INSTALLATION INSTRUCTION
Product WIBAT
VERSION EN 3-09 ANG
2, rue des Métiers
21110 - Genlis
Tél. : [phone]
Fax : [phone]
http://www.mantion-smt.fr

2
WARNING: important safety instructions.
These instructions must be followed in the interest of personal safety; Keep
these instructions.
WIBAT is exclusively designed for opening and closing swing shutters. It must not be used for any
purpose other than that specified in these instructions. The manufacturer or supplier shall not be liable
for any damage resulting from improper use thereof. The user alone shall be solely liable and assume
any risks arising from improper use of the product.
This shutter motor must be installed by persons fully aware of the hazards involved in currents,
drilling and chemical sealing who have the requisite qualifications to work on domestic installations
in accordance with good practice.
Follow all the instructions because faulty installation can cause injury.
The assembly steps must be followed, as must the operating instructions, and safety rules must
always be heeded.
Before installing the shutter motor, check that both the driven part and the entire WIBAT are in good
physical condition and that the structure has the necessary load-bearing capacity for the WIBAT in its
entirety.
The electrical installation must be done according to prevailing national standards and in accordance
with all legal obligations and/or prevailing obligations to that effect.
(Electrical compatibility: voltage and frequency as marked on the product and that of the power
network where it will be used.) Do not connect the device without first checking that the control
circuit is dead.
Check the installation frequently to detect any imbalances or signs of wear or damage. Do not use
the device if it needs repairing or adjusting.
Disconnect the power supply when cleaning it or carrying out other maintenance or servicing
tasks.
Never modify or fit any additional parts to the device that may compromise safety without MANTION
SMT's written permission.
Be very careful not to get your fingers caught when using the device.
The user alone is solely and entirely responsible for any breach of these safety rules, and any
damage resulting therefrom.
The product must be stored indoors in a dry place at a temperature of between 0°C and +45°C.
When fitting it, the installation engineer must heed accident prevention instructions and the
standards in force in the country.
Do not immerse the gear motor in water or splash it.
Do not dispose of it in fire or bring it into contact with flame or any heat source.
Do not use household products or chemicals to clean it. Only use a moist sponge and soap.
Do not dispose of the packaging in the environment; treat waste according to the standards in
force in the country.
Keep products, devices and documentation out of reach of children.
Do not let children play with the fixed control devices. Keep remote controls out of reach of
children.
When using a switch without a lock, make sure everyone else is kept at a distance.
Use only the MANTION SMT-approved embedding kit and drilling equipment.

3
The manufacturer or supplier shall not be liable for any damage resulting from the use of other
products. If replacing the product, only use MANTION SMT or MANTION SMT-approved products.
Radio control:
Use of the wireless remote control is only authorized if any disturbance in the transmitter or
receiver poses no danger to people or animals, or if such hazards are removed by other
arrangements.
The user of the wireless control is not protected against interference generated by other
telecommunications installations and remote-controlled devices. If there is a high level of
interference, contact the organization in charge of measuring wireless interference (radiolocation).
Do not use the radio transmitter in places sensitive to radio transmissions (airports, hospitals) or
only after taking all the necessary precautions.
The swing shutter remote control may pose risks and for this reason please heed the following
points when using it:
1. Make sure no object or person is within range of the swinging shutters.
2. Only operate them when direct visual inspection is possible.
The wireless control is not a toy; do not let children play with it. Keep it out of reach of children and
animals.
Terms of the guarantee
MANTION SMT products come with a 5 (five) years guarantee from the date of delivery.
The guarantee is limited, as decided by MANTION SMT, either to replacement or to repair of
products MANTION SMT recognizes as faulty, with the proviso that:
1. Subject to MANTION SMT's written permission to return the products, the said products are
returned to MANTION SMT forthwith with the details of the fault and a copy of the
installation engineer or dealer's bill stating the date of installation.
2. The products have been stored, installed, maintained and used in accordance with
MANTION SMT's instructions and specifications.
The guarantee is strictly limited to the provisions of this clause, and any other guarantee or
liability, including loss of profits or damage directly or indirectly resulting from the sale or use of the
products, is excluded.
MANTION SMT shall on no account be liable for drilling and embedding conditions.
MANTION SMT shall in any event only be liable for the WIBAT product. The guarantee does not
apply in case of overvoltage or short-circuiting resulting for instance from connection errors,
weather conditions such as lightning etc. The guarantee does not cover normal wear.

