Thank you for your purchase of a Marshall Miniature or Compact Genlock Camera.
The Marshall Camera team recommends thoroughly reading this guide for a deep understanding
of on-screen-display (OSD) menus, breakout cable operation, settings adjustment explanation,
troubleshooting, and other critical information.
Please carefully remove all contents of box, which should include the following components:
CV566/CV568 includes:
• CV566 camera with 3.6mm lens(interchangeable), CV568 camera with 4.4mm
lens(interchangeable)
• Camera Breakout Cable (Power/RS485/Audio)
• 12V Power Supply
CV366/CV368 includes:
• Camera with CS/C mount (lens sold separately)
• C-Mount Lens Adaptor (only used when using C-mount lens)
• Camera Breakout Cable (Power/RS485/Audio)
• 12V Power Supply
The CV566 ships with a 3.6mm lens installed and is interchangeable to any number of Marshall M12
lenses. The CV568 ships with a 4.4mm lens installed and is interchangeable to 1/1.8” M12 lenses.
Each camera comes set to default at 1920x1080p @ 30fps out of the box; which can be changed in
the OSD Menu to a variety of resolutions and framerates.
If the camera is accidentally changed to a resolution or framerate that your monitor or equipment
doesn’t accept, please follow the instructions below to reset camera to factory default:
1. Plug the camera into power source and connect breakout cable to rear camera panel (locking
connection), Power LED should illuminate.
2. Push OSD joystick button UP, DOWN, UP, DOWN and PUSH and HOLD for five seconds.
3. Camera should reset to 1920x1080p @ 30fps.
4. If camera does not reset, repeat steps after a power-cycle.
1. General Information

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com3 4
.
SETUP SUB MENU SUB MENU
WB CONTROL
ATW BLUE OFFSET
RED OFFSET
ONE PUSH
INDOOR
OUTDOOR
MANUAL BLUE
RED
AE CONTROL
AUTO
AGC MAX
AE BRIGHT
LENS MODE
SHUT FIX
SHUTTER
AGC MAX
AE BRIGHT
AGC FIX
AGC
AE BRIGHT
LENS MODE
MANUAL SHUTTER
AGC
DAY / NIGHT DAY
NIGHT
AUDIO
MIC/LINE
AUDIO LEVEL
MIC ATTENUATOR
SAMPLE BITS
GENLOCK
MODE
SYNC OUTPUT
H-SYNC PHASE
V-SYNC PHASE
PHASE SET
SETUP SUB MENU SUB MENU
IMAGE CONTROL
LENS SHADING
CONTRAST
BRIGHTNESS
SATURATION
HUE
EDGE ENHANCE
AUTO SATURATE
AUTO EDGE
BLACK WHITE LV
BLACK LEVEL
WHITE LEVEL
GAMMA CORRECT
DNR DNR MODE
DNR LEVEL
SPECIAL
DZOOM
DEFOG
DIS
BACKLIGHT
BINNING
DEFECT PIXEL
DISP FUNCTION
WDR
PRIVACY
SETUP
CAM TITLE
COMMUNICATION
CAM ID
ID DISPL AY
BAUD RATE
MODEL
S/W VER
OUTPUT FORMAT
RESET
USER/FACTORY
EXIT
2. Menu Structure

