON-
SULT AN EYE SPECIALIST IMMEDIATELY. IF THE FLUID IS ACCIDENTALLY SWALLOWED,
DRINK LARGE QUANTITIES OF WATER OR MILK, FOLLOWED BY MILK OF MAGNESIA OR
VEGETABLE OIL AND SEEK MEDICAL ADVICE IMMEDIATELY. THE BATTERY RELEASES EX-
PLOSIVE GASES; KEEP IT AWAY FROM FLAMES, SPARKS, CIGARETTES OR ANY OTHER
HEAT SOURCES. ENSURE ADEQUATE VENTILATION WHEN SERVICING OR RECHARGING
THE BATTERY.
KEEP OUT OF THE REACH OF CHILDREN
BATTERY LIQUID IS CORROSIVE. DO NOT POUR OR SPILL ON PLASTIC COMPONENTS IN
PARTICULAR. ENSURE THAT THE ELECTROLYTIC ACID IS COMPATIBLE WITH THE BATTERY
BEING ACTIVATED.
Maintenance rules
GENERAL PRECAUTIONS AND INFORMATION
When repairing, dismantling and reassembling the vehicle, follow the recommendations given below
carefully.
BEFORE DISASSEMBLING COMPONENTS
•Beforedismantling components, remove dirt, mud, dust and foreignbodies from the vehicle.
Use the special tools designed for this bike, as required.
COMPONENTS REMOVAL
•Donot loosen and/ortighten screws andnuts using pliersor any other tools than the specific
wrench.
•Mark the positions on all connection joints (pipes, cables, etc.) before separating them, and
identify them with different distinctive symbols.
•Each component needs to be clearly marked to enable identification during reassembly.
•Clean and wash the dismantled components carefully using a low-flammability detergent.
Characteristics STELVIO 1200 NTX
CHAR - 8
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

•Keep mated parts together since they have "adjusted" to each other due to normal wear.
•Some components must be used together or replaced altogether.
•Keep away from heat sources.
REASSEMBLING COMPONENTS
CAUTION
BEARINGS MUST ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE, OTHERWISE, THEY
NEED TO BE REPLACED.
•Only use ORIGINAL Moto Guzzi SPARE PARTS.
•Comply with lubricant and consumables use guidelines.
•Lubricate parts (whenever possible) before reassembling them.
•When tightening nuts and screws, start from the ones with the largest section or from the
internal ones, moving diagonally. Tighten nuts and screws in successive steps before ap-
plying the tightening torque.
•Always replace self-locking nuts, washers, sealing rings, circlips, O-rings (OR), split pins
and screws with new ones if their tread is damaged.
•When assembling the bearings, make sure to lubricate them well.
•Check that each component is assembled correctly.
•After a repair or routine maintenance procedure, carry out pre-ride checks and test the ve-
hicle on private grounds or in an area with low traffic density.
•Clean all coupling surfaces, oil guard rims and gaskets before refitting them. Smear a light
layer of lithium-based grease on the oil guard rims. Reassemble oil guards and bearings
with the brand or lot number facing outward (visible side).
ELECTRIC CONNECTORS
Electric connectors must be disconnected as described below; failure to comply with this procedure
causes irreparable damage to both the connector and the wiring harness:
Press the relative safety clips, if applicable.
•Grip the two connectors and disconnect them by pulling them in opposite directions.
•If any signs of dirt, rust, moisture, etc. are noted, clean the inside of the connector carefully
with a jet of compressed air.
•Ensure that the cables are correctly fastened to the internal connector terminals.
•Then connect the two connectors, ensuring that they couple correctly (if fitted with clips, you
will hear them "click" into place).
CAUTION
DO NOT DISCONNECT CONNECTORS BY PULLING THE CABLES.
NOTE
THE TWO CONNECTORS CAN ONLY BE CONNECTED IN ONE DIRECTION: CONNECT THEM
THE RIGHT WAY ROUND.
