Mantis Swift Split Original instruction manual

© 2006 Mantis, Div. of Schiller-Pfeiffer Inc. All Rights Reserved.
Owners Manual and Safety Instructions
Log Splitter Manual

3
4. Remove and open box that is packaged between the log splitter cart and the vertical beam.
5. Remove pivoting support from the box. Also remove wheels and hardware bag.
9
14
11
8
3
28
29
30
111
31
7
KNOB
CABLE TIE 152MM (6") LONG
2510501
2
1
1
2
2
510146
510543
510144
510524
WHEEL SHAFT
M14 WHEEL NUT
ALLEN WRENCH 6MM
ALLEN WRENCH 8MM (DRAIN PLUG)
2
2
4
2
2
510508
510509
510503
510104
510507
BOLT HEX M6 x 30mm
CONNECTING LINK
NUT LOCK M6, NYLON INSERT
WASHER FLAT ÿ6
BOLT HEX M6 x 40mm
22510500 M10 CARRIAGE BOLT,SQUARE NECK, 60mm LONG
510147
ITEM NO. QTY DESCRIPTION
PART NO.

18
O. Exploded View
LOG SPLITTER EXPLODED VIEW
37
34
36
39
40
35
38
REV F, 12-20-05

19
O. Parts List
ITEM PART #. DESCRIPTION / REMARKS QTY
1 510100 CART BOTTOM WELDED ASSEMBLY 1
2 510500 M10, CARRIAGE BOLT, SQ NECK, 60MM LG 2
3 510501 KNOB 2
4 510101 WHEEL 10 IN DIA 2
5 510102 HANDLE UPPER ASSEMBLY 1
6 510103 STABILIZING BAR/PIVOTING SUPPORT 1
7 510104 CONNECTING LINK 2
8 510509 BOLT HEX M6 X 40MM 2
9 510507 NUT LOCK M6, NYLON INSERT 6
10 510109 SOLENOID PROTECTION BRACE 1
11 510508 WASHER #6 4
12 510502 BOLT HEX M6 X15MM 2
13 510105 END CAP 2
14 510503 BOLT HEX M6 X 30MM 2
15 510106 PROTECTIVE BRACE 1
16 510504 WASHER 6MM DIA 4
17 510505 SCREW M6 X 35MM 2
18 510510 NUT M6 2
19 510107 SWITCH BOX ASSEMBLY 2
20 510506 NUT M16 (THIN) 2
21 510900 MOTOR ASSEMBLY 110V 1
22 510108 HYDRAULIC ASSEMBLY 1
23 510601 WARNING LABEL 1
24 510110 DIP STICK 1
25 510111 DIP STICK SEAL 1
26 510510 AIR BLEED SCREW 1
27 510512 DRAIN PLUG SEAL 1
28 510144 WHEEL SHAFT 2
29 510524 M14 WHEEL NUT 2
30 510512 ALLEN WRENCH 6MM (DIP STICK) 1
31 510147 CABLE TIE 152MM (6") LONG 1
32 510600 SWIFT SPLIT LOGO LABEL 2
33 510148 SWITCH PROTECTIVE COVER 2
SWITCH BOX ASSEMBLY
34 510149 SWITCH BOX 2
35 510150 SWITCH BOX COVER 2
36 510151 SWITCH 2
37 510152 STRAIN RELIEF (SWITCH BOX) 2
38 510526 SCREW M4 X 25 LONG 8
39 510527 FLAT WASHER #4 8
40 510528 NUT M4 8
HYDRAULIC ASSEMBLY
41 510153 BLEED SCREW SEAL 1
42 510154 UPPER COVER PLATE 1
43 510155 WIPER SEAL(UPPER COVER PLATE) 1
44 510156 O-RING, 30MM DIA, UPPER COVER PLATE 1
