Find the Northland-Marvel / Marvel Scientific 15CM5000 at our website: Click HERE

Installaon
Operaon
and
Maintenance
Instrucons
Ice Machines
15CM
25CM
Freezer
15AF
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1
CONTENTS
Unpacking your ice machine or freezer ...
..........
..
.................
Removing the packaging......................
............
...................
Warranty Registraon.....................
.................
....................
Installing your ice machine or freezer ....
...........
..
.
................
Selecng the locaon..........................
.............
..................
Cabinet Clearances..................................
.........
...................
Leveling legs......................................
.............
.....................
Grounding method..............................
...
...........
..................
Electrical Requirements........................
...........
...................
Handle Installaon ...........................
............
........................
Door Alignment ............................
............
.............................
Installing the ice machine water supply...
.............
..
...............
Using your ice machine.............
...........
...........
.....
.................
Turning on your ice machine..
..
.........
.............
...
...................
Ice machine operaon.
.................
......
..............
..................
Using your freezer .................................................................
Dimensions For 15CM Solid Door.....
....
............
...
...................
Recommended Rough in Opening Dimensions
For 15CM Solid Door.
...............
.........................
..................
Dimensions For 25CM Solid Door
.
.......................................
Recommended Rough in Opening Dimensions
For 25CM Solid Door.
...............
.........................
..................
Dimensions For 15AF Solid Door ...........
.
.............
.................
Recommended Rough in Opening Dimensions
For 15AF Solid Door ............
...............
..............
...................
Features .........................................
.............
.......
...................
Care and Cleaning...................................
..........
....................
Condenser air ow..............................................................
Cabinet ............................
...............
.........
.......
.....................
Interior ................................................................................
Defrosng instrucons..............
..................
......
...................
Troubleshoong your ice machine .....
..
...........
....
..................
Troubleshoong your ice machine or freezer ........................
Obtaining Service.........................
......................
...................
Commercial Product Warranty..............
...............
..................
Important Safety Instrucons
Warnings and safety instrucons appearing in this guide are not
meant to cover all possible condions and situaons that may
occur. Common sense, cauon, and care must be exercised when
installing, maintaining, or operang this appliance.
Recognize Safety Symbols,
Words, and Labels.
WARNING-Hazards or unsafe pracces which could result in
personal injury.
CAUTION-Hazards or unsafe pracces which could result in
personal injury or property or product damage.
NOTE
NOTE-Important informaon to make a problem free instal-
laon.
2
2
2
3
3
3
3
3
3
4
5
6
7
7
7
8
9
9
10
10
11
11
12
13
13
13
13
13
14
15
16
17
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

