Margaritaville DM1500 Series User manual

The Navigator
DM1500/1700 Series User Manual
K W™
 B Mrgts Cm Fr Mrgtvl®
Frozen ConCoCtion Maker®

WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
1. READ ALL INSTRUCTIONS BEFORE USING.
2. To protect against electric shock, do not immerse appliance,
cord or plug in water or other liquids.
3. Close supervision is necessary when any appliance is used near
children. This appliance should not be used by children.
4. Switch OFF and unplug from outlet when not in use, before
putting on or taking off parts, and before cleaning.
5. Blinking light indicates ready to operate. Avoid any contact
with blades or moveable parts.
6. Do not operate any appliance with damaged cord or plug or
after the appliance malfunctions, or is dropped or damaged in
any manner. Contact 1-877-689-2737 for customer service.
7. Do not use outdoors.
8. Do not let cord hang over the edge of a table or counter,
or touch hot surfaces, including the stove. Do not use
extension cords.
9. Keep hands and utensils out of container while blending
and/or ice shaving to reduce risk of severe injury to persons
or damage to the unit. A rubber spatula may be used but must
be used only when the appliance is not running.
10. Blades are sharp; handle carefully.
11. Always operate appliance with Jar Lid and
Ice Reservoir Lid in place.
12. The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
13. Do not use broken, chipped, or cracked Blending Jar
or Ice Reservoir.
14. To reduce risk of injury to persons, never place blending
blade assembly on base without the Blending Jar properly
attached.
15. Do not leave appliance unattended while it is operating.
IMPORTANT SAFEGUARDS

To disconnect, turn control to off, then remove plug from
wall outlet.
Do not use appliance for other than intended use.
Never place fingers or other utensils into feed or
discharge areas.
Check Ice Reservoir for presence of foreign objects
before using.
Be certain the Jar Lid and Ice Reservoir Lid are securely
locked in place before operating appliance.
Do not blend hot liquids.
NOTE: NEVER SHAKE OR REMOVE BLENDER JAR
DURING OPERATION AS JAR BLADE ASSEMBLY
CAN GET DAMAGED.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
Polarized Plug
This appliance has a polarized plug (one blade is wider than the
other). As a safety feature, this plug will fit in a polarized outlet only
one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not attempt
to defeat this safety feature.
16.
17.
18.
19.
20.
21.

-2-
MAX ICE MAX ICE
PARTS LIST
1 Ice Reservoir Lid –
Covers the Ice Reservoir.
2 Ice Reservoir –
Holds the ice for making frozen drinks.
3 Shaving Paddle –
Moves ice across the Shaving Blade.
4 Ice Hopper
4a Ice Hopper (ice deflector blade assembly) –
Feeds ice from reservoir to Shaving Blade.
5 Ice Shaving Blade – Shaves ice.
5a Ice Shaving Blade with deflector – Shaves ice.
6 Shaving Blade Assembly Nut –
Holds Shaving Blade in place.
6a U-Lock - Holds Shaving Blade in place.
7 Ice Chute – Directs ice from Ice Hopper
into Blending Jar.
8 Blending Base – Holds Blending Jar
securely in place.
9 Control Panel – Contains all necessary controls
to operate your unit.
2
3
9
8
1
7
5
4
6 6a
5a
4a
Frozen Concoction
Maker®
Welcome
Cngrlis  r rch  t Mrgtvl®
Fro CncoiMkr® – DM1500/1700 Si!
To learn more about Margaritaville® products,
please visit us at www.margaritavillecargo.com.

KEY WEST™ CONTROL PANEL
10 Mess-Free Lid With Easy
Pour Spout – Seals the blending jar.
11
Blending Jar – Has maximum
capacity of 36 oz.
12
Blending Blade Sealing Ring – Seals
the blending jar and blending base.
13 Blending Blade – Creates forward
action when blending drinks.
14 Jar Base – Designed with wide base
for stability.
15
Ice Reservoir Release Button –
Releases ice reservoir from unit.
16
Ice Melt Reservoir – Contains melted
ice excess.
17
Cord Storage Door – Covers power
cord storage area.
1 ON/OFF Rotary Switch –
Turns your unit on and off.
2 Shave ’n Blend™ Toggle Switch –
Used to select automatic
Shave ’n Blend™ cycle.
3 Power Indicator Light – Blinks when
unit is plugged in to indicate ready
for use. Avoid any contact with blades
or moveable parts.
4 Progress Indicator Lights – Shows
status of Shave ’n Blend™ cycle.
5 Blend Only/Shave Only Toggle Switch –
Used to manually operate ice shaver
and blender.
6 Number of Drinks Rotary Switch –
Used to select 1, 2 or 3 twelve oz.
frozen drinks.
MAX ICE MAX ICE
10
11
12
13
14
123 5 64
-3-
MAX ICE MAX ICE
15
16
17