TIGHTENING TORQUES
CAUTION
REMEMBERTHATTHETIGHTENINGTORQUES FORALLFASTENING ELEMENTSONWHEELS,
BRAKES, WHEEL AXLES AND ANY OTHER SUSPENSION COMPONENTS PLAY A KEY ROLE
STELVIO 1200 NTX Characteristics
CHAR - 9
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

IN ENSURING VEHICLE SAFETY AND MUST COMPLY WITH SPECIFIED VALUES. CHECK THE
TIGHTENING TORQUES OF FASTENING ELEMENTS ON A REGULAR BASIS AND ALWAYS USE
A TORQUE WRENCH TO REASSEMBLE THESE COMPONENTS. FAILURE TO COMPLY WITH
THESE RECOMMENDATIONS MAY CAUSE ONE OF THESE COMPONENTS TO LOOSEN OR
EVEN DETACH, CAUSING A WHEEL TO LOCK OR COMPROMISING VEHICLE HANDLING. THIS
MAY LEAD TO FALLS, WITH THE RISK OF SERIOUS INJURY OR DEATH.
Running-in
Engine run-in is essential to ensure engine long life and correct operation. Twisty roads and gradients
are ideal to run in engine, brakes and suspensions effectively. Vary your riding speed during the run-
in. This ensures that components operate under both "loaded" and "unloaded" conditions, allowing the
engine components to cool.
CAUTION
THE CLUTCH MAY EMIT A SLIGHT BURNING SMELL WHEN FIRST USED. THIS PHENOMENON
SHOULD BE CONSIDERED NORMAL AND WILL DISAPPEAR AS SOON AS THE CLUTCH DISCS
GET ADAPTED.
ITISIMPORTANTTOSTRAIN ENGINECOMPONENTS DURINGRUN-IN,HOWEVER,MAKESURE
NOT TO OVERDO THIS.
CAUTION
THE FULL PERFORMANCE OF THE VEHICLE IS ONLY AVAILABLE AFTER THE SERVICE AT
THE END OF THE RUN-IN PERIOD.
Follow the guidelines detailed below:
•Do not twist the throttle grip abruptly and completely when the engine is working at a low
revs, either during or after run-in.
•During the first 100 Km (62 miles) use the brakes gently, avoiding sudden or prolonged
braking. That is to permit the adequate adjustment of the pad friction material to the brake
discs.
AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN OFFICIAL Moto Guzzi DEALER
FOR THE CHECKS INDICATED IN THE "AFTER RUN-IN" TABLE IN THE SCHEDULED MAINTE-
NANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHI-
CLE.
Vehicle identification
SERIAL NUMBER LOCATION
These numbers are necessary for vehicle registration.
NOTE
ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR-
TICULAR, MODIFYING THE CHASSIS NUMBER IMMEDIATELY VOIDS THE WARRANTY.
Characteristics STELVIO 1200 NTX
CHAR - 10
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

This number consists of numbers and letters, as in
the example shown below.
ZGULZB000YMXXXXXX
KEY:
ZGU: WMI (World manufacturer identifier) code;
LZ: model;
B00: version variation;
0: digit free
Yyear of manufacture
M: production plant (M= Mandello del Lario);
XXXXXX: progressive number (6 digits);
CHASSIS NUMBER
The chassis number is stamped on the right side
of the headstock.
ENGINE NUMBER
The engine number is stamped on the left side,
close to the engine oil level check cap.
