March Networks X Series User manual

March Networks
X-Series All IP Recorder
Models X32, X48, and X64
Installation Guide

Copyright © 2023. March Networks Corporation. All rights reserved.
Information in this document is subject to change without notice. MARCH NETWORKS,
March Networks Command, March Networks Searchlight, March Networks RideSafe, and
the MARCH NETWORKS logo are trademarks of March Networks Corporation. All other
trademarks are the property of their respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries.
North America.....................................1 800 563 5564
Latin America.......................................+52 55 5259 9511
Europe..................................................+39 0362 17935
Asia.......................................................+65 6818 0963
Australia and New Zealand.................+61 1300 089 419
Middle East and Africa........................+971 04 399 5525
www.marchnetworks.com
Notice of Rights
The software described in this document is furnished under a license agreement or
nondisclosure agreement. The software may be used or copied only in accordance with
the terms of those agreements. The contents of this manual and accompanying software
are protected by copyright. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means, electronic, mechanical,
recording, or otherwise without the prior written permission of March Networks
Corporation.
Part Number
41225 Rev 1.1, June 2023

X-Series All IP Recorder Installation Guide 3
Contents
Chapter 1: Mandatory Regulations......................................................... 5
Regulatory Compliance Statements ..................................................................................................... 5
United States - Federal Communications Commission ................................................................ 5
Europe............................................................................................................................................. 5
Environmental Directive Compliance................................................................................................. 6
Battery Notices....................................................................................................................................... 6
NiCd Battery Pack Notice .............................................................................................................. 6
Lithium Battery Notice ................................................................................................................... 6
Avis pour les batteries ........................................................................................................................... 6
Avis sur le bloc de batterie NiCd ................................................................................................... 6
Avis sur la batterie Lithium ............................................................................................................ 7
Safety Notice .......................................................................................................................................... 7
Avis de sécurité ...................................................................................................................................... 7
Rack Mounting Safety Precautions ....................................................................................................... 8
Précautions de sécurité pour une installation dans un rack ............................................................... 8
Anti-Static Precautions .......................................................................................................................... 9
Servicing Notice ..................................................................................................................................... 9
Shipping Notice ...................................................................................................................................... 9
Regulatory Model Definition Information ............................................................................................ 9
Chapter 2: Feature Overview................................................................ 10
Key Features ......................................................................................................................................... 11
Packaging/Shipment Contents ........................................................................................................... 12
Additional Optional Items ............................................................................................................ 12
Specifications ....................................................................................................................................... 13
Dimensions ....................................................................................................................................... 13
Weight ............................................................................................................................................... 13
Operating and Storage Temperature ...............................................................................................13
Power Ratings ................................................................................................................................... 14
Video Capture Rates ............................................................................................................................ 14
Front Panel LEDs .................................................................................................................................. 15
Hard Drive Caddy LEDs.................................................................................................................... 16

X-Series All IP Recorder Installation Guide 4
Contents
USB Ports ...............................................................................................................................................17
Front USB...........................................................................................................................................17
Back USB ...........................................................................................................................................17
Ethernet Ports .......................................................................................................................................18
Three Ethernet Ports and LEDs ........................................................................................................18
HD Video Monitor Output.....................................................................................................................19
Power Connections for Redundant Power Supply .............................................................................20
Power Supply Module LEDs..................................................................................................................21
Hard Drives ............................................................................................................................................22
Hard Drive Error LED Status ............................................................................................................23
Hard Drive Array - Important Considerations.....................................................................................23
NiCd Battery Pack and Lithium Battery ..............................................................................................24
NiCd Battery Pack .............................................................................................................................24
Lithium Battery..................................................................................................................................24
Chapter 3: Unit Setup............................................................................ 25
Mounting the Recorder.........................................................................................................................26
Removing or Replacing Hard Drives....................................................................................................27
Installation Requirements .............................................................................................................27
Replacing a Redundant Power Supply Module...................................................................................29
Replacing a Redundant Power Supply Module................................................................................29
Turning the Recorder On and Off ........................................................................................................30

