Marport Catch Sensor User manual

Contents
Legal 4
History 4
Copyright 4
Disclaimer 4
Introduction and
Presentation 5
Introduction 6
Applications 7
Safety Guidelines 7
Description 7
System Compatibility 7
Firmware and Features 8
Technical Specifications 9
Main Parts 10
Sensor Configuration 12
Connecting the Sensor to Mosa2 13
Battery Information 16
Diagnostic Information 17
Configuring the Trawl Node 18
Configuring the Uplink Frequency and
Power 20
Configuring Measurement Sending
Sequence 21
Configuring the Echo Sounder 22
About the Automatic Range Mode 24
Changing the Detection Threshold of the
Catch Sensor 26
Applying Osets to Measurements 26
Testing Measures 27
SD Card Recording 28
Saving a Configuration on Mosa2 31
Exporting Sensor Configuration 33
Importing a Sensor Configuration 34
System Configuration and
Display 36
Adding the Sensors to the Receiver 37
Adding the Sensors to the Receiver 37
Configuring the Sensor Settings 38
Configuring Data Display in Scala2 39
Replaying Data from A2S Files 44
Installation 45

Contents | iii
Installing the Catch Navigator on the
Trawl 46
Maintenance and
Troubleshooting 48
Charging the Sensor with the Dock 49
Cleaning the Sensor 50
Maintenance Checklist 51
Replacing the Pull Cords 52
Replacing the Catch Magnet 53
Troubleshooting 56
Mosa2 does not open due to error message 56
Sensor does not connect correctly with Mosa2
when using the Configuration Cable 56
The echogram has a lot of interference 57
Support Contact 59
Appendix 60
Frequency Plan 60
Index a

Legal
History
V1 12/30/22 First release
Copyright
© 2022 Marport. All Rights reserved.
No part of this document may be reproduced, stored in a retrieval system or transmitted in any
form by any means; electronic, mechanical, photocopying or otherwise, without the express
written permission from Marport. “Marport”, the Marport logo and Soware Defined Sonar are
registered trademarks of Marport. All other brands, products and company names mentioned
are the trademark and property of its respective owners only. Marport is a division of Airmar
Technology Corporation.
Disclaimer
Marport endeavors to ensure that all information in this document is correct and fairly stated, but
does not accept liability for any errors or omissions.
Catch Navigator | V1 | Legal 4

Introduction and Presentation
Get a basic knowledge of the sensor.
Introduction
Marport's Catch Navigator tells you when your trawl starts to fill. Placed on the top of
the trawl codend, it monitors the amount of catch that you have and warns you when
the trawl is full. You can even use it to determine a precise amount of fish inside the
trawl net. This way, you can monitor the contents of the codend while you are fishing,
avoid problems of overfilling and increase fish survival rate inside the trawl net. It is
recommended to install several sensors along the trawl to better monitor the filling
processes.
The Catch Navigator provides a high-definition echogram image of the volume of catch
inside the codend. In order to eiciently follow the trawl descent, echogram ranges are
configurable from 5 to 160 meters. Moreover, the sensor includes an automatic range
mode: when descending, the sensor can automatically switch to a lower range of 20
meters to get sharper pictures. Optionally, it can also track pitch, roll, depth, height and
temperature data.
Catch Navigator | V1 |
Introduction and Presentation 6

Applications
Examples of data received and displayed in Scala2 application.
1. Catch status: empty / 2. Catch status: full / 3. The echogram shows the codend filling
up, until the catch sensor is triggered.
Safety Guidelines
Important: To ensure proper and safe use of this equipment, carefully read
and follow the instructions in this manual.
Description
System Compatibility
The Catch Navigator is compatible with the following versions of Marport's soware
and equipment.
Mosa2 02.11.10 or later
Scala2 02.10.03 or later
Catch Navigator | V1 |
Introduction and Presentation 7

Mx receiver firmware 08.05.03 or later
Dock 01.01.01 or later
Firmware and Features
This section describes the firmware and features that must be configured on MASP to
set up the sensor.
To be operational, the sensor needs to be configured with two files:
•a firmware file (*.A2F): it is the firmware of the sensor,
•an application file (*.A2A): it defines the sensor features and options.
These files are generated via MASP.
Firmware
The latest version of the firmware is available for download on MASP.
Compatibility: F450-02.02.02 and aer
Features and Options
The features and options are configurable according to the type of hardware and
customer's choices.
Features •Product name: Manually entered.
•Application: Catch Navigator
•Body: Small
•Battery capacity (not configurable): 1-
pack
Sounding Options •Down
•Down2
Misc. options •SD Card Log: records a log of the sen
sor activity. This option is useful for trou
bleshooting support.
•High Resolution (always activated)
Catch Navigator | V1 |
Introduction and Presentation 8

Measures •Battery (always activated)
•Catch (always activated)
•Pressure (depth)
•Temperature
•Pitch
•Roll
•Height
Technical Specifications
Uplink frequency 30 to 60 kHz
Range to vessel up to 2500 m*
Data update rate •5-meter range: Echogram @0.75 s - temperature, depth, pitch, roll,
battery level, catch @5.24 s
•10-meter range: Echogram @0.91 s - temperature, depth, pitch,
roll, battery level, catch @6.39 s
•20-meter range: Echogram @1.24 s - temperature, depth, pitch,
roll, battery level, catch @8.69 s
•40-meter range: Echogram @1.00 s - temperature, depth, pitch,
roll, battery level, catch @7.00 s
•80-meter range: Echogram @1.26 s - temperature, depth, pitch,
roll, battery level, catch @8.85 s
•160-meter range: Echogram @1.79 s - temperature, depth, pitch,
roll, battery level, catch @12.53 s
Depth range up to 1800 m
Depth resolution 0.1 m with 0.1% full scale accuracy
Echogram range 20 (auto) / 40 / 80 / 160 meters
Pitch and roll range -180° to +180°
Pitch & roll accuracy +/- 1°
Temp measurement range -5° C to +25° C
Temp accuracy ±0.1° C
Catch Navigator | V1 |
Introduction and Presentation 9

