Assembly Manual
Children’s Swoon Pod
MM00147-PNK
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

M&M Sales
Enterprises, Inc.
1300 Synergy Ct,
Dubuque, IA 52002
877-242-0154
mandmsalesinc.com
Important Safety Information
Please read all instructions carefully before assembling this furniture.
For your safety, assembly by two or more adults is strongly recommended.
Use only vendor-supplied hardware to assemble this item. Using unauthorized
hardware could jeopardize the structural integrity of the item.
Hardware may loosen overtime. Periodically check that all connections are tight.
Before Assembly
Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
The shipping box provides an ideal work surface.
To avoid accidentally discarding small parts or hardware, do not dispose of any
packaging or contents of the shipping carton until assembly is complete.
Use the parts and hardware lists below to identify and separate each of the
pieces included.
The use of power tools for assembly is not recommended. Power tools can
damage the hardware. Note: Do not fully tighten all bolts until all parts are in
place. Failure to follow these instructions may cause the bolts to misalign during
assembly.
Care and Cleaning
Dust often and use a vacuum cleaner crevice tool to clean cushion. To maintain
the appearance, gently clean soiled areas with a soft cloth dampened with a
mild, water based detergent. Remove all lather and wipe with a clean damp
cloth. Dry with another soft cloth by blotting the damp surface (do not rub).
Do not place furniture in direct sunlight and keep furniture at least 60 cm / 2 ft
from heat sources to avoid fading.
WARNING: This product can expose you to chemicals including Antimony Trioxide, which is known to the State of California
to cause cancer, birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
SAFETY RATED: 125 LB

Components and Hardware
D
H
(A) Circular Base w/ 3 Molded Feet C
(B) Vertical Height Pole
(C) Curved Top Pole with Cap
(D) Hanging Pin 15mm x 80mm I
(E) Round Hex Nut & Bolt M8 x 42mm G E
(F) Lock Washers M8
(G) Set Screw M6 x 5mm B
(H) Carabiner M8 J
(I) Pod G
K
(J) Cushion F
(K) Bungee Cord w/ 2 Carabiners
(L) Hex Wrenches
(A)
Circular Base w/
3 Molded Feet
Qty: 1
(B)
Vertical Height Pole
Qty: 1
(C)
Curved Top Pole w/ Cap
Qty: 1
(D)
Hanging Pin
Qty: 1
(E)
Round Hex Nut & Bolt
Qty: 2
(F)
Lock Washer
Qty: 4
(G)
Set Screws
Qty: 2
(H)
Carabiner
Qty: 1
(I)
Pod
Qty: 1
(J)
Cushion
Qty: 1
(K)
Bungee Cord
Qty: 1
(L)
Hex Wrenchs
Qty: 3
Tools Needed for Assembly
(2) M8 and (1) M6 Hex
Wrenches Included
A
G
F

Steps 1-5 Build Stand
1.) Place A (Circular Base) on a level surface with the non-skid feet
resting on the floor surface.
2.) Connect B (Vertical Height Pole) to A (Circular Base) using one
E (Round Hex Nut & Bolt) and two F (Lock Washers). Tighten
hardware.
3.) Insert C (Curved Top Section) of stand to B (Vertical Height
Pole) using the remaining E (Round Hex Nut & Bolt) and two F
(Lock Washers). Tighten hardware.
4.) Drop D (Hanging Pin) through the end of C (Curved Top
Section). The cap of the pin should be on top.
5.) Insert one end of (H) Carabiner through the hole punched in the
lower end of D (Hanging Pin).
Steps 6-7 Connect Stand and Swoon Pod:
6.) Slide the circular hanger at the top of the pod frame to the open
end of the H (Carabiner). Make sure Pod opening for
entering/exiting seating is facing outward away from the stand.
7.) Place J (Cushion) in Cozy Hanging Pod.
Steps 8-10 Attach Motion Resistant Bungee Strap
8. Connect one Carabiner on K (Bungee Cord) to the horizontal rib
running around the frame of the Pod.
9.) Bring K (Bungee Cord) around B (Vertical Height Pole) and
return the other end to the same horizontal rib of Pod to secure
other Carabiner. Confirm both Carabiners on K (Bungee Cord) are
closed.
10.) Lastly, tighten both G (Set Screws) with the smaller M6 (L)
(Hex Wrench).