X-Series All IP Recorder Installation Guide 5
Chapter 1
Mandatory Regulations
You must be familiar with the following mandatory regulations governing the product’s operations.
You should also adhere to these instructions to ensure the installation meets regulatory
compliance.
Regulatory Compliance Statements
Canada - Industry Canada
This Class A digital apparatus complies with Canadian ICES-003.
CAN ICES-3 (A)/NMB-3(A)
United States - Federal Communications Commission
Supplier’s Declaration of Conformity
Product Name: IP NDVR
Product Model: NDVR HP
Company Name: March Networks Inc.
The Pinnacle Building
3455 Peachtree Road North East, Suite 500
Atlanta, Georgia 30326
1 800 563 5564
1 This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed and used in
accordance with the installation guide, is liable to cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case users will be required to correct the interference at their own
expense. Modifications not expressly approved by the manufacturer could void the user's
authority to operated the equipment under FCC rules.
2 This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Europe
This equipment complies with the following EU directives: 2014/30/EU, 2014/35/EU, 2011/65/EU,
and (EU) 2015/863. A Declaration of Conformity is available upon request.

X-Series All IP Recorder Installation Guide 6
Mandatory Regulations
Environmental Directive Compliance
March Networks is committed to doing our part to protect the environment. March Networks is
compliant with current RoHS and WEEE directives:
• RoHS 2 (2011/65/EU) with RoHS 3 (EU) 2015/863
• WEEE recast (directive 2012/19/EU) and its amendments
Further details on corporate environmental policies and on RoHS and WEEE compliance are
available from March Networks customer support.
Battery Notices
CAUTION: There is risk of explosion if any battery is replaced with another battery of the incorrect
type. Ensure that you only use the NiCd battery pack and lithium battery provided by March Networks.
NiCd Battery Pack Notice
The unit contains an internal NiCd battery pack that is used during power shortages. The NiCd
battery pack may explode, leak, or get hot, causing personal injury if the following precautions are
not followed:
• Do not remove the NiCd battery pack and use it in a device other than the recorder.
• The unit has a built-in battery charger. Do not attempt to charge the NiCd battery pack using a
different battery charger.
• Replace only with a March Networks NiCd battery pack.
• Do not disassemble the NiCd battery pack.
• Do not open or try to open the individual NiCd battery pack cells.
• Do not dispose of the NiCd battery pack in fire.
• Do not short circuit the NiCd battery pack terminals.
Dispose of the NiCd battery pack in accordance with all applicable federal, state, provincial, and
local regulations. Inquire with your local recycling office for recycling guidelines.
Lithium Battery Notice
The unit contains an internal lithium battery that powers the clock and other system operations.
Ensure you consider the lithium battery when disposing of the unit. Dispose of the lithium battery in
accordance with all applicable federal, state, provincial, and local regulations. Inquire with your
recycling office for recycling guidelines.
Avis pour les batteries
ATTENTION: Il y a un risque d’explosion si une batterie est remplacée par un autre type de batterie.
Assurez-vous d’utiliser le bloc de batterie NiCd et la batterie Lithium de March Networks.
Avis sur le bloc de batterie NiCd
L’unité contient un bloc de batterie interne qui est utilisé lors de pannes de courant. Le bloc de
batterie NiCd peut exploser, couler ou devenir chaud, pouvant causer des blessures si les
précautions suivantes ne sont pas respectées :
• Ne pas enlever le bloc de batterie NiCd et/ou l’utiliser à d’autres fins.
• L’unité a un chargeur de batterie intégré. N’utiliser pas un autre chargeur pour charger le bloc
de batterie.