UNPACKING YOUR ICE MACHINE OR FREEZER
2
Remove Packaging
Your ice machine has been packed for shipment with all parts
that could be damaged by movement securely fastened. Cut
the banding material at the boom of the carton, unfold the
carton at the boom, and remove the carton from the appliance.
Remove the plasc bag, styrofoam corner posts, and any tape
holding the door closed and internal components in place. The
owners manual is shipped inside the unit in a plasc bag along
with the warranty registraon card.
Important
Keep your carton packaging unl your unit has been thoroughly
inspected and found to be in good condion. If there is dam-
age, the packaging will be needed as proof of damage in transit.
Aerwards please dispose of all items responsibly in parcular
the plasc bags which can be a suocaon hazard.
Note to Customer
This merchandise was carefully packed and thoroughly inspected
before leaving our plant. Responsibility for its safe delivery
was assumed by the retailer upon acceptance of the shipment.
Claims for loss or damage sustained in transit must be made to
the retailer.
DO NOT RETURN DAMAGED MERCHANDISE TO THE MANUFAC-
TURER - FILE THE CLAIM WITH THE RETAILER.
Help Prevent Tragedies
Child entrapment and suocaon are not problems of the past.
Junked or abandoned refrigerators are sll dangerous - even if
they sit out for “just a few days”.
If you are geng rid of your old refrigerator, please follow the
instrucons below to help prevent accidents.
Before you throw away your old refrigerator or freezer:
Take o the doors or remove the drawers.•
Leave the shelves in place so children may not easily climb •
inside.
If the unit was shipped or has been laying on its back for any
period of me allow the ice machine to sit upright for a period
of at least 24 hours before plugging in. This will assure oil returns
to the compressor. Plugging the ice machine in immediately may
cause damage to internal parts.
It is important you send in your warranty registraon card im-
mediately aer taking delivery of your ice machine or you can
register online at www.marvelscienc.com.
The following informaon will be required when registering your
unit.
Model Number
Serial Number
Date of Purchase
Dealers name and address
The model number and serial number can be found on the serial
plate which is located on the boom face inside the cabinet.
Warranty Registraon
NOTE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INSTALLING YOUR ICE MACHINE OR FREEZER
3
Figure 2
Do not splash or spray water from a hose on the ice ma-•
chine! Doing so may cause an electrical shock, which may
result in severe injury or death.
This unit should not, under any circumstances, be un-•
grounded.
Grounding Method
This product is factory equipped with a power supply cord that
has a three-pronged, grounded plug. It must be plugged into a
mang grounding type receptacle in accordance with the Na-
onal Electrical Code and applicable local codes and ordinances
(see Figure 2). If the circuit does not have a grounding type re-
ceptacle, it is the responsibility and obligaon of the customer to
exchange the exisng receptacle in accordance with the Naonal
Electrical Code and applicable local codes and ordinances. The
third ground prong should not, under any circumstances, be cut
or removed.
Electrical Connecon
115 volts, 3.3 amps running max. 15 amp dedicated circuit re-
quired. 3 prong grounded receptacle required.
Leveling Legs
Front Grille, keep
this
area open.
Figure 1
Select Locaon
The proper locaon will ensure peak performance of your ap-
pliance. We recommend a locaon where the unit will be out
of direct sunlight and away from heat sources. To assure your
product performs to specicaons the recommended installaon
locaon temperature range is from 65 to 90°F (18 to 32°C).
Cabinet Clearance
Venlaon is required from the boom front secon of the unit.
Keep this area open and clear of any obstrucons. Adjacent
cabinets and counter top can be installed around the unit as long
as the grille and door access remain unobstructed.
Do not use an extension cord with
this appliance.
Front Grille
Do not obstruct the front grille. The openings within the front
grille provides air to ow into and exit from the ice machine
condenser. For this reason it is important this area to not be ob-
structed and be kept clean. AGA MARVEL does not recommend
the use of custom made grilles as air ow may be restricted
because of inadequate openings. (See Figure 1).
Leveling Legs
Adjustable legs at the front and rear corners of the unit should
be set so the unit is rmly posioned on the oor and level from
side to side and front to back. Turn leveling legs clockwise to
raise unit, counterclockwise to lower it. (See Figure 1).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

HANDLE INSTALLATION
Handle Installaon (Solid Door Models)
Remove the handle, (2) screws, and 5/32” allen wrench from 1.
the bag shipped inside the cabinet.
Locate handle opposite the hinges and secure in place using 2.
the (2) screws and the allen wrench.
(See Figure 3).
Screws
Handle
Figure 3
Right hand hinged
door shown
Door Reversal
It is possible to reverse the door (change from right hand swing
to le hand swing or vice versa) if you wish. To do so it will be
necessary to order one of the service kits below.
Hinge Color Door Color Right Hand Le Hand
Chrome Black 42247595 42247599
Chrome White 42247639 42247640
Black Black 42247596 42247600
White White 42247597 42247601
Stainless
Steel
Stainless
Steel
42247598 42247602
4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