Dimensions and mass
WEIGHT AND DIMENSIONS
Specification Desc./Quantity
Maximum width (without accessories) 2305 mm (90.75 in)
Maximum width at handlebar 910 mm (35.83 in)
Maximum width of vehicle with accessories 1080 mm (42.52 in)
Minimum / maximum height (adjustable windshield) 1395 / 1440 mm (54.92 / 56.69 in)
Saddle height 800 mm (31.5 in)
Minimum ground clearance 185 mm (7.3 in)
Wheelbase 1535 mm (60.43 in)
Kerb weight 251 kg (553 lb)
Kerb weight of vehicle with accessories 278 kg (613 lb)
Engine
ENGINE
Specification Desc./Quantity
Type Four stroke 90° transverse V-twin
Number of cylinders 2
Cylinder layout 90° V
STELVIO 1200 NTX Characteristics
CHAR - 11
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Specification Desc./Quantity
Bore / stroke 95 x 81.2 mm (3.74 x 3.20 in)
Engine capacity 1151 cm³ (70 cu.in)
Compression ratio 11: 1
Electric starter
Idle speed 1100 ± 100 rpm
Clutch hydraulicsingleplatedryclutchwithintegratedflexiblecoupling
Lubrication system Pressurised circuit with regulator valves and trochoidal pump
Air filter dry cartridge air filter
Cooling air/oil system with independent trochoidal pump and pressure
regulator valve for oil cooling circuit
Timing system diagram single overhead camshaft with bucket tappets and rockers
Values valid with control clearance between rocker and valve intake: 0.10 mm (0.0039 in)
exhaust:
With the A5 series, the clearance is 0.15 mm (0.0059 in)
From the A8 series on, the clearance is 0.20 mm (0.0079 in)
Transmission
TRANSMISSION
Specification Desc./Quantity
Primary drive Helical gear, ratio 26/35 = 1:1.346
Gearbox 6 speed mechanical gearbox with foot gearshift lever on left
hand side of engine
1st gear ratio 17/38 = 1:2.2353
2nd gear ratio 20/34 = 1:1.7
3rd gear ratio 23/31 = 1:1.3478
4th gear ratio 26/29 = 1:1.1154
5th gear ratio 31/30 = 1:0.9677
6th gear ratio 29/25 = 1:0.8621
Final drive cardan shaft
Ratio 12/44 = 1:3.6667
Capacities
CAPACITIES
Specification Desc./Quantity
Engine oil Oil change and oil filter replacement: 3,500 cm³ (214 cu.in)
Gearbox oil 500 cm³ (30.5 cu.in)
Transmission oil 380 cm³ (23.2 cu.in)
Fuel (reserve included) 18 ± 1.5 l (3.96 ± 0.33 UK gal)
Fuel reserve 4 l (0.88 UK gal)
Seats 2
Maximum weight limit 475 kg (1047 lb)
Electrical system
ELECTRICAL SYSTEM
Specification Desc./Quantity
Spark plug NGK PMR8B (long life)
Alternatively:
Spark plug NGK CR8EKB (long life)
Electrode gap 0.6 - 0.7 mm (0.024 - 0.028 in)
Battery 12 V - 18 Ampere/hour
Alternator (permanent magnet type) 12 V - 550 W
Main fuses 30A - 40A
Auxiliary fuses 3 - 15 A (10A for ABS only)
ABS fuses 40 - 25A
Front daylight running light 12V - 5W
Characteristics STELVIO 1200 NTX
CHAR - 12
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Specification Desc./Quantity
Low/high beam headlight (halogen) 12 V - 55 W / 60 W H4
Turn indicators 12V - 10 W
Tail light/stop light LED
Supplementary headlamps (if fitted) 12 V/55W - H3
Instrument panel lighting LED
License plate light 12V - 5 W
Turn indicator warning light LED
Neutral gear warning light LED
Alarm warning light - Shift indicator LED
Side stand down warning light LED
Low fuel warning light LED
High beam warning light LED
ABS warning light LED
Frame and suspensions
CHASSIS
Specification Desc./Quantity
Type High strength tubular steel frame with engine as stressed ele-
ment
Trail 125 mm (4.92 in)
Steering rake 27°
Front Upside down telescopic hydraulic fork with 50-mm (1.97 in) di-
am. stanchions and radial calliper mounting with adjustable
spring preload and hydraulic compression and rebound damp-
ing.
Front wheel travel 170 mm (6.69 in)
Rear single sided swingarm with progressive linkage and mono-
shock with adjustable hydraulic rebound and compression
damping and spring preload.
Unloaded shock absorber spring length 180 mm (7.09 in)
Rear wheel travel 155 mm (6.10 in)
SIZES A AND B
Specification Desc./Quantity
Size A 745.0 mm (29.33 in)
Size B 403.16 mm (15.87 in)
Brakes
BRAKES
Specification Desc./Quantity
Front dual 320 mm (12.6 in) diam. stainless steel floating wavy discs
with radial callipers with 4 differentiated, horizontally opposed
pistons.