Pineapple
Juice
Cranberry
Juice
Cream of
Coconut
Daiquiri
Mix
Rum Light
Rum
Pína Colada Daiquiris
No-Brainer
Mixing Tool
2
1 Twist and Release Spout –
Twist to “EMPTY” position
to release ingredients into
blending jar.
2 Fill Level – Follow the marks
to indicate how much of each
ingredient to add. Make sure
tool is in the “FILL” position
when adding ingredients.
To clean the No-Brainer mixing tool, wash with warm water and soap.
It is also acceptable to wash in the top rack of the dishwasher.
Note: The No-Brainer Mixing Tool separates into 2 parts for easy cleaning.
NOTE: The no-brainer mixing tool has measurements for use with 36-ounce and
54-ounce jars. RECIPES FOR USE WITH 36-OUNCE JARS ARE IN GREEN;
RECIPES FOR USE WITH 54-OUNCE JARS ARE IN RED.
Be sure to use the correct recipe for your size jar.
 N-Brnr xng t ncud erm rngs
r ng n btc  t to tr o  p.
For more recipes, go to margaritavillecargo.com.
Ingredients for Pina Coladas,
Daiquiris, and Margaritas can
be perfectly measured using
the No-Brainer Mixing Tool.
-4-
1

1. Place the unit on a clean dry flat surface.
2. Place the Ice Reservoir on the unit front first,
then push down firmly on back. Reservoir must
click into place.
NOTE: IF ICE RESERVOIR IS NOT SEATED FIRMLY
IN PLACE THE UNIT WILL NOT OPERATE.
3. Remove the Cord Storage Door by pushing down
on the release tab located on the Cord Storage Door.
Remove the power cord and plug the unit
into a standard 120 Volt wall socket. Replace
the Cord Storage Door and position the power cord in
the slot below the cord storage release tab.
4. Remove the Ice Reservoir Lid using the
Release Button located on the top of the
Ice Reservoir.
NOTE: NEVER PUT ANYTHING BUT ICE IN
THE ICE RESERVOIR.
5. Fill the Ice Reservoir with ice cubes.
6. Replace the Ice Reservoir Lid and snap closed.
7. Lift and remove the Blending Jar.
The Ice Chute is spring-loaded and
can be pushed up.
8. Remove Blending Jar Lid.
Making frozen
drinks
-5-

10. Replace Blending Jar Lid and return
Blending Jar to Blending Base by pushing up
on the Ice Chute with the Blending Jar and
then placing it on the Blending Base.
11. Set the Number of Drinks Rotary Switch to
correspond to the number of drinks being
made. (Always select 3 drinks when using
No-Brainer Mixing Tool.)
12. Rotate the ON/OFF Rotary Switch on the
Control Panel to the ON position.
9. Add appropriate amount of liquid ingredients to the Blending Jar for the
number of drinks being made (1, 2 or 3).
NOTE: NEVER SHAKE OR REMOVE JAR DURING OPERATION –
BLADE ASSEMBLY WILL GET DAMAGED.
-6 -
Number of Drinks
Rotary Switch
On/Off
Rotary Switch
Pineapple
Juice
Cranberry
Juice
Creamof
Coconut
Daiquiri
Mix
Rum Light
Rum
PínaColada Daiquiris
9. Make sure the top is
set to “FILL” position.
Follow guidelines on
No-Brainer Mixing
Tool for adding
ingredients, using
36-ounce recipe.
Pineapple
Juice
Cranberry
Juice
Creamof
Coconut
Daiquiri
Mix
Rum Light
Rum
PínaColada Daiquiris
9b. Place No-Brainer
Mixing Tool on top of
assembled Blending Jar
and twist to “EMPTY”
position to release mix.
Remove No-Brainer
Mixing Tool.
The Best Margarita Recipe
1 Drink 2 Drinks 3 Drinks
fl oz ml fl oz ml fl oz ml
Margaritaville® Gold Tequila 1 30 2 60 3 90
Triple Sec 1⁄4 7.5 1⁄2 15 3⁄4 22.5
Lime Juice 1⁄2 15 1 30 1 1⁄2 45
Orange Juice 1⁄2 15 1 30 1 1⁄2 45
Margaritaville® Margarita Mix 1 30 2 60 3 90
Total Volume 3 1⁄4 97.5 6 1⁄2 195 9 3⁄4 292.5
Ingredients
Amount (12 fluid oz drink)