DOOR ALIGNMENT
Door Alignment Procedure
The door should be parallel to the sides and top of the refrig-
erator. If alignment is necessary the door may be adjusted by
loosening the 2 screws which secure the hinge adapter brackets
to the door and adjusng the door side to side. Use a 5/32” allen
wrench for this procedure. (See Figure 4 below).
Figure 4
Hinge adapter screws loosen
these to adjust door, on the
top and boom of the door
Top hinge pin re-
move to remove
the door.
Door must be
parallel to top
and sides of
refrigerator
9/32”
(7.1mm)
NOTE: For door closer to work properly it is necessary to main-
tain a min. space of 9/32” (7.1mm) between door and cabinet
ange as shown. This space can be adjusted by adjusng the top
and boom hinge adapter.
NOTE
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INSTALLING THE ICE MACHINE WATER SUPPLY
Figure 5
Back view of
ice machine
Water supply
inlet
Water Supply
Observe and follow all local building codes when installing this
appliance.
Aach the supplied water line adapter (Figure 6) to the water
valve inlet on the back of the ice machine (See Figure 5). Be sure
the rubber washer is in place in the inlet valve nut. Bend the
1/4” copper tubing to suit your installaon being sure not to kink
the tubing. Use 1/4” copper tubing for your water supply which
is available at any local hardware or plumbing supply store. The
water line ng supplied with your ice maker is to be used on
a 1/4 inch copper water supply line only. Do not aach a plasc
supply line to your unit with this ng.
Water pressure must be at a minimum of 20 psi for proper op-
eraon.
Make certain all water connecons are waterght aer instal-
laon. Form the tubing so that it will not vibrate against the
cabinet body or kink when your ice machine is set in posion.
NOTE
6
Rubber Washer
Adapter
Valve Fing
Compression Fing
Compression Nut
1/4 Diameter Copper water supply
line (supplied by customer)
From water supply
to ice maker
Figure 6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

USING YOUR ICE MACHINE
Icemaker operaon
Make certain water pressure is at least 20 psi and no more •
than 120 psi and the water is turned on.
The unit must be installed level for proper ice maker opera-•
on.
The shuto arm wire must be down in its lowest posion for •
the ice maker to operate.
When the freezer secon and ice maker unit has suciently •
cooled, the ice maker will harvest ice cubes automacally.
When the ice bucket is full, the ice maker will automacally •
shut o.
You may manually stop the ice maker by raising the shut o •
arm to the locking posion at the up most posion.
Arm down, ice maker
will operate
Arm up, stops operaon
When operaon of the appliance is to be disconnued for any
length of me, the ice cube cavity in the ice maker should be
emped and dried. The water supply and power supply should
also be shut o and the ice bucket should be emped and
cleaned.
If the ice is not used regularly, it will clump together with me.
For best ice results, discard ice in the bin as required and allow
the ice maker to make a new fresh batch of ice.
7
Figure 8
Cover
pulls o
Water adjustment screw behind cover
on side of housing
Turning on the ice machine
Aer connecng the water supply, and seng your ice machine
in place plug the power cord into the wall receptacle. Then
place the switch located in the grille (see Figure 7) to the “ON”
posion. The temperature control is factory preset, allow the ice
maker to run for 24 hours so the interior temperature will sta-
bilize. If you wish to adjust the interior temperature use a small
bladed screwdriver pushed through the right hand side of the
grille to turn the temperature control sha. Turning it clockwise
will make the unit colder. Turning it counterclockwise will make
it warmer. Turning it counterclockwise unl it stops will shut o
the compressor and fan motor.
Figure 7
“ON/OFF” Rocker
Switch in front grille
Temperature control located
behind right side of air in-
take -exhaust grille.
Should you turn o your control, allow at least ve (5) minutes
before restarng in order to give the motor control me to auto-
macally reset so that it can restart the motor. Electrical power
to your unit is controlled by the “ON/OFF” rocker switch located
in the front grille. (See Figure 7).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Temperature control located
behind right side of air in-
take -exhaust grille.
Should you turn o your control, allow at least ve (5) minutes
before restarng in order to give the motor control me to auto-
macally reset so that it can restart the motor. Electrical power
to your unit is controlled by the temperature control located in
the front grille. (See Figure 9).
USING YOUR FREEZER
Turning on the freezer
Aer seng the freezer in place, leveling (see page 3), plug the
power cord into the wall receptacle. The freezer should start
aer plugging in. The temperature control is factory preset to a
mid range seng. Allow the freezer to run for 24 hours so the
interior temperature stabilizes. If you wish to adjust the interior
temperature use a small bladed screwdriver pushed through
the right hand side of the grille to turn the temperature control
sha. Turning it clockwise will make the unit colder. Turning it
counterclockwise will make it warmer. Turning it counterclock-
wise unl it stops will shut o the compressor and fan motor.
8
Figure 9
Turn counterclockwise unl
it stops to shut o the com-
pressor and fan
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
RECOMMENDED ROUGH IN OPENING DIMENSIONS,15CM SOLID DOOR
*24” (61 cm)
standard cabinet
depth * Depth dimension may vary depending on
each individual installaon.
24-5/8”
(62.53cm)
Electrical Requirements: 115 volts, 3.3 amps running max. 15
amp dedicated circuit required. 3 prong grounded receptacle
required.
Power outlet can be located in the back wall behind unit. Add
1” to depth for thickness of plug, or recess outlet 1” into the
wall. Power outlet can also be installed in adjacent cabinetry
with a cutout for roung of power cord. Follow all local build-
ing codes when installing electrical and unit.
Product weight = 72 lbs. ( 32.7kg.)
15” (38.1cm)
DIMENSIONS FOR MODEL 15CM SOLID DOOR
14-7/8”
(37.8cm)
19-11/16”
(50.01cm)
21-25/32”
(55.32cm)
23-1/32”
(58.5cm)
35-11/16”
(90.65cm)
3-15/16” to 4-5/8”
(10.01 to 25.43cm)
24-1/8” to 24-13/16”
(61.26 to 63.02cm)
15-7/8”
(40.34cm)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