X-Series All IP Recorder Installation Guide 7
Mandatory Regulations
• Remplacer seulement avec les blocs de batterie de marque March Networks.
• Ne pas modifier le bloc de batterie NiCd.
• Ne pas ouvrir ou tenter d’ouvrir la batterie individuelle NiCd
• Ne pas jeter le bloc de batterie dans le feu.
• Ne pas court-circuiter les terminaux du bloc de batterie NiCd.
Disposer du bloc de batterie NiCd en accord avec les lois locales, provinciales ou fédérales.
Renseignez-vous à votre bureau de recyclage local pour les règles de recyclage.
Avis sur la batterie Lithium
L’unité contient une batterie Lithium interne qui procure du pouvoir à l’horloge interne de l’unité et
au système d’opération.
Assurez-vous de considérer la batterie Lithium lorsque vous disposer de l’unité. Disposez de la
batterie Lithium en accord avec les lois locales, provinciales ou fédérales. Renseignez-vous à votre
bureau de recyclage local pour les règles de recyclage.
Safety Notice
Before you access any components located inside the unit, power down the unit using
the power On/Off pinhole (for location, see “Hard Drives” on page 22). After the status
LEDs turn off, to prevent injury, disconnect the unit from the power source by removing
both power cords from the unit.
Only qualified service personnel should access the inside of the unit.
An AC power cord is provided with a grounded attachment plug. To avoid electrical shock, always
use the AC power cord and plug with a properly grounded outlet (connected to earth).
To maintain safety compliance, ensure the AC power cord has the appropriate safety approvals for
the country in which the equipment is to be installed. For North America, the AC power cord must
be a UL listed SJT NEMA 5-15 equivalent or better.
IP cameras and networks that are directly connected to the recorder must be located indoors only
(intra-building). Connect the recorder only to PoE networks without routing to the outside plant.
If you carry or move the recorder unit using the handles on the front panel, always use both
handles. Do not attempt to carry or move the unit using only one of the handles.
Do not insert any foreign objects into the fan, vents, ports, or other opening in the unit.
Avis de sécurité
Avant d’accéder aux composantes internes de l’unité, mettez l'unité hors tension à l'aide
du trou d'épingle Marche / Arrêt (pour l'emplacement, voir « Hard Drives » à la
page 22 ). Une fois les voyants d'état éteints, pour éviter les blessures, débranchez
l'appareil de la source d'alimentation en retirant les deux cordons d'alimentation de l'unité.
Caution: risk of electrical shock
Attention: risque d’ é lectrocution

X-Series All IP Recorder Installation Guide 8
Mandatory Regulations
Seulement le personnel de service qualifié a le droit d’accéder l’intérieur de l’unité.
Le câble de pouvoir AC est fournie avec un câble de mise à terre. Pour éviter tout choc, utilisez
toujours le câble de pouvoir AC relié avec la prise de courant adéquate (contenant une mise à terre).
Pour maintenir votre conformité de sécurité, assurez-vous que le câble de pouvoir AC a obtenu les
approbations de sécurité applicables pour le pays ou l’installation est faites. Pour l’Amérique du
Nord, le câble de pouvoir AC doit avoir une certification UL SJT NEMA 5-15, équivalente ou meilleur.
Les caméras IP et les réseaux connectés directement à l'enregistreur doivent être situés à l'intérieur
uniquement (intra-bâtiment). Branchez l'enregistreur uniquement aux réseaux PoE sans
acheminement vers l'installation extérieure.
Si vous transportez ou déplacez l'enregistreur à l'aide des poignées du panneau avant, utilisez
toujours les deux poignées. N'essayez pas de transporter ou de déplacer l'unité en utilisant
seulement une des poignées.
N’insérez pas d’objets étrangers dans le ventilateur, les évents, les ports ou toute autre ouverture
dans l’unité.
Rack Mounting Safety Precautions
You must observe the following installation precautions when mounting the recorder in a rack.
• Ambient temperature: When installing the recorder in a closed rack or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than ambient
temperature of the room. Airspace or airflow around the recorder unit must provide ambient air
of less than 104° Fahrenheit (40° Celsius) when measured above and below the unit.
• Air flow: Installation of the recorder in a rack must allow sufficient air flow for safe operation.
• Mechanical loading: Installation of the recorder in a rack must ensure that a hazardous
condition does not occur because of uneven mechanical loading.
• Circuit overloading: When connecting the recorder to the power supply circuit, ensure that you
do not overload the circuit. Consider the effects of circuit overload on overcurrent protection
and supply wiring. Use equipment nameplate ratings to verify the requirements.
• Reliable earthing: You must maintain reliable earthing of any rack-mounted equipment. Pay
particular attention to connections other than direct connections to the branch circuit (for
example, the use of power bars).
Précautions de sécurité pour une installation
dans un rack
Vous devez respecter les précautions d'installation suivantes lors du montage de l'enregistreur
dans un rack.
• Température ambiante: Lors de l'installation de l'enregistreur dans un rack fermé ou dans un
rack comprenant plusieurs étages, la température ambiante de fonctionnement de
l'environnement du rack peut être supérieure à la température ambiante de la pièce. L'espace
aérien ou le flux d'air autour de l'enregistreur doit fournir un air ambiant inférieur à 40 ° C (104
° F) lorsqu'il est mesuré au-dessus et au-dessous de l'unité.
• Flux d'air: L'installation de l'enregistreur dans un rack doit permettre un débit d'air suffisant
pour un fonctionnement sûr.
• Chargement mécanique: L'installation de l'enregistreur doit garantir qu'aucune condition
dangereuse ne se produise en raison d'une charge mécanique inégale.
• Surcharge du circuit: Lorsque vous connectez l'enregistreur au circuit d'alimentation, veillez à
ne pas surcharger le circuit. Tenez compte des effets de la surcharge du circuit sur la protection

