Martin M1 Setup guide

Martin M1
Safety and Installation Guide

I© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
©2010 Martin Professional A/S. Information subject to change without notice. Martin Professional A/S and all
affiliated companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic
loss or any other loss occasioned by the use of, inability to use or reliance on the information contained in this
manual. The Martin logo, the Martin name and all other trademarks in this document pertaining to services or
products by Martin Professional A/S or its affiliates and subsidiaries are trademarks owned or licensed by
Martin Professional A/S or its affiliates or subsidiaries.
P/N 35000233 - Rev. B
Table of Contents
......................................................................................1
Dimensions
......................................................................................4
Introduction
................................................................................................................................... 5Technical Support
................................................................................................................................... 5Safety Information
................................................................................................................................... 6Included Items
......................................................................................7
Setup and Assembly
................................................................................................................................... 7Unpacking
................................................................................................................................... 7Placement
................................................................................................................................... 8Power Connections
......................................................................................9
Connections
................................................................................................................................... 9Front panel
................................................................................................................................... 9Back panel
......................................................................................10
Service
......................................................................................11
Specifications

1© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Dimensions
All dimensions are in millimeters
Martin M1 closed screen

2© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Martin M1 open screen

3© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide

4© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Introduction
Thank you for purchasing the Martin M1 Lighting Control System.
M1 is the next generation of Martin Controllers. With the full power of a larger desk and the agility of a
small one, it is the ultimate all-in-one lighting console.
Please read this Safetyand Installation Guide carefully. Visit the Martin website www.martin.com for further
documentation including the user manual for the M1 and access to our user forums.

5© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Technical Support
For a complete list of Technical Support phone numbers, see the Martin website at http://www.martin.
com/service/hotline.asp
Safety Information
This product is for professional use only. It is not for household use. It presents risks of lethal or
severe injury due to electric shock. Read this user manual before powering or installing the M1 , follow
the safety precautions listed below and observe all warnings in this manual and printed on the
product.
If you have questions about how to operate the product safely, please contact your Martin supplier or
call the Martin 24-hour service hotline on [phone], or in the USA on 1888-tech-180.
Connect the product electrically to ground (earth).
Use only a source of AC power that complies with local building and electrical codes and has
both overload and ground-fault protection.
Use the supplied power cords and chose the correct one for the country of operation. Use of
the factory provided power cable is mandatory for operation in the US and Canada.
Replace fuses with ones of the same type and rating only. Never attempt to bypass a fuse.
Disconnect the product from power immediately if the power cable or any cover or component
is wet or not in perfect condition. Do not reconnect to power until the damaged item has been
repaired or replaced.
Do not expose the product to rain or moisture.
Allow free unobstructed airflow to the sides of the product. Do not block the ventilation slots.
Do not use the product if the ambient temperature exceeds 40°C (104° F)
Refer any service operation not described in this manual to a qualified technician.
Do not modify the product or install other than genuine Martin parts.
Only transport in suitable packaging or a custom fitted road case. Transportation damage is not
covered under warranty.
Caution: Risk of Fire and Electrical Shock. Use only in dry locations.
Caution: Risk of Explosion if Battery is replaced by an incorrect type. Dispose of used batteries
according to local environmental regulations.

6© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Included Items
Each Martin M1 contains the following items:
M1 Contoller
1.5 m (4.9 ft.) power cable, 3-pin IEC P/N 11501012 (for use outside the US and Canada)
1.5 m (4.9 ft.) power cable, 3-pin IEC P/N 11501502 (with NEMA 15-5P plug for use within
the US and Canada)
Two 2 AT fuses, installed
User manual (Part number 35000233)

7© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Setup and Assembly
Unpacking
Open the shipping box carefully and stow away all included foam pieces and protective covers. Store
them for re-use.
The M1 should never be shipped in any other container than the factory-provided box or a custom
manufactured protective case.
Placement
The M1 controller requires a stable mounting position that provides support for all 4 rubber feet on the
bottom of the console.
Place the console carefully onto the surface and fold open the attached screen.
Apply some weight with a hand on the rubber hand rest when operating the hinge mechanism. The
hinges are strongly damped and the controller could tip over if the screen is not opened carefully.

8© 2010 Martin Professional A/S
Martin M1 Safety and Installation Guide
Power Connections
Martin M1 is rated 100-240V 50/60Hz, operates over 90-264V 50/60Hz. Do not connect it to
power outside this range.
The provided IEC cable is not fitted with a country-specific plug.
Please install a plug that meets local and national electric codes and is suitable for the country's
specific power outlet types.
A 3-prong grounding-type plug must be installed following the plug manufacturer’s instructions. The
table below shows some possible pin identification schemes; if the pins are not clearly identified, or if
you have any doubts about proper installation, consult a qualified electrician.
A cable with a NEMA 15-5P plug is provided for use of the M1 in the US and Canada. The approved
cable must be used in North America.
Wire color (standard EU code)
Pin
Symbol
brown
live
L
blue
neutral
N
yellow/green
ground
1. Check the Power Switch and ensure that is set to the OFF position.
2. Insert the provided power cable into the MAINS IN connector and connect the cable to a properly
protected and grounded power outlet.
3. Turn on the M1 by toggling the power switch to ON.
In addition to the IEC inlet the M1 also provides a IEC outlet port to connect a monitor or a
MaxModule device.
Do not exceed a current-draw of 4A on the IEC outlet port.
