Philips
LCD monitor
140 cm (55")
Full HD
BDL5545E
Entice your target audience
with stunning picture clarity in full HD
Deliver your marketing messages in style with this cost-effective 140 cm (55") LCD display.
With a wide array of features this full HD display is sure to leave your audience spellbound.
Operational flexibility
• Open Pluggable Specification Slot
• Display Port for faster graphics support
• SmartPower for energy saving
• Smart insert in the backcover to place a small pc
• Enhanced zoom feature supports tiled matrix applications
• Remote Management and Configuration via RS232
• Many Functions. One Wire
Optimized for public viewing
• Full HD LCD display, 1920x1080p
• Slim bezel design for a stylish look
Lower total cost of ownership
• Brightness automatically adjusts with ambient conditions
• Advanced anti image sticking function

BDL5545E/00
Highlights
LCD monitor
140 cm (55") Full HD
OPS Slot
Developed for the Digital Signage market, the
Open Pluggable Specification (OPS) slot is
designed to make changing or upgrading your
media player mere child’s play. Simply plug your
media player in to the display - and you’re ready.
No matter whether you have an entry level,
mid-range or high-end media player, OPS is fully
compatible bringing you a lower TCO over the
longer term.
Display Port
Enjoy crystal clear images with the high-
bandwidth graphics support of the Display Port.
As well as transmitting full high-definition video
the Display Port will also transmit audio, thus
eliminating the need for extra cables.
Slim bezel
A slim bezel design adds a stylish look to a public
display to nicely blend in just about any
environment. Furthermore this design makes
the display ideal for tiled matrix video walls.
Full HD LCD display 1920x1080p
This display has a resolution that is referred to
as Full HD. The state-of-the-art LCD screen
technology has the full high-definition
widescreen resolution of 1080 progressive lines,
each with 1920 pixels. This allows the best
possible picture quality for HD input signals with
up to 1080 lines. It produces brilliant flicker-free
progressive scan pictures with optimum
brightness and superb colors. This vibrant and
sharp image will provide you with an enhanced
viewing experience.
Smart Insert
Professional PC's are part of most public signage
installations. Quite often they increase the
overall depth to the display and cause a lot of
cable clutter. So we have designed this display
with Smart insert in the back cover which is ideal
for the integration of a professional small form
factor PC. On top of that, the cable management
system offers a great solution to keep your
cables neat and professional looking.
SmartPower
The backlight intensity can be controlled and
pre-set by the system to reduce the power
consumption by up to 50%, which saves
substantially on energy costs.
Zoom function for tiled matrix
The internal zoom function enables easy
implementation of a video wall matrix, without
the need for expensive external equipment.
Capable of many different configurations,
creating a stunning video wall has become
simplicity itself.
Advanced anti image sticking
Static images left on-screen for extended
periods of time may leave a "ghost image" or
image sticking effect on LCD displays. Although
image sticking in LCD displays is not permanent,
you want to prevent this to happen, especially in
locations where content is shown 24/7.
Automatic brightness control
The adjustment of display settings to
correspond with ambient light without user
intervention.
Remote Management:: RS232
Remote Management allows the user to control
and adjust the displays remotely via the RS232
protocol. Using CEC commands, you are able to
have full control over all the displays in your
signage network at any time.
One Wire
Take full control of your display by running all
operational commands as well as your video
signal through just one single HDMI cable. This
unique feature makes it so much easier and
more convenient to ensure the smooth running
and maintenance of your display. Consumer
Electronics Control (CEC) commands make
finding out vital information about your display
absolute childsplay.

BDL5545E/00
Specifications
LCD monitor
140 cm (55") Full HD
Picture/Display
• Panel resolution: 1920x1080p
• Optimum resolution: 1920 x 1080 @ 60 Hz
• Brightness: 500 cd/m²
• Contrast ratio (typical): 5000:1
• Response time (typical): 8 ms
• Aspect ratio: 16:9
• Viewing angle (H / V): 178 / 178 degree
• Display colors: 1.07 Billion
• Diagonal screen size: 55 inch / 139.7 cm
• Pixel pitch: 0.63 x 0.63mm
• Display screen type: LCD Full HD W-UXGA Act.
matrix
• Picture enhancement: 3/2 - 2/2 motion pull down,
3D Combfilter, Motion compens. deinterlacing,
Progressive scan, 3D MA deinterlacing, Dynamic
contrast enhancement
Supported Display Resolution
•Computer formats
Resolution Refresh rate
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
1024 x 768 60Hz
1280 x 768 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1360 x 768 60Hz
1366 x 768 60Hz
1440 x 900 60Hz
1600 x 1200 60Hz
1920 x 1080 60Hz
1920 x 1200 60Hz
•Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576p 50Hz
576i 50Hz
720p 50, 60Hz
1080i 50, 60Hz
1080p 50, 60Hz
Connectivity
• PC: VGA-in D-Sub 15HD, VGA-out D-Sub 15HD,
DVI-D x1, RS232 D-Sub9, RS232 D-sub9 output, 3.5
mm PC audio input x1
• AV input: Component (BNC) x1, Audio (L/R) x2
• AV output: Audio (L/R) x2
• Other connections: OPS, AC-out, HDMI, Display
Port
Convenience
• Picture in picture: PBP, PIP, POP
• Signal Loop Through: RS232, VGA
• Keyboard control: Hidden, Lockable
• Ease of installation: AC Out, Carrying Handles,
Smart Insert
• Energy saving functions: Ambient light sensor, Smart
Power
• Packaging: Reusable box
• Network controllable: RS232
• Tiled Matrix: Up to 5 x 5
Dimensions
• Bezel thickness: 42.2 mm / 1.6"
• Set dimensions (W x H x D):
1299x 769.8 x 129.9 mm
• Set dimensions in inch (W x H x D):
51.1 x 30.3 x 5.1 inch
• Product weight: 42.7 kg
• Product weight (lb): 88 lb
• VESA Mount: 400 x 200 / 400 x 400 mm
Operating conditions
• Temperature range (operation): 0 - 40 °C
• Relative humidity: 5 - 90 %
• MTBF: 60,000 hour(s)
Power
• Standby power consumption: <0.5W
• Consumption (On mode): 215W (Typ)
Sound
• Built-in speakers: 2 x 7W (RMS)
Accessories
• Included accessories: Remote Control, Batteries for
remote control, AC Power Cord, VGA cable, User
manual on CD-ROM, Quick start guide
• Optional accessories: Fixed wall mount, Flexible wall
mount, Ceiling mount
• Stand: BM05211
Miscellaneous
• On-Screen Display Languages: English, French,
German, Italian, Polish, Turkish, Russian, Simplified
Chinese
• Regulatory approvals: CE, FCC, Class B, UL/cUL,
CCC, RoHS
Packaging dimensions
• EAN: 87 12581 60488 2
• Number of products included: 1
• Packaging type: Carton
•
Issue date 2020-10-05
Version: 4.6.1
12 NC: 8670 000 76927
EAN: 87 12581 60488 2
© 2020 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