X-Series All IP Recorder Installation Guide 9
Mandatory Regulations
contre les surintensités et le câblage d'alimentation. Utilisez les spécifications indiquées sur
l’enseigne du manufacturier de l'équipement pour vérifier les exigences.
• Mise à la terre fiable: Vous devez maintenir une mise à la terre fiable de tout équipement monté
en rack. Portez une attention particulière aux connexions autres que les connexions directes au
circuit d’alimentation (par exemple, l'utilisation de barres d'alimentation).
Anti-Static Precautions
Ensure proper use of an anti-static guard during installation to avoid damage to the unit from
electrostatic discharge.
Servicing Notice
The procedures contained in this publication outline how to install or service components located
inside the unit, requiring the removal of the cover. Installation and maintenance procedures
requiring internal unit access are to be performed by qualified service personnel only.
Shipping Notice
Shipment of the unit and components may expose the unit to temperature extremes. We
recommend you allow the unit to return to room temperature prior to operation.
Regulatory Model Definition Information
Certification regulatory model names for the X-Series All IP recorder are defined in the following table.
Recorder Certification Regulatory Model Name
• X64 All IP recorder
• X48 All IP recorder
• X32 All IP recorder
NDVR HP

X-Series All IP Recorder Installation Guide 10
Chapter 2
Feature Overview
The 32, 48, or 64 channel X-Series All IP Recorders are scalable recording platforms that support
high-resolution IP cameras. The models included are the X32, X48, and the X64.
The X-Series All IP Recorder offers outstanding video compression and storage, and can be
managed using the March Networks Command video management platform.
Note: If you want to use an X-Series All IP Recorder in a managed environment, you must use the
Command Enterprise Software (the R5 ESM is not supported). To configure the recorder, the
Command Config software is required. For more information, see the Command Enterprise
Installation Guide, the Command Enterprise and Client User Guide, and the X-Series All IP Recorder
Configuration Guide, available from the March Networks Partner Portal website.
This section of the installation guide contains the following information:
• “Key Features” on page 11
• “Packaging/Shipment Contents” on page 12
• “Specifications” on page 13
• “Video Capture Rates” on page 14
• “Front Panel LEDs” on page 15
• “USB Ports” on page 17
• “Ethernet Ports” on page 18
• “HD Video Monitor Output” on page 19
• “Power Connections for Redundant Power Supply” on page 20
• “Power Supply Module LEDs” on page 21
• “Hard Drives” on page 22
• “Hard Drive Array - Important Considerations” on page 23
• “NiCd Battery Pack and Lithium Battery” on page 24

X-Series All IP Recorder Installation Guide 11
Feature Overview
Key Features
The X-Series All IP Recorder comes in three different models, the X32, X48, and X64. All models
contain up to 8 hard drives and a 2U height. The following table shows the key differences between
the different models.
Some of the key features and benefits of the X-Series All IP Recorder include:
• Video compression for IP cameras — H.265, H.264, MPEG4, MPEG, MJPEG
• High-capacity internal storage — up to 8 SATA hard drives
• You can use the Command Config software application to create a RAID 1 or RAID 5 array (for
details, see the X-Series All IP Recorder Configuration Guide). RAID 5 includes an optional spare
disk. The recorder does not include RAID until you add it using the Command Config software.
• Redundant power supply: Contains two power supply modules. Each power supply module is
capable of powering the entire recorder if one of them fails. This minimizes chance of a
complete shutdown.
• High temperature shutdown: the recorder shuts down if it gets too hot, and restarts when the
temperature drops to a safe level.
• Internal back-up battery for power brown-out protection
• Advanced networking features for unlimited scalability and dependable remote access
• Advanced health management features for centralized support and maximum up-time
• Analytics facilitated via analytics-enabled cameras
• Front panel QR code containing recorder information such as model number and serial number
Feature X32 X48 X64
Total IP Inputs
32 48 64
IP Performance
(aggregate)
200 Mbps 300 Mbps 400 Mbps
Hard Drives
Up to 8 hard disk drives
Mounting Rack mount: 2U high, 19"
2 post rack ONLY supported with shelf kit
4 post rack (rails included)

