M&M E107C User manual

Smart toilet seat
Instruction manual
Apply to E107C

Contents
Thank you for purchasing this intelligent seat, please use is carefully after reading this manual.
Cautions …………………………………………………………………………………… 2-5
Components name ………………………………………………………………………6-8
Product installation ……………………………………………………………………… 9-13
Confirmation before use ………………………………………………………………14-15
Operation method ………………………………………………………………………16-18
Cleaning steps …………………………………………………………………………… 18-19
Not used for a long time ……………………………………………………………… 20
Malfunction judgement and solution ………………………………………………21-22
Technical data ………………………………………………………………………………23
1

Cautions
To prevent harm to users or others and property damage,Please read
the [Cautions] carefully and follow them! In order to use this product
correctly.
Symbol Meaning
Indicates that if you ignore this flag while operating,
It may cause serious injury or death.
The content indicated by this fl ag is: Unprohibited
[Prohibited] content
The content indicated by this fl ag is: mandatory content
that must be executed
Warning
Prohibited
Compulsory
compliance
The content represented by this flag is：
High temperature and flammable objects are prohibited.
The content represented by this flag is：
Connected to ground.
The content represented by this flag is：
Do not touch with wet hands.
The content represented by this flag is：
Prohibition of immersion in water.
The content represented by this flag is：
Disassembly or unauthorized modification of the product is
prohibited.
The content represented by this flag is：
Unprohibited [Prohibited] content
The content represented by this flag is：
Content that must be enforced.
2

Please use a splash box,Do not pour water or
detergent on the product and power plug.
It may cause damage to the product or fire or
electric shock.
Do not use loose or faulty outlets.
It may cause fi re or electric shock.
Check that the power outlet is grounded.
This product must be well grounded. Only
connect a dedicated 220V, 50Hz, 10A
circuit with a ground fault circuit breaker or a
ground leakage protector.
If the power cord is damaged, it needs to be
replaced. To avoid danger, please observe the
following:
Please contact the retail store where you
purchased this product or the nearby customer
service center. Must be replaced by the
manufacturer’s service department or an
authorized professional.
When using in a bathroom, make sure that the
power outlet is waterproof. Failure to do maybe
result in electric
Failure to do maybe result in electric shock or fire.
Tips
Persons with disabilities and those with limited experience or common sense (including
children) are required to use this product under the supervision of a person.
Do not install the product in a room where frost may form. The indoor temperature must
not be lower than 0 °C，This product must be connected to the cold water supply (inlet
water temperature is approximately 4~35 °C), otherwise the machine will be burn or
caused trouble.
3

Do not plug or unplug the power plug with
wet hands.
It may cause an electric shock.
Do not pour urine on the body and nozzle.
Failure to do so may result in malfunction
or smudges such as pink and
brown.
Do not connect any wastewater, mixed
water, industrial water, sea water or other
untreated or semi-treated water.
May cause skin infection or malfunction.
Do not pull or damage the power plug/power
cord at will.
It may cause fire, short circuit, or electric shock.
Please turn off the power and pull out the
plug before removing or cleaning the product.
Otherwise, there is a danger of electric shock.
Do not disassemble and modify this product
for any purpose, for any purpose.
It may cause fire, short circuit, or electric shock.
Do not place high temperature and flammable
materials near the product. it may cause fire
Glowing cigarettes and other burning materials
must not be thrown into the toilet.
4

Do not bend or twist the water supply hose.
May cause water leakage.
Do not use the following items to clean the
product:
Gasoline, banana water, benzene, paint thinner,
decontamination powder and nylon brush.
When not in use for a long time, drain
the water from the water hose and unplug
the power cord.
Do not lean on the cover.
It may damage the seat cover and cause personal
injury.
Do not expose the productdirectly to water,
strong light or sunlight.
May cause fading and unstable race temperature.
Do not install the product in a room where frost
may form. The indoor temperature must not be
lower than 4 °C.
Prevent product freezeage and damage the
movement components.
5

6
Nightlight
Women wash
Quick release cover
Safety notes
Heating seat
Sensor zone
Handle
Operation panel
Rear wash
Components Name
Plug

7
Components Name
Bottom inlet model
Water inlet
Water inlet
Power cord outlet
Fixing plate
Fixing plate
Quick release putter
Interior atmosphere light
Power cord outlet
Quick release putter
Interior atmosphere light
Side inlet model