-7-
13. Start the Automatic
Shave ’n Blend™ Cycle
by pushing up on the
Shave ’n Blend™ Toggle Switch.
14. The unit will shave ice for
the appropriate time (based on the
settings selected). The blender will
start automatically. The unit will stop
at the completion of the cycle.
NOTE: DURING THE SHAVE ‘N BLEND™ CYCLE
THE PROGRESS INDICATOR LIGHTS WILL
ILLUMINATE IN A SEQUENCE FROM LEFT TO RIGHT
TO INDICATE THE CYCLE PROGRESS.
15. The Power Indicator Light will blink
to indicate the unit is ready to make
more drinks.
16. To serve: With the Mess-Free lid, there’s
no need to remove the lid for serving.
NOTE: To remove excess ice from the Ice Reservoir hold the Shave Only Toggle Switch
in the Shave Only position until the Ice Reservoir is empty.
WARNING: DO NOT PLACE FINGERS IN THE
ICE HOPPER THE SHAVING BLADE IS SHARP
AND COULD CAUSE INJURY.
17. Turn off the unit.
18. Periodically check the Ice Melt Reservoir
and empty as needed.
AUTOMATED SHAVE ’N BLEND™ CYCLE
Shave ’n Blend™
Toggle Switch

-8 -
Blend Only/
Shave Only
Toggle Switch
MANUAL CYCLE
To make a thicker drink:
. Hold the “Blend Only/Shave Only” Toggle
Switch in the Shave Only position to add
more ice to the Blending Jar.
b. To stop adding ice, release the toggle switch.
. To mix the newly added ice into the drink,
hold the Blend Only/Shave Only Toggle
Switch in the blend only position until the
desired consistency is achieved. To stop the
blending release the toggle switch.
. Use less drink mixer than in recipe.
(example: for 3 drinks, use 9 oz. liquid content)
To make a thinner drink:
. Hold the Blend Only/Shave Only Toggle
Switch in the Blend Only position until the
desired consistency is achieved.
b. To stop blending release the toggle switch.
. Add more drink mixer than in recipe
(example: for 3 drinks, use 10.5 oz. of total mix)

-9-
Cleaning and
Maintenance
IMPORTANT: Your Blending Jar, Shaving and Blending Blades are subject to wear
during normal use. Always inspect for nicks, chips, or cracks. Always inspect for
broken, cracked, or loose blades. If the jar or Shaving and Blending Blades are
damaged, do not use. Call our toll-free customer service number, 1-877-689-2737,
to obtain replacement parts.
1. Make sure unit is unplugged. Place on a clean dry surface.
Turn the unit so the back is facing you. Push down on the
Ice Reservoir Release Button. Lift the back of the Ice Reservoir
and remove. This will expose the Shaving Paddle and
Ice Hopper.
Note the location of the Shaving Blade
inside the Ice Hopper.
WARNING: DO NOT PLACE FINGERS INSIDE THE
ICE HOPPER NEAR THE SHAVING BLADE.
BLADE IS SHARP HANDLE CAREFULLY.
2. To Remove the Shaving Paddle:
Press the button located behind the Ice Chute.
If the button cannot be pressed, rotate the
Shaving Paddle for a half turn and retry.
While pressing the button, rotate the Shaving Paddle
counter-clockwise (to the left) by placing fingers in the
ridges of the Shaving Paddle and unscrew.
This will expose the Ice Hopper and Shaving Blade.
To re-assemble the Shaving Paddle,
simply replace it into the threaded insert and
rotate clockwise. Hand tighten only.
SHAVING BLADE

-10-
SHAVING BLADE
3. Press the two Ice Hopper release catches and
lift the Ice Hopper to remove.
4. Turn the Shaving Blade Assembly Nut
counter clockwise (to the left) and remove,
then remove the Shaving Blade and store
in a safe place.
5. Carefully lift the Jumbo Jar straight up to remove.
The Ice Chute is spring-loaded and can be pushed up.
If the Blending Jar is not easily removed, rock gently
and lift. Do not twist.
6. Turn the Jumbo Jar upside down and unscrew the
Jar Base counter clockwise (to the left). Carefully
remove the Blending Blade, and Blending Blade
Sealing Ring.
WARNING: THE BLENDING BLADE IS SHARP.
HANDLE WITH CARE.
7. To remove the Ice Melt Reservoir hold the unit still
and pull straight out on the handle.
8. The Ice Reservoir Lid, Ice Reservoir, Shaving Paddle,
Ice Hopper, Shaving Blade Assembly Nut, Shaving Blade,
Blending Jar Lid, Jumbo Jar, Blending Blade, Blending
Blade Sealing Ring, Jar Base and Ice Melt Reservoir
can be safely washed in the top rack of your dishwasher.
Use only top rack. Failure to do so will result in damage.
9. Use a damp cloth to clean the outside of the unit.
WARNING: UNPLUG UNIT BEFORE CLEANING.
DO NOT USE SOLVENTS.
NEVER IMMERSE THE UNIT IN WATER.