Rear 282 mm (11.1 in) diam. stainless steel disc
STELVIO 1200 NTX Characteristics
CHAR - 13
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Wheels and tyres
WHEELS AND TYRES - STELVIO NTX
Wheel Model Wheel rim Measure
ment Tyre pressure with rider only Tyre pressure, rider + passenger
Front (standard) Metzeler Tourance 2.50 x 19" 110/80
R19 - 59V 2.4 bar (240 kPa) (34.8 PSI) 2.5 bar (250 kPa) (36.3 PSI)
Front (alternative) Metzeler Karoo (*) (***) 2.50 x 19" 110/80
R19 - 59R
M+S
2.5 bar (250 kPa) (36.3
PSI) (**) 2.5 bar (250 kPa) (36.3 PSI) (**)
Front (alternative) Pirelli Scorpion Sync 2.50 x 19" 110/80
R19 - 59V 2.5 bar (250 kPa) (36.3 PSI) 2.5 bar (250 kPa) (36.3 PSI)
Rear (standard) Metzeler Tourance 4.25 x 17" 150/70
R17 - 69V 2.7 bar (270 kPa) (36.1 PSI) 2.9 bar (290 kPa) (42.1 PSI)
Rear (alternative) Metzeler Karoo (*) (***) 4.25 x 17" 150/70
R17 - 69R
M+S
2.7 bar (270 kPa) (36.1
PSI) (**) 2.9 bar (290 kPa) (42.1 PSI) (**)
Rear (alternative) Pirelli Scorpion Sync 5.50 x 17 180/55
R17 - 73V 2.9 bar (290 kPa) (42.1 PSI) 2.9 bar (290 kPa) (42.1 PSI)
(*) Maximum speed limit = 170 km/h (105 mi/h).
(**) Tyre pressure must be adjusted to suit terrain conditions for off road use.
(***) Do not install on vehicles equipped with ABS
WHEN FITTING Metzeler Karoo TYRES, THE MAXIMUM SPEED WARNING LABEL (INCLUDED
WITH TYRES) MUST BE APPLIED TO THE SPEEDOMETER. USE EXTREME CAUTION WHEN
RIDING ON TARMAC ROADS WITH "OFF-ROAD / ALLROUND" TYRES AS THESE TYRES OFFER
POOR GRIP AND STABILITY ON TARMAC.
DO NOT INSTALL M+S TYPE TYRES ON VEHICLES EQUIPPED WITH ABS.
Supply
FUEL SYSTEM
Specification Desc./Quantity
Fuel system Electronic injection (Weber . Marelli) with Stepper motor
Diffuser diameter: 50 mm (1.97 in)
Fuel Premium unleaded petrol, minimum octane rating 95 (NORM)
and 85 (NOMM)
Tightening Torques
HEADS
Name Torque in Nm
Oil cap (2) 25 Nm (18.44 lbf ft)
Rocking lever support nut - M10x1.5 (8) 15 Nm (11.06 lbf ft) + 42 Nm (30.98 lbf ft)
Camshaft - rocking levers support fixing screws (12) 17 Nm (12.54 lbf ft)
Head fixing screw (4) - pre-tightening 15 Nm (11.06 lbf ft)
Head fixing screw (4) - final tightening 42 Nm (31 lbf ft)
Screw fixing head to chain compartment - M6x120 (4) 10 Nm (7.38 lbf ft)
Oil temperature sensor 11 Nm (8.11 lbf ft) - Loctite 243
Oil temperature sensor container 11 Nm (8.11 lbf ft) - Loctite 601
Characteristics STELVIO 1200 NTX
CHAR - 14
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Name Torque in Nm
Head covers fixing screws (8) 8 Nm (5.9 lbf ft)
Spark plug (2) 15 Nm (11.06 lbf ft) - Molykote
CRANKCASE
Name Torque in Nm
Crankcase stud bolt - cylinder (8) 25 Nm (18.44 lbf ft)
Transmission side flange stud bolt - M8x66 (3) 35 Nm (25.81 lbf ft)
Transmission side flange stud bolt - M8x75 (2) 35 Nm (25.81 lbf ft)
Gear side crankshaft flange screw - TE M8x25 (8) 26 Nm (19.18 lbf ft)
Timing system cover screw - TCEI M8x55 (4) 25 Nm (18.44 lbf ft)
Timing system cover screw - TCEI M6x30 (10) 10 Nm (7.38 lbf ft)
Oil vapour union screw - TCEI M6x20 (2) 10 Nm (7.38 lbf ft)