X-Series All IP Recorder Installation Guide 12
Feature Overview
Packaging/Shipment Contents
The following items are included in each system shipment, and should be located/verified before
installation begins:
• X-Series All IP recorder
• AC power cord
• Hard drive caddy keys
• 4-post rack rail kit
• Instructions for downloading software and technical publications from the March Networks
Partner Portal website.
Additional Optional Items
• 2-post shelf kit available for purchase from March Networks (part number 34916).
Do not install the recorder in a 2-post rack unless you are using this shelf kit.
WARNING: The procedures contained in this guide outline how to install or service components located
inside the unit, requiring the removal of the cover. Installation and maintenance procedures requiring
internal unit access are to be performed by qualified service personnel only.
When working inside the unit, ensure you take anti-static precautions.
Any attempt to service components of the recorder that are not considered field replaceable will
invalidate your warranty. The list of field serviceable parts includes:
• Hard drive with caddy
• Back-up battery
• Fans
• Power supply
Do not power up or operate the unit with the cover removed. The cover ensures the safe operation of the
unit. Operating the unit without the cover can expose you to live electric current and can cause the hard
drives to overheat.
ATTENTION : Les procédures contenues dans ce guide décrivent comment installer ou réparer les
composants situés à l'intérieur de l'unité, nécessitant le retrait du capot. Les procédures d'installation et
de maintenance nécessitant un accès interne à l'unité doivent être effectuées uniquement par du
personnel de maintenance qualifié.
Lorsque vous travaillez à l'intérieur de l'appareil, assurez-vous de prendre des précautions antistatiques.
Toute tentative de réparation de composants de l'enregistreur qui ne sont pas considérés comme
remplaçables sur site annulera votre garantie. La liste des pièces réparables sur site comprend:
• Disque dur avec caddy
• Batteries de sauvegarde
• Ventilateurs
• Source de courant
N'allumez pas et ne faites pas fonctionner l'appareil avec le couvercle retiré. Le couvercle garantit le
fonctionnement sûr de l'unité. Faire fonctionner l'appareil sans le couvercle peut vous exposer à un
courant électrique sous tension et entraîner une surchauffe des disques durs.

X-Series All IP Recorder Installation Guide 13
Feature Overview
Specifications
This section contains the dimensions, weight, temperature ranges, and power ratings of the unit.
Dimensions
Weight
Recorder unit — 25.64 pounds / 11.63 kilograms (without hard drives)
Each hard drive (HDD) — 1.7 pounds / 0.8 kilograms
Operating and Storage Temperature
Operating temperature: 32 to 104°Fahrenheit / 0 to 40°Celsius
Storage temperature: -40 to 158°Fahrenheit / -40 to 70°Celsius
WARNING: The recorder must be mounted in accordance with the mounting guidelines in this publication to
ensure the unit remains within the recommended operating temperature range. For more information, see
“Mounting the Recorder” on page 26.
ATTENTION : L'enregistreur doit être monté conformément aux directives de montage de cette publication
pour garantir que l'unité reste dans la plage de températures de fonctionnement recommandée. Pour plus
d'informations, voir « Mounting the Recorder » à la page 26.
High Temperature Shutdown
This feature ensures that the recorder shuts down if it gets too hot, and restarts when the
temperature drops to a safe level. If this occurs, a critical software alert is triggered.
17 inches/43.5 centimeters
19 inches/48 centimeters
22.2 inches/56.3 centimeters
3.5 inches/8.9 centimeters
0.9 inches/2.2 centimeters
21 inches/53.3 centimeters
1.2in/3cm

X-Series All IP Recorder Installation Guide 14
Feature Overview
Power Ratings
Power input: 100-240 volts AC input (auto-sensing)
Current rating: 2.5 A
Frequency range: 50-60 Hz
Power consumption: 100 W typical, 150 W maximum
Video Capture Rates
The IP camera input capture rate is dependent on the resolution and quality of the images captured.
The X-Series All IP recorders accommodate a total recording rate of up to:
• 400 Mbps for the X64 model
• 300 Mbps for the X48 model
• 200 Mbps for the X32 model
There is no set limit per camera channel.