4
TECHNICAL CHARACTERISTICS
The WIBAT enables the automated opening and shutting of the flap shutters (one or two leaves).
It is designed for domestic use.
1 Leaf
2 Leaves
Minimal breadth
0.30 m*
0.60 m *
Maximum breadth
0.8 m*
1.6 m*
Maximum area
1.6 m²*
3.2 m²*
Maximum weight per leaf
50 Kg
Minimal distance for strap
hinge/shutter
30 mm
Typical movement finish
Dynamic (stopping when hindered)
Voltage/current
24 V DC ± 10%
Power/ Current
100 W
Motor torque
25 Nm
Shutter rotation speed
1.9 rpm
Opening or closing time limit
18 s
Temperature to be used at
-30/+70 degrees C
Colour
Black (other colours on request)
NB : All of the data in the table is by way of indication, depending on specific conditions (wind,
state of hinges) and does not constitute a firm commitment by MANTION SMT
* For all other sizes contact MANTION SMT.
We recommend you do not operate the WIBAT with very strong winds; this could damage the shutters and
the device
Associated with this product, we recommend using steel or stainless steel hinges thickness 5mm mini
THE ABSOLUTELY ESSENTIAL
MINIMAL DISTANCE BETWEEN THE
FLAN OF THE SHUTTERS AND THE
HINGE AXIS IS 30 mm
MIN

5
ASSEMBLY INFORMATION
LIST OF MATERIALS FOR INSTALLATION:
CONTENT OF THE KIT for double motorisation:
1 Rotary Comb hammer Drill
1 Diamond core bit  to 68mm 
1 Steel drill bit mm
Metric hexagonal keys 2 and 4
Flexible electrical wires 2 x 1.5 mm 2and 3 x 0.75
mm 2
1 Electrical box 60 mm depth (hard wired version)
1 concrete drill bit length according to wall
thickness
1 Dispenser for chemical sealing
1 Sealing kit (with mesh sleeves)
Motor 1
Motor 2
Control box
Switch
Drilling gauges
2 seal mounting rings
4 flanges fixing screws
2 flanges
2 gaskets
4 Spade crimp terminals
4 Shutter fixing screws (still in place)
Or
2 manchons
Remote control
1
2
3
4
7
12
6’
6
8
9
11
10
13

6
1 –CHECKING BEFORE INSTALLATION
A. SPACE OCCUPIED
If you do not have the recommended distance of 30 mm between the shutter flan and the hinge
axis, it will be necessary to change the position of all of the shutter strap hinges, and remove the
existing hinges before proceeding to the installation of the WIBAT.
When the hinges have been removed it is necessary to re-block the holes left.
B. CHOICE OF HINGES TO MECHANISE
It is recommended to align stoppers with motorization
For shutters fitted with two strap hinges per leaf, MANTION SMT recommended to mechanised
the bottom hinge. For shutters with three strap hinges, it is recommended that the hinge in the
middle is mechanised.
Shutter
stopper
Shutter
stopper
Removes this pair of hinge
MIN

7
C.Verify la the presence of high and low shutter stoppers
The presence of high and low shutter stoppers is essential for the proper functioning of the
product.
2 –DRILLING OF THE STRAP HINGES
a- Disassemble the shutters and mark the drilling site 20 mm from the edge of the strap hinge.
b- Drill the strap hinges with a 6.5 mm drill bit right through and very perpendicular to the
shutter
The drilling can be done in parallel or perpendicular to the shutter.
High and low stoppers
Shutter
bottom
Perpendicular drilling
U
Parallel drilling
Or
U
hinge
drill
Ǿ 14 à 18
Ǿ 6,5
Ǿ 12
Ǿ 5,5

8
3 –MARKING FOR DRILLING
To ensure that the system operates smoothly, position and lock the shutters in the closed
position and ensure that the hinge axis are vertical.
Install and wedge the shutters in a closed position. Put the drilling gauge (3) on the strap hinge of
the shutter and draw in the area to be drilled with a pencil.
4 –DRILLING OF THE WALL
A. Remove the shutters.
Use the rotary comb hammer on drilling only position. Do not use it on Hammer position.
Fixe the diamond core bit and the hole –starting aids.
B. Drill the 2 holes to a depth of 150 mm always vertically and horizontally perpendicular to the
wall.
For drilling, follow the safety instructions recommended by the manufacturer of the drill.
Marking
3
3