TCEI M6x40 Screw (2) 10 Nm (7.38 lbf ft)
Timing sensor - TCEI M5x12 (2) 6 Nm (4.42 lbf ft)
Service shaft bearing locking screw (2) 10 Nm (7.38 lbf ft)
Oil pressure sensor (1) 25 Nm (18.44 lbf ft)
Screw fixing oil pressure sensor support - TCEI M10x20 (1) 18 Nm (13.28 lbf ft)
Oil cap (2) 25 Nm (18.44 lbf ft)
OIL SUMP
Name Torque in Nm
Oil pipe on sump reduction (1) 20 Nm (14.75 lbf ft)
Oil pipe on sump 20 Nm (14.75 lbf ft)
Oil sump lower screw - TCEI M6x30 (4) 10 Nm (7.38 lbf ft)
Oil sump screw - TCEI M6x55 (14) 10 Nm (7.38 lbf ft)
Oil sump screw - TCEI M6x60 (2) 10 Nm (7.38 lbf ft)
Oil drainage plug - M10x1 (1) 20 Nm (14.75 lbf ft)
Oil filter (1) 15 Nm (11.06 lbf ft)
Oil filter fitting (1) 40 Nm (29.5 lbf ft) - Loctite 243
Oil pipe in sump 20 Nm (14.75 lbf ft) - Loctite 648
Pressure-relief plug 40 Nm (29.5 lbf ft)
Cap on oil sump flange (2) 20 Nm (14.75 lbf ft)
Cap (1) 40 Nm (29.5 lbf ft)
CRANKSHAFT - FLYWHEEL
Name Torque in Nm
Connecting rod screw (4) - pre-tightening 40 Nm (29.5 lbf ft)
Connecting rod screw (4) - final tightening 80 Nm (59 lbf ft)
Screw fixing clutch disc on crankshaft - M8x25 (6) 42 Nm (30.98 lbf ft) - Loctite 243
Screw fixing clutch bell on disc - M7x16 (6) 20 Nm (14.75 lbf ft)
Start-up crown gear fixing screw (6) 10 Nm (7.38 lbf ft)
OIL PUMP
Name Torque in Nm
Oil pump fixing screws - M6x45 (3) 10 Nm (7.38 lbf ft)
Oil pump gear nut - M10x1.25 (1) 20 Nm (14.75 lbf ft)
Pressure-relief plug 40 Nm (29.5 lbf ft)
Cooling oil intake filter fixing screw (5) 10 Nm (7.38 lbf ft)
Lubrication oil intake filter fixing screw (2) 10 Nm (7.38 lbf ft)
TIMING SYSTEM
Name Torque in Nm
Service shaft flange screw - TBEI M6x14 (2) 8 Nm (5.9 lbf ft)
Timing system gear nut on service shaft - M18 (1) 150 Nm (110.6 lbf ft)
Timing system gear nut on crankshaft - M25 (1) 200 Nm (147.51 lbf ft)
Timing system upper gear TE screw (2) 30 Nm (22.13 lbf ft)
Screw fixing timing system upper gear closing cap - TBEI
M5x10 (4) 7 Nm (5.16 lbf ft)
Cylinder chain tensioner cap (2) 30 Nm (22.13 lbf ft)
Screw fixing movable chain slider (2) 25 Nm (18.44 lbf ft)
STELVIO 1200 NTX Characteristics
CHAR - 15
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

ALTERNATOR
Name Torque in Nm
Alternator fixing screw - TCEI M8x45 (1) 22 Nm (16.23 lbf ft)
Alternator fixing nut - M10x1.5 (1) 30 Nm (22.13 lbf ft)
Alternator pulley nut on crankshaft - M16 (1) 80 Nm (59 lbf ft) - Loctite 243
Belt tension 50 Nm (36.88 lbf ft)
Alternator belt cover screw - TCEI M6x16 (4) 10 Nm (7.38 lbf ft)
Alternator belt cover screw (radiator bracket retainer) TCEI
M6x40 (2) 10 Nm (7.38 lbf ft)
GEAR
Name Torque in Nm
Gear shift cable lever nut 10 Nm (7.38 lbf ft)
Gear shift tie rod lever nut on gear pre-selector 10 Nm (7.38 lbf ft)
Gearbox to crankcase fixing nut - M8 (5) 20 Nm (14.75 lbf ft)
TE flanged screw fixing gearbox to crankcase - M8x45 (1) 20 Nm (14.75 lbf ft)
Oil cap M18x1.5 (1) 28 Nm (20.65 lbf ft)
Breather cap (1) 8 Nm (5.9 lbf ft)
Gear in neutral sensor (1) 10 Nm (7.38 lbf ft)
Oil drainage plug - M10x1 (1) 24 Nm (17.7 lbf ft)