RECOMMENDED ROUGH IN OPENING DIMENSIONS, 25CM SOLID DOOR
*24” (61 cm)
standard cabinet
depth * Depth dimension may vary depending on
each individual installaon.
34-1/2”
(87.6 cm)
Electrical Requirements: 115 volts, 3.3 amps running max. 15
amp dedicated circuit required. 3 prong grounded receptacle
required.
Power outlet can be located in the back wall behind unit. Add
1” to depth for thickness of plug, or recess outlet 1” into the
wall. Power outlet can also be installed in adjacent cabinetry
with a cutout for roung of power cord. Follow all local build-
ing codes when installing electrical and unit.
Product weight = 86 lbs. (39.1 kg.)
DIMENSIONS FOR MODEL 25CM SOLID DOOR
10
15” (38.1cm)
14-7/8”
(37.8cm)
35-9/16”
(90.32cm)
19-11/16”
(50.09cm)
21-25/32”
(55.32cm)
23-1/32”
(58.5cm)
3” to 3-1/4”
(7.62 to 8.26cm)
34-1/4” to 34-1/2”
(87 to 87.6cm)
15-7/8”
(40.34cm)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

RECOMMENDED ROUGH IN OPENING DIMENSIONS, 15AF SOLID DOOR
*24” (61 cm)
standard cabinet
depth * Depth dimension may vary depending on
each individual installaon.
24-5/8”
(62.53 cm)
Electrical Requirements: 115 volts, 3.3 amps running max. 15
amp dedicated circuit required. 3 prong grounded receptacle
required.
Power outlet can be located in the back wall behind unit. Add
1” to depth for thickness of plug, or recess outlet 1” into the
wall. Power outlet can also be installed in adjacent cabinetry
with a cutout for roung of power cord. Follow all local building
codes when installing electrical and unit.
Product weight = 70 lbs. (31.8 kg.)
DIMENSIONS FOR MODEL 15AF SOLID DOOR
11
15” (38.1cm)
14-7/8”
(37.8cm)
19-11/16”
(50.01cm)
21-25/32”
(55.32cm)
23-1/32”
(58.5cm)
35-11/16”
(90.32cm)
3-15/16” to 4-5/8”
(10.01 to 25.43cm)
24-1/8” to 24-13/16”
(61.26 to 63.02cm)
15-7/8”
(40.34cm)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

