Master Bilt IHC-48 User manual

ITEM NO. ______________________________________________________
PROJECT ______________________________________________________
LOCATION _____________________________________________________
DATE _________________________ QTY. ___________________________
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
CONSTRUCTION
• Heavy-duty 6"-7" adjustable legs
• 4 heavy-duty welded wire gray epoxy-
coated cantilever shelves per section
• 21/2" foamed-in-place “zero ODP”
urethane insulation
FINISH
• Stainless steel front
• Anodized aluminum sides and interior
DOORS
• Two staggered height, energy saving
insulated inner doors with magnetic
catches per section
• Door swing:
IHC-27 .............................hinged left
IHC-48 .............left door hinged left,
right door hinged right
• Self-closing doors with 90° hold-open
feature
• Sure-sealing magnetic gaskets
(replaceable)
• Heavy-duty horizontal door handle
• Anti-condensate door frame heater
• 2" stainless steel foamed-in-place doors
• Lift-off inner and outer doors
REFRIGERATION
• Refrigerant: R-404A
• Self-contained, top mounted,
semi-hermetic refrigeration system
• Minimum 4" clearance required be-
tween cabinet back and wall
• Temperature range:
0° to -37°F (-18° to -38°C)
• R-factor (insulation efciency rating):
21.55 on walls, 17.24 on doors
• Drain plumbing hookup recom-
mended. Condensate pan avail-
able if there is no access to drain
plumbing. Condensate pan must
be eld installed and requires a
dedicated 15 amp, 120 volt circuit.
WARRANTY
• Standard limited three year extend-
ed compressor and two year limited
parts and labor
FEATURES
IHC-48
IHC SERIES
Ice Cream Hardening
And Holding Cabinets
OPTIONS
❑ Add sufx “R” for remote system
on IHC-48 only
❑ Casters
❑ Extra welded wire gray epoxy-
coated cantilever shelves
❑ Pan rack
❑ Voltage boosting transformer
❑ Condensate evaporator drain pan
NOTE: Must be eld installed and
requires a dedicated 15A, 120v
circuit.
MODELS
❑ IHC-27
❑ IHC-48
The IHC series
contains the most
powerful standard
refrigeration
system in its class.
STANDARD
ELECTRONIC CONTROL
• Allows user to easily monitor
defrost functions from the panel
interface on the front of the
merchandiser
• Audible and visual alarm
• Decreases service time and calls
• Eliminates room thermostat,
defrost termination/fan delay
control, defrost timer and
digital thermometer or other
temperature indicator

NOTE: Cabinet designed for optimum performance in air-conditioned area at 75°F ambient and 55% relative humidity.
All specications subject to change without notice.
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
IHC SERIES
ICE CREAM HARDENING AND HOLDING CABINETS
TECHNICAL SPECIFICATIONS
LISTINGS
HOOKUP
BID SPECIFICATIONS
Item no. IHC-_______________
Provide_______________( ) Ice Cream
Hardening and Holding Cabinet(s), Master-
Bilt model no. IHC-___________.
Cabinet will be equipped with an elec-
tronically controlled monitoring system. It
will also be provided with 6"-7" adjustable
legs, four welded wire, gray epoxy-coated
1146-12/11-web
©Master-Bilt Products division of Standex International, Inc. All rights reserved. Printed in U.S.A.
Via plug in, 8 foot long, exible 3
wire 14/3 cord with molded plug.
15 amp/220 volt service is
recommended.
PLAN VIEW SIDE VIEW ELEVATION VIEW
cantilever shelves, 21/2" foamed-in-place
“zero ODP” urethane insulated walls. Cabi-
net to have stainless front with anodized
aluminum sides and interior.
Cabinet also to have 2" stainless steel,
self-closing, foamed-in-place doors. Inte-
rior doors to be provided with cabinet.
The refrigeration system is to be top
mounted, self-contained and use R-404A re-
frigerant. The temperature range will be
0° to -37°F (-18° to -38°C). Cabinet to have
standard limited three year extended com-
pressor warranty and two year limited parts
and labor warranty. Cabinet to be UL,
C-UL and NSF listed.
NEMA 6-15P
MODEL
DIMENSIONS
(in.)
DIMENSIONS
(mm)
VOLTS** AMPS
UNIT
H.P.
NO. OF
SECTIONS
NO. OF
SHELVES
STANDARD
SHELF SIZE
(in inches)
CAP.
3 GAL.
CANS
SHIP
CU.
FT.
SHIP
WT.
LB/KGL D H* L D H*
IHC-27 31 36 82 787 914 2083 208-230 7.4 1 1 4 233/8 x 245/8 20 76.0 490/223
IHC-48 52 36 82 1321 914 2083 208-230 11.5 11/22 8 22 x 231/243 119.0 690/314
*Height includes 6-7" adjustable legs. **IHC models operate on a minimum of 208 volts. A voltage boosting transformer (part no. 39-01087)
must be used when the supply voltage is less than 208 volts.