Transmission shaft ring nut (1) 100 Nm (73.76 lbf ft)
OIL RADIATOR
Name Torque in Nm
Radiator to chassis retainer M6x30 (3) 10 Nm (7.38 lbf ft)
Nipples to radiator retainer M16x1.5 (2) 20 Nm (14.75 lbf ft)
Oil pipes to radiator and engine retainer M16x1.5 (2 + 2) 20 Nm (14.75 lbf ft)
CHASSIS TO ENGINE UNIT
Name Torque in Nm
M6x40 TCEI DA screw 8 -12 Nm
Reduction 20 Nm
FUEL SUPPLY CONTROL UNIT
Name Torque in Nm
M5x12 TCEI screw 6 -7 Nm
Stainless M5x16 TBEI flanged screw 6 -7 Nm
M6x25 TCEI DA screw 8 -12 Nm
CHASSIS
Name Torque in Nm
Front engine to chassis retainer 80 Nm
Transmission to chassis retainer (M12x250 + M12x230) 50 Nm
Right fixing plate - transmission retainer 25 Nm
Plate clamp - Blow-by retainer 10 Nm
Coil plate retainer 10 Nm
Electronic control unit retainer 10 Nm
Bushings to electronic control unit retainer - M6x35 (1) 10 Nm (7.38 lbf ft) - Loct 243
Tank support rubber rings to chassis retainer (2) Manual - Loct 243
Filter casing fixing bolts 10 Nm
Left and right footrest plate to chassis upper retainer M8x30 (2
+2) 20 Nm (14.75 lbf ft)
Left and right footrest plate to chassis lower retainer M8x75 (2
+2) 20 Nm (14.75 lbf ft)
Brake switch on plate retainer Manual
Chrome-plated ring to plate retainer M5x10 (6) 6 Nm (4.42 lbf ft)
Retainer for cable guide on right footrest plate 6 Nm
Support retainer for M6 top boxes with countersunk head (6) 9.6 Nm (7.08 lbf ft)
Support retainer for M6 top boxes (4) 9.6 Nm (7.08 lbf ft)
Screws retainer behind the M6 bead protection (4) 9.6 Nm (7.08 lbf ft)
Screws retainer for M6 chassis supports (4) 23 Nm (16.96 lbf ft)
Cross-member retainer for M6 top boxes (2) 9.6 Nm (7.08 lbf ft)
Characteristics STELVIO 1200 NTX
CHAR - 16
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

FOOTRESTS AND LEVERS
Name Torque in Nm
Footrest rubber retainer 10 Nm
Rider footrest sliding pin - M8 25 Nm
Passenger footrest support to lateral plates retainer 38 Nm
Rider heelrest to plates retainer 6 Nm
Passenger heelrest retainer 3 Nm
Rod retainer (nut) 10 Nm
Gear shift lever / brake pin retainer 10 Nm
Gear shift lever / pre-selector retainer 10 Nm
Gear shift lever pin - brake retainer M8 (1+1) 15 Nm (11.06 lbf ft) - Loct 243
SIDE STAND
Name Torque in Nm
Stand plate to engine upper retainer 50 Nm
Stand plate to engine lower retainer 25 Nm
Side stand retainer pin 10 Nm
Switch fixing screw - M6x20 (1) 10 Nm (7.38 lbf ft) - Loct 243
Lock nut 30 Nm
Stand cable guide to engine retainer M8 (1) 25 Nm (18.44 lbf ft)
Side lever arm retainer - M6x16 (2) 10 Nm (7.38 lbf ft) - Loct 243
SWINGARM
Name Torque in Nm
Swingarm on bushing clamp retainer 10 Nm
Swingarm on bevel gear pair retainer 50 Nm
Reaction rod to bevel gear pair retainer 50 Nm
Reaction rod to chassis retainer 50 Nm
Swingarm bolt to swingarm retainer 60 Nm
Preloading bushing to swingarm bolt retainer 10 Nm
FRONT SUSPENSION
Name Torque in Nm
Tube lock plate to steering base retainer 6 Nm
Fork stem on upper plate retainer - M8x30 (2) 20 Nm (14.75 lbf ft)
Fork stem on lower plate retainer - M8x30 (4) 20 Nm (14.75 lbf ft)