FEATURES
Probe Port (oponal) for 15AF
The oponal probe port is a hole from the inside to the outside of
the unit, which could be located on the top, side, or back of the
unit. Aer inserng your wires or probe, seal the hole ghtly with
caulk, puy, foam, etc. for proper operaon.
Product Temperature versus Air Temperature
Air temperature moves up and down with door openings and
compressor run and o cycles. Air has lile thermal mass and
therefore changes temperature relavely quickly as the unit
cycles on and o. Stored products have thermal mass so their
temperatures change much more slowly. While air temperature
may change 5 to 10 degrees C between run and o cycles, stored
product temperature typically changes less than 2 degrees C due
to their thermal mass. Always measure product temperature, not
air temperature, to determine if the products being stored are at
the proper temperature.
15AF Features
Can be installed on the counter top or built in.
Temperature range = -4°C to -20°C.
Flat door liner.
Manual defrost.
15CM Features
Can be installed on the counter top or built in.
Makes crescent shaped ice cubes.
Temperature range = -7° to -20°C.
Flat door liner.
Manual defrost
No drain required.
25CM Features
Makes crescent shaped ice cubes.
Temperature range = -7° to -20°C.
Flat door liner.
Manual defrost
No drain required.
12
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Condenser Air Flow
The machine compartment located beneath the cabinet does
not require frequent cleaning; however, sasfactory perfor-
mance depends on adequate venlaon. Be sure nothing ob-
structs the required air ow openings in front of the cabinet. At
least once or twice a year, brush or vacuum lint and dirt from the
front grille openings. See Figure 1 on page 3.
Cabinet
The painted cabinet can be washed with either a mild soap and
water and thoroughly rinsed with clear water. NEVER use abra-
sive scouring cleaners.
Interior
Wash interior compartment with mild soap and water. Do NOT
use an abrasive cleaner, solvent, polish cleaner or undiluted
detergent.
Care of Unit
Avoid leaning on the door, you may bend the door hinges or 1.
p the unit.
Exercise cauon when sweeping, vacuuming or mopping 2.
near the front of the unit. Damage to the grille can occur.
Periodically clean the interior of the unit as needed.3.
Periodically check and/or clean the front grille as needed.4.
CARE AND CLEANING
Defrosng Instrucons 15CM and 25CM
Push the rocker switch located in the front grille to the 1.
“OFF” posion.
Remove the ice bucket and place a towel in the lower front 2.
area of the ice maker to absorb the defrost water.
Aer defrosng is completed replace the ice bucket and 3.
press the rocker switch to the “ON” posion.
Defrosng Instrucons 15AF
Disconnect the power cord and set the temperature control 1.
to the o posion. (See page 8).
Remove the contents from the freezer.2.
Place pans of hot water in the freezer if you wish to speed 3.
up defrosng.
When defrosng is complete wipe out the interior and 4.
replace the contents.
Connect power cord to outlet. 5.
Set the temperature control to the desired level.6.
Do not use an ice pick, knife, or any type of sharp object to
remove the ice. Doing so may puncture the units refrigerant
system and damage it beyond repair. You may speed up defrost-
ing by lling the ice bucket with hot water and placing it back
into posion.
13
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14
TROUBLESHOOTING YOUR ICE MACHINE
Problem Possible Cause Remedy
Unit operates but does not produce any
ice.
The unit has just been started and it •
has been less than 24 hours.
Water supply is not turned on.•
Inadequate water pressure to unit.•
The ice maker shut o arm is in the •
uppermost posion.
Freezer secon has not reached •
temperature.
Thermostat control set too warm.•
Condenser fan air ow is restricted.•
Room and/or water temperature is •
too warm.
Typical ice producon is 8 pounds per •
day. Allow for the freezer secon to
reach temperature and the ice maker
to cycle and accumulate ice.
Turn on water supply to the unit.•
Water pressure to the unit must be at •
a minimum of 20 psi.
When the ice maker shut o arm is •
in the uppermost posion, the ice
