MARELUX Lumilink User manual

c
Lumilink
User Manual
Please read this user manual carefully before starting to use the
product, and use the product properly based on the thorough
understanding of this user manual.

c
Product Features
Material: Anodized Aluminum Alloy
Dimensions: 82mm (W) x 70mm (H) x 64mm (D)
Weight in Air: 180g
Depth Rating: 100m
Battery: 1x10440 lithium battery
Installed on the camera housing's fiber optic port, Lumilink amplifies and encrypts the signal
received from the camera housing's internal optical flash trigger, and then forwards it through
optical signals.
Lumilink is capable of extending the range of optical signal transmission, with an effective
transmission distance of 2m (underwater) and an optical signal emission angle of 160 degrees.

c
Parts Illustration
Power button
Fiber port
Indicator light
Optical signal transmitter

c
Battery Installation
Rotate counterclockwise to remove the battery cap.
After inserting the battery as shown, rotate clockwise to tighten the battery cap.

c
Install It Onto The Camera Housing
Insert the Lumilink into the camera housing's fiber port.
Rotate the bolt clockwise to tighten and secure it.

c
Operation
Press and hold the power button for 2 seconds to turn on. The indicator light will stay on
continuously. When the shutter button is pressed, it will trigger the Lumilink to emit a blue
light signal, triggering the Apollo strobe. There is also a separate fiber optic port on the top,
which does not occupy the original fiber optic port of the camera housing.

c
Maintenance And Storage
1. After diving, make sure the Lumilink is locked and sealed, wash the strobe body with
fresh water.
2. When immersed with fresh water, push each button few times, thus can help to let salt
and sand go out.
3. Use a soft cloth to wipe and clean the glass on the dome.
4. After each dive, clean the O-rings and check if there are damages on the O-rings.
5. Use sturdy and shock-proof case to carry the Lumilink and its accessories.
6. Don’t leave the Lumilink for too long inside vehicle under exposure to sunlight or heat.
7. Please stop charging the battery when it is full to prevent overcharging and damage to
the battery.
8. If don’t use the Lumilink for long period, remove the batteries.
9. This product is prohibited for use or play by children under 10 years old.

c
Warranty
1. Marelux provides 2 years warranty for its housing body, cable (such as fiber cable and
HDMI cable), and 1 year warranty for electronic parts and components made of
silicon, rubber and plastic.
2. Marelux will keep components and parts for repair and maintenance in storage for 5
years after EOL of each model. Beyond this period, Marelux may not be able to
provide repair service for those products.
3. Repair caused by following reasons will still be charged by marelux even during the 2
years warranty.
⚫Damage from misuse, incorrect maintenance or storage not complying with the
specifications and notices in this users’ manual；
⚫Damage from falling or inappropriate placement of the product；
⚫Damage caused by repair, maintenance, dismantlement, modification or cleaning
by any unauthorized vendor or service center by Marelux;
⚫Product without authentic Marelux serial number, or with erased, distorted or
falsified serial number;
⚫Damage caused by usage of non Marelux recommended accessories, parts,
components from other makers or suppliers, such as Flash Trigger, Cable, Dome
Port, Extension Ring, Convertor and etc；
⚫Damage caused by misuse or mistreatment by human, or by natural disaster or
other situations of force majeure;
⚫Malfunction or damage caused by erosion due to not cleaning the housing or
accessories.
4. Batteries, lubricants and other consumable supplies are not in warranty.
5. All parts and components replaced from the housing and its accessories in the
warranty service should belong to Marelux.
6. Marelux is not responsible for and will not compensate any collateral damages or
financial losses caused by using Marelux products, such as income or fees related
to the users of Marelux products.

c
⚫Warranty is only provided to products sold inside the service territory of the
distributor or reseller.
⚫Products purchased and used for rental business are not included in warranty.
⚫Products will lose warranty immediately after unauthorized repair or
modification.
⚫The warranty terms above are made for Marelux customers to conduct free
warranty service and repair and have no restriction to any legal rights that
customers shall possess.
Made in China