Headstock ring nut 40 Nm
Headstock counter ring nut manual + 90 degrees
Upper yoke fixing cap 100 Nm
Fork hub closing - M6x30 (2+2) 10 Nm (7.38 lbf ft)
REAR SUSPENSION
Name Torque in Nm
Shock absorber to chassis retainer - 8.8 50 Nm
Double connecting rod/shock absorber retainer - 10.9 40 Nm
Single connecting rod/double connecting rod retainer - 10.9 50 Nm
Single connecting rod to chassis retainer - 8.8 50 Nm
Double connecting rod/swingarm retainer - 10.9 50 Nm
AIR FILTER CASING - BLOW-BY
Name Torque in Nm
Blow-by expansion tank spacer to engine retainer 10 Nm
Filter housing to chassis retainer 10 Nm
EXHAUST
Name Torque in Nm
Exhaust pipe to engine retainer 25 Nm
Silencer to chassis connecting pipe retainer 25 Nm
Muffler to chassis retainer - M8x45 (1) 25 Nm (18.44 lbf ft)
Heat guard retainer - M6 (3) 10 Nm (7.38 lbf ft)
Lambda probe retainer 38 Nm
STELVIO 1200 NTX Characteristics
CHAR - 17
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Name Torque in Nm
Clamps retainer - M8 (3) 20 Nm (14.75 lbf ft)
FRONT WHEEL
Name Torque in Nm
Wheel pin nut 80 Nm
REAR WHEEL
Name Torque in Nm
Disc retainer 25 Nm
Rear wheel retainer 10.9 110 Nm
FRONT BRAKING SYSTEM
Name Torque in Nm
Front brake right and left calliper retainer 50 Nm
REAR BRAKING SYSTEM
Name Torque in Nm
Rear brake calliper retainer 50 Nm
Rear brake fluid reservoir retainer 3 Nm
Rear brake fluid reservoir support to plate retainer 10 Nm
Rear brake rod lock nut manual
Brake pump retainer - M6x20 (2) 10 Nm (7.38 lbf ft) - Loctite 243
HANDLEBAR AND CONTROLS
Name Torque in Nm
Retainer for handlebar lower U-bolts on steering upper plate 50 Nm
Retainer for handlebar upper U-bolts 25 Nm
Anti-vibration counterweight fastener 10 Nm
Brake pump and clutch U-bolts retainer 10 Nm
Right and left light switch retainer 1.5 Nm
Clutch control cylinder to gear retainer 10 Nm
Rear-view mirror Manual
ELECTRICAL SYSTEM
Name Torque in Nm
Coil retainer 2 Nm
Horn retainer 15 Nm
Odometer sensor on bevel gear pair retainer 3 Nm
INSTRUMENT PANEL AND LIGHTS
Name Torque in Nm
Instrument panel retainer 3 Nm
Front arrows retainer - M4 (2) 3 Nm (2.21 lbf ft)
Front headlamp retainer - M6x30 (6) 10 Nm (7.38 lbf ft)
Rear light to license plate retainer - M5x16 (4) 6 Nm (4.42 lbf ft)
Screws retainer for additional lights (2) 10 Nm (7.37 lbf ft)
FUEL PUMP FLANGE
Name Torque in Nm
Pump support to tank retainer 6 Nm
FUEL TANK
Name Torque in Nm
Filler to tank retainer 5 Nm
Screws on cap ring nut (aesthetic) 5 Nm
Tank to chassis front retainer 10 Nm
Characteristics STELVIO 1200 NTX
CHAR - 18
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

ENGINE COVER
Name Torque in Nm
Right cover plate retainer - M10x20 (2) 40 Nm (29.5 lbf ft)
Left cover plate retainer - M10 (1) 40 Nm (29.5 lbf ft)
Front engine guard retainer - M8x40 (4) 15 Nm (11.06 lbf ft)
FRONT BODYWORK
Name Torque in Nm
Front mudguard retainer 6 Nm
Air deflector self-tapping retainer (4+4) Manual
Fairing junction - M5 (2+2) Manual
Glove-box - self-tapping (4) Manual
Compartment lock - M6 (2) Manual
