M&M Models WW08 User manual

1
Welcome Wagons WW 08
Bogie Bolster C (Fitted)
History
The ‘Bogie Bolster C’ was of a new design built for British Railways, five diagrams cover the type and
all examples are 45ft over headstocks with a 30ton capacity.. This kit covers part of diagram No. 1/477
which were vacuum fitted. For more info see British Railway Wagons the first half million.
Running Numbers
B922700 –922999 Lot 3200 Swindon 1959
B923000 –923099 Lot 3238 Swindon 1959
All above were vacuum fitted, If you require to build to lot 3059 (B944640 –945379) which had cast
bogies sides and Oleo buffers, then send back side frames and buffers to M&M for replacement with
other type.
Transfer layout, drawing not to scale.

2
Parts List
Etch Instructions
Coupling springs x 2 Coupling links x 4
6BA bolts or M3 x 2 8”of 0.7mm wire
6BA nuts or M3 x 2 Split pins x 2
W/M castings
DW-65, Buffer x 4 DW-16, Detail set x 2
DW-33, Vac pipe x 2 DW-29, Vac cylinder x 2
DW-94, Bogie side frame x 4 DW-79, Bogie cross member x 2
DW-82a, Brake X shaft long x 2 DW-81, Bolster Top x 4
DW-83, Brake X shaft short x 2 DW-85, Side pockets x 16
DW-86, Brake X shaft link x 2 DW-84, Side shackles x14(can be supplied in lwb if available)
ITEMS REQUIRED TO COMPLETE, 2 x sets of 3’1” 3hole wheels sets inc. bearings, Slaters 7122 or
the New Welcome turned steel insulated Wheels c/w ball races, Paint and transfers. These items
except the paint can be found on the website www.modelrailwaywagons.co.uk
Reference Books
British Railways Wagons the First half million
By Don Rowland
ISBN 07529 03780
British railways Goods wagons in Colour
By Robert Hendry
ISBN 1 85780 03780
British Railway wagons, opens and hoppers
By G. Gamble
ISBN 1 1900298 06 6
British Railway Wagons No.1, Open & Hoppers
ISBN 1900298 015
Web Reference
Paul Bartlet Wagon Photos
(http://paulbartlett.zenfolio.com/brsteelcarryingwagons/h178a6790#hf470de7)

3
Plan not to scale.

4
Note: - Some parts of the kit will require some small amount of filling to achieve a snug fit of parts, i.e.
the ends of solebars and cross members.
Tip: - To make the long folds easier, scribe the half etched fold lines before bending.
Instructions.
1. Take the floor (1), Push out rivet detail at ends then fold up top lip through 90° all round. Then
fold up sides through 90° all round, this should form a tray then solder up corner seems. Photo
1
2. Take the outer solebars (2), inner solebars (3), inner cross members (5) and buffer beams (4),
on parts (5 and 2) push out rivet detail at ends, fold up to form a U shape.
3. Solder outer solebars to buffer beams to form a rectangle, now take this and solder to underside
of wagon floor. Photo 2
4. Fold up two of the trusses (6) and the four truss posts (7). Solder truss posts to trusses (6) see
Photo 3. Now mark a line 16mm from truss end of post. Photo 3.
5. Now mark a line across the underside of the wagon floor 58.5mm from outside of buffer beams
and fit the truss assembly to behind the solebar so that the bottom of the truss is 16mm from the
bottom of the solebar. Photo 4. Now repeat with the other side.

5
6. Now fit the cross members (5) up against the solebar and truss assay, three on each side.
Photo 5.
7. Fit the two inner solebars (3) between the buffer beams and up against the cross members.
8. Next take the end braces (14) trim the long pair to match the short pair, fold to L shape and fit
up against buffer beam and inner solebars. Photo 6. (note:- these may have to have some
metal removed from the top edge to clear wheel sets, best done for position when the bogies
are fitted.
9. Take the two truss cross braces (8), trim to length, fold to L shape and fit between Trusses.
Photo 7
10. Next take the inner trusses (6), fold to shape and fit these up against the outside face of the
inner solebars. Or if you prefer you can build these from the individual parts (6a) and (6b). To
finish make some short lengths of L section from unused truss parts to go between the inner
trusses and inner solebars. Photo 8
11.Take the bogie mount plate (9), trim 4mm of the length on each side. Open out hole to clear
6BA bolt (2,7mm) or M3, now solder a 6BA or M3 nut over hole on the side with the half etched
lines. Bend to shape and fit over inner solebars and up against outer sole bars, spaced at 35’6”
centres (248.5mm). Or (33.5mm) in from outside of buffer beams. Photo 8
12. Take 4 V hangers (10) fit two at r/h end behind solebar but outside of the outer truss with the
end leg 85mm from buffer beam and the other two to the outside face of the near side inner
solebar. Photo 9
13.Now fit the remaining V hangers (10), fit hangers to inside face of outer solebar up against the
truss post and to the inside face of the far side inner solebar. Photo 9
14.Now take the long brake X shaft (DW-82A), These then fit between the inner V hangers
together with the vacuum cylinder (DW-29). Photo 10
15.Next fit the short X shafts (DW-83) and link (DW-86) between the outer V hangers. Photo 11.
Add wire from the long X shaft to the bogie mount plate. Photo 12. Repeat at other end.
16. Take brake pin down bars (11), fold to shape and fit to solebars 68mm from buffer beam. Next
take the brake handles (12) and bend to shape, these fit from the outer V hanger to the brake
pin down bar. Photo 13
17. Add buffer beam detail, buffers, coupling hook and back plate, lamp bracket and vac pipes.
18. Now fit the solebar and body side detail, wagon plate, load clip, shackles and bolster pockets.
Photo 14
19.Bolsters, take etched parts (13) and bend to from shallow U shape. Take two of part (13) and
solder back to back, these then fit to the under side of the cast bolsters DW-81(you may have to
trim the top corners of part (13) to fit snugly into the cast bolster. Photo 15. Now fit the
completed bolsters to the wagon floor, the pegs go into the cast side pockets in the desired
positions. Photo 15
20. Bogies, take the side frames (DW-94) drill out to take your chosen axle bushes, you can fit a
M2.5 washer (not supplied) under the flange of the top hat bush, this will take up most of the
axle end float. Take bogie bolsters (DW-79) and remove pips from inside of ends.If you require
compensation, cone out the centre hole just enough so that the screw head (see21 ) will not
pass thru. A small countersink bit is the ideal tool for the job.

6
21.NB:- Only one end of the wagon requires this process Assemble bogies with wheel sets,
make sure all is square, fit bolster between side frames and solder up. Photo 16.
22. The bogies are held on to the chassis with 2 x 6BA (or M3) bolts. You may find that you have to
trim some metal off the members (14) to clear the wheel sets and from the insides of the bogie
cross member to clear the head of the M3 bolt. Photo 16.
23. This completes the model, all to do now is clean the model, paint and apply transfers, see
drawing and photos for position.

7