9
C. Drill the 16 mm diameter holes for sheathing
Clean tidily the holes with a vacuum cleaner and a metallic brush. The chemical seal
doesn’t adhere on dust
5 –SETTING UP OF THE MECHANISED HINGE
A- Unscrew the two mounting screws (13). Take the motor from the fitting box guard.
13

10
B- Provide a sheath for the electrical connection. Prepare for the wire to be 200 mm long on
the other side of the wall.
Fit the mesh sleeve furnished with the sealing WIBAT and the fitting box guard in the hole.
Make penetrate the sheath in the box guard.
In case the wall is porous and to avoid water seepage through the back of the product,
MANTION SMT recommended to silicone seal in the cable hole at the bottom of the box guard.
C- Pass wires through the joint (9).
Connect wire according to the wiring diagram and reassemble the case.

11
D. Turn the motor several times to twist the wires and get up again to the case.
E. SHUTTERS INSTALLATION
Position the rings (4) on the 2 hinges and readjust the shutters in place.
Fix the hinges motorized on the strap hinges.
4
4

12
6 –SEALING
Pay attention to the correct vertical alignment of the hinges.

13
Use the nozzle with its extension diameter 6 mm.
Inject chemical sealing Approve by MANTION SMT in the cells of the engine while starting with 2
blows of trigger at the bottom of the mesh sleeve then distribute 3 other blows while returning
towards the wall. Make this operation in the 4 holes envisaged to this end.
5- Add the chemical seal around the fitting box in order to fill the cavity around the perimeter.
Clean the surpluses of sealing with a wet sponge.
Respect the time of catch according to the data of the manufacturer before any handling.
4
1
3
2
5

14
Mount the mask of protection (8) with the 2 screws (13).
In order to avoid water infiltration into the product, MANTION SMT recommends placing silicone
seal around the periphery of the protective flange (8).
7 –ASSEMBLY OF THE SHUTTER ON THE MECHANISED HINGES
a- Dismount the shutters.
b- Withdraw the ring (4).
c- Mount back the shutters.
d- Apply threadlocker on the 2 M4 screws (11)
a- Fix the shutters on the hinges by the sleeve (10) and 2 screws M4 (11) on each hinge.
8
13
8
10
11
11
4

15
8 –SETTING UP OF THE CONTROL CASING
1) Hard-wired kit:
For the hard-wired kit attach a 60 mm deep flush fitting box to the inside of the house and connect
the wires as shown in the cabling diagram.
2) Radio:
The casing can be installed at your liking, in the false ceiling, the wall lining, a flush fitting
box etc. …
7
6’

16
ELECTRICAL CONNECTION
ELECTRICAL CONNECTION RADIO VERSION
Radio switch
Feed not
supplied
Motor 1 Motor 2
Antenna
Pay attention to your safety:
- The electrical installation must be carried out in accordance with the national standards in
force, as well as any obligations foreseen by the law and/or by all obligations in force, laid
down for this purpose.
- Electrical connection must take place without voltage: Do not connect the sector before
having disconnected all assembly operations.
- Do not use any switches other than those supplied in the kit (4)
- If the cables from the control casing are damaged, contact our after-sale department.
- The 220V-24V feed used must comply with standards in force

17
ELECTRICAL CONNECTION HARD WIRED VERSION
Wires for
switch
Feed not
supplied
Motor 1 Motor 2
230 V
24 VDC
2 x 1.5
2 x 0.75
Identification of motor 1.
Motor 1 mechanises the covered flap.

18
Connection of motors
Be careful to the polarity of the engines Following model
If your WIBAT is intended for the mechanisation of a single flap shutter, it is absolutely essential to
connect it on motor 1
12
White Point = polarity +

19
Feed connection
Alimentation 24 V DC ± 10 %
24 V
230 V
Connecting the power supply should meet the recommendations of the manufacturer
thereof.
Feed not supplied
Feed 24 V DC ± 10%

20
Push button connection Wired version
To access the push button to connect the wires of the switch, remove the two front buttons => pull
down the button:
Pressing one of the buttons and at the same time insert the wire into one of the two cavities
located below the button. Releasing the button, the wire is then clamped in the cavity. Check by
gently pulling on it. Reiterate handling for each of the three wires.
Radio switch connection
Screw or stick the radio switch to the place of your choice at least 20 m from the control casing.
White wire 0.5 mm ²
common
Black wire 0.5 mm ²
opening
Grey wire 0.5 mm ²
closing
realized a bridge
with 0.5mm² wire
mini