maker is o. Flip the shut o arm
down to turn on the ice maker.
Allow the freezer secon to reach •
temperature.
Turn the temperature control clock-•
wise to allow the unit to run colder.
Allow 24 hours before readjusng the
temperature control.
Make certain the grille in front of the •
unit is free and open for air circula-
on. Clean grille as required.
Move the unit to an area where •
ambient temperature is below 90°F.
The unit should not be placed next to
a heat source such as an oven. Check
for cold water connecon.
Small ice cubes. Water input may require adjustment.• Due to diering water pressures, the •
ice maker water input may require
adjustment. See Figure 8 on page 7
for water adjustment screw locaon.
Ice cubes are scking together. Ice consumpon is low.•
Room temperature is too warm.•
Use the ice in the bin frequently. Ice •
will sck together if le in insulated
bin over long periods of me.
Move the unit to an area that is •
below 90°F.
Before You Call for Service
If the unit appears to be malfunconing, read through this
manual rst. If the problem persists, check the troubleshoong
guide below. Locate the problem in the guide and refer to the
cause and its remedy before calling for service. The problem may
be something very simple that can be solved without a service
call. Some remedies listed in the troubleshoong guide are very
complex. Consulng or contracng a qualied service technician
may be necessary.
Electrocuon Hazard - Never aempt to repair or perform main-
tenance on the unit unl the main electrical power has been
disconnected.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Problem Possible Cause Remedy
Unit too warm or too cold inside. Control set too warm or cold.•
Airow to front grille blocked.•
Excessive usage or prolonged door •
openings.
Door gasket not sealing properly.•
Adjust temperature colder or warmer •
as required. Allow 24 hours for tem-
perature to stabilize.
Airow must not be obstructed to •
front grille. See “clearances” on page
3.
Allow temperature to stabilize for at •
least 24 hours.
Adjust or replace door gasket.•
Noise or Vibraon. Unit not level.•
Water line tubing vibraon.•
Level unit, see “Leveling Legs” on •
page 3.
Adjust the tubing as necessary to •
eliminate unwanted vibraons.
Unit will not run. Unit turned o.•
Power cord not plugged in.•
No power at outlet.•
Turn unit on. See page 7 or 8.•
Plug in power cord.•
Check house circuit.•
Moisture collects on outside surface of
cabinet.
Hot and humid condions.• Extremely hot and humid condions •
can cause condensaon on outside of
the cabinet. As humidity and/or tem-
perature decreases, the condensaon
will disappear.
Moisture collects on inside of the unit. To many door openings.•
Prolonged door openings.•
Hot and humid condions.•
Limit the amount of door openings.•
Limit the amount of me with the •
door open.
Extreme hot and humid condions. •
Move unit to a controlled environ-
ment.
TROUBLESHOOTING YOUR ICE MACHINE OR FREEZER
15
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16
For Your Records
Date of Purchase
Dealer’s name
Dealer’s Address
Dealer’s City
Dealer’s State
Dealer’s Zip Code
Appliance Serial Number
Appliance Model Number
Date Warranty Card Sent (Must be
within 10 days of purchase).
In all correspondence regarding service, be sure to give the •
model number, serial number, and proof of purchase.
Try to have informaon or descripon of nature of the prob-•
lem, how long the unit has been running, the room temper-
ature, and any addional informaon that may be helpful in
quickly solving the problem.
Fill in pernent informaon below regarding your product •
for future reference.
If Service is Required:
If the product is within the rst year warranty period please •
call AGA MARVEL Customer Service at 800.223.3900 for
direcons on how to obtain warranty coverage in your area.
If the product is outside the rst year warranty period, AGA •
MARVEL Customer Service can provide recommendaons of
service centers in your area. A lisng of authorized service
centers is also available at www.marvelscienc.com under
the service and support secon.
OBTAINING SERVICE
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

