Malatech EMERALD PRO INDUSTRY User manual
USER MANUAL
PROFESSIONAL MULTIFUNCTIONAL SOLAR FLOOD LIGHT
WITH 2.4G REMOTE CONTROL
EMERALD PRO INDUSTRY
MANUFACTURER/IMPORTER:
MALATECH WATER, LTD.
1/E Vanyi way, Alsonemedi,
2351 Hungary
+36 30 377 8089
info@malatechsolar.com
2
LED power: 15 W
Luminous ux: 3 280 lumen
LED chip data: EPISTAR SMD 2835, 192 pcs
Light color: Cold white 6000K
Solar Panel: 10V/50W monocrystalline solar
Li-battery: 6.4V/24 Ah/154Wh LiFePO4 battery
Waterproof IP rating: IP65
Body material: Tempered glass + die-casting Aluminium
Light size: 375X275X52 mm
Solar panel size: 400X670X17 mm
Net weight: 4.45 kg (light head) + 2.75 kg (solar panel)
Charging Time: 4.5 h (considering sucient sunshine during
charging)
Discharging Time: >10h on full capacity (considering full battery
load)
Lighting area: 45-60 m2
Working mode:
By light sensor and remote control (adjustable
brightness, timer, continuous lighting or
motion sensor setup)
Working temperature: -15 - +70 Celsius
Expected battery lifetime: >1500 cycles
Expected LED lifetime: >50,000 hours
Charging methods: 100% solar powered
Remote control: Yes, 2.4G technology remote control
Beam angle: 120 degrees
Motion sensor: Yes, microwave (radar) sensor
Waterproof cable length: 4.5 m
Warranty period: 2 years
Recommended eld of use: Domestic and industrial
Lamp box length/width/height 415X356X89 mm
Solar panel box length/width/height 676X409X26 mm
3
CONTENT OF THE BOX:
ATTENTION! Battery is built-in, non-replaceable!
ATTENTION! The performance of the battery may drop below 0 Celsius, and
above 40 Celsius temperatures.
Emerald Pro Industr y
ood light (1 pc)
Adapter cable
(4.5 m, 1 pc)
solar panel
(1 pc)
mounting bracket
(stand) (2 pcs)
2.4G remote control
(1 pc)
AAA battery
(2 pcs)
hit-in dowel
(expansion screw)
(4 pcs)
M4*10 screw
(4 pcs)
4
USER INSTRUCTIONS
1. Instructions, and information about using the battery, and maximizing
its life span:
ATTENTION! The life span of the battery depends on you as well! Please keep
using the product as described in this manual to maximize its life span for your
pleasure:
• Whenever you turn o your light after use, please make sure that
the battery did not run low. If that happens (the light indicates low
voltage by decreasing the luminosity), please load the battery!
• It is recommended to full-charge the light before rst use!
• If you do not use your light for a longer period, please always pay
attention to full-charge the battery ONCE A MONTH! The light can be
stored on the shelf for another month after that. A long-term storage
of the light with totally discharged battery may signicantly reduce
the life span of the battery, or may damage the battery!
ATTENTION! THE STANDBY OPERATION OF THE LIGHT CONSUMES BATTERY
CHARGE AS WELL, WHICH MEANS THAT THE BATTERY IS BEING DISCHARGED
SLOWLY EVEN WHEN YOU DO NOT USE YOUR LIGHT! THAT IS WHY IT IS KEY
ESSENTIAL TO KEEP THE ABOVE WRITTEN INSTRUCTIONS!
2. Instructions for solar charging, information about charging the
battery:
• Please pay attention to keep the solar panel clean. Please follow
“Cleaning instructions” below for cleaning your light!
• Below the LEDs the indicator light keeps blinking until the solar panel
receives enough light for charging. Depending on the level of charge
in the battery the blinking light can be red, yellow or green. Once
the indicator light stops blinking, it means the solar panel does not
receive sucient light to charge the battery. Continuous green light
means the the battery is full-charged.
• In order to maximize the eciency of solar charging, please set the
solar panel to approximately 45 degrees with the solar panel facing
towards the midday sun.
5
Please pay attention to place your light in a non-shaded place with
sucient sunshine provided for its operation.
ASSEMBLING THE LIGHT & INSTALLATION
Measure and sign the
location of the ood light ’s
bracket (stand) on the chosen
surface. Please care about
the distance bet ween the 2
holes, measure it exac tly.
Tighten the nuts with
a wrench (Care! do not
overtighten!).
Drill the 2 holes (M10)
Place the ood light’s bracket
(stand) onto the screws.
Set up the desired angle of
the ood light, and tighten
the connection ttings (Care!