X-Series All IP Recorder Installation Guide 15
Feature Overview
Front Panel LEDs
The colored LEDs (Light Emitting Diodes) on the front panel of the unit indicate status. Each
tricolor LED is marked to indicate which component the LED displays information about. The color
of the LED and whether the light is on solid, flashing, or off, gives you information about the
recorder.
UNIT
Unit LED
The status of
the unit.
Green Solid: The unit’s software and hardware are operating correctly.
Flashing: The
power On/Off pinhole has been pressed or the AC power
has been removed — the system is waiting for software to complete the
shutdown of the unit.
Blue Solid: The operating system is loaded but the unit’s software application is still
loading.
Flashing: The unit is booting up after power has been applied, or after a
software reboot.
Red Solid: The hardware watchdog timer has expired and reset the system.
Flashing: The unit’s temperature is too hot for startup. The flashing red unit
LED indicates that startup is delayed until the fans cool the unit to an
acceptable temperature.
OPER
Operation LED
The status of
the unit’s
operation.
Green Solid: The software in the unit is operating correctly, and the unit is powered
and running.
Blue Solid: Software is loaded, waiting for confirmation that all required recorder
subsystems have started successfully.
If blue remains solid, indicates that a recorder subsystem non-critical error has
been detected. For non-critical errors use the Command Config or Command
Client software to review the health alert and determine a possible resolution.
Flashing: The operating system is available but the software is still loading.
Red A critical error has occurred.
Use Command Config or Command Client software application to review the
health alert and determine a possible resolution.
For more information, see the X-Series All IP Recorder Configuration Guide
or
Command Enterprise and Client User Guide , available from the March
Networks Partner Portal website.
Front Panel LEDs

X-Series All IP Recorder Installation Guide 16
Feature Overview
Note: Information about operation and recording errors (indicated by the Operation or Recording
LED) can be retrieved using the Command Config or Command Client software.
For more information, see the X-Series All IP Recorder Configuration Guide or the Command
Enterprise and Client User Guide, available from the March Networks Partner Portal website.
Hard Drive Caddy LEDs
Each hard drive caddy has a green and a red LED on the front to provide information about the
hard drive.
Green LED
Indicates that a hard drive is present in the caddy and has power.
Red LED
Indicates that there is a problem with the hard drive in that caddy.
Use the Command Config or Command Client software application to review the health alert and
determine a possible resolution. For more information, see the X-Series All IP Recorder
Configuration Guide or Command Enterprise and Client User Guide, available from the March
Networks Partner Portal website.
REC
Recording LED
The status of
the unit’s
recording.
Green Actively recording as configured (the recorder may be configured to record
continuously or only configured to record when triggered by an alarm or a
schedule).
Blue There is a recording problem unrelated to the recorder. One or more cameras
may be disconnected or offline, or one or more storage groups may be
disconnected, offline, or removed.
Red A recorder-level problem has occurred which is affecting current recording or
will affect future recording.
Off The recorder is starting up or is not currently configured to record.
EXP
Export LED
The status of
an export to
an external
media device.
Green Solid: Media transfer is complete.
Flashing: Media transfer is in progress.
Blue Solid: External media device detected.
Flashing:
• A request to export media clips to an external media device has been
initiated but the recorder is still logging the media. Exporting will not start
until the recorder finishes logging the media.
• Media clips are ready to be exported to the external media device but no
external device is detected.
• The external media device is full. Empty the device or insert a new one.
Red Failure of media transfer.
Off No external media device is connected or the external device is not usable.
Hard drive presence
indicator LED (green)
Hard drive error
LED (red)