Accessories
Side inlet model
4、Waterway accessories
Water inlet
hose（1）
Water inlet
connector（1）
（To the T-cock）
Waterinletconnector（1）
（to the main body）
Water inlet T-cock
connector
Water inlet
hose（1）
Water inlet T-cock
connector
1、Main body
Bottom inlet model
Screw+
Pom nut(2)
Adjustment sheet(2)Flat washer(2)
3、Installation accessories
2、The printing
fixing plate（1） Positioning
cardboard（1）
Manual（1）
4、Waterway accessories
1、Main body
Screw+
Pom nut(2)
Adjustment sheet(2)Flat washer(2)
3、Installation accessories
2、The printing
fixing plate（1） Positioning
cardboard（1）
Manual（1）
Instruction manual
Instruction manual
8

1
3
2
4
5
Distance between mounting
holes：135-165mm
The distance between the
mounting hole and the front of
the ceramic430-470mm
The distance from the inner circle
of the toilet to the front of the
ceramic＞375mm
Distance from water tank to the
front of ceramic＞505mm
Ceramic width≤380mm
9
Product installation
Adapt to ceramic dimension requirements
Preparation before installation
Before installing the toilet seat
1. Remove the existing toilet and close the
water supply system of the toilet.
2.Press the flush button to release the
pressure from the water supply pipe.
3.Place a container with water under the
water inlet valve.
4.Disconnect the toilet inlet valve from the
water supply pipe.
Note: When determining the location of the
circuit exit, follow local standards
1.The inlet of the separate seat is on the left
side and the bottom.
2.When the water inlet is from the bottom,
the ceramic holes must be able to pass
through the power cord and water inlet pipe;
Installation circuit outlet
1. Before installing the circuit, please reserve a power socket
within about 1 meter to the right of the toilet.
2. It is recommended to use waterproof sockets. Do not use extension
cords to connect the product.

1. Open the angle valve to drain
water for 10S, and confirm that
the inlet water channel is normally
flowing.
2. Place positioning cardboard, align
the front of the cardboard with the
front of the ceramic.
3. Plug the expansion screw into
the ceramic mounting hole,
place the fixing plate in the hollow
position of the positioning
cardboard, place the adjustment
piece according to the position of
the ceramic installation hole, and
screw the adjustment piece to lock
the fixing plate to the ceramic.
4. After the installation of the fixing
plate is completed, remove the
installation positioning cardboard.
01
Installing the fixing plate
04
02
0403
10

Toilet installation and removal
Installation:
Align the toilet with the fixing
plate, push it in the direction
of the arrow, and hear a "click"
sound, indicating that the
toilet is installed in place.
Disassembly:
Press the side quick-release
pusher inward and pull out the
toilet horizontally with both
hands.
Side inlet
Toilet pipe
Side water inlet
Connects the hose in the accessory
package with the water inlet joint.
Bottom inlet
1.Unscrew the plug at the
bottom water inlet.
2. Connect the water inlet
connector and the water inlet
in the accessory kit, and then
insert the water inlet pipe
into the water inlet
connector.
11

Installation:
Pass the power cord and water
inlet pipe through the ceramic
rear hole, and align the toilet
with the fixed plate (the
exposed length of the fixed
plate is about 15mm, the rear
shell is flat against the ceramic),
and then push in the direction
of the arrow on the right, and
hear a“click”indicating that the
toilet is installed in place.
Disassembly:
Press the side quick-release pusher
inward, pull the toilet horizontally
with both hands until it is loose
(the exposed length of the fixing
plate is about 15mm), and then
lift the toilet upward.
Bottom inlet
15mm
12

1.Applicable water pressure
range：0.075-0.8MPa
2.Applicable water
temperature range：
4-35℃
3.Usage environment 0-40℃，
relative humidity≤95%；
4.The new hose must be used. The
old hose assembly cannot be
reused.
In the same room where this
product is installed, you need to
install a water stop valve within
easy reach. It is used in emergency
situations to cut off the water inlet
of the product without the use of
tools. Otherwise, unexpected
failure of the product may cause
user loss
Built-in filter
Built-in filter
Bottom inlet water supply
Side inlet water supply
Connector power:
Separate water and
electricity installation
locations
Warning
Connect power and water
Connect the external water source to the
water inlet connector with the supplied
hose and filter
Connect the external water source to the
water inlet connector with the supplied
hose and filter
1.220V (greater than 10A) socket installed
at a position 50cm above the ground.
2.The socket must be installed in a place
where water cannot easily splash.
3.Use a grounded socket.
4.Plug the power plug of the
product into the socket.
The plug should be connected
to a valid grounded socket,
otherwise it may cause
electric shock in the event
of power failure or leakage.
Please connect the power
according to the product
power supply requirements，
Otherwise it may cause the product
to malfunction.
Notice
Notice
Notice
13