-11-
TROUBLESHOOTING
If the Power Indicator Light does not light:
Check that the unit is plugged into a working power outlet.
If liquid leaks from the base of the Blending Jar:
Remove it from the unit and check that the Blending Blade Sealing Ring
is properly installed and that the Blending Jar Base is tightened.
If water leaks from the unit:
Empty the Ice Melt Reservoir and make sure reservoir is in place.
If the Blending Jar overflows during the Shave ’n Blend™ cycle:
Follow the drink recipes included in “Making Frozen Drinks” section and make
sure to not exceed the specified total volume.
If the Blending Jar will not sit on the Blending Base:
Remove it from the unit and check for ice on the Blending Base.
WARNING: unplug the unit before removing ice from the Blending Base.
If the shaver does not shave sufficient ice for the liquid in the Blending Jar:
Check that the Number of Drinks Rotary Switch setting corresponds to the amount
of liquid in the Blending Jar.
DOS AND DON’TS
DO NOT place fingers into the Blending Jar or Ice Hopper. The blades in this unit
are sharp and could cause injury.
DO NOT place Blending Jar onto Blending Base while motor is running. The
spinning Blending Base could damage the Blending Jar.
DO NOT twist Blending Jar when removing. Simply lift and remove. Twisting the
Blending Jar could loosen the Blending Jar Base causing it to leak.
DO NOT put hot liquid into the Blending Jar. Hot liquids could be ejected during the
blending process causing injury.
DO NOT place ice, frozen foods or very cold liquids into a Blending Jar which has
come directly from a hot dishwasher. The sudden change in temperature could
cause the Blending Jar to crack.
DO NOT place very hot liquids or foods into a Blending Jar that has come directly
from the freezer. The sudden change in temperature could cause the Blending Jar
to crack.
DO Follow the Cleaning and Maintenance instructions prior to your first use.
DO unplug the unit when not in use.

-12-
1 Year Limited Warranty
Sunbeam Products, Inc, d/b/a Jarden Consumer Solutions or if in Canada, Sunbeam Corporation
(Canada) Limited d/b/a Jarden Consumer Solutions (collectively “Sunbeam”) warrants that for a
period of one year from the date of purchase, this product will be free from defects in material
and workmanship. Sunbeam, at its option, will repair or replace this product or any component
of the product found to be defective during the warranty period. Replacement will be made with a
new or remanufactured product or component. If the product is no longer available, replacement
may be made with a similar product of equal or greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is
not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty
performance. Sunbeam dealers, service centers, or retail stores selling Sunbeam products do
not have the right to alter, modify or any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the
following: negligent use or misuse of the product, use on improper voltage or current, use
contrary to the operating instructions, disassembly, repair or alteration by anyone other than
Sunbeam or an authorized Sunbeam service center. Further, the warranty does not cover:
Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by
the breach of any express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of
merchantability or fitness for a particular purpose is limited in duration to the duration
of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied,
statutory or otherwise.
Sunbeam shall not be liable for any damages of any kind resulting from the purchase, use or
misuse of, or inability to use the product including incidental, special, consequential or similar
damages or loss of profits, or for any breach of contract, fundamental or otherwise, or for any
claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied warranty lasts, so the above
limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from
province to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
If you have any question regarding this warranty or would like to obtain warranty service,
please call 1- 877-689-2737 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. located in Boca Raton, Florida 33431.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO
THE PLACE OF PURCHASE.

NOTES

DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE
For product questions:
Jarden Consumer Services U.S.A.
1-877-689-2737
www.margaritavillecargo.com
©2012 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All rights reserved.
Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions,
Boca Raton, Florida Boca Raton, Florida 33431.
Margaritaville® is a registered trademark of Margaritaville. Used with permission.
Printed in China P. N. 163639 SPR-103112-814P