Do not overtighten!).
Connect the adapter cable to
the connections of the light’s,
and the solar panel ’s cable
connections. Care about
waterproong, connections
must be attached correctly.
Place the hit-in dowels
(expansion screws) in the
holes, and push them in with
a hammer.
Use the 4 pcs M4 screws
to assemble the 2 pcs of L
prole brackets (stands) of
the solar panel.
Loosen the nut, and remove
it together with the 2
washers.
Considering the points
written above, x the solar
panel assembled with its
brackets (stands) on its
chosen location. You nd
2 hit-in dowels (expansion
screws) for xing the solar
panel on the chosen surface.
Place the 2-2 washers on
each screw (spring washer
should be put last), then
drive in the nut on each.
Use the remote-control unit
to operate and customize
your light.
6
Correct wiring:
Once you connect the ood light with the solar panel, the “AUTO”
operational mode is activated where the solar panel charges the battery
daytime, and the light turns on at dusk. In the morning the light sensor
switches o the light, and starts charging again. Other operational modes
than “AUTO” can be set up by the 2.4G remote control unit.
Functions of the remote control:
You can customize the operation of your light by the 2.4G remote control
unit. Due to 2.4G technology you do not necessarily need to point at the
light with the remote to control it within the operational radius (10-20 m
depending on obstacles). 4 constant lighting options are available with
dierent power setups: 25%, 50%, 75%, and 100% power can be applied.
You can set up time-controlled operations (4h, 6h, 12h), or you can operate
the light with 2 motion sensor setups: light is o, and switches to 100%
power when motion sensor is triggered, or the light shines at 30% power,
and switches to 100% power when motion sensor is triggered. You can
operate the light by the light sensor (AUTO), or you can override the light
sensor operation by pushing the ON/OFF button, which activates daylight
mode.
OPERATING & CUSTOMIZING THE LIGHT,
FUNCTIONS OF THE REMOTE CONTROL
7
Important notes:
1. If you intend to choose constant lighting with time-control, please set
up the desired power rst (if needed).
2. If you activate any of the 4 power modes, only constant lighting mode
is available.
3. The motion sensor options cannot be altered, you can only add time-
control to these setups.
4. The ood light blinks 2 times shortly whenever it receives a command
from the remote control.
5. With the ON/OFF button you can override AUTO operation, and
operate the light daytime (e.g. at indoor installations).
ON/OFF, manual mode, even daytime
operation can be applied.
Operation by the light sensor. At dusk the
light switches on, early in the morning it
switches o.
Constant lighting modes with 4 dierent
power setups
When activating Test mode, the light switches
on for 60 seconds, then it turns o.
Time-controlled operation (4h, 6h, 12h
operation with constant lighting or by
motion sensor)
Motion sensor operation 1: light is o, and
turns to 100% power when motion sensor is
triggered ( ligh t remai ns on for 60 sec onds a fte r motion is
not detected anymore, t hen it s witches o ).
Motion sensor operation 2: light shines at
30% power, and turns to 100% power when
motion sensor is triggered (lig ht keep s 100% power
for 60 second s after mot ion is not dete cte d anym ore, then it
switches b ack to 3 0% power).
8
1. After receiving your light, please open the light’s box gently with paying
attention not to cause harm to the light and its parts.
2. Before starting to use your light, please make sure that there are no
visible damages on the light and its parts.
3. If you observe breaking, crack, fracture on the light or on its parts,
please do not use the product, but contact us for replacement.
4. Please do not apply strong physical force on the product that can
damage the light or its parts. Non-ordinary use of the product results
the loss of product warranty.
5. Please keep the box, the packaging material, and the content out of the
reach of children, and pets. There are small objects among the parts
of the light, which children or pets can ingest, or can cause harm to
themselves with.
6. Please do not disassemble the light, do not bend the light, or
apply physical stress on the light. Please follow the user manual’s
instructions for installation, and operation.
7. Do not expose the light to higher heat than natural caused by weather
changes. Excessive heat may damage more constituents of the light.
8. Do not expose the light to continuous high- or low-pressure water
ow, even if you intend to clean your light. The IP65 protection does
not mean you can put the light in water, or you can wash the light with
continuous water stream. The next chapter declares the right method
of cleaning.
9. Please always contact Malatech Water, Ltd, or a professional appointed
by our company if you intend to disassemble the light, remove any
of its parts, or service the light. Service attempts made by users are
prohibited, and result the loss of product warranty.