COMMERCIAL PRODUCT WARRANTY
Enre Product - One Year Parts and Labor Warranty
AGA MARVEL warrants to the original purchaser that it will sup-
ply all necessary parts and labor to repair or replace in the end
user’s establishment, any component which is found by an autho-
rized representave of AGA MARVEL to be defecve in materials
or workmanship, subject to the condions and exclusions stated
below, for a period of one year from the date of purchase by the
end user.
Refrigeraon System - Addional Second Through Fih Year
Parts Only Warrranty
During the four years following expiraon of the one year limited
warranty, AGA MARVEL warrants to the original purchaser that
it will supply replacement parts for the hermecally sealed re-
frigeraon system which consists of the compressor, evaporator,
condenser, drier, and connecng tubing that are found to be de-
fecve in workmanship or materials. Other parts, labor costs, and
freight charges are the responsibility of the end user.
If AGA MARVEL is unable to repair or replace the defecve prod-
uct or component, AGA MARVEL shall issue a credit to the buyer
for all or part of the purchase price, as AGA MARVEL shall de-
termine. The repair, replacement or payment in the manner de-
scribed above shall be the sole and exclusive remedy of buyer for
a breach of this warranty.
Buyer must give wrien noce of any alleged defect in the prod-
uct to AGA MARVEL within 30 days aer discovery of the defect
by buyer. If noce is not given within such period, any claim for
breach of warranty shall be conclusively deemed to have been
waived, and AGA MARVEL shall not be liable under these war-
ranes. AGA MARVEL or its agents shall be entled to examine
the product. AGA MARVEL shall have the opon of requiring the
return of the defecve component, transportaon prepaid, to es-
tablish the claim. The acceptance by AGA MARVEL of any compo-
nent returned shall not be deemed an admission that the product
is defecve or in breach of any warranty and, if AGA MARVEL de-
termines that the product is not defecve, the component shall
be reshipped to the buyer at the buyer’s expense. No component
will be returned to AGA MARVEL without its prior consent.
The above warranes do not cover:
Shipping costs of replacement parts or returned defecve •
parts.
Customer educaon or instrucons on how to use the refrig-•
erator/freezer.
Any content loss, or incidental or consequenal damage or •
loss due to product failure.
Removal or installaon.•
Nor do the above warranes cover failure of this product or its
components due to:
Transportaon, damage sustained in transit or subsequent •
damages.
Use in hosle environments or use for storage of contents •
hosle to the product.
Improper installaon, misuse, abuse, accident or alteraon, •
use on wiring not conforming to electrical codes, low volt-
ages, failure to provide necessary maintenance, or other un-
reasonable use.
Parts or service not supplied or designated by AGA MARVEL.•
The above warranes also do not apply if:
The original bill of sale, deliver date, or serial number cannot •
be veried.
The refrigeraon equipment is not in the possession of the •
original end use purchaser.
The warranes set forth herein are the only warranes extend-
ed by AGA MARVEL and are in lieu of all warranes, express,
implied, statutory or otherwise. In parcular, AGA MARVEL
makes no warranty of merchantability or tness for a parcular
purpose.
AGA MARVEL’s liability for any defect in the product shall not ex-
ceed the purchase price of the product. AGA MARVEL shall have
no liability for consequenal damages of any kind whatsoever,
including, but not limited to, personal injury, property damage,
lost prots or other economic injury due to any defect in the
product.
No person, rm, or corporaon is authorized to modify, expand or
extend these warranes, to waive any of the limitaons or exclu-
sions, or to make any other warranty or assume any other obli-
gaon for AGA MARVEL These warranes apply only to products
used in any of the y states of the United States and the District
of Columbia.
To obtain performance of this warranty, report any defects to:
P.O. Box 400
Greenville MI 48838-0400
Phone: 616.754.5601
Toll-Free: 800.223.3900
17
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18
NOTES
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
This manual suits for next models
3
Table of contents
Popular Ice Maker manuals by other brands

Polar Electro
Polar Electro T316 instruction manual

Klarstein
Klarstein Kristall manual

Manitowoc
Manitowoc B Series Service technician's handbook

Cornelius
Cornelius IMD300-15A installation manual

Back to Basics
Back to Basics Electric Ice Shaver instruction manual

Marvel
Marvel 30iMT Installation, operating and maintenance instructions

Hoshizaki
Hoshizaki KM-520MAJ-E instruction manual

Manitowoc
Manitowoc S1000M Installation use and care manual

Whirlpool
Whirlpool GI15NFLTS - Ice Maker instruction sheet

oraimo
oraimo OIM-211A user manual

Hoshizaki
Hoshizaki IM-210BAB-21 parts list

Follett
Follett Horizon Elite HCD710A Operation and service manual