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com5 6
3. OSD Joystick and Button
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
>
>
>
>
>
>
>
>
MENU
566/568
I/O Cable (included in box) for CV566, 568, 366, 368.
366/368
Use the UP & DOWN
buttons to select the
desired item.
Use the LEFT & RIGHT
buttons to change the
sub-item.
> Icon indicates “Press OSD button” or “Enter Sub Menu”
1. SET Used to access the menu and confrim selection.
2. UP Used to move the cursor up.
3. DOWN Used to move the cursor down.
4. LEFT Used to move the cursor left and change the value
5. RIGHT Used to move the cursor to the right and change the value.
Press SET button to access the Main Menu
4. WB CONTROL
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
MODE
PUSH
BLUE
RED
BLUE OFFSET
RED OFFSET
RETURN
>
>
>
>
>
>
>
>
>
MANUAL
50
50
50
50
>
MENU WB CONTROL
1. Adjust White Balance first by using the ATW mode before switching to MANUAL mode.
2. White Balance may not work properly under the following conditions. In this case, select
the ATW mode.
• When the ambient illumination of the subject is dim.
• If the camera is directed towards a fluorescent light or is installed in place where
illumination changes dramatically, the White Balance operation may become unstable.
Select WB CONTROL using the UP or DOWN button. You can change between AUTO, ATW, PUSH,
and MANUAL using the LEFT or RIGHT buttons.
• ATW: Continuously adjusts camera color balance in accordance with any change in color
temperature. Compensates for color temperature changes within the range of 1,900°K to
11,000°K.
• BLUE OFFEST: Adjust the Blue tone within the ATW mode.
• RED OFFSET: Adjust the Red tone within the ATW mode.
• ONE PUSH: Color temperature will be manually adjusted by pushing the OSD button. Place
the white paper in front of the camera when OSD button is pressed to obtain optimum result.
• MANUAL: Select this to fine-tune White Balance manually.
You can adjust the blue and red tone level manually.
1. BLUE: Adjust the Blue tone of the image. (0~255)
2. RED: Adjust the Red tone of the image. (0~255)
• INDOOR: Select this to adjust white balance to indoor lighting condition.
• OUTDOOR: Select this to adjust white balance to outdoor lighting condition.
1
3
2
54 R
U
L
D

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com7 8
5. AE CONTROL
• AUTO: Adjusts the exposure level automatically. Detailed fine tuning options are available under
this menu.
• SHUT FIX: Provides more detailed shutter speed options. All other controls are tuned for the
selected shutter speed.
• AGC FIX: Provides more detailed gain option. All other controls are tuned for the selected gain.
• MANUAL: Adjusts the exposure level manually
1. SHUTTER: Speed can be set at auto or manual. (NTSC: 1/30~1/10,000, PAL: 1/25~1/10,000)
2. AGC: Electronic gain level can be controlled. (0dB~48dB)
3. AGC MAX: Used to set maximum gain value to control the video noise caused by Auto Gain
Control. (0~15)
• LENS MODE: Adjusts lens mode for the installed lens.
(This option is for DC IRIS lens only, available on CV366 and CV368 )
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
AE MODE
SHUTTER
AGC
AGC MAX
AE BRIGHT
LENS MODE
RETURN
>
>
>
>
>
>
>
>
AUTO
7
MANUAL
MENU AE CONTROL
Select AE CONTROL using the UP or DOWN button. You can select one sub-mode using the UP or
DOWN buttons.
• MODE: Set camera to either color mode or B&W mode. (Day, Night)
• DAY: When set to DAY mode, camera stays in color (and IR cut filter is engaged for CV366 &
CV566).
• NIGHT: When set to NIGHT mode, camera stays in B&W (and IR cut filter is removed for
CV366 & CV566).
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
MODE
RETURN
>
>
>
>
>
>
>
>
DAY (COLOR)
MENU DAY/NIGHT
6. DAY / NIGHT
Select DAY / NIGHT using the UP or DOWN button. You can select one sub-mode from AUTO,
COLOR, and NIGHT using the UP or DOWN buttons.

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com910
• MIC / LINE: Select MIC or LINE for the audio input source.
• AUDIO LEVEL: Select this to adjust audio levels manually.
• MIC ATTENUATOR : Audio attenuation can be controlled from this menu to minimize the
audio noise level
• AGC LIMIT: Audio gain limit can be controlled while MIC ATTENUATOR is in used.
1. SAMPLE BITS: Select the bit depth of audio
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
MODE
AUDIO LEVEL
MIC AT TENUATOR
AGC LIMIT
SAMPLE BITS
RETURN
>
>
>
>
>
>
>
>
OFF
0 dB
OFF
24 BITS
MENU AUDIO
7. AUDIO
Select AUDIO using the UP or DOWN button and enter ON using SEL button. You can select one
sub-mode using the UP or DOWN buttons.
• MODE(EXT. SYNC): Turn ON of OFF the tri-level genlock sync feature.
• When the camera is properly synchronized the blue LED from the back of the camera will light
up.
• SYNC OUTPUT: Turn ON the SYNC OUTPUT to enable genlock daisy chain feature.
• H-SYNC PHASE: Adjust the pixel shifting from this menu.
• V-SYNC PHASE: Adjust the line shifting from this menu.
• PHASE SET: When H-sync and/or V-sync is adjusted, press OK from this menu to apply the
changes.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
MODE (EXT. SYNC)
SYNC OUTPUT
H-SYNC PHASE
V-SYNC PHASE
PHASE SET
RETURN
>
>
>
>
>
>
>
>
ON
ON
0
0
PRESS OK
MENU AUDIO
8. GENLOCK
Select GENLOCK using the UP or DOWN button and enter ON using SEL button. You can select one
sub-mode using the UP or DOWN buttons.