For preserving the aesthetical outlook, and maintaining the maximum
functionality, and eciency of your light, cleaning is recommended from
time to time. Since the light is operated by solar energy, keeping the solar
panel clean & free of dust is key-essential to ensure its eciency, and
maximize discharging time. Please follow the instructions below when
cleaning your light:
USER INSTRUCTIONS, INFORMATION
CLEANING INSTRUCTIONS
9
1. Please always use a suitable, soft, and damp towel for cleaning the
solar panel
2. Apply the towel with higher water content for the rst time at each
cleaning procedure to remove the majority of dust preferably with one
movement.
3. After washing the towel in continuous water stream to remove the
accumulated dust, squeeze the water out of the towel, and remove
the remainder of dust with the towel gently from the surface of the
solar panel if necessary. Care to avoid scratching the surface of the
solar panel.
4. If you observe scaling, or other accumulated dirt on the surface of the
solar panel, please only use a chemical or natural enzymatic based
agent for cleaning which is recommended for solar panel cleaning by
its manufacturer.
5. Cleaning of the plastic and metal parts of the light body can be
executed easily, but attention is needed to avoid scratching of the
surfaces.
6. Cleaning the dome which protects the LED group from external eects
also requires cautious approach for cleaning to avoid scratching.
Please apply chapter 1)-4) above for the dome as it is written in case
of the solar panel.
The light recognizes low battery voltage, and switches o automatically
to prevent the battery from damage, and to maximize the life cycle of the
battery. Besides that, the light applies an eco-mode when the battery
level is low but sucient for operation. In this case the light will shine at
a dimmed mode. Please charge your light whenever any of the above
written occurs!
The WEEE (Waste Electrical and Electronic Equipment) sign
means that every electrical, and electronic wastes must
be collected, and treated separately. According to The
Waste Electrical and Electronic Equipment Directive (WEEE
Directive), the European Community Directive 2012/19/EU
on waste electrical and electronic equipment (WEEE) which, together with
the RoHS Directive 2011/65/EU lights, and light bodies are electrical, and
AUTOMATIC BATTERY PROTECTION
WASTE DISPOSAL
10
electronical wastes, and cannot be disposed, and treated together with
municipal waste. Since they require special treatment, these wastes can
only be handled to organizations, and companies authorized to treat these
kinds of wastes. Whenever your light comes to the end of its life cycle,
please cooperate with treating your waste as written above, we can help
you in that:
According to the local government act 197/2014 (VII.1) we pay waste
disposal and handling cost in case of each sold units, large light bodies
(any dimensions of the light exceeding 50 cm), and small light bodies (no
dimensions of the light exceeding 50 cm) included. We teamed up with an
intermediary organization ELECTRO-COORD Non-prot, Ltd. for fullling
our obligatory duties, and we also operate a collection point at our facility
where we can take over your wasted lights either those you purchased
from us, or functionally similar light waste that you originally purchased
from elsewhere.
Important information regarding the lights distributed by Malatech Water,
Ltd:
• The Aluminium, steel, plastic (Acrylic, Polycarbonate) parts of the lights
do not cause environmental or health risk either in perfect or damaged
condition of the light.
• The LEDs do not cause environmental or health risk either in perfect
or damaged condition, but according to the laws they are meant to be
electrical, and electronical wastes, which require special disposal, and
treatment.
• The built-in Li-ion batteries, and the photovoltaic panels are dangerous
wastes, which means that you must not dispose the wasted light into the
municipal waste container but you need to keep them separated from
municipal waste, and dispose it at an authorized location only.
• Since our lights are IP65 rated lights, the parts in many places are
waterproof adhesive-bonded, glued. Disassembling the light is
prohibited by users. Please let certied specialists do this job instead,
and handle your wasted light preferably in a perfect, non-damaged
condition.
For more information on electric, and electronic waste disposal locations,
please visit www.electro-coord.hu, or www.malatechsolar.com.
11
Malatech Water, Ltd. provides all-inclusive, attractive, customer-oriented
warranty terms and services for its products during the warranty period
for all of our customers in the following countries (by alphabetical order):
Despite all of our products are high-end premium quality, and they
go through multiple quality & aesthetical check procedures during
production, and one last check procedure is performed by us for quality,
functionality, aesthetics, package accessories content before packaging
for the customer, the lights are technical equipment made by humans,
which means some may go wrong at our customers during using them,
or may get hurt aesthetically because of a transportation failure when
delivering the order. In case you encounter any problems with your
purchased light, please follow the instructions below:
1. Our company usually accepts photos as proof of aesthetical damage
caused by courier transportation at order delivery. In case you
experience external damage on the product, please, if possible take
photos of the damage immediately, and send it to us to service@
malatechsolar.com as soon as possible. Please always highlight your
order no. in your e-mail, and send the scanned version of your invoice
as an image or pdf le for us being able to send you the replacement
in due course.