45 510157 PISTON'S REM WITH WELDED PULL BRACKET 1
46 510158 PISTON BODY 1
47 510159 O-RING 25MM DIA, PISTON 1
48 510160 SEAL (SQ SECTION) 25MM DIA 1
49 510161 RETURN SPRING 1
50 510529 NUT M14 2
51 510530 NUT M14 4
52 510162 THREADED RODS 4
53 510163 CYLINDER 1
54 510164 OIL RESERVOIR WITH WELDED WEDGE 1
55 510531 BOLT M8 X 12 LONG 4
56 510165 LOG GUIDE 2
ITEM PART #. DESCRIPTION / REMARKS QTY
57 510166 THRUST PAD 2
58 510167 PRESSURE PLATE 1
59 510168 BOTTOM COVER PLATE 1
60 510169 O-RING 55MM DIA, BOTTOM COVER 1
61 510170 DRAIN PLUG, M10X8MM THREAD 1
62 510532 LOCK NUT M10 NYLON INSERT 4
63 510533 EXTERNAL STAR WASHER #10 4
64 510534 PLUG WITH M14X1.5 THREAD, PRESSURE
RELIEF VALVE 1
65 510535 PLUG WITH M20X1.5 THREAD, SOLENOID 1
66 510171 OIL PUMP COVER 1
67 510172 GEAR 2
68 510173 KEY (TO HOLD GEAR TO THE MOTOR SHAFT) 1
69 510174 O-RING 10.6MM DIA, OIL SEAL 2
70 510175 GEAR SHAFT 1
71 510176 BALL 1
72 510177 WIRE SNAP RING 2
73 510178 OIL PUMP SLEEVE 2
74 510179 OIL PUMP PIN 8MM DIA, 25MM HIGH 2
75 510180 GEAR PLATE 1
76 510181 O-RING SEAL 45MM DIA 2
77 510536 BOLT M8X28MM HIGH 3
78 510537 SPRING LOCK WASHER#8 9
79 510538 FLAT WASHER #8 9
80 510539 BOLT M8X55 MM LONG 6
81 510182 RETURN SPRING (SOLENOID) 1
82 510183 SPOOL VALVE (SOLENOID) 1
83 510184 SPOOL VALVE HOUSING (SOLENOID) 1
84 510185 SOLENOID COIL 1
85 510186 SOLENOID CAP 1
86 510187 STRAIN RELIEF (SOLENOID) 1
87 510188 AC TO DC CONVERTER WITH LED INDICATOR 1
88 510189 RELIEF POPPET (PRESSURE RELIEF VALVE) 1
89 510190 RELIEF SPRING (PRESSURE RELIEF VALVE) 1
90 510191 PORT PLUG WITH TWO O-RINGS 1
91 510192 O-RING (PRESSURE RELIEF VALVE) 2
92 510193 PORT PLUG HOUSING (PRESSURE RELIEF VALVE) 1
93 510194 PRESSURE RELIEF VALVE ADJUSTMENT 1
94 510195 THREADED PIN (PRESSURE RELIEF VALVE) 1
95 510540 M6 NUT ((PRESSURE RELIEF VALVE) 1
96 510196 COVER (PRESSURE RELIEF VALVE) 1
MOTOR ASSEMBLY
97 510197 MOTOR 1
98 510198 WIRE CLAMP 1
99 510199 15 AMP CIRCUIT BREAKER 1
100 510541 C/B NUT 1
101 510200 CORD STRAIN RELIEF 1
102 510201 CORD (OUTDOOR USE) 1
103 510202 STRAIN RELIEF 1
104 510203 RUBBER COVER 2
105 510204 CAPACITOR 300VAC 1
106 510205 CAPACITOR 125VAC 1
107 510206 GASKET (MOTOR JUNCTION BOX) 1
108 510207 MOTOR JUNCTION BOX 1
109 510208 LID 1
110 510542 SCREW M4X10MM SELF TAPPING 8
111 510543 ALLEN WRENCH #8 (DRAIN PLUG) 1