Charging time (from 0% to
100%)‡
2 hours
Battery type Lithium-Ion
Weight of sensor in air 5.5 kg
Weight of sensor in water 1.6 kg
Warranty 2 years (Sensor & Battery) **
*Reference only. Depends on communication settings and transmission conditions /
† Depends on sensor uplink power and options. Lifetime has been estimated with a
uplink power at 33%. / ‡ Based on average charging time. / **Marport Standard Marine
Limited Warranty
Dimensions
Main Parts
External View
1. Pressure sensor
2. Temperature sensor
3. Negative charge
4. Water switch
5. Positive charge
6. Shoulder bolts
7. Pull cords (center-pull)
Catch Navigator | V1 |
Introduction and Presentation 10

1. Transducer
2. End cap
3. Pull cords (side-pull)
CAUTION:
•Do not put foreign objects into pressure sensor opening or try to open it.
•Do not remove the shoulder bolts from the outside of the sensor.
It may damage the components.
Catch Navigator | V1 |
Introduction and Presentation 11

Sensor Configuration
Learn how to configure the sensor settings.
To be able to change the settings of the sensor: Press command + A or click Menu
and click User Mode > Advanced.
Connecting the Sensor to Mosa2
To configure the sensor, you need to connect it to Mosa2 application, using either the
Dock or the Configuration Cable.
Using a Dock Charger Plug
Catch Navigator | V1 | Sensor Configuration 13

1. Connect one Dock charging plug to the sensor's endcap.
2. Mosa2 discovery page opens. The sensor is displayed.
◦Click to open the sensor
configuration page.
◦Click to show the deploy
animation on the charger plug
for 30 seconds.
Using the Configuration Cable
Simply connect the Configuration Cable from the computer to the sensor to display the
sensor configuration page on Mosa2.
Tip: Refer to the Configuration Cable Quick Reference Guide for more details
about the use of this product.
1. Move other electrical devices minimum 1 m away from the computer.
2. Connect the USB connector directly to the computer.
Catch Navigator | V1 | Sensor Configuration 14

Mosa2 opens automatically and the startup wizard is displayed. The LED on the
plug is solid blue.
3. Connect the three-pin plug to the sensor.
The LED on the plug blinks alternatively blue and green.
4. Wait a few seconds. The configuration page of the sensor is displayed on Mosa2.
The LED on the plug is solid green.
You can now configure the sensor.
Note: You can keep the Configuration Cable continuously connected by
USB, and virtually eject or connect it. When no sensor is connected to
the Configuration Cable, click Menu > Eject Config Plug or Connect
Config Plug. When ejected, you come back to the discovery page. It stays
disconnected until you virtually connect to it or manually disconnect then
connect it.
Catch Navigator | V1 | Sensor Configuration 15

Battery Information
The battery lifetime is displayed on the first page.
Catch Navigator | V1 | Sensor Configuration 16

You can also check the battery level at anytime from the top bar:
Note: When you change settings such as the uplink power or sounding
range, it aects the battery consumption and remaining lifetime. The battery
information will update aer the sensor has been switched on and operating
for 10 minutes.
Diagnostic Information
Scala2 and Mosa2 applications warn the user in case of water ingress in the sensor.
Note: Diagnostic information is available for Marport Pro sensors (A2S and A2H
PCBA versions), from the firmware version F450-02.02.00 or later and Mosa2
version 02.11.08.
Catch Navigator | V1 | Sensor Configuration 17

In case of water ingress in the sensor, alarms are displayed in Scala2 Virtual Charger
Room, in Mosa2 and on the charger plug when connected to the sensor.
•Mosa2 displays a dialog at the start of the application and warning icon in the
toolbar and diagnostic page:
•The charger plug displays a warning icon:
When the alarm appears, take the sensor out of water immediately and contact Marport
support.
Warning: In case of water ingress in the product, do not charge it: battery may
vent or rupture, causing product or physical damage.
Configuring the Trawl Node
You need to give a trawl node to the sensor. It is the number corresponding to the
position of the sensor on the trawl.
The trawl nodes corresponding to the positions on the codend are the following:
Trawl number Node numbers
Trawl 1 1 to 6
Trawl 2 101 to 106
Trawl 3 201 to 206
Trawl 4 301 to 306
Catch Navigator | V1 | Sensor Configuration 18

Trawl number Node numbers
Trawl 5 601 to 606
1. Go to the Communication page, then click in Uplink.
2. Enter a node according to the position of the sensor on the trawl.
Important: Make sure to put the same number when adding the sensor
to Scala2 receiver page. If not, change it accordingly.
Catch Navigator | V1 | Sensor Configuration 19

3. Click .
Configuring the Uplink Frequency and Power
Configure the settings of the communication link between the sensor and the vessel.
1. Go to the Communication page, then click in Uplink.
2. Enter a frequency for the communication with the vessel. Default is 44,000 Hz.
3. Drag the slider to change the power of the uplink signal.
Note: A higher level of uplink power reduces the battery lifetime.
Catch Navigator | V1 | Sensor Configuration 20