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com11 12
• LENS SHADING: Corrects inconsistent brightness level in the image.
• CONTRAST: Adjust the image contrast level.
• BRIGHTNESS: Adjust the image brightness level.
• SATURATION : Adjust the image saturation level.
• HUE: Adjust the image hue level.
• EDGE ENHANCE: Adjust the image sharpness level.
• AUTO SATURATE : Decrease saturation automatically when noise scene is detected.
• AUTO EDGE: Adjust line sharpness level automatically.
• BLACK WHITE LEVEL: Adjust the image black level value.
• GAMMA CORRECT: Adjust the image output gamma level.
• DNR: Reduces video noise at low ambient light.
Select the DNR level from OFF, LOW, MIDDLE, and HIGH using the LEFT or RIGHT button.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
LENS SHADING
CONTRAST
BRIGHTNESS
SATURATION
HUE
EDGE ENHANCE
AUTO SATURATE
AUTO EDGE
BLACK WHITE LV
GAMMA CORRECT
DNR
RETURN
>
>
>
>
>
>
>
>
11
11
10
0
5
>
>
MENU IMAGE CONTROL
9. IMAGE CONTROL
Select IMAGE CONTROL using the UP or DOWN button.
You can select LENS SHADING, CONTRAST, HUE, And EDGE ENHANCE using the UP or DOWN
buttons.
• DZOOM: Digitally zoom the video by the desired ratio.
• DEFOG: This feature will help increase visibility in extreme weather conditions, such as fog,
rain or in a very strong luminous intensity.
• DIS: This feature enables digital image stabilization
• BACKLIGHT: Adjust backlight compensation by choosing either BLC HLM from this menu.
• BINNING: Enable or disable pixel binning.
• DEFECT PIXEL: Advanced defective pixel correction menu.
• DISP FUNCTION: Display effect such as freeze mirror, rotation, and style can be applied from
this menu.
• WDR: This feature enables user to view both object and background more clearly when
background is too bright.
• PRIVACY: Mask an area you want to hide on the screen by applying the privacy zones.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
DZOOM
DEFOG
DIS
BACKLIGHT
BINNING
DEFECT PIXEL
DISP FUNCTION
WDR
PRIVACY
RETURN
>
>
>
>
>
>
>
>
OFF
OFF
OFF
OFF
OFF
ON
>
OFF
>
MENU SPECIAL
10. SPECIAL
Select SPECIAL using the UP or DOWN button.
You can select DEFOG, MOTION DETECT, BACKLIGHT, DEFECT PIXEL, and FLICKER DETECT using
the UP or DOWN buttons.

