marposs Nemo How to use

Quick Starting Guide

- 2 -
PAGE 3
PAGE 6
PAGE 11
PAGE 15
INDEX
1 GETTING STARTED......................................................................
2 SETTINGS.....................................................................................
3 PROGRAMMING...........................................................................
4 MEASURE.....................................................................................
This is Nemo Quick Starting Guide, for any other detailed information it is
necessary to refer to the Software Manual officialy released and available
also on the Marposs website.

- 3 -
1 GETTING STARTED
There are three Nemo versions with a different rear panel; one of them,
with DigiCrown box connectors, it is designed for digital probe devices and
Marposs DigiNet products (see FIGURE 1). The second one is designed for
input devices using USB connections and Marposs EasyBox products (see
FIGURE 2). The last one is designed for input devices using USB connections
like Red Crown2 USB (see FIGURE 3).
FIGURE 1
MAX. 3
MODULES
MAX. 8
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
FIGURE 2
NO
MAX. 8
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
MAX. 2
DEVICES
FIGURE 3
NO
MAX. 8
DEVICES
MAX. 8
DEVICES
MAX. 8
DEVICES
MAX. 2
DEVICES
read

- 4 -
FIGURE 1
1
1EasyBox using the USB port
(see FIGURE 1).
Bluetooth® key dongle for
wireless Marposs wave devices
using the USB port (see FIGURE 2).
FIGURE 2
FIGURE 3
DigiCrown box making sure
the box is locked in position
by pushing the tab down
(see FIGURE 3).
This chapter describes the operations sequence to connect all devices.

- 5 -
FIGURE 4
FIGURE 5
Insert the power cable into the connector and
screw finger tight to secure (see FIGURE 4).
Turn on the NEMO (see FIGURE 5).
2
2
3
3

- 6 -
2 SETTINGS
This chapter describes the operations sequence to identify the input devices
and to see which transducers are connected to Nemo.
Tap on “HARDWARE SETTINGS” button (see FIGURE 2).
From the Home page, tap on “SETTINGS” button (see
FIGURE 1).
1
1
2
2
FIGURE 1
FIGURE 2

- 7 -
Tap on “UPDATE” button (see FIGURE 4).
Tap on “MEASURE DEVICES” button (see FIGURE 3).
3
3
4
4
FIGURE 4
FIGURE 3

- 8 -
Tap on “NO” in the following window (see FIGURE 5).
Wait few seconds to recognize the device (see FIGURE
5b). After that, the new device is ready to use.
5
5FIGURE 5
FIGURE 5a
FIGURE 5b
5
5
a
a
5
5
b
b
Tap on “YES” if you like to add a wireless Marposs
wave device (see FIGURE 5a).
After that, select the correct wireless Marposs wave device, setting all
parameters required. When it’s requested, perform the binding operation on
the device selected.
If a Bluetooth® key dongle is not connected to the Nemo, go to the step 6.
Otherwise keep on as follows:
Note: For more information about binding consult the Software Manual.

- 9 -
After Nemo has automatically recognized the
devices connected, it may be necessary to enable
and connect the highlighted/selected transducer/
sensor to device. Double tap on the red field or tap
on the “EDIT” button (see FIGURE 6).
6
6
FIGURE 6
7
7Select the transducer from the dropdown list and tap
on “OK”(see FIGURE 7).
FIGURE 7

- 10 -
Tap on “TRANSD.” button to see the selected
transducer’s current reading or sensor’s value (see
FIGURE 8).
8
8
FIGURE 8
Tap on “HOME” button to return to the Home page.
9
9
FIGURE 9

- 11 -
3 PROGRAMMING
This chapter describes the operations sequence to program a measuring
cycle.
From the Home page, tap on “PROGRAMMING” button
(see FIGURE 1).
FIGURE 2
Tap on “PART PROGRAMS” button (see FIGURE 2).
1
1
2
2
FIGURE 1
Note: If you like to define a Master Set before a
Part Program consult the Software Manual.

- 12 -
3
3Tap on “NEW” button (see FIGURE 3).
Tap on “OK” button (see FIGURE 4).
4
4
FIGURE 4
FIGURE 3

- 13 -
Tap on “OK” button (see FIGURE 5).
5
5
Double tap on the Formula field and write using the
virtual keyboard the formula of the characteristic.
Then tap on “Ok” button (see FIGURE 6).
6
6
FIGURE 6
FIGURE 5

- 14 -
Tap on “HOME” button to return to the home page.
7
7
8
8
You can now associate more than one characteristic
to the part program, by tapping on “NEW” and
repeating the entry shown in FIGURE 6 with a new
characteristic. At the end of that operation tap on
“OK” (see FIGURE 7).
The new part is created (see FIGURE 8).
FIGURE 8
FIGURE 7

- 15 -
FIGURE 1
4 MEASURE
This chapter describes the operations sequence to execute and display the
measurements.
From the home page, tap on “MEASURE” button (see
FIGURE 1).
FIGURE 2
Tap on “BATCHES” button (see FIGURE 2).
1
1
2
2

- 16 -
3
3
4
4Tap on “NEW” button (see FIGURE 4).
Tap on “ALL” button (see FIGURE 3).
FIGURE 4
FIGURE 3

- 17 -
Enter the name of the batch and Tap on “OK”
button (see FIGURE 6).
Select a part program and tap on “OK” button (see
FIGURE 5).
5
5
6
6
FIGURE 6
FIGURE 5

- 18 -
7
7
8
8Tap on “START” button to begin the measure cycle
(see FIGURE 8).
Tap on “MEASURE” button (see FIGURE 7).
FIGURE 8
FIGURE 7
Note: If you like to perform a Zeroing before start
measure consult the Software Manual.

- 19 -
Tap on “HOME” button to return to the home page.
Tap on “STOP” button at the end of the measure
cycle (see FIGURE 9).
9
9
FIGURE 9