X-Series All IP Recorder Installation Guide 17
Feature Overview
USB Ports
There is one USB 3.0 port on the front of the unit, and two USB 2.0 ports on the back of the unit.
Front USB
There is one USB port on the front of the unit for connection of external peripherals.
The front port provides up to 1 A to power peripherals with a USB cable.
The port supports USB version 3.0 and is USB version 2.0 compatible.
Back USB
Two more USB ports are available at the rear of the unit.
These ports provide connections for external peripherals, provide up to 0.5 A per port to power
peripherals with a USB cable, and support USB version 2.0.
USB 3.0 Port on front (USB 1)
Two USB 2.0 Ports on back (USB 2 and USB 3)

X-Series All IP Recorder Installation Guide 18
Feature Overview
Ethernet Ports
There are three Ethernet ports available on the back of the unit.
Three Ethernet Ports and LEDs
The gigabit Ethernet ports are on RJ-45 connectors, with LEDs to indicate
the status of the connection. They each provide a 10/100/1000 BaseT
auto-negotiated Ethernet connection on a standard network pinout.
There are three Ethernet ports. The 0/1 Camera port is for IP camera
networks.
The 0/0 Network is the primary network port and the 0/2 Network port is
redundant.
All network communication defaults over the primary network port. If the
connection on the primary port is lost, network communication switches
to the redundant port and a health alert is sent.
While using the redundant network port, the recorder monitors the primary port. When the primary
port becomes available again, the system reverts back to the primary port.
Important: If managing this recorder with Command Enterprise, when setting up the Network tab
of the Enterprise Console, you must ensure that the primary network address is listed first in the
Published Addresses list (at the top of the list). For more information, see the Command Enterprise
Installation Guide, available from the March Networks Partner Portal website.
Ethernet port LEDs
Each Ethernet port has colored LEDs that indicate the connection status.
• Amber LED (on solid): A link is established with the point of presence (POP).
• Amber LED (flashing): There is activity on the established link.
• Green LED (on solid): A 1000 BaseT link is negotiated on the port.
• Green LED (off): A 10/100 BaseT link is negotiated on the port.
Default Network Configuration
• 0/0 Network - DHCP (Dynamic Host Configuration Protocol) and LLA (Link-Local Address)
• 0/1 Camera - Static IP: 192.168.0.1/24
• 0/2 Network - DHCP
3 Ethernet Ports and LEDs

X-Series All IP Recorder Installation Guide 19
Feature Overview
HD Video Monitor Output
There is an HD video monitor output available on the back of the unit.
The HD monitor output port incorporates HDMI®technology and allows
you to connect an HDMI monitor.
The HD Monitor 1 port offers up to 4K resolution of 3840 x 2160 @ 30 FPS.
Display Monitor
You can connect a monitor to the HD Output, and use Command Config to
configure how the video is displayed (no video is displayed by default). You can configure the
display time, choose which cameras to display, add IP cameras, show the cameras in various size
grids, and change the order that the cameras display.
For more information, see the X-Series All IP Recorder Configuration Guide.
HD Video Monitor Output

X-Series All IP Recorder Installation Guide 20
Feature Overview
Power Connections for Redundant Power Supply
The power connections for the redundant power supply are located on the back of the unit.
The redundant power supply contains two power supply modules. Each power supply module is
capable of powering the entire recorder, if necessary. If one module fails, the other module powers
the recorder alone until the failed module is replaced. The switch between the power supply
modules is seamless, so that normal use of the recorder is not affected.
You must connect the unit to two power outlets using two connected AC power cords. If one of the
power supply modules is not connected, an alarm sounds and an alert is generated.
• An alarm sounds and a software alert is generated if one of the power supply modules fails or is
not connected.
• You can silence the alarm by reconnecting the cable or replacing the failed module.
See “Replacing a Redundant Power Supply Module” on page 29.
• The LED on the back of the failed power supply module is solid amber. (The LED on a correctly
functioning power supply module is solid green.)
Important: Ensure that you only use the AC power cords supplied with your recorder unit. Failure to
use the correct power cords can result in damage to the power supply or unexpected power loss.
For the unit’s power ratings, see “Specifications” on page 13.
For information on powering the unit, see “Turning the Recorder On and Off” on page 30.
2 Redundant Power Supply Modules