Confirmation and pilot run
Confirmation before use
When the human body seat
induction is on, press down / up
the handle to see if the nozzle is
extended normally to start the
women wash / rear wash function.
3.Check panel function
1. Detect power 2. Seat sensor
4.Check flush function
Make sure the power plug is
plugged in tightly. The indicator
light on the plug indicates that
the system is powered on. If the
indicator light is not on, you can
press the reset button on the
plug to power on. After the
power is turned on, the system
emit a beep.
There is a seat sensor in the area
shown in the figure. Only when
the system senses that someone
is seated, the system emits a
beep.
Press the "night light", "seat
temperature", and "water
temperature" on the panel to
see if the related function
indicators are normally on / off.
Open the valve
Open the water inlet valve to provide water for the whole machine
14

Power
Supply
Night
Light
Seat
Temp
Water
Temp
Warm water on/off button
Operation panel
Heating seat temperature
on/off button
Night light on/off button
Power Indicator
Rear wash
Women wash
Light sensitive area
15

Operation panel function illustrate
Lift the handle parallel to the operation panel,
you can end the "rear wash" and "women wash"
Rear wash
Stop
Women wash
Operation method
When someone is seated and sensed by the seat,
lift the handle up and the nozzle extends to start
the rear washing function; The water flow
changes with the rotation of the handle; After the
rear wash, lift the handle down until it is parallel
to the operation plane. (There will be a sense of shifting,
accompanied by a "click" sound)
The rear wash is a stream of air bubble water with massage function
for a gentle and comfortable experience.
When the seat does not sense someone sitting, lift the handle up
to open the rear wash, the nozzle will not extend out, but only water
come out from the self-cleaning mouth, and with “beep” alarm.
When someone is seated and sensed by the seat,
lift the handle down and the nozzle extends to
start the women washing function;The water flow
changes with the rotation of the handle; After the
women wash, lift the handle up until it is parallel
to the operation plane. (There will be a sense of shifting,
accompanied by a "click" sound)
The women wash is a stream of air bubble water with massage function
for a gentle and comfortable experience.
When the seat does not sense someone sitting, lift the handle down
to open the women wash, the nozzle will not extend out, but only
water come out from the self-cleaning mouth, and with “beep”
alarm.
16

The power indicator is always on after the power is turned on.
Power Indicator
Press the water temperature button , when the indicator
light is on, the water temperature heating function is turned
on; when the indicator light is off, the water temperature
heating function is turned off.
(Note: When the warm water cleaning function is needed, if
the product water temperature is set to off, please turn on
the water temperature button before using to ensure comfort.)
Water temperature
Press the seat temperature button , when the indicator light
is on, the seat heating function is turned on; when the seat is
not sensed, the seat is warmed at 34 ° C. After the seat is
sensed, it is heated to a comfortable 37.5 ℃; After the
temperature reaches to 37.5 ℃, the seat will automatically
cool down to 33 ℃ to prevent low temperature burns;
When the indicator light is off, the seat heating function is
turned off.
Seat temperature
Press the night light button , the night light function is
turned on when the indicator light is on; the night light
function is turned off when the indicator light is off.
Nightlight
(Remarks: The night light is controlled by the light sensor,
and the light intensity of the external light source is <2 Lux.
The night light will be on. If the light intensity of the
external light source is> 2 Lux, the night light will
automatically turn off.)
17

1、Cleaning nozzle
a、Use your forefinger to hold the
bottom of the nozzle and gently pull out
the nozzle; use a soft cloth, sponge or
small brush to apply neutral detergent;
b、Gently hold the nozzle and wipe the
nozzle and sprayer
c、Put back the nozzle, switch to rear or
women wash, clean the detergent and
dirt with self-cleaning water.
2、Cut the power supply
Unplug the power plug
before cleaning the product
body.
Product cleaning
Cleaning steps
Function description
1、Seat detection
There is a seat detection switch on the toilet seat, used to detect whether a
person is seated when the power is on. When the person is seated, the
"rear wash" and "women's wash" functions can be turned on; When the seat
does not sense someone sitting, turn on above functions, the nozzle. will
not extend out, but only water come out from the self-cleaning mouth, and
with “beep” alarm. When the product is powered off, the seating detection
does not work, the warm water washing functions and heating seat function
cannot be used, but only normal temperature water with "rear wash" and
"women wash".
2、Nozzle self-cleaning
Before the "rear wash" and "women wash" functions starting, the nozzle is
self-cleaning, and then the nozzle is extended to start the "rear wash" and
"women wash" functions;When the seat does not sense someone sitting,
turn on rear wash and women wash functions, the nozzle will not extend
out, but nozzle will start self-cleaning and machine with “beep” alarm.
3、Protected against low temperature burns
When the seat is sensed, it is heated to a comfortable 37.5 ℃; After the
temperature reaches to 37.5 ℃, the seat will automatically cool down to 33 ℃
to prevent low temperature burns;
18