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com13 14
• CAM TITLE: Camera title can be turned ON or OFF.
• COMMUNICATION: VISCA communication can be adjusted.
1. CAM ID: Camera ID can be setup. (0~254)
2. ID DISPLAY: Camera ID display can be displayed.
3. BAUDR ATE : Camera baudrate can be set.
(2400, 4800, 9600, 19200, 38400, 115200)
• MODEL: Displays product module number.
• S/W VER: Displays software version number.
• OUTPUT FORMAT: Camera resolution and frame rate can be set.
(1080 by default)
Select the FRAME RATE using the LEFT or RIGHT buttons.
Available Frame Rates are:
1920 x 1080p 60, 59.94, 50, 30. 29.97, 25, 24, 23.98
1920 x 1080i 60, 59.94, 50
1280 x 720p 60, 59.94, 50
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
CAM TITLE
COMMUNICATION
MODEL
S/W VER
OUTPUT FORMAT
RETURN
>
>
>
>
>
>
>
>
>
1080p30 >
MENU SETUP
11. SETUP
CAMERA setup can be adjusted from this menu.
You can select CAMERA ID, Communication, System Info, and Output Format using the UP or DOWN
buttons.
• RESET MODE: Select the desired setting mode.
1. USER: Select “USER” if setting value user saved last is needed.
2. FACTORY: Select “FACTORY” if factory default setting is needed.
“FRAME RATE”, “CAM ID”, and “BAUDRATE” will note change.
• RESET: Reset the camera to the mode set on RESET MODE.
• SAVE AS USER: Save the current camera settings as “USER”.
• RESET: Reset the camera settings the factory defaults or user setting value.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
RESET MODE
RESET
SAVE AS USER
RETURN
>
>
>
>
>
>
>
>
USER
>
MENU RESET
12. RESET
Select RESET using the UP or DOWN buttons.

CV566/CV568/CV366/CV368 Manual
www.marshall-usa.com15 16
• SAVE: Exit the setup after saving the value changes.
WB CONTROL
AE CONTROL
DAY/NIGHT
AUDIO
GENLOCK
IMAGE CONTROL
SPECIAL
SETUP
RESET
EXIT
>
>
>
>
>
>
>
>
MENU
13. EXIT
Select EXIT using the UP or DOWN button.
13. TROUBLESHOOTING
Before sending the camera for repair, please check below to make sure that the camera is
installed correctly. If it still does not perform adequately, please consult with your supplier.
Problem Solutions
a. Check that all connected devices are powered on.
b. Confirm that the voltage is correct.
c. Confirm that the power supply provides enough current to power the camera.
d. Check that all video cables are correctly connected.
Nothing appears
on the screen.
The picture is
not clear.
a. Check that your monitor is correctly adjusted.
b. Confirm that the glass in front of the lens is clean. If there is dust, dirt, or
fingerprints on the glass, the image quality will be affected.
To clean the glass, use a soft, dry, and non-abrasive cloth or a commercially
available lens cleaning set.
c. Correctly adjust the focus.
The picture has
interference.
a. The camera may be close to a high voltage source, such as a power generator.
b. The BNC cable is not terminated properly.
c. The video cables are not connected properly.
The picture is
flickering
continually.
a. Check the termination and set the impedance at 75 properly.
b. Ensure that the camera is not pointing towards the Sun or any light source.
c. Check if there is any intermediate device.
d. Check if the distance of the video cable exceeds the maximum transferable
limitation.
The camera is not
synchronizing with
the reference signal.
a. Make sure Tri-Level reference signal is used.
b. Locking takes up to 1 minute depending on the signal strength.
Make sure the sync LED is solidly lit.
c. Check if the cable and connectors used in reference sync are in good condition.
d. Make sure the cable length used in reference sync does not exceed 100 ft.
e. Make sure OUTPUT EN is on when using the genlock output.
Focus The miniature (M12) lens that comes installed on camera is set to
optimal focus position, however if lens is slightly out of focus rotate lens
clockwise or counter-clockwise slightly to fine tune. Once the desired
focus point is achieved, rotate the locking nut back towards the camera
which will hold the lens position at optimal focus point.

20608 Madrona Avenue, Torrance, CA 90503
Tel: [phone] • Fax: [phone]
www.marshall-usa.com
[e-mail]
Marshall Electronics warranties to the first consumer that this device will, under normal use,
be free from defects in workmanship and materials, when received in its original container, for
a period of two years from the purchase date. This warranty is extended to the first consumer
only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase
provided with a warranty claim, Marshall Electronics reserves the right not to honor the warranty
set forth above. Therefore, labor and parts may be charged to the consumer. This warranty
does not apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations or
modifications in design or construction void this warranty. No sales personnel of the seller or
any other person is authorized to make any warranties other than those described above, or to
extend the duration of any warranties on behalf of Marshall Electronics, beyond the time period
described above.
Due to constant effort to improve products and product features, specifications may change
without notice.
Warranty
NB060419a