2. If you experience any operational troubles during the warranty period
of your light, please contact us by e-mail at service@malatechsolar.
com. Please always highlight your order no. in your e-mail, and send
the scanned version of your invoice as an image or pdf le. In most
cases our company accepts a detailed description with preferably a
simple short video as a proof made by for example your cell phone
about the issue. If you can do the video, please attach in low resolution
to your e-mail, or upload it to a free le sharing platform, and send
us the link. We examine your case as soon as possible, and contact
WARRANTY TERMS
• Austria
• Belgium
• Bulgaria
• Croatia
• Cyprus
• Czechia
• Denmark
• Estonia
• Finland
• France
• Germany
• Great Britain
• Greece
• Hungary
• Ireland
• Italy
• Latvia
• Lithuania
• Luxembourg
• Malta
• Netherlands
• Norway
• Poland
• Portugal
• Romania
• Slovakia
• Slovenia
• Spain
• Sweden
• Switzerland
12
you with a solution. We either can x your problem remotely, identify
the wrong setup, and help you address it, or we identify the failed
component. In the latter case, we send you a replacement for that
part, if the component can be replaced by the customer, and do not
require service. If we determine that the light has a technical issue to
be addressed at the service, according to our decision, there could be
2 ways to go:
• We either decide that the light cannot be repaired economically, and
we supply you a brand-new product, in this case you have no further
action needed to be done, we inform you about the details of the
delivery. The process takes 3-5 working days (+ transportation time
6-10 working days) if the product is on stock. If the product is not
on stock the process takes longer period, but in this case, we are
in continuous contact with our customer, and provide information
about the delivery status.
• Or we decide to call back the product for service, and x the
problem. For this scenario, we tried to make the process for our
customers as simple, and easy as possible: we have a contract with
our courier (FedEx-TNT) for returning the goods to us for service. In
this case you just need to pack the products in a box caring to ll the
void spaces with the necessary elements to prevent damage during
transportation, close & seal the box safely, and wait for the call of the
courier driver. Although not obligatory, we recommend you to keep
the box of the product with the original packaging material, it could
make it easier for you if service is needed. Please care to pack every
content in the box, all accessories you received with your light. Once
you handled the box to the courier, we take care about the rest for
you: once the service of your product is done, we send it back to you,
or if the problem cannot be xed, we send you a new product. All the
above written are free of charge for you, our company takes care
about all the expenses during the warranty period.
Basic warranty terms:
1. Warranty period / scope
With the warranty, our company guarantees that the product does not
have any material or workmanship defects at the time of the purchase.
The warranty period varies between 1-3 years from the date of purchase
depending on product. The warranty period for each product is dened in
the specication sheet of the product. Our product warranties are valid in
the European Union, Great Britain, Switzerland, and Norway
13
2. Required documents for warranty claims
Warranty is only valid for all of our products once the original invoice,
or the copy of the original invoice of the purchase is presented by our
customer. Our company accepts scanned image or pdf versions of the
invoice sent by e-mail.
3. Addressing a warranty claim
Warranty claims must be addressed within the warranty period. The
warranty starts on the date of the rst purchase according to the original
invoice. We reserve the right to refuse the warranty claim if the proof of
purchase is missing or incomplete.
4. Exclusions of warranty
Warranty claims are refused in the event of damage caused by:
• abusive or improper treatment,
• environmental inuences (heat, overvoltage, dust etc.),
• abusing the safety precautions applicable to the device,
• damage caused by improper use of the product neglecting the
operating instructions
• damage caused by external force (e.g. blow, push, fall),
• interventions that were not carried out by our service, or a service
authorized by our company
• unauthorized repair attempts,
• changes made to the item
• damage due to improper packaging that is not safe for transportation
(excluding the rst transportation of the product which is organized
by our company, please read instructions above for damages caused
by courier when completing the order)
Please always read the user manual carefully for each product you
purchase from us before using it, and follow the instructions.
5. Other information about service
Service, and repair works of solar lights out of the warranty period done
by our company or authorized service companies are not free of charge.
Please contact us at service@malatechsolar.com, or call +36 30 377 8089
for information, and quotation on repair work services after warranty
period.
14
Manufacturer/Importer:
Malatech Water, Ltd.
1/E Vanyi way, Alsonemedi, 2351 Hungary
Customer service:
+36 30 377 8089
info@malatechsolar.com
www.malatechsolar.com
Issue warranty claims:
service@malatechsolar.com
CE Conrmation:
Malatech Water, Ltd. conrms that this light meets with the competent
EU directives, legislation, and harmonized acts.
15
Table of contents
Other Malatech Floodlight manuals