Hinge locking bracket - self-tapping (2) Manual
Rear tank cover - M5 (2) 4 Nm (2.95 lbf ft)
Rear tank cover - M6 (2) 10 Nm (7.38 lbf ft)
Left - right fairing - M5 (2) 4 Nm (2.95 lbf ft)
Left - right fairing - M6 (2) 10 Nm (7.38 lbf ft)
REAR BODYWORK
Name Torque in Nm
Left - right fairings retainer - M6 (3+3) 10 Nm (7.38 lbf ft)
Retroreflector to support retainer 4 Nm
Retroreflector support to license plate holder retainer 4 Nm
License plate holder and light reinforcing retainer - M5 (1) 4 Nm (2.95 lbf ft)
Cases support retainer - M6 (2) 10 Nm (7.38 lbf ft)
Cases support retainer - M8 (2+2) 25 Nm (18.44 lbf ft)
Passenger grab handle to chassis retainer - M8 (2) 25 Nm (18.44 lbf ft)
Passenger grab handle to chassis retainer - M6 (4) 10 Nm (7.38 lbf ft)
License plate holder to chassis retainer - M5 (4) 4 Nm (2.95 lbf ft)
Luggage carrier brackets retainer - M8 (2+2) 25 Nm (18.44 lbf ft)
FINISHINGS
Name Torque in Nm
Ignition lock retainer - shear head screw - Nm
Overhaul data
Assembly clearances
Cylinder - piston assy.
Measurement of the cylinder diameter must be done at three heights, turning the dial gauge 90°.
Check that cylinders and pistons are of the same selection types (D, E, F).
Check clearance between cylinders and pistons on the selected diameter; if it exceeds the value speci-
fied, it is necessary to replace cylinders and pistons.
The pistons of an engine must be balanced; a weight difference of up to 1.5 g (0.0033 lb) is allowed.
PISTON - CYLINDER SELECTION TYPES
Specification Desc./Quantity
Piston diameter - selection D 94.935 - 94.945 mm (3.73759 - 3.73798 in)
Cylinder diameter - selection D 95.000 - 95.010 mm (3.74015 - 3.74054 in)
Piston diameter - selection E 94.945 - 94.955 mm (3.73798 - 3.73837 in)
Cylinder diameter - selection E 95.010 - 95.020 mm (3.74054 - 3.74093 in)
STELVIO 1200 NTX Characteristics
CHAR - 19
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

Specification Desc./Quantity
Piston diameter - selection F 94.955 - 94.965 mm (3.73837 - 3.73877 in)
Cylinder diameter - selection F 95.020 - 95.030 mm (3.74093 - 3.74133 in)
PIN - PISTON COUPLING
Specification Desc./Quantity
Pin diameter 21.998 - 21.994 mm (0.86606 - 0.86590 in)
Pin hole diameter on piston 22.016 - 22.011 mm (0.86677 - 0.86657 in)
Clearance between pin and holes on piston 0.013 - 0.022 mm (0.00051 - 0.00087 in)
Piston rings
On each piston there are:
•1 top piston ring;
•1 middle piston ring;
•1 oil scraper piston ring.
Turn the rings so that the coupling ends are 120 degrees from each other.
CLEARANCE BETWEEN PISTON RINGS AND SEATS ON PISTON
Specification Desc./Quantity
Top ring 0.030 - 0.065 mm (0.00118 - 0.00256 in)
Middle ring 0.020 - 0.055 mm (0.00079 - 0.00216 in)
Oil scraper ring 0.010 - 0.045 mm (0.00039 - 0.00177 in)
Gap between the end of the piston rings inserted in the cylinder:
•Top and middle piston ring: 0.40 - 0.65 mm (0.00158 - 0.00255 in)
•Oil scraper piston ring: 0.30 - 0.60 mm (0.00118 - 0.00236 in).
Characteristics STELVIO 1200 NTX
CHAR - 20
Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten
